05-11 8010-01 Indicator (green) Headlamp high beam indicator ▶ Front fog lamp indicator ▶ Side light indicator ▶ Indicator (blue) Indicator (green) Indicator (amber) Glow indicator(DSL only) ▶ Indicator (red) Fuel filter indicator(DSL only) ▶ This indicator comes on when the tail lamp is switched on. This indicator comes on when the ignition switch is turned to the "ON" position and will go off when the glow plugs are sufficiently heated. This indicator comes on when the water level in the fuel filter exceeds a certain level. This lamp comes on when the headlamp high beam is operated. This indicator comes on when the fog lamp switch is operated after the tail lamps comes on. 3) Details of Warning Lamps and Indicators |
