SAFE DISTANCE ALERT (1/4)
The function is activated when the vehi-
cle speed is between about 19 and
1
124 mph (30 and 200 km/h).
Location of the camera 1
Make sure the windscreen is not ob-
scured (by dirt, mud, snow, condensa-
tion etc.).
Location of the radar 2
Ensure that the radar area is not ob-
structed (by dirt, mud, snow, a badly
fitted front number plate), impacted,
2
modified (including painting) or hidden
by any accessory fitted on the front of
the vehicle (on the grille or logo etc.).
Using the information from the radar 2
and camera 1, this function informs the
driver of the time interval between their
vehicle and the vehicle in front so that a
safe stopping distance between the two
vehicles can be maintained.
This function is an addi-
tional driving aid. This func-
tion is not under any cir-
cumstances intended to
replace the due care and attention
of the driver, who should at all times
be in control of the vehicle.
2.67
SAFE DISTANCE ALERT (2/4)
- press the 5 or 6 control repeatedly to
3
reach the “Distance warning” menu.
Press the switch 7 OK;
- press the switch 7 OK again to acti-
vate or deactivate the function:
=
function activated
<
function deactivated
4
5
7
6
Activating/deactivating the
Vehicles not fitted with a multimedia
screen
function
- With the vehicle stopped, press the
Vehicles fitted with a multimedia
switch 4 as many times as required
screen 3
to reach the “Vehicle” tab;
To activate or deactivate the function,
- press the 5 or 6 control repeatedly to
refer to the multimedia instructions.
reach the “Settings” menu. Press the
Select “ON” or “OFF”.
switch 7 OK;
- press the 5 or 6 control repeatedly to
reach the “DRIVING ASSIST” menu.
Press the switch 7 OK;
Each time the vehicle is started,
the function continues the mode
saved the last time the engine was
stopped.
2.68
SAFE DISTANCE ALERT (3/4)
- C (orange): the time interval falls be-
8
tween around 1 and 2 seconds (in-
A
sufficient distance between the two
vehicles);
- D (red): the time interval is less than
B
or equal to around one second (very
insufficient distance between the two
The measurement is dis-
vehicles).
played for information: the
If the interval between the two vehi-
system does not carry out
C
cles is less than approximately 0.5 sec-
any action on the vehicle.
onds, the 8 indicator and the D display
This function is not designed for use
will flash in red on the instrument panel
in urban conditions or for a dynamic
D
along with “-.- s”.
driving style (sudden cornering, ac-
Under certain conditions, the time inter-
celeration, braking, etc.), but rather
val may not be displayed:
for stable driving conditions.
Operation
- while cornering;
The function does not interact with
With the function activated, the 8 in-
the braking system.
- when changing lane;
dicator is displayed on the instrument
The radar and camera zones must
panel and informs the driver of the dis-
- if the vehicle in front is sufficiently far
be kept clean and free of any tam-
tance between their vehicle and the ve-
or outside the range of the radar or
pering in order to ensure the proper
hicle in front.
camera.
operation of the system.
- A (grey): function not operational;
Any work carried out in the area
- A (green): no vehicle detected;
where the radar or camera is lo-
cated (repairs, replacements, wind-
- B (green): the time interval is greater
screen and/or bumper modifica-
than or equal to around two seconds
tions, etc.) must be carried out by a
(distance between the two vehicles
qualified professional.
adapted to your speed);
2.69
SAFE DISTANCE ALERT (4/4)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-
fected. Deactivate the function and consult an authorised dealer.
- Any work carried out in the area where the radar and/or camera is located (replacements, repairs, windscreen and/or
bumper modifications, etc.) must be carried out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
- obstruction of the windscreen or the bumper (by dirt, glass, snow, condensation, etc.);
- a complex environment (metal bridge, tunnel etc.);
- poor weather conditions (snow, hail, black ice etc.);
- poor visibility (night, fog etc.);
- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding and undulating (tight bends etc.)
Risk of erroneous false alarms.
2.70
ACTIVE EMERGENCY BRAKING (1/8)
Depending on the reactivity of the
driver, the system can assist with brak-
1
ing in order to limit damage or prevent
a collision.
Location of the camera 1
Make sure the windscreen is not ob-
scured (by dirt, mud, snow, condensa-
tion etc.).
Location of the radar 2
Ensure that the radar area is not ob-
structed (by dirt, mud, snow, a badly
This system can apply maximum
fitted front number plate), impacted,
braking to the vehicle until it is
2
modified (including painting) or hidden
completely stationary if necessary.
by any accessory fitted on the front of
For safety reasons, always wear
The system uses information from the
the vehicle (on the grille or logo etc.).
your seat belt when travelling in
radar 2 and the camera 1 to determine
your vehicle and make sure that it
the distance from your vehicle:
is loaded so that no items can be
- from the vehicle ahead in the same
thrown forward and hit the occu-
lane;
pants.
- surrounding pedestrians and cyclists.
The system informs the driver if there
is a risk of head-on collision to enable
appropriate emergency manoeuvres
This function is an addi-
(pressing the brake pedal and/or turn-
tional driving aid. This func-
ing the steering wheel).
tion is not under any circum-
stances intended to replace
the due care and attention of the
driver, who should at all times be
in control of the vehicle.
2.71
ACTIVE EMERGENCY BRAKING (2/8)
Operation
Special features of warnings
Depending on the speed, the warning
Detection of vehicles
and braking may be activated simulta-
When driving, in the event of a risk of
neously.
collision with the vehicle in front the
system will:
3
Special features of stationary
vehicles
- warn of the risk of collision: when
the vehicle speed is between 4 mph
Stationary vehicles are detected when
(7 km/h) and 106 mph (170 km/h),
your vehicle is being driven at a speed
the message “Brake” is displayed
between approximately 4 mph (7 km/h)
in red on the instrument panel 3 ac-
and 50 mph (80 km/h). The system is
companied by an audible warning.
not active and does not emit a warning
for stationary vehicles when you exceed
If the driver presses the brake pedal
approximately 50 mph (80 km/h).
and the system still detects a risk
of collision, the brake force is in-
creased;
If the vehicle stopped as a result of
active emergency braking, the driver
- braking may be triggered: when
must keep the vehicle stationary by ap-
the vehicle is moving slower than ap-
plying the brake pedal.
proximately 75 mph (120 km/h), if the
driver does not respond to the warn-
Note: if the driver uses the vehicle con-
ing and a collision becomes immi-
trols (steering wheel, pedals, etc.) the
nent.
system may delay certain operations or
not activate.
In the event of emergency manoeu-
vre, you can stop braking at any
moment by:
- tapping the accelerator pedal;
or
- turning the steering wheel as a
collision avoidance manoeuvre.
2.72
ACTIVE EMERGENCY BRAKING (3/8)
Detection of pedestrians and
Special features of warnings
cyclists
Depending on the speed, the warning
(depending on the vehicle)
and braking may be activated simulta-
When there is a risk of collision with a
neously.
cyclist or pedestrian while the vehicle is
moving, the system will:
3
- warn of the risk of collision: when
the vehicle speed is between 4 mph
(7 km/h) and 50 mph (80 km/h),
the message “Brake” is displayed
in red on the instrument panel 3 ac-
companied by an audible warning.
If the driver presses the brake pedal
and the system still detects a risk
of collision, the brake force is in-
creased;
If the vehicle stopped as a result of
active emergency braking, the driver
- trigger braking: if the driver does
must keep the vehicle stationary by ap-
not respond to the warning and the
plying the brake pedal.
collision becomes imminent.
Note: if the driver uses the vehicle con-
trols (steering wheel, pedals, etc.) the
system may delay certain operations or
not activate.
In the event of emergency manoeu-
vre, you can stop braking at any
moment by:
- tapping the accelerator pedal;
or
- turning the steering wheel as a
collision avoidance manoeuvre.
2.73
ACTIVE EMERGENCY BRAKING (4/8)
- press the 6 or 7 control repeatedly to
reach the “Active braking” menu and
4
press the 8 OK switch.
Press the switch 8 OK again to activate
or deactivate the function:
=
function activated
<
function deactivated
Upon deactivation of the system, the
5
6
warning light illuminates or, de-
pending on the vehicle, the
warning light illuminates on the instru-
8
7
ment panel.
Activating or deactivating the
For vehicles not fitted with a
multimedia screen
system
- With the vehicle stopped, press the
Vehicles fitted with a multimedia
switch 5 as many times as required
screen 4
to reach the “Vehicle” tab;
To activate or deactivate the function,
- press the 6 or 7 control repeatedly to
please refer to the multimedia instruc-
reach the “Settings” menu. Press the
tions.
switch 8 OK;
- press the 6 or 7 control repeatedly to
Select “ON” or “OFF”.
reach the “DRIVING ASSIST” menu.
Press the switch 8 OK;
This system is reactivated each time
the ignition is switched on.
2.74
ACTIVE EMERGENCY BRAKING (5/8)
Temporarily not available
Operating faults
If the system detects a temporary
and
or, depending on the
fault the
warning light illumi-
vehicle,
illuminated on the instru-
nates, or depending on the vehicle the
ment panel indicate that the system has
warning light illuminates on the
detected an operating fault. Consult an
instrument panel.
approved dealer.
The possible causes are:
- the system is temporarily blinded
(glare from the sun, dipped beam
headlights, bad weather conditions
etc.). The system will be operational
again when visibility conditions are
better;
- the system is temporarily interrupted
(e.g. the windscreen or the front or
rear bumper is obscured by dirt,
mud, snow, condensation, etc.). In
this case, park the vehicle and switch
off the engine. Clean the windscreen
and front bumper. When you next
start the engine, the warning light
and the message go out.
If this is not the case, this may arise from
another cause; contact an Approved
Dealer.
2.75
ACTIVE EMERGENCY BRAKING (6/8)
Active emergency braking
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle. The triggering of this function may be
delayed or prevented when the system detects clear signs of control of the vehicle by the driver (action on the steer-
ing wheel, pedals etc.).
The system cannot be activated:
- when the gearbox lever is in neutral or the clutch pedal has been depressed during approximately ten seconds;
- when the parking brake is activated;
- when the Electronic Stability Program (ESC) has started.
System servicing/repairs
- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-
fected. Deactivate the function and consult an authorised dealer.
- Any work in the area where the radar and/or camera is located (repairs, replacements, windscreen modifications, etc.) must
be carried out by a qualified professional.
Only an authorised dealer is qualified to service the system.
2.76
ACTIVE EMERGENCY BRAKING (7/8)
System disturbance
Some conditions can disturb or damage the operation of the system, such as:
- a complex environment (metal bridge, tunnel etc.);
- poor weather conditions (snow, hail, black ice etc.);
- poor visibility (night, fog etc.);
- poor contrast between an object (vehicle, pedestrian etc.) and the surrounding area (e.g. pedestrian dressed in white lo-
cated in a snowy area);
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- obstruction of the windscreen or the radar area (by dirt, ice, snow, condensation etc.);
- ...
In these conditions, the system may not react, may warn the driver or may brake inadvertently.
Limitation of the system operation
- Each time the vehicle is started, the system carries out a calibration according to the vehicle surroundings and may be inac-
tive for a length of time between approximately two and five minutes;
- a vehicle moving in the opposite direction will not trigger any alert or affect operation of the system;
- the radar and camera zones must be kept clean and free of any modifications in order to ensure the proper operation of the
system;
- the system may not respond to small vehicles such as motorbikes as effectively as to other vehicles;
- the system may not operate properly when the road surface is slippery (rain, snow, black ice, etc.);
- to ensure correct operation, the system needs to distinguish the complete outline of the pedestrian. So the system cannot
detect:
- pedestrians in the darkness or in poor lighting conditions;
- partially visible pedestrians:
- pedestrians less than approximately 80 cm tall;
- pedestrians carrying large objects;
- ...
In these conditions, the system may not react, may warn the driver or may brake inadvertently.
2.77
ACTIVE EMERGENCY BRAKING (8/8)
Deactivating the function
You must disable the function if:
- the brake lights are not functioning;
- the area of the camera has been damaged (e.g. on the inside or outside of the windscreen);
- the front of the vehicle was damaged (impact, scratch on the radar, etc.);
- the vehicle is being towed (breakdowns);
- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an approved
dealer);
- you are not driving on a paved road.
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
Halting the function
You can halt the active emergency braking function at any time by tapping the accelerator pedal or by turning the steering
wheel in an avoidance manoeuvre.
2.78
FATIGUE DETECTION WARNING (1/2)
The fatigue detection warning is a func-
tion which is useful on monotonous
roads (motorways, high-speed roads
1
etc.).
It analyses driver behaviour and takes
account of events to inform you of any
risk of fatigue such as:
- steering wheel movement;
- driver actions on other devices (indi-
cators, windscreen washer etc.);
- time spent driving without stopping;
- ...
Activation/deactivation
Vehicles fitted with a multimedia
screen 1
To activate or deactivate the function,
refer to the multimedia instructions.
This function is an addi-
Select ON or OFF.
tional driving aid in case of
risk of fatigue. This function
does not take the place of
the driver.
Under no circumstances should this
function replace the driver’s care or
responsibility whilst driving.
When the engine is started, the
system remembers its position
when the ignition was last switched
off.
2.79
FATIGUE DETECTION WARNING (2/2)
- repeatedly press the control 3 up or
Note:
down until you reach the “Fatigue
- if the warning is not deleted by press-
detection warning” menu, then press
ing switch 2 OK, the beep repeats;
the switch 2 OK.
- the function may interpret certain
- press the 2 OK switch again to acti-
2
driving styles as a sign of tiredness
3
vate or deactivate the function.
(sporty driving, incorrect driving etc.)
or driving along a road which is in
Operation
poor condition.
The function is set to notify the
driver if:
Operating faults
- the vehicle speed is greater than ap-
If the system detects a fault, the mes-
proximately 37.2 mph (60 km/h);
sage “Check fatigue warning” is dis-
and
played on the instrument panel. Call an
- Approximately
15 minutes have
approved Dealer.
passed since the deletion of the pre-
Vehicles not fitted with a multimedia
vious warning.
screen
The function triggers an alert if the
- With the vehicle at a standstill, press
system detects repeated signs of fa-
and hold the switch 2 OK to access
tigue in the driver at the steering wheel.
the settings menu;
When a risk of fatigue is detected,
- repeatedly press the control 3 up or
the message “Fatigue warning have a
down until you reach the “Driving as-
break” is displayed on the instrument
sistance” menu. Press the switch 2
panel accompanied by a beep.
OK;
Press switch 2 OK to delete the warn-
ing.
It is advisable to stop as soon as pos-
sible for a break.
2.80
DETECTION OF ROAD SIGNS (1/4)
Note: make sure the windscreen is not
For vehicles equipped with a navigation
obscured (dirt, mud, snow, condensa-
system and if the vehicle is travelling in
1
tion etc.).
a country where the speed units differ
from those of the vehicle, the system
For vehicles which are equipped with it,
displays the speed limit sign in the unit
the system also uses information from
of the country, alongside the speed limit
the navigation system.
converted to the unit used by the vehi-
Once the speed limiter is activated, you
cle’s instrument panel.
can adjust the speed limiter indication
For countries where the speed limit is
displayed by the system.
reduced during rainy weather on some
If the limit speed is exceeded, the dis-
types of roads, on vehicles equipped
play panel is modified to warn the driver.
with a navigation system, the system
can modify the limited speed after a few
seconds of wiping the windscreen.
Special situations
The system detects speed limit signs
The system does not take into account
on the side of the road and displays the
exceptional speed limit measures, such
speed limit on the instrument panel.
as peak pollution days.
It mainly uses information taken from
the camera 1, attached to the wind-
screen behind the rear view mirror.
2.81
DETECTION OF ROAD SIGNS (2/4)
- press the 4 or 5 control repeatedly
to reach the “Settings” menu and
2
press 6 OK;
- press the 4 or 5 control repeatedly to
reach the “DRIVING ASSIST” menu
and press 6 OK;
- press the 4 or 5 control repeatedly
to reach the “Speed alert” menu and
press 6 OK;
- press the 6 OK switch to activate or
3
4
deactivate the function:
=
function activated
6
5
<
function deactivated
Activating/deactivating the
With the function activated, depend-
ing on local regulations, you can acti-
system
vate the “Risk area display” option. The
Vehicles fitted with a multimedia
system will notify you of the distance
screen 2
separating you from this zone, and
while you are travelling in the zone.
To activate or deactivate the function,
refer to the multimedia instructions.
Vehicles not fitted with a multimedia
Select “ON” or “OFF”.
screen
- With the vehicle stopped, press the
switch 3 as many times as required
to reach the “Vehicle” tab;
2.82
DETECTION OF ROAD SIGNS (3/4)
If the speed limit is exceeded, the circle
7
8
around the road sign symbol 7 flashes
along with a sound signal to warn the
driver (depending on the vehicle).
9
10
Operation
Varying the limit speed
If the speed limit notification differs from
Warning lights
the detected speed value, press and
The function displays the following
hold the following switches:
warning lights:
- 9 (RES/+) to increase the notification
- 7
Speed limit road signs.
speed to the detected speed;
8
Additional road signs (start or end
- 10 (SET/-) to reduce the notification
of “No overtaking” zone, slip road
speed to the detected speed.
speed limit, speed in case of a cara-
van, speed limit with length of appli-
cation, etc.).
2.83
DETECTION OF ROAD SIGNS (4/4)
Operating faults
The system cannot detect the speed
limit if:
- the windscreen is not clean;
- the camera is blinded by the sun;
- there is insufficient visibility (night,
fog etc.);
- the signs are not legible (snow, etc.)
or are hidden (by another vehicle or
by trees);
- the information taken from the navi-
gation system is not up to date.
This function is an additional driving aid. This function is not under any
circumstances intended to replace the due care and attention of the
driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, re-
gardless of the system indications.
The system detects speed limit signs and does not detect other signs (e.g. entry/
exit to/from urban areas, etc.).
The system may not detect all speed limit signs or may interpret them incorrectly.
The driver should not ignore signs that are not detected by the system and should,
as a priority, comply with the traffic signage and the highway code.
In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system
may not indicate the correct speed to the driver.
The driver should always adapt their speed to the traffic conditions, regardless of
the system indications.
2.84
SPEED LIMITER (1/4)
6
5
1
4
3
2
The speed limiter function helps you
Controls
stay within the driving speed limit that
1 Speed limiter On/Off switch.
you choose, known as the limit speed.
2 Cruise control On/Off switch.
Depending on the vehicle, the speed
limiter is linked with the “Hill Descent
3 Switch to activate and decrease the
Control” function which uses the brak-
limit speed (SET/-).
ing system to optimise downhill speed
4 Switch to activate and increase the
limitation.
limit speed or to set the stored limit
The presence of the
“Hill Descent
speed (RES/+).
Control” function can be identified by
5 Speed limiter function standby (with
the presence of the 6 button.
limited speed memory) (0).
You can link the speed limiter to
the “Road sign detection” function.
➥ 2.81.
2.85
SPEED LIMITER (2/4)
7
7
1
4
3
Driving
Switching on
To store the current speed, press the 4
switch (RES/+) or the 3 switch (SET/- ):
When a limit speed has been set but
Press switch 1. The 7 warning light ap-
the limit speed replaces the dashes
not yet reached, driving is similar to
pears in grey. The “Speed limiter ON”
and, depending on the vehicle, the 7
driving a vehicle without the speed lim-
message appears on the instrument
warning light appears in white.
iter function.
panel accompanied by dashes to indi-
The minimum stored speed is 20 mph
cate that the speed limiter function is in
Once you have reached the stored
(30 km/h).
operation, waiting to store a limit speed.
speed, no effort on the accelera-
tor pedal will allow you to exceed
the programmed speed except in an
emergency (refer to information on
“Exceeding the limit speed”).
2.86
SPEED LIMITER (3/4)
Exceeding the limit speed
Limited speed cannot be maintained
It is possible to exceed the limit speed
When driving down a steep gradient,
at any time. To do this: press the accel-
the system may not maintain the limit
erator pedal firmly and fully (beyond
speed: the limit speed flashes in red
the resistance point).
on the instrument panel and an audi-
While the speed is being exceeded, the
ble signal sounds at regular intervals to
speed limiter flashes red on the instru-
inform you of this situation.
ment panel. Then, release the accelera-
tor pedal: the speed limiter function will
return as soon as you reach a speed
4
lower than the memorised speed.
3
Varying the limit speed
The limit speed may be changed by
Cruise control/speed
pressing repeatedly or holding down:
limiter with Hill Descent
- switch 4 (RES/+) to increase speed;
Control:
the function may act on the
- switch 3 (SET/-) to reduce speed.
braking system.
Cruise control/speed limiter with-
out Hill Descent Control:
The function never interacts with the
braking system.
Please note that you must always
keep your feet close to the pedals
If the speed limiter is not
in order to react in an emergency.
available (after several at-
tempts to activate), contact
an approved dealer.
2.87















Content      ..     8      9      10      11     ..
