04-5

7340-00

2. OPERATING PROCESS

1) Sunroof Switch

This can be closed or open manually to block sunlight when the sunroof function is not in use.

The sunroof glass can be open in two steps and can be tilted by the switch operation.

The sunroof switches are included in the overhead console switches and consists of the TILT,

CLOSE and OPEN switches.

TILT

CLOSE

OPEN

▷

▷

▷

Sun shade panel

Sunroof glass

Sunroof switch

▶

Opens only rear section of the sunroof.

Closes the sunroof.

Opens the sunroof.

Sunroof glass

▶

Sun shade panel

▶

04-6

2) Sunroof Sliding Opening/Closing

Closing sunroof (Sliding close)

Pull down the switch briefly: auto sliding close

When pulling down the switch briefly, the sunroof is automatically closed. To stop the closing

sunroof, operate the switch to either direction.

-

Pull down and hold the switch: manual sliding close

The sunroof is closed as long as pulling down the switch.

-

Pull down the switch

-

Push up the switch

-

Open: 2-step open

Push up the switch briefly: 2-step auto sliding open

When pushing up the switch briefly, the sunroof is automatically opened. Opening is carried out in 2

steps. In first step, the area 5 cm behind the sunroof is not opened. Push up the switch once again

in order to open the sunroof completely. The sunroof operation stops if you operate the switch

during its operation.

-

Push up and hold the switch: manual sliding open

The sunroof is opened as long as pushing up the switch.

-

04-7

7340-00

3) Sunroof Tilt Up/Down

This function is to raise or lower the rear section of the sunroof.

When leaving the vehicle, make sure the sunroof is completely closed. The sunroof may look closed

but it might be tilted up.

Tilt Down

Tilt Up

The rear side of the sunroof is tilted up when pulling down the sunroof switch with the sunroof

closed.

-

The rear side of the sunroof is tilted down when pushing up the sunroof switch with the sunroof

tilted up.

-

Pull down the switch

-

Push up the switch

-

04-8

5) Emergency Operation

If the sunroof becomes out of order while it is

open or tilted, the sunroof can be operated

through the motor operating hole of the sunroof

motor.

When you drive this vehicle with the window or sunroof open at a certain position, you may feel

some pressure upon your ears or hear some noises similar to those from a helicopter. This happens

because of an influx in air through the window or sunroof and its resonance effect. If this happens,

adjust by opening the window or sunroof.

-

The anti-pinch function is deactivated just before the sunroof closes.

The sunroof safety function is just a safety supplementary system which cannot replace driver's care

and caution. Moreover, it may not be able to operate due to electric part or other conditions.

To prevent any body parts from being trapped by the sliding sunroof, an Anti-Pinch Function

automatically opens the sunroof when an object is trapped.

4) Sunroof Safety Function

Wind buffeting

▶
