Renault Zoe (2024 year). Manual in english - page 11





2.47

ENG_UD74981_4

Avertisseur d’angle mort (X10 - Renault)



BLIND SPOT WARNING

(4/5)

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, regardless of the system indications.

The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.

System servicing/repairs

–  In the event of an impact, the alignment of the sensors may be changed and its operation may consequently be affected.

Deactivate the function and consult an authorised dealer.

–  Any work in the area where the sensors are located (repairs, replacements, etc.) must be carried out by a qualified profes-

sional.

Only an authorised dealer is qualified to service the system.

System disturbance

Some conditions can disturb or damage the operation of the system, such as:
–  complex surroundings (metal bridges, tunnels, roads with barriers at the edge, etc.);
–  poor weather conditions (snow, hail, black ice, etc.).

Risk of false alarms or absence of warnings

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

2.48

ENG_UD74981_4

Avertisseur d’angle mort (X10 - Renault)



BLIND SPOT WARNING

(5/5)

Limitation of the system operation

– The sensors must be kept clean and free of modifications in order for the system to operate correctly.
– Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the

system.

–  When the vehicle enters corners and curves, the system may temporarily cease to detect vehicles in adjacent lanes.
–  The system may not react when there is a significant difference in speed with other vehicles.
–  If the vehicle is being overtaken by a long vehicle (e.g. heavy goods vehicle overtaking at a similar speed to the vehicle) the

system may interrupt the warning before the end of the manoeuvre.

–  The vehicle is travelling on a winding road.

Deactivating the function

You must disable the function if the sensors have been damaged (rear bumper).

driving aids ................................................

(up to the end of the DU)

overspeed warning ....................................

(up to the end of the DU)

driver assistance........................................

(up to the end of the DU)

sign detection: overspeed warning ............

(up to the end of the DU)

2.49

ENG_UD72734_2

Détection des panneaux (X10 - Renault)



Note:

 make sure the windscreen is not

obscured (dirt, mud, snow, condensa-

tion etc.).
For vehicles which are equipped with it,

the system also uses information from

the navigation system.
Once the speed limiter is activated, you

can adjust the speed limiter indication

displayed by the system.
If the limit speed is exceeded, the dis-

play panel is modified to warn the driver.

Detection of road signs

DETECTION OF ROAD SIGNS

(1/4)

For vehicles equipped with a navigation

system and if the vehicle is travelling in

a country where the speed units differ

from those of the vehicle, the system

displays the speed limit sign in the unit

of the country, alongside the speed limit

converted to the unit used by the vehi-

cle’s instrument panel.
For countries where the speed limit is

reduced during rainy weather on some

types of roads, on vehicles equipped

with a navigation system, the system

can modify the limited speed after a few

seconds of wiping the windscreen.

Special situations

The system does not take into account

exceptional speed limit measures, such

as peak pollution days.

1

The system detects speed limit signs

on the side of the road and displays the

speed limit on the instrument panel.
It mainly uses information taken from

the camera

1

, attached to the wind-

screen behind the rear view mirror.

multifunction screen...................................

(current page)

2.50

ENG_UD72734_2

Détection des panneaux (X10 - Renault)



DETECTION OF ROAD SIGNS

(2/4)

Activating/deactivating the

system

Vehicles fitted with a multimedia

screen.

Vehicle stationary, engine running,

from the multimedia screen

2

 select

the “Settings” menu, “Vehicle” tab, the

“Driving assistance” menu, “Traffic

signs”, then select “ON” or “OFF”.

With the function activated, depend-

ing on local regulations, you can acti-

vate the “Risk area display” option. The

system will notify you of the distance

separating you from this zone, and

while you are travelling in the zone.

Vehicles not fitted with a multimedia

screen

– With the vehicle stationary, press

switch

3

, as many times as required

to reach the “Vehicle” tab;

–  press the

4

 or

5

 control repeatedly to

reach the “Settings” menu. Press the

switch

6



OK

;

–  press the

4

 or

5

 control repeatedly to

reach the “DRIVING ASSIST” menu.

Press the switch

6



OK

;

–  press the

4

 or

5

 control repeatedly

to reach the “Speed alert” menu and

press the

6



OK

 switch;

–   press  the

6



OK

 switch to activate or

deactivate the function:



=

 function activated



<

 function deactivated

3

4

5

6

2

2.51

ENG_UD72734_2

Détection des panneaux (X10 - Renault)



DETECTION OF ROAD SIGNS

(3/4)

Operation

Warning lights

The function displays the following

warning lights:

7

  Speed limit road signs

8

 Additional road signs (start or end

of “No overtaking” zone, slip road

speed limit, speed in case of a cara-

van, speed limit with length of appli-

cation, etc.)

7

8

If the speed limit is exceeded, the circle

around the panel flashes (

7

 warning

light) along with a sound signal to warn

the driver.

Varying the limit speed

If the speed limit notification differs from

the detected speed value, press and

hold the following switches:
–

9

 (RES/+) to increase the notification

speed to the detected speed;

–

10

 (SET/-) to reduce the notification

speed to the detected speed.

10

9

operating faults ..........................................

(current page)

faults

operating faults ....................................

(current page)

2.52

ENG_UD72734_2

Détection des panneaux (X10 - Renault)



This function is an additional driving aid. This function is not under any

circumstances intended to replace the due care and attention of the

driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, re-

gardless of the system indications.
The system detects speed limit signs and does not detect other signs (e.g. entry/

exit to/from urban areas, etc.).
The system may not detect all speed limit signs or may interpret them incorrectly.
The driver should not ignore signs that are not detected by the system and should,

as a priority, comply with the traffic signage and the highway code.
In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system

may not indicate the correct speed to the driver.
The driver should always adapt their speed to the traffic conditions, regardless of

the system indications.

Operating faults

The system cannot detect the speed

limit if:
–  the windscreen is not clean;
–  the camera is blinded by the sun;
– there is insufficient visibility (night,

fog etc.);

–  the signs are not legible (snow, etc.)

or are hidden (by another vehicle or

by trees);

–  the information taken from the navi-

gation system is not up to date.

DETECTION OF ROAD SIGNS

(4/4)

driving ........................................................

(up to the end of the DU)

speed limiter ..............................................

(up to the end of the DU)

cruise control .............................................

(up to the end of the DU)

cruise control-speed limiter........................

(up to the end of the DU)

2.53

ENG_UD69255_2

Limiteur de vitesse (X10 - Renault)



Speed limiter

Controls

1

  Speed limiter On/Off switch.

2

  Cruise control On/Off switch.

3

  Switch to activate and decrease the

limit speed (SET/-).

4

  Switch to activate and increase the

limit speed or to set the stored limit

speed (RES/+).

5

  Speed limiter function standby (with

limited speed memory) (0).

The speed limiter function helps you

stay within the driving speed limit that

you choose, known as the

limit speed

.

SPEED LIMITER

(1/4)

You can link the speed limiter to

the “Road sign detection” function.

 2.49.

2

1

3

4

5

Driving

When a limit speed has been set but

not yet reached, driving is similar to

driving a vehicle without the speed lim-

iter function.
Once you have reached the stored

speed, no effort on the accelera-

tor pedal will allow you to exceed

the programmed speed except in an

emergency (refer to information on

“Exceeding the limit speed”).

2.54

ENG_UD69255_2

Limiteur de vitesse (X10 - Renault)



SPEED LIMITER

(2/4)

To store the current speed, press the

4



switch (RES/+) or the

3

 switch (SET/- ):

the limit speed replaces the dashes

and, depending on the vehicle, the

6



warning light appears in white.

The minimum stored speed is 20 mph

(30 km/h).

6

Switching on

Press switch

1

. The

6

 warning light ap-

pears in grey. The “Speed limiter ON”

message appears on the instrument

panel accompanied by dashes to indi-

cate that the speed limiter function is in

operation, waiting to store a limit speed.

1

3

4

2.55

ENG_UD69255_2

Limiteur de vitesse (X10 - Renault)



Limited speed cannot be maintained

When driving down a steep gradient,

the system may not maintain the limit

speed: the limit speed flashes in red

on the instrument panel and an audi-

ble signal sounds at regular intervals to

inform you of this situation.

Exceeding the limit speed

It is possible to exceed the limit speed

at any time. To do this: press the accel-

erator pedal

firmly and fully

 (beyond

the resistance point).
While the speed is being exceeded, the

speed limiter flashes red on the instru-

ment panel. Then, release the accelera-

tor pedal: the speed limiter function will

return as soon as you reach a speed

lower than the memorised speed.

The speed limiter function is

in no way linked to the brak-

ing system.

If the speed limiter is not

available (after several at-

tempts to activate), contact

an approved dealer.

SPEED LIMITER

(3/4)

Varying the limit speed

The limit speed may be changed by

pressing repeatedly or holding down:
– switch

4

 (RES/+) to increase speed;

– switch

3

 (SET/-) to reduce speed.

3

4

2.56

ENG_UD69255_2

Limiteur de vitesse (X10 - Renault)



SPEED LIMITER

(4/4)

Putting the function on

standby

The speed limiter function is suspended

when you press switch

5

 (0). The limit

speed is stored and displayed in grey

on the instrument panel.

Recalling the limit speed

If a speed has been stored, it can be re-

called by pressing the

4

 switch.

Switching off the function

The speed limiter function is inter-

rupted:
–  when you press the

1

 switch. In this

case, the speed is no longer stored;

–  when you press the

2

 switch. In this

case the cruise control is selected

and there is no stored speed.

The warning light

6

 disappears from

the instrument panel to confirm that the

function is no longer active.

When the speed limiter is set to

standby, pressing the

3

 switch re-

activates the function without taking

into account the memorised speed:

the speed at which the vehicle is

moving is taken into account.

6

2

1

3

4

5

driving ........................................................

(up to the end of the DU)

cruise control .............................................

(up to the end of the DU)

cruise control-speed limiter........................

(up to the end of the DU)

2.57

ENG_UD78584_4

Régulateur de vitesse (X10 - Renault)



Cruise control

The cruise control function helps you to

maintain your driving speed at a speed

that you choose, called the

cruising

speed.

This cruising speed may be set at any

speed above 19 mph (30 km/h).

Controls

1

  Cruise control On/Off switch.

2

 Switch to activate and decrease

cruising speed (

SET/-

).

3

 Switch to activate and increase

cruising speed or to recall the mem-

orised cruising speed (

RES/+

).

4

  Switch the function to standby (with

cruising speed saved) (

0

).

5

  Speed limiter On/Off switch.

CRUISE CONTROL

(1/5)

1

5

2

3

4

This function is an addi-

tional driving aid.
It can under no circum-

stances replace the driver’s

responsibility to respect speed limits

or to be vigilant. The driver must

always be in control of the vehicle.
Cruise control must not be used

in heavy traffic, on winding or slip-

pery roads (black ice, aquaplan-

ing, gravel) and during bad weather

(fog, rain, side winds etc.).

There is a risk of accidents.

2.58

ENG_UD78584_4

Régulateur de vitesse (X10 - Renault)



Driving

Once a cruising speed is registered

and the cruise control function is active,

you may lift your foot off the accelera-

tor pedal.

Please note that you must

keep your foot close to the

pedals in order to react in

an emergency.

Activating cruise control

At a steady speed above approximately

19 mph (30 km/h), press the

2

 (

SET/-

)

switch or the

3

 (

RES/+

) switch : the

function is activated and the current

speed is taken into account.

The cruising speed replaces the



dashes. Cruise control is confirmed

when the memorised speed and warn-

ing light appear in green

6

.

If you try to activate the function below

19 mph (30 km/h), the message “Invalid

Speed” will be displayed and the func-

tion will remain inactive.

Switching on

Press switch

1

.

The

6

 warning light appears in grey.

The “Cruise control ON” message ap-

pears on the instrument panel accom-

panied by dashes to indicate that the

cruise control function is in operation

and waiting to memorise a cruising

speed.

CRUISE CONTROL

(2/5)

6

1

5

2

3

2.59

ENG_UD78584_4

Régulateur de vitesse (X10 - Renault)



CRUISE CONTROL

(3/5)

Exceeding the cruising speed

The cruising speed may be exceeded

at any time by depressing the accelera-

tor pedal.
While it is being exceeded, the cruising

speed flashes on the instrument panel.
Then, release the accelerator pedal:

after a few seconds, the vehicle will

automatically return to its set cruising

speed.

Cruising speed cannot be

maintained

When driving down a steep gradient,

the system is unable to maintain the

cruising speed: the stored speed will

flash on the instrument panel informa-

tion display to inform you of this situ-

ation.

Adjusting the cruising speed

The cruising speed may be changed by

pressing the following repeatedly:
– the

2

 switch (

SET/-

) to reduce the

speed;

– the

3

 switch (

RES/+

) to increase the

speed.

Note:

 press and hold one of the

switches to modify speed by succes-

sive increments.

If the cruise control is no

longer available (after sev-

eral attempts to activate it),

contact an approved dealer.

The cruise control function

is in no way linked to the

braking system.

2

3

2.60

ENG_UD78584_4

Régulateur de vitesse (X10 - Renault)



Returning to the cruising speed

If a speed is stored, it can be recalled,

once you are sure that the road condi-

tions are suitable (traffic, road surface,

weather conditions, etc.). Press the

switch

3

 (

RES/+

) if the vehicle speed is

above 19 mph (30 km/h).
When the speed is stored, cruise con-

trol activation s confirmed by display of

the cruising speed and, depending on

the vehicle, the

6

 warning light is dis-

played.

Putting the function on

standby

The function is set to standby if you:
–

4

 switch (0);

–  the brake pedal;
–  move to the neutral position.
The cruising speed is stored and dis-

played in grey on the instrument panel.

CRUISE CONTROL

(4/5)

NB:

 if the speed previously stored is

much higher than the current speed,

the vehicle will accelerate more rapidly

to reach this threshold.
When the cruise control is set to

standby, pressing switch

2

 (

SET/-

) re-

activates the cruise control function

without taking into account the stored

speed: it is the speed at which the vehi-

cle is moving that is taken into account.

6

2

3

4

Cruise control switches to standby

each time ECO mode is activated or

deactivated

 2.13.

2.61

ENG_UD78584_4

Régulateur de vitesse (X10 - Renault)



CRUISE CONTROL

(5/5)

Putting the cruise control

on standby or switching it

off does not cause a rapid

reduction in speed: you

must brake by depressing the brake

pedal.

Switching off the function

The cruise control function is inter-

rupted:
–  when you press the

1

 switch. In this

case, the speed is no longer stored;

–  when you press the

5

 switch. In this

case the speed limiter is selected

and there is no stored speed.

The warning light

6

 disappears from

the instrument panel to confirm that the

function is no longer active.

6

1

5

driving ........................................................

(up to the end of the DU)

electronic parking brake ............................

(up to the end of the DU)

handbrake..................................................

(current page)

parking brake .............................................

(up to the end of the DU)

stopping the engine ...................................

(up to the end of the DU)

ignition switch ............................................

(up to the end of the DU)

instrument panel ........................................

(up to the end of the DU)

indicators:

instrument panel ..................................

(up to the end of the DU)

instrument panel messages.......................

(up to the end of the DU)

2.62

ENG_UD58183_1

Autohold (X10 - Renault)



“AUTOHOLD” function

Conditions for interrupting the

braking force

The following conditions must be met:

– the driver accelerates sufficiently

with a gear engaged;

or

–  the driver disables the function.

Warning light

 goes out on the in-

strument panel.

“AUTOHOLD” FUNCTION

Vehicle stopped (e.g. at a red light, an

intersection, a traffic jam, etc.), the func-

tion ensures braking force even when

the driver releases the brake pedal.

The braking force is released as soon

as the driver accelerates sufficiently

with a gear engaged.

Activation

Press switch

2

.

The switch warning light

2

 illuminates

to confirm that the function is activated.

Deactivation

Press the brake pedal and

2

  switch si-

multaneously.

The switch warning light

2

 turns off,

confirming that the function is deacti-

vated.

If the braking force is maintained, the

parking brake is applied automatically

when:

–  the driver exits the vehicle;

or

–  the vehicle is immobilised for more

than approximately three minutes.

Before leaving the vehicle,

check that the electronic

parking brake is fully ap-

plied. The indicator light on

switch

1

 and the warning light

}



on the instrument panel illuminate to

show that the parking brake is ap-

plied and switch off when the doors

are locked.

1

Conditions for maintaining the

braking force

The following conditions must be met:

–  the seat belt for the driver is fas-

tened;

and

–  the electronic parking brake is re-

leased;

and

–  the vehicle is not stationary on a very

steep slope.

The maintained braking force is con-
firmed by the

 warning light on

the instrument panel.

Upon each start-up, the function

continues the mode set at the time

the engine was last switched off.

2















Content      ..     9      10      11      12     ..
