12-11

8530-00

5) ECO Cruise Control

The ECO cruise control system has nearly same functions with the auto cruise control system. It is an

automatic speed control system that maintains a desired driving speed without using the accelerator

pedal.

ECO cruise driving mode

The engine ECU controls the sharp acceleration and deceleration to improve the fuel economy.

The ECO cruise system is ready when pushing down the cruise control lever. At this moment, the

ECO indicator on the instrument cluster comes on.

The ECO cruise system operates when pulling up the cruise control lever.

To cancel the ECO cruise driving, push doen the cruise control lever. At this moment, the ECO

indicator on the instrument cluster goes off and the auto cruise starts to operate.

-

-

-

-

Control lever

ECO indicator

ON

Blinking

Push down the lever

O

Push down it again

O

12-12

6) Normal Cancellation of the Cruise Control

The cruise control system will be canceled when one or more items of the following conditions are

applied;

When the brake pedal is depressed.

When the cruising speed is downed less than 38 km/h.

 When pushing the ON-OFF switch of the cruise control lever.

When ESP is activated.

When applying the parking brake when driving.

When using the clutch in order to shift (M/T only).

And the cruise control system can be operated again in driving state.

1.

2.

3.

4.

5.

Keep the main cruise control switch in the neutral position when not using the cruise control.

12-13

8530-00

Do not move the shift lever to Neutral position while driving with the cruise control turned on.

Otherwise, it may result in system malfunction or accidents.

Always be prepared to use the brake or accelerator pedal for safe driving while the cruise control

system is running.

The actual speed can be different from the set speed momentarily when driving on a uphill or

downhill. So, it is recommended to disable the cruise control function on a uphill or downhill. hen

driving on a steep hill use the engine brake and foot brake properly to protect the vehicle system

and for a safe driving.

Ensure that the safe distance is maintained and use the brake pedal if needed.

1.

2.

3.

4.

(1) Abnormal Cancellation of the Cruise Control

Sharp acceleration or deceleration

- 50 km/h faster than set speed

- 25 km/h faster than set speed for one minute

- 70 km/h slower than set speed

- 65 km/h slower than set speed for 3 minutes

When the cruise control lever is faulty.

When the brake switch and the brake light switch input signal are implausible.

1.

2.

3.

When the cruise control function is cancelled abnormally or intermittent problems occur, stop the vehicle

and turn off the ignition switch and remove the key to reset the system. After a while, turn on the ignition

switch again to operate the cruise control system.

13-3

1793-01

E-EGR bypass valve

Solenoid valve

Drivien by

Vacuum

(Solenoid valve)

1. SPECIFICATION

Item

E-EGR valve

Motor

EGR response time

50 mS

Driven by

DC motor

Valve

EGR gas flow rate

120 Kg/h

Position sensor

Sensing type

Hall sensor

Supply voltage

5V ± 10%

Signal range

5% ~ 95%

Max. current consumption

＜15mA

E-EGR cooler

Cooling capacity

8.3 kW or more

Coolin fin type

Wavy fin

Coller type

U-shaped
