SSANGYONG MY2002
8B-30 SUPPLEMENTAL RESTRAINTS SYSTEM
Circuit Description
When the ignition switch is turned to ON, the sensing
and diagnostic module (SDM) will perform tests to
diagnose critical malfunctions within SDM itself. Upon
passing these tests ignition and deployment loop
voltages are measured to ensure that they are within
their respective normal voltage ranges. The SDM
monitors the voltages at the driver low (terminal 14),
p a s s e n g e r l o w ( t e r m i n a l 1 1 ) , d r i v e r s e a t b e l t
pretensioner low (terminal 7) and passenger seat belt
pretensioner low (terminal 4) to detect short to ground
in the deployment loops.
DTC 07 Will Set When
DTC 07 will set when the voltage at driver seat belt
pretensioner low falls below a specified value, and ignition
voltage is within the normal operating voltage range.
DIAGNOSTIC TROUBLE CODE (DTC) 07
DRIVER SEAT BELT PRETENSIONER SHORTED TO GROUND
This test is run during start-up test and every 250
milliseconds during continuous monitoring.
Action Taken
The SDM will turn on the airbag indicator (blink mode
4) and set DTC 07. The SDM will shutdown the driver
seat belt pretensioner deployment loop.
DTC 07 Will Clear When
The scan tool CLEAR CODES command is received.
Diagnostic Aids
Carefully inspect the wires in passenger airbag
deployment loop for cutting or chafing.
KAA8B120
DTC 07 - Driver Seat Belt Pretensioner Shorted to Ground
Caution: The sensing and diagnosis module (SDM)
can maintain sufficient voltage to deploy the airbags
and pretensioners for 0.15 seconds after the ignition
is OFF and the fuse has been removed. If the airbags
or pretensioners are not disconnected, do not begin
s e r v i c e u n t i l o n e m i n u t e h a s p a s s e d a f t e r
disconnecting power to the SDM. Otherwise, injury
could result.
Caution: During service procedure, be very careful
when handling the SDM. Never strike or jar the SDM.
Never power the supplemental restraints system
(SRS) when the SDM is not rigidly attached to the
vehicle. Also SDM mounting nuts must be carefully
tightened to ensure proper operation of the SRS.
The SDM could be activated if it is powered when it
is not rigidly attached to the vehicle, resulting in
unexpected deployment and possible injury.
Perform the SRS Diagnostic System Check.
Is the SRS Diagnostic System Check complete?
Step
Action
Value(s)
Yes
No
1
-
Go to Step 2
-
