Renault Zoe (2022 year). Manual in english - page 2





HANDS-FREE CARDS: general information (1/3)
The card is used for:
card operating range
- locking/unlocking the opening ele-
This varies according to the environ-
1
ments (doors, boot);
ment: take care not to accidentally lock
- unlocking the charging cable ➥ 1.8 ;
or unlock the vehicle by inadvertently
4
- switching on the vehicle lighting re-
pressing the buttons on the card.
motely (refer to the following pages).
Note: if any opening element (door or
2
luggage compartment) is open or not
Battery life
properly shut, locking is unsuccessful
3
and the hazard warning lights and side
Make sure that the correct battery type
indicator lights do not flash.
is being used, and that the battery is in
good condition and inserted correctly.
Its service life is approximately two
years: it should be replaced when the
message “Keycard Battery Low” ap-
pears on the instrument panel ➥ 5.15.
1
Unlocking the doors and luggage
compartment.
2
Locks all the opening elements.
3
Unlocking/locking the boot.
4
Switching on the lighting remotely.
When the battery is flat, you can still
lock/unlock and start your vehicle.
➥ 2.2 ➥ 1.32 ➥ 5.15.
1.21
HANDS-FREE CARDS: general information (2/3)
Interference
Interference by factors in the immediate
vicinity (external installations or the use
of equipment operating on the same
4
frequency as the remote control) may
affect the operation of the remote con-
trol.
Advice
Driver’s responsibility
Avoid leaving the card in hot, cold or
when parking or stopping
humid areas.
the vehicle
Do not keep the card in a place
Never leave an animal,
where it could be bent or dam-
child or adult who is not self-suffi-
aged accidentally, such as in a back
cient alone in your vehicle, even for
pocket of a garment.
a short time.
Distance lighting function
They may pose a risk to themselves
or to others by starting the engine,
Pressing button
4 switches on
the
activating equipment such as the
dipped beam headlights and the exte-
electric windows or locking the
rior lighting for approximately 20 sec-
doors, for example.
onds. This can be used, for example,
Also, in hot and/or sunny weather,
to identify the vehicle from a distance
Replacement: need for an
please remember that the tempera-
when parked in a car park. Pressing
additional card
ture inside the passenger compart-
and holding the 4 button for approxi-
If you lose your card or require an-
ment increases very quickly.
mately two seconds activates the exte-
other, you can obtain one from an
rior lighting and a sound is emitted.
RISK OF DEATH OR SERIOUS
authorised dealer.
Note: pressing button 4 again switches
If a card is replaced, it will be neces-
INJURY.
off the lighting.
sary to take the vehicle and all its
cards to an approved Dealer to ini-
tialise the system.
You may use up to four cards per
vehicle.
1.22
HANDS-FREE CARDS: general information (3/3)
5
A
7
8
6
Fitting a strap 7
Insert the strap into the 8 component
and pass the end of the strap through
Slide the rear casing
5 downwards
the buckle.
while pressing on zone A.
Position the strap at the 6 opening and
close the cartridge.
Note: check that the diameter of the
strap cord 7 will fit the opening 6.
1.23
“HANDS-FREE” CARD: use (1/5)
There are two ways to unlock/lock the
Deactivating/activating the
vehicle:
“hands-free” mode
-
“hands-free”, when approaching and
Depending on the vehicle, you can de-
moving away from the vehicle;
activate/activate unlocking when ap-
-
using the card in remote control
proaching and locking when moving
mode.
away from the vehicle.
You can also disable/activate the sound
signal that is emitted upon locking when
Driver’s responsibility
moving away from the vehicle ➥ 1.92.
when parking or stopping
the vehicle
Never leave an animal,
child or adult who is not self-suffi-
cient alone in your vehicle, even for
a short time.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or locking the
doors, for example.
Also, in hot and/or sunny weather,
please remember that the tempera-
ture inside the passenger compart-
ment increases very quickly.
RISK OF DEATH OR SERIOUS
INJURY.
Do not store the card anywhere it
may come into contact with other
electronic equipment
(computer,
Never leave your vehicle
phone etc.) as this could hinder its
with the card inside.
operation.
1.24
“HANDS-FREE” CARD: use (2/5)
1
1
3
2
Unlocking in “hands-free”
Remote “Hands-free” locking
Depending on the equipment level, the
door mirrors fold in automatically to
mode, when approaching
With the card on you, doors and lug-
confirm locking.
and moving away from the
gage compartment door closed, move
vehicle
away from the vehicle: it will lock auto-
If the card has been within the detection
matically once you have left the access
area 1 for approximately 15 minutes,
With the card in access zone 1, the ve-
remote locking is disabled. To lock the
zone 1.
hicle will unlock.
vehicle, press button 3 on the card.
Note: the distance at which the vehicle
The hazard lights and side repeaters
The vehicle cannot be remotely locked
locks depends on the surroundings.
flash once to indicate that the doors
if the card is within the area 2.
have unlocked and, on some vehicles,
The hazard lights flash twice then
the door mirrors fold out automatically.
remain illuminated for about four sec-
onds, a beep sounds to indicate that
the doors have locked and, on some
vehicles, the door mirrors fold in auto-
matically.
1.25
“HANDS-FREE” CARD: use (3/5)
Special features of the
unlocking system
Under certain circumstances, approach
unlocking is deactivated:
- after eight days of no use of the vehi-
cle;
- if the card remains close to the 1
area of the vehicle for approximately
five minutes after the vehicle has
been locked;
- after several passes in the vicinity of
4
the 1 area of the vehicle and without
the door being unlocked.
Press button 4 or the remote control to
“Hands-free” unlocking using
unlock the vehicle and reactivate the
button 4
mode.
With the card in area 1 and the vehi-
cle locked, press button 4 to unlock the
entire vehicle.
Unlocking is indicated by one flash of
the hazard warning lights and the indi-
cator lights.
1.26
“HANDS-FREE” CARD: use (4/5)
Locking using the card
With the doors and boot closed, press
5
button 3: the vehicle locks.
The hazard warning lights flash twice
to indicate that the vehicle is locked
and, depending on the vehicle, the door
3
mirrors automatically fold in.
Pressing the 3 button twice locks the
vehicle and enables the closure of the
2
front and rear windows (depending on
the vehicle).
Note:
- the maximum distance at which the
vehicle locks depends on the sur-
Using the card as a remote
roundings;
If, while the engine is running, a door
is opened and closed, and the card is
control
- if a door or the boot is open or not
no longer in the zone 2, the message
properly shut, locking is not carried
Unlocking with the card
“Keycard Not Detected” indicates that
out. A beep sounds but the hazard
the card is not inside the vehicle. This
Press button 5.
warning lights and side repeaters do
will, for example, prevent you from driv-
not flash.
Unlocking is indicated by one flash of
ing away after dropping off a passenger
the hazard warning lights and the indi-
who has kept the card on them.
cator lights.
The warning disappears when the card
is detected again.
The card buttons are deactivated
when the engine is running.
1.27
“HANDS-FREE” CARD: use (5/5)
Unlocking the charging cord
Press button 5 to unlock the charging
5
cable from the vehicle.
Driver’s responsibility
6
when parking or stopping
the vehicle
Never leave an animal,
child or adult who is not self-suffi-
cient alone in your vehicle, even for
a short time.
Locking/unlocking only the
They may pose a risk to themselves
or to others by starting the engine,
boot
activating equipment such as the
Press the button 6 to lock/unlock the
electric windows or locking the
boot only.
doors, for example.
Also, in hot and/or sunny weather,
please remember that the tempera-
ture inside the passenger compart-
ment increases very quickly.
RISK OF DEATH OR SERIOUS
INJURY.
1.28
CARD: deadlocking
To activate deadlocking
To deactivate deadlocking
Press button 2 twice in quick succes-
Unlock the vehicle using button 1 on
1
sion.
the card.
The hazard lights and side repeaters
The hazard warning lights flash once to
flash twice slowly and flash three
indicate that the doors have been un-
times quickly to indicate that the doors
locked.
2
are locked and, depending on the ve-
hicle, the door mirrors fold in automat-
ically.
If the vehicle is equipped with a dead-
locking function, this allows you to lock
the opening elements and to prevent
the doors from being unlocked using
the interior handles (for example, by
breaking the window and then trying to
open the door from the inside).
Never use deadlocking if
someone is still inside the
vehicle.
1.29
OPENING AND CLOSING THE DOORS (1/2)
2
1
4
3
Opening the doors from the
Rear doors
Opening from the inside
outside
With the doors unlocked:
Pull handle 4.
- press on recess
2 to move the
Front doors
handle 3;
Lights-on reminder buzzer
With the doors unlocked, pull handle 1.
– slide your hand into the handle 3 and
A warning beep sounds when the driv-
pull towards you.
er’s door is opened to warn you that the
lights are still on.
As a safety precaution,
the doors should only be
opened or closed when the
vehicle is stationary.
1.30
OPENING AND CLOSING THE DOORS (2/2)
Driver’s responsibility
6
when parking or stopping
the vehicle
5
Never leave an animal,
child or adult who is not self-suffi-
cient alone on your vehicle, even for
Door/tailgate open buzzer
Special note
a short time.
They may pose a risk to themselves
When stationary, the warning light
Once the engine has been switched off,
or to others by starting the engine,
the lights and accessories (radio, etc.)
activating equipment such as the
shows when a door, the boot or
will continue to operate until the driver’s
electric windows or by locking the
the charging flap is open or not closed
door is opened.
doors.
properly. The warning light 5 indicates
Also, in hot and/or sunny weather,
that the door or the boot is open or not
Child safety
please remember that the tempera-
properly closed.
ture inside the passenger compart-
When the vehicle reaches a speed of
To make it impossible for the rear doors
ment increases very quickly.
approximately 12 mph (20 km/h), the
to be opened from the inside, move the
RISK OF DEATH OR SERIOUS
lever 6 and check from the inside that
INJURY.
warning lights
and 5 are accom-
the doors are securely locked.
panied by a message indicating that the
opening element is open or not properly
closed.
1.31
LOCKING, UNLOCKING THE DOORS (1/3)
If the card does not work:
In certain cases, the card may not
2
work:
1
A
- when the card battery is drained, flat
battery, etc.
- due to the use of electronic devices
near to the remote control
(e.g.
mobile telephone);
- vehicle located in a high electromag-
netic radiation zone.
It is then possible:
- to use the key that is built into the
card;
- to lock each of the doors manually;
The card’s built-in key
- to use the interior door locking/un-
The integrated 2 key is used to lock or
locking control (refer to the following
unlock the front left-hand door if the
pages).
card does not work.
Access with key 2
Slide the rear casing
1 downwards
while pressing on zone A.
1.32
LOCKING, UNLOCKING THE DOORS (2/3)
3
2
Using the key integrated in the card
Locking the doors manually
Insert the key 2 into the lock of the front
Turn screw 3 with the door open (using
left-hand door and lock or unlock.
the end of the key) and close the door.
This means that the doors are then
locked from the outside.
The doors may then only be opened
from the inside or by using the key in
the front left-hand door.
1.33
LOCKING, UNLOCKING THE DOORS (3/3)
Door and tailgate status
Locking the doors without
indicator
the card
When the ignition is on, the indicator
For example, in the event of a dis-
light above the 4 switch informs you of
charged battery or the card temporarily
the locking status of the opening ele-
not working, etc.
4
ments:
With the engine switched off and an
- indicator light on, the doors and tail-
opening (door or boot) open, press
gate are locked,
and hold the switch 4 for more than five
seconds.
- indicator light off, the doors and tail-
gate are unlocked.
When the door is closed, all the doors
and tailgate will be locked.
If the ignition is off, when you lock the
doors the warning light remains lit for
Note: unlocking the vehicle from the
some time before disappearing.
outside is only possible with the card in
the vehicle’s access zone or using the
Interior locking/unlocking
key integrated in the card.
door control
Switch 4 simultaneously controls the
doors and the tailgate.
Never leave your vehicle
with the card inside.
If a door or the tailgate is open or not
closed properly, the doors and tailgate
lock/unlock quickly.
If transporting an object with the tail-
gate open, you can still lock the doors:
After locking/unlocking the vehi-
Driver’s responsibility
with the ignition off, press and hold
cle using the buttons on the card,
switch 4 for more than five seconds to
If you decide to keep the
remote locking and hands-free un-
lock the other opening elements.
doors locked when you are
locking are deactivated.
driving, remember that it
To reactivate the “hands-free” mode:
may be more difficult for those as-
restart the vehicle.
sisting you to gain access to the pas-
senger compartment in the event of
an emergency.
1.34
AUTOMATIC LOCKING WHEN DRIVING
Activating/deactivating the
Operating faults
function
If you experience an operating fault
With the engine running, press the
(no automatic locking, the indicator
button 1 for approximately 5 seconds,
light incorporated in button 1 does not
until you hear a warning beep.
light up when trying to lock the open-
1
ing elements, etc.), firstly check that the
NB: if a door is opened or closed, it will
opening elements are properly closed.
automatically lock again when the vehi-
If they are properly closed, contact an
cle reaches a speed of 6 mph (10 km/h).
authorised dealer.
Operating principle
After the vehicle is started, the system
automatically locks the doors when you
are driving at approximately 6 mph (10
km/h) and over.
The door can be unlocked:
- by pressing the button 1 to unlock
the doors;
- with the vehicle stationary, by open-
Driver’s responsibility
ing a front door from inside the vehi-
cle.
If you decide to keep the
doors locked when you are
driving, remember that it
may be more difficult for those as-
sisting you to gain access to the
passenger compartment in the
event of an emergency.
1.35
STEERING WHEEL (1/2)
Activating the function
With the ignition on, press switch 3, the
indicator light in the switch lights up.
Deactivating the function
2
- Automatic:
The function switches off automatically
after the regulation phase of approxi-
mately 30 minutes. The indicator light
1
in switch 3 goes out.
Note: if the function has switched off
automatically, press the switch 3 twice
3
to reactivate it.
If switch 3 is not pressed again, the
Adjusting the steering wheel
Steering wheel heating
function will be reactivated the next
(depending on vehicle)
time the ignition is switched on.
height and depth
This function heats the steering
- Manually:
Lower the lever 1 and position the
steering wheel in the required position.
wheel 2.
To deactivate the function during the
regulation phase, press the switch 3.
Then, raise the lever fully, beyond the
Operating principle
The indicator light in switch 3 goes out.
point of resistance to lock the steering
When the temperature is reached, the
wheel.
function regulates the temperature of
Make sure that the steering wheel is
the heated areas for approximately
correctly locked.
30 minutes and then switches off auto-
matically.
For safety reasons, only
adjust the steering wheel
when the vehicle is station-
ary.
1.36
STEERING WHEEL (2/2)
Power-assisted steering
The variable power-assisted steering
system is equipped with an electronic
control system which alters the level of
assistance to suit the vehicle speed.
Steering is made easier during parking
manoeuvres (for added comfort) while
the force needed to steer increases
progressively as the speed rises (for
enhanced safety at high speeds).
Never leave the steering wheel on
full lock when the vehicle is station-
ary.
With the engine switched off, or if
there is a system fault, it is still pos-
sible to turn the steering wheel. The
force required will be greater.
Never switch off the igni-
A noise may be heard when the
tion when travelling down-
steering wheel is moved quickly.
hill, and avoid doing so in
This is normal.
normal driving (assistance
is not provided).
1.37
REAR VIEW MIRRORS
Heated door mirrors
When the engine is started, mirror de-
icing is activated with the rear screen
de-icing/demisting.
Folding door mirrors
The door mirrors will fold-out automati-
cally when the vehicle is unlocked. The
1
2
door mirrors fold in when the vehicle is
locked.
3
In any case, you can force fold in or fold
A
out:
B
- press switch 3 in position B to auto-
2
matically fold in the door mirrors;
- press switch 3 in position A to auto-
Door mirrors with electrical
Interior rear view mirror
matically fold out the door mirrors.
adjustment:
Its position can be adjusted.
Select the door mirror using switch 2,
Rear view mirror with lever 2
then use button 1 to adjust it to the de-
When driving at night, to avoid being
sired position.
dazzled by the headlights of the vehicle
behind, depress the little lever located
behind rear view mirror 2.
Objects observed in the
Rear view mirror without lever 2
door mirror glass are actu-
The rear view mirror automatically dark-
ally closer than they appear.
ens when you are being followed by a
For your safety, take this
vehicle using main beam headlights or
into account in order to correctly
in very bright lighting.
assess the distance before any ma-
For safety reasons, carry
noeuvre.
out any adjustments when
the vehicle is stationary.
1.38
FRONT SEATS (1/2)
To tilt the seatback
Turn control knob 3 to the required po-
sition.
1
3
2
To move the seat forwards or
To adjust the lumbar support
back
on the driver’s seat
(depending on vehicle)
Lift handle 1 to unlock. Release the
For safety reasons, carry
handle once the seat is in the correct
Lower handle 2 to increase the support
out any adjustments when
position and ensure that the seat is fully
and lift it to decrease it.
the vehicle is not being
locked into position.
driven.
We would advise you not to recline
the seatbacks too far to ensure that
the effectiveness of the seat belts is
not reduced.
No object should be placed on the
floor (in front of the driver). Nothing
should be placed around the driv-
After making adjustments,
er’s feet as such objects may slide
make sure that the seat-
under the pedals during sudden
backs are correctly locked
braking manoeuvres and obstruct
in place
their use.
1.39
FRONT SEATS (2/2)
Operating faults
When an operating fault is detected,
the warning lights in the 4 switch for the
seat concerned switch off after approxi-
mately five seconds.
Consult an approved dealer.
4
Heated seats
With the ignition on:
- Pressing the switch 4 on the re-
quired seat for the first time activates
the heating system on high. Both in-
tegrated switch warning lights come
on;
- pressing the switch for the second
time changes the heating to low. One
integrated warning light comes on;
- pressing for the third time turns the
heating off.
1.40
SEAT BELTS (1/5)
Always wear your seat belt when trav-
Before starting, first adjust your driv-
elling in your vehicle. You must also
ing position, then ask all occupants
comply with the legislation of the par-
to adjust their seat belts to ensure
ticular country you are in.
optimum protection.
Adjusting your driving
position
1
-
Sit well back in your seat
(having
Make sure that the rear bench seat
removed your coat or jacket etc.).
is locked in position correctly so that
This is essential to ensure your back
the rear seat belts will operate cor-
is positioned correctly;
rectly. ➥ 3.24.
-
adjust the distance between the
seat and the pedals. Your seat
should be as far back as possible
2
while still allowing you to fully de-
press the pedals. The seatback
Adjusting the seat belts
should be adjusted so that your arms
Incorrectly adjusted or
are slightly bent when you hold the
Sit with your back firmly against the
twisted seat belts may
steering wheel;
seatback.
cause injuries in the event
-
adjust the position of the steering
The shoulder strap 1 should be as close
of an accident.
wheel.
as possible to the base of the neck but
not on it.
Use one seat belt per person,
whether child or adult.
Lap belt 2 should be worn flat over the
thighs and against the pelvis.
Even pregnant women should wear
a seat belt. In this case, ensure that
The seat belt must be worn as close to
the lap belt is not exerting too much
the body as possible. Eg: avoid wearing
pressure on the abdomen, but do
heavy clothing or keeping bulky objects
not allow any slack.
under the belts, etc.
1.41















Content      ..      1      2      3      ..
