01-12

T/C oil supply pipe

M16

1

25±2.5Nm

(Fitting Screw)

-

M10

1

17±2.0Nm

(Hollow Bolt)

-

T/C oil return pipe

M6×16(to block)

2

10±1Nm

-

M6×16

(to turbocharger)

2

10±1Nm

-

EGR valve

M8×30

3

25±2.5Nm

-

Name

Size

Numbers of

fastener

Tightening

torque (Nm)

Note (total

tightening

torque)

Hot water inlet pipe

M6×12

2

10±1Nm

-

Alternator

M10×90

1

(LO) 25±2.5Nm

-

M10×116

1

(HI) 46±4.6Nm

-

Air conditioner

compressor

M8×85

4

25Nm

-

Air conditioner bracket

M6×25

4

10±1Nm

-

Intake manifold

M8×35

2

25±2.5Nm

-

M8×110

6

25±2.5Nm

-

Oil filter module

M8×40

6

25±2.5Nm

-

M8×80

1

25±2.5Nm

-

M8×140

2

25±2.5Nm

-

Knock sensor

M8×28

2

20±5Nm

-

Camshaft position

sensor

M8×14

1

10~14Nm

-

T-MAP pressure

sensor

M6×20

1

10±1Nm

-

Exhaust manifold

M8

10

40±4Nm

-

Turbocharger

M8

3

25±2.5Nm

-

T/C support bolt

M8  x 35

1

25±2.5Nm

(Turbo Side)

-

M8  x 16

1

25±2.5Nm

(Block Side)

-

01-13

0000-00

Name

Size

Numbers of

fastener

Tightening

torque (Nm)

Note (total

tightening

torque)

Idler pulley/tensioner

pulley

1

45±4.5Nm

-

Glow plug

M5

4

20±2Nm

-

Vacuum pump

M6×25

3

10±1Nm

-

Timing gear case cover

M6×40

7

10±1Nm

-

M6×45

1

10±1Nm

-

M6×50

3

10±1Nm

-

Cylinder head cover

M6×35

21

10±1Nm

-

Oil dipstick gauge cover

M6×16

1

10±1Nm

-

Oil filter cap

1

25±2.5Nm

-

Fuel rail

M8×25

2

25±2.5Nm

-

Injector clamp bolt

M6×44

2

9±1.0Nm

130˚±10˚

-

High pressure pipe

(between high pressure

pump and fuel rail

assembly)

M17 1

30±3Nm

-

High pressure pipe

(between fuel rail assembly

and injector)

M17 4

30±3Nm

-

Crankshaft position

sensor

M5×14

1

8±0.4Nm

-

Main wiring

M6×16

5

10±1Nm

-

Intake duct

M8×25

4

25±2.5Nm

-

Power steering pump

M8×100

3

25±2.5Nm

-

Cylinder head front

cover

M6×10

5

10±1Nm

-

Ladder frame

M8×35

5

30±3Nm

-

EGR pipe bolt

(to air duct)

M6×16

2

10±1Nm

-

EGR pipe bolt

(to EGR cooler)

M8×25

2

25±2.5Nm

-

01-14

7. CODING AND INITIALIZATION

1) Engine Variant Coding

Unit

Selection

Description

Remarks

Additional heater

YES

For PTC auxiary heater equipped
vehicle, select "YES"

YES

NO

-

Gear box

5 MT

"DSI 6 AT" is selected
automatically.

-

6 MT

Select

5 AT(DC 5 AT)

-

6 AT(DSI 6 AT)

Select

7 AT(DC 7 AT)

-

Immobilizer

NO

Select "YES" if the vehicle has
immobilizer.

-

YES

YES

Fan

PWM control

Select "PWM"

PWM fan

Relay

-

Engine level control

NO

YES

SKM key

NO

NO

YES

-

Glow plug

AQGS (CAN)

Select "AQGS"

AQGS (CAN)

Relay (K-line)

-

A/C

Refrigerant pressure

sensor

Select the appropriate system.

Pressure sensor

for A/C refrigerant

NO

-

Vehicle speed sensor

CAN

Select "CAN" if the vehicle has
ABS or ESP

CAN

WIRE

-

Cruise control

YES

Select "YES" if the vehicle has
cruise control.

YES

NO

-

G-sensor

YES

2WD ABS & Non-ABS: NO
4WD ABS & ESP: YES

Select

NO

Select

01-15

0000-00

2) Chassis Variant Coding

Unit

Selection

Description

Domestic/Export

Domestic

Select the region.

GEN. Export

EUROPE

EPB application

YES

Select "NO".

NO

Shift lever type

MT

AT: Select "DURA lever (CAN)".
MT: Select "MT".

DC lever (CAN)

DURA lever (CAN)

DSIH (NO-CAN)

Electric power steering
(EPS)

NO

NO

YES

Transper case

P/T

Select "2WD" or "P/T".

4WD

2WD

TOD

AWD

Sedan/Limousine

Sedan (RV)

Select "Sedan (RV)".

Limousine

Vehicle code (Engine)

Undefined

Select "D20DTR".

D32DT

D27DT

D27DTP

D20DTR

EAS

NO

Select "NO".

ECS

EAS2 corner

EAS4 corner

Telematics

NO

Select "NO".

YES
