06-43

8510-00

3) Cruise Control Switch

Cruise control switch

The cruise control is an automatic speed control system that maintains a desired driving speed without

using the accelerator pedal. The cruise control switch is fitted to the bottom right section of the steering

wheel. When this switch is operated, the AUTO CRUISE or ECO lamp on the instrument cluster comes

on.

The cruise control switch has a fivefold switch in it. The engine ECU can determine the current driving

condition since the resistance varies depending on the operation of the switch.

The cruise control system is operated at vehicle speed of between 38 km/h and 150 km/h. The manual

transmission is operated in the range of 3rd gear or higher.

This function can be used at the following traffic condition. (It is important to be careful for using this

function)

Cruise control (ON)

Cruise control (OFF)

Cruise control (Acceleration)

Cruise control (Deceleration)

Cruise control (Reset)

06-44

Horn (high)

Horn (low)

Theft deterrent horn

▶

Theft deterrent horn

4) Horn Switch

Two horns are installed in the radiator grille at the bottom of both sides (one on each side). There is

another horn installed at the bottom of the battery tray side in the engine compartment for theft alarm.

Operating the horn switch on the steering wheel applies the power to the horn relay to operate both

horns (Dual horn). The theft deterrent horn is controlled by the BCM in armed mode regardless of the

horn relay operation.

Horn (dual horn)

▶

Horn switch

06-45

8510-00

Front seat heating and ventilation switch (2-

level of driver seat heating and ventilation, 2-

level of passenger seat heating)

A. Driver seat heating switch
B. Driver seat ventilation switch
C. Passenger seat heating switch

5. SEAT HEATING AND VENTILATION SWITCH

1) Front Seat Heating and Ventilation Switch Overview (2-level of
    Driver Seat Heating and Ventilation, 2-level of Passenger Seat
    Heating)

The temperature of the seat can be adjusted in 3
levels (Level 2 → Level 1 → OFF) with the

seat heated wire and ventilation switch. Every

time the seat heating and ventilation switch is

pressed, the temperature level goes down by

one level. Pressing the switch a third time will turn

off the operation. Pressing the desired side of the

switch heats the seat cushion and seatback or

activates the seat ventilation function. The

temperature of the seat is kept uniform by cutting

off or connecting power through thermistor fitted

in the seat. The seat heating and ventilation unit

controls the rpm of the motor using PWM control

to operate the seat ventilation.

Front seat heating & ventilation switch (2-level of driver seat heating and ventilation, 2-level of

passenger seat heating)
Front seat & rear seat heating (Driver and passenger seats: LO↔HI, rear seats: ON↔OFF)

-

-

The front seat heating and ventilation functions cannot be operated at the same time.

The front seat heating and ventilation switch functions only when the engine is started.

-

-

Seat heating and ventilation unit & switch application

▶

06-46

Front seat heating switch

(Driver: LO↔HI, Passenger: LO↔HI)

A. Driver seat heating switch
B. Passenger seat heating switch

Rear seat heating switch

A. Rear LH seat heating switch

A. Rear RH seat heating switch

The front seat heating switch can be operated to

the desired temperature (LO/HI) by pressing the
front seat heating switch. Press the “HI (High
temperature)" or “LO (Low temperature)" on

the seat heating switch to heat the seat and

seatback. When the temperature reaches 40
±5℃, the thermistor integrated in seat

connects and cuts the power to keep the

temperature stable. There is no separate seat

warmer unit to control the temperature of the seat

heating system.

2) Front Seat & Rear Seat Heating Switch Overview
   (Driver and Passenger Seats: LO↔HI, Rear Seats: ON↔OFF)

LH

RH

The front seat and rear seat heating switches operates with IGN ON.

The seat heating and ventilation unit is not fitted in a vehicle without seat ventilation function.

-

 -
