Renault Megane (2022 year). Manual in english - page 11





SPEED LIMITER (4/4)
7
7
5
1
4
3
2
Putting the function on
Switching off the function
standby
The speed limiter function is inter-
The speed limiter function is suspended
rupted:
when you press switch 5 (0). The limit
- when you press the 1 switch. In this
speed is stored and displayed in grey
case, the speed is no longer stored;
on the instrument panel.
- when you press the 2 switch. In this
case the cruise control is selected
Recalling the limit speed
and there is no stored speed.
If a speed has been stored, it can be re-
The warning light 7 disappears from
called by pressing the 4 switch.
the instrument panel to confirm that the
When the speed limiter is set to
function is no longer active.
standby, pressing the 3 switch re-
activates the function without taking
into account the memorised speed:
the speed at which the vehicle is
moving is taken into account.
2.88
CRUISE CONTROL (1/5)
4 Switch the function to standby (with
cruising speed saved) (0).
5 Speed limiter On/Off switch.
6
4
5
3
This function is an addi-
tional driving aid. The func-
tion does not take the place
2
of the driver.
1
Therefore, it can under no circum-
The cruise control function helps you to
The presence of the
“Hill Descent
stances replace the driver’s respon-
maintain your driving speed at a speed
Control” function can be identified by
sibility to respect speed limits and to
that you choose, called the cruising
the presence of the 6 button.
be vigilant (the driver must always
speed.
be ready to brake).
This cruising speed may be set at any
Controls
Cruise control must not be used in
speed above 19 mph (30 km/h).
heavy traffic, on undulating or slip-
1 Cruise control On/Off switch.
Depending on the vehicle, cruise con-
pery roads (black ice, aquaplan-
trol is linked with “Hill Descent Control”
2 Switch to activate and decrease
ing, gravel) and during bad weather
which uses the braking system to opti-
cruising speed (SET/-).
(fog, rain, side winds etc.).
mise downhill cruise control.
3 Switch to activate and increase
There is a risk of accidents.
cruising speed or to recall the mem-
orised cruising speed (RES/+).
2.89
CRUISE CONTROL (2/5)
7
7
3
2
1
Switching on
Activating cruise control
Driving
Press switch 1.
While the vehicle is moving a steady
Once a cruising speed is registered
speed above approximately 19 mph
and the cruise control function is active,
The 7 warning light appears in grey.
(30 km/h), press the 2 (SET/-) switch
you may lift your foot off the accelera-
The “Cruise control ON” message ap-
or the 3 (RES/+) switch: the function
tor pedal.
pears on the instrument panel accom-
is activated and the current speed is
panied by dashes to indicate that the
taken into account.
cruise control function is in operation
The cruising speed replaces the
and waiting to memorise a cruising
dashes. Cruise control is confirmed
speed.
when the memorised speed and warn-
ing light appear in green 7.
If you try to activate the function below
19 mph (30 km/h), the message “Invalid
Please note that you must
Speed” will be displayed and the func-
keep your feet close to the
tion will remain inactive.
pedals in order to react in
an emergency.
2.90
CRUISE CONTROL (3/5)
Exceeding the cruising speed
The cruising speed may be exceeded
at any time by depressing the accelera-
tor pedal. While it is being exceeded,
the cruising speed flashes in red on the
instrument panel.
Cruise control with cruising
speed maintained during gear
Then, release the accelerator pedal:
changing:
after a few seconds, the vehicle will
automatically return to its set cruising
This function maintains the cruise
speed.
control speed before and after a
3
gear change, without any action re-
Cruising speed cannot be
quired from the driver.
maintained
2
When driving down a steep gradient,
the system may be unable to main-
Adjusting the cruising speed
tain the cruising speed: the memorised
Cruise control/speed
speed will flash in red on the instrument
The cruising speed may be changed by
limiter with Hill Descent
panel and an audible signal sounds at
pressing the following repeatedly:
Control:
regular intervals to inform you of this
the function may act on the
- the 2 switch (SET/-) to reduce the
situation.
braking system.
speed;
- the 3 switch (RES/+) to increase the
Cruise control/speed limiter with-
speed.
out Hill Descent Control:
The function never interacts with the
Note: press and hold one of the
braking system.
switches to modify speed by succes-
sive increments.
Please note that you must always
keep your feet close to the pedals
in order to react in an emergency.
If the cruise control is no
longer available (after sev-
eral attempts to activate it),
contact an approved dealer.
2.91
CRUISE CONTROL (4/5)
7
7
4
3
2
Putting the function on
Returning to the cruising speed
NB: if the speed previously stored is
much higher than the current speed,
standby
If a speed is stored, it can be recalled,
the vehicle will accelerate more rapidly
once you are sure that the road condi-
The function is set to standby if you:
to reach this threshold.
tions are suitable (traffic, road surface,
- 4 switch (0);
weather conditions, etc.). Press the
When the cruise control is set to
- the brake pedal;
switch 3 (RES/+) if the vehicle speed is
standby, pressing switch 2 (SET/-) re-
above 19 mph (30 km/h).
activates the cruise control function
- the clutch pedal for a prolonged
without taking into account the stored
period or upon prolonged neutral po-
When the speed is stored, cruise con-
speed: it is the speed at which the vehi-
sition on vehicles equipped with a
trol activation is confirmed by the dis-
cle is moving that is taken into account.
manual gearbox;
play in green of the cruising speed and,
depending on the vehicle, the 7 warn-
- shifting to neutral position on ve-
ing light is displayed.
hicles equipped with an automatic
gearbox.
The cruising speed is stored and dis-
played in grey on the instrument panel.
2.92
CRUISE CONTROL (5/5)
7
7
5
1
Switching off the function
The warning light 7 disappears from
the instrument panel to confirm that the
The cruise control function is inter-
function is no longer active.
rupted:
- when you press the 1 switch. In this
case, the speed is no longer stored;
- when you press the 5 switch. In this
case the speed limiter is selected
and there is no stored speed.
Putting the cruise control
on standby or switching it
off does not cause a rapid
reduction in speed: you
must brake by depressing the brake
pedal.
2.93
ADAPTIVE CRUISE CONTROL (1/13)
Based on information from a radar
According to conditions on the road
This function is an addi-
or camera, the adaptive cruise con-
(traffic, weather etc.), the adaptive
tional driving aid. The func-
trol function
(or Stop and Go adap-
cruise control function can be activated:
tion does not take the place
tive cruise control function on vehicles
- 0 mph (0 km/h) to 105 mph (170 km)
of the driver.
equipped with an automatic gearbox)
on vehicles fitted with an automatic
enables you to maintain the speed se-
Therefore, it can under no circum-
gearbox;
lected (known as cruising speed) while
stances replace the driver’s respon-
- 19 mph (30 km/h) to
105 mph
keeping a following distance with the
sibility to respect speed limits and
(170 km) on vehicles fitted with a
vehicle in front in the same lane.
safe distances and to be vigilant
manual gearbox.
(the driver must always be ready to
On vehicles fitted with an automatic
The function is indicated by the
brake).
gearbox, if the vehicle in front stops,
symbol.
the Stop and Go adaptive cruise control
The driver must always be in con-
function may apply the vehicle brakes
Note:
trol of the vehicle. The driver must
to a full-stop before allowing the vehicle
- the driver must observe the maxi-
always adapt their speed according
to move-on.
mum speed limit and safe distances
to the surroundings and traffic con-
in the country where they are driving;
ditions. The adaptive cruise control
The system controls acceleration and
- the adaptive cruise control can brake
must only be used on a motorway
deceleration of your vehicle using the
the vehicle up to a third of the brak-
(or multi-lane road separated by a
engine and braking system.
ing capacity. Depending on the situ-
barrier). The cruise control must not
The system’s maximum range is ap-
ation, the driver may need to brake
be used in heavy traffic, on wind-
proximately 150 m. This may vary ac-
harder.
ing or slippery roads (black ice, aq-
cording to the road conditions (ground
uaplaning, gravel) or during bad
relief, weather conditions, etc.).
weather (fog, rain, side winds etc.).
There is a risk of accidents.
The adaptive cruise control does
not trigger an emergency stop and
its braking capability is limited.
2.94
ADAPTIVE CRUISE CONTROL (2/13)
1
8
11
9
3
10
4
7
5
6
2
Location of the camera 1
Controls
6
Cruising speed activation, storage
and decrease switch (SET/-).
Make sure the windscreen is not ob-
3 Safe distance settings
scured (by dirt, mud, snow, condensa-
7
Switch to activate and increase cruis-
4 Switch the function to standby (with
tion etc.).
ing speed or to recall the memorised
cruising speed saved) (0).
cruising speed (RES/+).
5 Adaptive cruise control main stop/
Location of the radar 2
start switch
Ensure that the radar area is not ob-
structed
(dirt, mud, snow, a badly
fitted/attached front number plate), im-
pacted, modified (including paintwork)
or hidden by any accessory fitted on the
The radar and camera
front of the vehicle (on the grille or logo
zones must be kept clean
etc.).
and free of any tampering in
order to ensure the proper
operation of the system.
2.95
ADAPTIVE CRUISE CONTROL (3/13)
Switching on
The cruising speed 11 replaces the
8
dashes and cruise control is confirmed
Press switch 5.
by the appearance of the cruising
Warning light
appears in grey, and
speed in green and warning light
11
the message “Adaptive Cruise Ctl ON”
If you try to activate the function when
9
appears on the instrument panel, ac-
the vehicle speed is over 105 mph
10
companied by dashes to indicate that
(170 km) or below 19 mph (30 km/h) for
the cruise control function is activated
vehicles fitted with a manual gearbox,
and waiting to store a cruising speed.
the message “Invalid Speed” is dis-
played and the function is not activated.
This function cannot be activated when:
Once a cruising speed is memorised
- the parking brake is applied;
and the cruise control function is active,
- the Park Assist function is already
you may lift your foot off the accelera-
activated ➥ 2.119.
tor pedal.
The message “Adaptive Cruise Ctl una-
Special feature on vehicles with
vailable” is displayed on the instrument
an automatic gearbox: if the vehicle
Displays
panel.
speed is below approximately 19 mph
8
Adaptive cruise control warning
(30 km/h), the cruising speed will auto-
light.
matically be set to 19 mph (30 km/h).
Activating cruise control
The vehicle will accelerate until it
9
Vehicle in front.
When the vehicle is stationary (vehicles
reaches the stored cruising speed.
10
Stored safe distance
equipped with an automatic gearbox) or
when the vehicle is moving at a steady
11
Stored cruising speed.
speed (all vehicles), press the 6 (SET/-)
or 7 (RES/+) switch to activate the func-
tion and store the current speed. The
minimum cruising speed is 19 mph
(30 km/h).
Important: you should keep
your feet near the pedals at
all times to prepare for any
event.
2.96
ADAPTIVE CRUISE CONTROL (4/13)
Safe distance control
activation
As soon as cruise control is activated,
the default safe distance 10 is displayed
in green on the instrument panel. The
default safe distance corresponds to
approximately two seconds (see follow-
A
ing pages).
B
If the system detects a vehicle in your
3
C
lane, an outline of a vehicle 9 appears
above the distance gauge 10 on the in-
7
D
strument panel.
6
Your vehicle adapts its speed to that
of the vehicle in front and applies the
brakes if necessary (the brake lights
Setting the cruising speed
Adjusting the following
come on) in order to maintain the dis-
tance displayed on the instrument
You can vary the speed by repeatedly
distance
panel.
pressing (for a small variation) or press-
You can vary the safe distance from the
ing and holding (for a larger variation)
vehicle in front at any time by pressing
Note: the size of the 9 outline varies ac-
switch 6 or 7:
switch 3 repeatedly.
cording to the distance separating you
from the vehicle in front. The larger the
- use the “SET/-” switch 6 to reduce
The horizontal distance gauge on the
outline, the closer the vehicle in front.
the speed;
instrument panel indicates the various
- use the “RES/+” switch 7 to increase
available safe distances:
the speed.
- distance gauge A: long distance
(corresponding to approximately
2.4 seconds);
2.97
ADAPTIVE CRUISE CONTROL (5/13)
Adjusting the safe distance
(cont.)
- distance gauge B: intermediate dis-
11
tance 2 (corresponding to approxi-
mately 2 seconds);
- distance gauge C: intermediate dis-
tance 1 (corresponding to approxi-
11
mately 1.6 seconds);
- distance gauge D: short distance
(corresponding to approximately
1.2 seconds).
The selected distance gauge appears
in green on the instrument panel. The
other gauges remain in grey.
Exceeding the cruising speed
Then, release the accelerator pedal:
Note: the distance must be set accord-
the cruise control and safe distance
ing to the traffic level, local regulation
The cruising speed may be exceeded
control will automatically resume the
and weather conditions.
at any time by applying the accelerator
speed and distance instructions that
pedal.
you had previously selected.
If it is exceeded, the cruising speed 11
appears in red.
Overtaking manoeuvre
The distance gauge flashes if the dis-
If you wish to overtake the vehicle in
tance between your vehicle and the
front, activating the indicator will tem-
vehicle in front is less than the safe
porarily cancel the safe distance con-
distance selected: the “safe distance
trol and enable an acceleration speed
control” function is no longer active.
sufficient to complete overtaking.
The safe distance is adjusted by de-
fault on the distance gauge B.
2.98
ADAPTIVE CRUISE CONTROL (6/13)
Stopping and starting on
Putting the function on
vehicles fitted with an
standby
automatic gearbox
You can set the function to standby
If the vehicle in front slows down, the
when:
system adapts its speed to a complete
- you press switch 4 (0);
stop if necessary (e.g. in heavy traffic).
- you apply the brake pedal while the
The vehicle stops a few metres from
vehicle is moving.
the vehicle in front. The Stop and Start
The function is deactivated by the
function can put the engine on standby
system if:
➥ 2.8.
- you set the automatic gearbox to P
4
When the vehicle in front sets off again:
or N;
7
- if the stop does not exceed about
- you engage the reverse gear;
three seconds, the vehicle sets off
- you unbuckle the driver’s seatbelt;
automatically without any action by
- you open one of the opening ele-
the driver;
ments;
- if the stop exceeds about three sec-
- you press the engine start/stop
In all circumstances, the standby is con-
onds, you must apply the accelera-
button;
firmed when the warning lights appear
tor pedal or press button 7 (RES/+) in
- the slope is too steep;
in grey and the message “Adaptive
order for the vehicle to set off again.
- the vehicle speed is above 112 mph
Cruise Ctl Disconnected” appears on
The message “Press RES/+ or ac-
(180 km/h);
the instrument panel.
celerate” appears on the instrument
- certain driving aids and correction
panel to confirm.
devices are triggered (active emer-
If the stop exceeds about three min-
gency braking, ABS, ESC etc.) ;
utes, the electronic parking brake is
- when you press the clutch pedal for a
automatically applied and the Stop
prolonged period or upon prolonged
Putting the adaptive cruise
and Go adaptive cruise control is de-
neutral position on vehicles equipped
control in standby or switch-
activated. The
warning light disap-
with a manual gearbox.
ing it off does not cause a
pears to confirm that the function is de-
rapid reduction in speed:
activated.
you must brake by applying the
brake pedal if necessary.
2.99
ADAPTIVE CRUISE CONTROL (7/13)
Exit from standby
Depending on the situation, the system
sounds a beep associated with:
Based on the stored cruising speed
- the orange alert E if the situation re-
If a speed is stored, it can be recalled,
quires the driver’s attention;
E
once you are sure that the road con-
or
ditions are suitable (traffic, road sur-
face, weather conditions, etc.). Press
- the red alert F accompanied by the
switch 7 (RES/+) in the range of con-
message “Brake”, if the situation re-
firmed speeds.
quires the driver’s immediate atten-
When the stored speed is recalled, acti-
tion.
vation of the cruise control is confirmed
In all situations, react accordingly
by the illumination of the cruising speed
F
and perform the appropriate ma-
in green.
noeuvres.
Note: if the stored speed is higher than
the current speed, the vehicle will ac-
celerate to reach that speed.
“Take control of the vehicle”
Based on the current speed
warnings
When the cruise control is set to
In some situations (e.g. coming upon
standby, pressing switch 6 (SET/-) re-
a much slower vehicle, vehicle in
activates the cruise control function
front changing lanes quickly etc.), the
without taking into account the stored
system may not have time to react.
speed: it is the speed at which the vehi-
cle is moving that is taken into account.
2.100
ADAPTIVE CRUISE CONTROL (8/13)
Operating faults
If the radar detection area is obstructed
or the radar signal is disrupted, the
If an adaptive cruise control function
message “Front radar no visibility” is
operating fault is detected, the mes-
displayed on the instrument panel and
sage “Check Adaptive Cruise control”
the adaptive cruise control is inter-
appears on the instrument panel and
rupted. The green warning light
the adaptive cruise control function is
disappears to confirm that the function
deactivated.
has been automatically deactivated.
Ensure that the radar area is not ob-
If an operating fault is detected on one
structed
(dirt, mud, snow, a badly
or more components of the system, the
fitted/attached front number plate), im-
adaptive cruise control function is inter-
7
pacted, modified (including paintwork)
rupted.
or hidden by any accessory fitted on the
5
The
warning light appears on
6
front of the vehicle (on the grille or logo
the instrument panel along with, de-
etc.).
pending on the malfunction, one of the
Conditions in certain geographical
following messages:
Switching off the function
areas may hinder the function, for ex-
- “Check Front camera
The adaptive cruise control function
ample:
is deactivated when you press the 6
- arid zones, tunnels, long bridges or
- “Front radar to check”;
switch.
lightly used roads without road lines,
- “Check Camera/Radar”;
without signs or trees nearby;
The warning light
disappears from
- “Check vehicle”.
the instrument panel to confirm that the
- a military or airport zone.
Consult an approved dealer.
function is no longer active.
You must leave such areas in order for
the function to work.
Temporary unavailability
In all cases, if the message is not
erased after the engine is restarted,
The radar is able to detect vehicles
please contact an authorised dealer.
in front of your vehicle. The system
cannot operate correctly if the radar de-
tection area is obscured or if its signal
is disrupted.
2.101
ADAPTIVE CRUISE CONTROL (9/13)
G
H
J
Limitations of system
The system cannot detect:
Detection during cornering
operation
- vehicles arriving at intersections: slip
When entering a corner or bend, the
roads (e.g. H) ;
radar and/or camera may temporarily
Vehicle detection
not be able to detect the vehicle in front
- vehicles driving on the wrong side of
The system detects only vehicles (cars,
(e.g. J).
the road or reversing towards you.
trucks, motorbikes) that are moving in
The system may trigger an accelera-
the same direction as your vehicle.
tion.
A vehicle turning into the same lane
When exiting a bend, the system’s de-
(e.g. G) will be taken into account by
tection of the vehicle in front may be
the system only once it enters the
disrupted or delayed.
camera and radar detection areas.
The system may trigger abrupt or
The system may trigger abrupt or
delayed braking.
delayed braking.
The adaptive cruise control must
only be used on a motorway (or
multi-lane road separated by a bar-
rier).
2.102
ADAPTIVE CRUISE CONTROL (10/13)
K
L
M
Detection of vehicles in adjacent
Vehicles hidden due to variations in
- vehicles transporting long objects
lanes
ground relief
which exceed the line;
The system may detect vehicles driving
The system will not detect vehicles
- the actual length of tall vehicles
on an adjacent lane when:
hidden due to variations in ground relief
(e.g. L) outside the radar detection
or those located outside of the camera
area (construction machine, agricul-
- you drive into a bend (e.g. K);
and radar detection areas when driving
tural equipment towing vehicle, etc.) ;
- you are driving on a road with narrow
uphill or downhill.
- vehicles insufficiently centred in the
lanes;
lane;
Vehicles outside the camera and
- the speed of the vehicle on the ad-
radar detection areas.
- narrow vehicles which are very close
jacent lane is slower and if one of
(e.g. M).
these vehicles is located too close to
The system will react late or not at all
the lane of the other.
if the detected vehicles are outside the
camera and radar detection areas, par-
The system may incorrectly trigger
ticularly in the following cases:
vehicle slowing or braking.
2.103
ADAPTIVE CRUISE CONTROL (11/13)
12
P
13
N
Q
Stationary and slow moving
- vehicles in front12 which change
Non-detection of fixed obstacles
vehicles
lane, revealing a stationary vehi-
and objects of a small size
cle 13 (e.g. P).
When your speed is over approximately
The system cannot detect:
31 mph (50 km/h), the system does
- pedestrians, bikes, scooters, etc. ;
not detect:
- animals;
- stationary vehicles (e.g N);
- fixed obstacles (toll barriers, walls,
- very slow moving vehicles.
etc.) (e.g. Q).
When your speed is less than approxi-
These are not taken into account by the
mately 31 mph (50 km/h), the system
Always be ready to take control
system. They do not trigger any alert or
may not react or may react very late
of your vehicle when you come
reaction by the system.
to:
upon stationary or very slow
- stationary vehicles (e.g N);
moving vehicles (e.g. N).
– very slow moving vehicles;
The adaptive cruise control does
not trigger an emergency stop and
its braking capability is limited.
2.104
ADAPTIVE CRUISE CONTROL (12/13)
This function is an additional driving aid. It can under no circumstances replace the driver’s responsibility to respect
speed limits and safe distances and to be vigilant.
The driver must always be in control of the vehicle.
The driver must always adapt their speed to the surroundings and driving conditions, regardless of system indications.
Except for lines delimiting lanes, traffic indicators (traffic lights, signs, pedestrian crossings etc.) are not recognised by the
system. These do not trigger any alert or reaction by the system.
The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.
The adaptive cruise control must only be used on a motorway (or multi-lane road separated by a barrier).
System servicing/repairs
- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-
fected. Deactivate the system and consult an authorised dealer.
- Any work in the proximity of the radar and/or camera (replacements, repairs, windscreen modifications, paintwork etc.) must
be carried out by a qualified professional.
Only an authorised dealer is qualified to service the system.
Deactivating the function
You must disable the function if:
- the vehicle is travelling on a windy road;
- the vehicle is being towed (breakdowns);
- the vehicle is towing a trailer or a caravan;
- the vehicle is being driven in a tunnel or close to a metallic structure;
- the vehicle arrives at a toll point, a roadwork area or on a narrow lane;
- the vehicle is being driven up or down a very steep slope;
- the visibility is poor (glaring sun, fog etc.);
- the vehicle is being driven on a slippery road surface (rain, snow, gravel, etc.);
- the weather conditions are poor (rain, snow, side winds, etc.);
- the radar area has been damaged (impacts etc.) ;
- the camera area has been damaged (e.g. on the inside or outside of the windscreen);
- the windscreen is cracked or distorted.
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
2.105
ADAPTIVE CRUISE CONTROL (13/13)
In the event of system disturbance
Some conditions can disturb or damage the operation of the system, such as:
- the windscreen or bumper is obscured in the area of the radar (by dirt, ice, snow, condensation, number plate etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, heavy rain, hail, black ice, etc.);
- poor visibility (night, fog etc.);
- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.);
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- narrow, winding or undulating road (tight bends etc.);
- a slower vehicle with a significant difference in speed;
- use of mats not adapted to the vehicle. On the driver’s side, only use mats suitable for the vehicle, attached with the pre-
fitted components, and check the fitting regularly. Do not lay one mat on top of another. There is a risk of wedging the
pedals.
In these cases, the system may wrongly intervene.
Risk of unwanted braking or acceleration.
Many unforeseen situations may affect the system operation. Certain objects or vehicles that can appear in the camera or
radar detection zone may be interpreted by the system incorrectly, possibly leading to inappropriate acceleration or braking.
You should always be attentive to sudden events that might occur while you are driving. Always keep your vehicle
under control by keeping your feet near the pedals, so that you are ready to act in any event.
2.106
PARKING DISTANCE CONTROL (1/6)
Operating principle
Ultrasonic sensors in the rear bumper
measure the distance between the ve-
hicle and an obstacle.
1
This measurement is indicated by
beeps which become more frequent the
closer you come to the obstacle, until
they become a continuous beep when
the vehicle is approximately
20 to
This function is an addi-
30 centimetres from the obstacle.
tional aid that indicates the
The system detects obstacles to the
distance between the vehi-
front, the rear and the sides of the ve-
cle and an obstacle whilst
hicle.
reversing, using sound signals.
The parking distance control system
Under no circumstances should it
is only activated when the vehicle is
replace the driver’s care or respon-
Location of the ultrasonic
driven at a speed below approximately
sibility whilst reversing.
sensors 1
6 mph (10 km/h).
The driver should always be ready
Ensure that the ultrasonic sensors indi-
The function does not take into account
for sudden incidents while driv-
cated by the arrows 1 are not obscured
towing or carrying systems that are not
ing: always ensure that there are
(by dirt, mud, snow, a badly fitted/at-
recognised by the system.
no small, narrow moving obstacles
tached number plate, etc.), impacted,
(such as a child, animal, pushchair,
modified (including paintwork) or ob-
bicycle, stone, post etc.) in the blind
structed by any accessory fitted to the
spot when manoeuvring.
rear and/or, depending on the vehicle,
to the front or sides of your vehicle.
2.107
PARKING DISTANCE CONTROL (2/6)
Note: in the event of a change in tra-
2
jectory during a manoeuvre, the risk of
C
collision with an obstacles may be sig-
nalled late.
A
B
Note: the display 2 shows the vehicle
Operation
surroundings and emits beeps.
Most objects located less near the
It is necessary to travel a few metres
front, rear and sides of the vehicle are
before the side detection is activated.
detected.
If all areas have a grey background, the
Depending on the distance of the ob-
An impact to the under-
whole area around the vehicle is being
stacle, the frequency of the beep will
side of the vehicle while
monitored:
increase when approaching it, and will
manoeuvring
(e.g.: strik-
become a solid beep at approximately
ing a post, raised kerb or
- A: analysis of the vehicle surround-
20 cm from obstacles to the sides and
other street furniture) may result in
ings in progress;
30 cm from obstacles to the front or
damage to the vehicle (e.g.: defor-
- B: analysis of the vehicle surround-
mation of an axle).
rear. Green, orange and red zones will
ings carried out.
be displayed on the display C.
To avoid any risk of accident, have
your vehicle checked by an ap-
proved Dealer.
2.108















Content      ..     9      10      11      12     ..
