07-13

8310-00

Center room lamp

Luggage lamp

Door courtesy lamp

07-14

2) Operation

(1) Front room lamp/Center room lamp

Front room lamp

Center room lamp

Operating the front room lamp and center room lamp switches illuminates the driver/passenger side

lamps and center room lamp.

Room lamp control by door coupled room lamp operation

▶

If a door except the tailgate is opened after the ignition is turned off, provided that door coupled front

room lamp switch is pressed, the front room lamp and center room lamp are illuminated for 2 sec.

and then fade out for 3 sec.

If a door except the tailgate is opened and then closed while the room lamp is fading out, the room

lamp is illuminated for 2 sec. and then fades out for 3 sec. If the ignition is turned on, the room lamp

goes off immediately.

The front room lamp and center room lamp are illuminated for 30 sec. when the door is unlocked by

the REKES or passive door UNLOCK function with IGN OFF and the ignition key removed. If the

REKES or passive door UNLOCK signal is received again, the room lamps are illuminated for

another 30 sec.

The room lamp goes off immediately when the REKES or passive door LOCK signal is received or

the ignition switch is turned to ON position.

If the room lamp is turned on after the ignition key is removed (door open or room lamp switch is

pressed), it is turned off after 10 minutes by the BCM.

When the door open state is changed or the ignition is turned on after the room lamp has been turned

off automatically, the battery saver feature is reset.

1.

2.

3.

4.

5.

07-15

8310-00

Sun visor lamp

Glove box lamp

(2) Luggage lamp

Luggage lamp

Courtesy lamp

The luggage lamp is turned on when the tailgate is opened

with the switch operated.

This lamp is not controlled by the BCM, unlike the

front/center room lamp.

(3) Other interior lamps

The glove box lamp comes on when the glove box is

opened after the tail lamp is illuminated.

The sunvisor lamp comes on when the sunvisor vanity

mirror cover is opened.

The door courtesy lamp comes on when the driver's door

or passenger's door is opened.

08-3

7810-00

1. WIPER CONTROL

2. CAUTIONS ON RAIN SENSOR

When the wiper switch is in the AUTO position, the wiper will operate for 1 cycle if the initial engine

start is made. This may cause the wiper blades to wear prematurely. Therefore, other than rainy

days, set the switch to the OFF position. Especially during the winter time, check if the wiper blades

are not frozen to the windshield.

Operating the wiper with the blades frozen can damage the wiper motor.

If you operate the wipers when the windshield is dry without spraying washer fluid, the windshield

can be scratched and the wiper blades can wear prematurely. Use the wiper with the washer fluid

when the windshield is dry.

When it does not rain, turn the wiper switch to the OFF position.

Turn the wiper switch to the OFF position before any car wash to avoid unwanted operation of the

wipers.

-

-

-

-

Wiper mist & washer coupled wiper

Auto washer coupled wiper

Rain sensor coupled wiper operation (LIN)

Speed sensitive intermittent wiper

Wiper low/high control

▶
▶
▶
▶
▶

Check if the sensor is off the position.

Check if the rain sensor cover is securely installed.

Check if the customer is familiar to how to control the wiper sensitivity.

Check if the wiper sensitivity control is set to the FAST side (step 5).

Check the wiper blade for wear.

If the wiper blade cannot wipe the glass uniformly and clearly, it may cause the rain sensor to

work irregularly. Therefore, in this case, replace the wiper blade with a new one.

-

-

-

-

-

Irregular operation (abrupt operation)

▶

When cleaning the windshield over the sensor with damp clothes, the wiper may operate suddenly. It

could cause serious injury. Make sure to place the wiper switch to the OFF position and ignition switch

OFF when not in use.
