11-8

Front tweeter speaker

 - Design changed

Front door speaker

- Design changed

Front tweeter speaker

▶

Front door speaker

▶

11-9

8910-05

Rear door speaker

▶

Rear door speaker

 - Design changed

11-10

1. OVERVIEW

2. LAYOUT

The audio head unit is fitted with the Bluetooth handsfree for convenience. It has a micro pole antenna

and its own integrated amplifier to improve the radio frequency reception rate and to provide the high-

quality sound. The iPod function also has been added to the USB terminal.

Front door speaker

Audio remote

control switch

Audio head unit

USB & AUX jack

assembly

Bluetooth (hands
-free)microphone

Front door tweeter

speaker

11-11

8910-05

Micro pole antenna

Rear door speaker

Bluetooth (hands-free)

microphone

Audio remote

control switch

USB/AUX jack assembly

Audio head unit
