11-4

Unit

Item

Specification

Micro pole

antenna

Audio

specification

Operating current

Max. 150 mA

Operating voltage

DC 10.5 V to 16 V

Operating temperature

-30℃ ~ +60℃

Storage temperature

-40℃ ~ +80℃

I/O impedance

75 Ω (FM)

11-5

8910-05

2. CAUTIONS AND WARNING FOR SAFETY

This mark indicates potentially hazardous situation which, if not observed, may result in serious

injury and material damage.

Ssangyong is not liable for any personal injury and material damage, caused by violation of traffic

regulations or neglect of observing actual traffic and driving situations.

Colors on display figures in this manual may differ from actual display due to publication concerns.

-

-

-

This mark indicates situation which, if not observed, may result in an accident or system

malfunction.

Do not disassemble or modify this system.

If doing so, it may cause an accident, fire or electric shock.

Do not use the system if it is malfunctioning (sound or video output problem).

Doing so may lead to an accident or electric shock.

Please contact a Ssangyong service dealer immediately.

The system should be used only when the engine is started.

Using the system for an extended period of the with the engine off may discharge the battery.

Do not leave beverages or foreign materials around the system.

If they enter the system, they may cause a fire.

The system may break down if a disc not supported by this system is inserted.

Do not apply impact to or drop this system.

It might cause malfunction.

Never leave the system in a hot or cold place for an extended period of time. Therefore, do not
park the vehicle in a hot or cold place. The ambient temperature should be -30℃ ~
+80℃ for proper operation.

-

-

-

-

-

-

-

-

11-6

LCD display digital clock

- LCD display digital clock adopted (center fascia switch → audio LCD display)

LCD resolution

- LCD display resolution increased

Audio head unit

- Audio head unit design changed

3. MAJOR CHANGES

Audio head unit

▶

Digital clock

11-7

8910-05

USB & AUX jack

- USB & AUX jack switch arrangement changed
- USB insertion (reverse direction → normal direction)
- iPod support function added to USB terminal

USB & AUX jack

▶

USB cable

▶

USB cable length changed due to new instrument panel

-

Front & rear feeder cables

▶

Front and rear feeder cables length changed due to new instrument panel

-
