Renault Megane (2022 year). Manual in english - page 9





DRIVER CORRECTION DEVICES AND AIDS (4/6)
Emergency brake assist
Braking anticipation
This system supplements the ABS
Depending on the vehicle, when you
and helps reduce vehicle stopping dis-
rapidly release the accelerator, the
tances.
system anticipates the braking ma-
noeuvre in order to reduce stopping
Operating principle
distances.
The system is for detecting an emer-
Special cases
gency braking situation. In this case,
When using the cruise control:
the braking assistance immediately de-
velops maximum power and may trig-
- if you use the accelerator, when you
ger ABS regulation.
release it, the system may be trig-
gered;
ABS braking is maintained as long as
the brake pedal is applied.
- if you do not use the accelerator, the
These functions are an ad-
system will not be triggered.
ditional aid in the event of
Hazard warning lights switching on
Operating faults
critical driving conditions,
Depending on the vehicle, these may
enabling the vehicle behav-
light up in the event of sudden decel-
When the system detects an operating
iour to be adapted to suit the driving
eration.
fault the message “WARNING: Check
conditions.
Braking System” appears on the instru-
These functions do not take the
place of the driver. They do not
ing light.
increase the vehicle’s limits and
Consult an approved dealer.
should not encourage you to
drive more quickly. Therefore,
they can under no circumstances
replace the vigilance or responsibil-
ity of the driver when manoeuvring
the vehicle (the driver must always
be ready for sudden incidents which
may occur when driving).
2.46
DRIVER CORRECTION DEVICES AND AIDS (5/6)
Hill start assistance
The hill start assistance
Depending on the gradient of the in-
system cannot completely
cline, this system assists the driver
prevent the vehicle from
when starting on a hill. It prevents the
rolling backwards in all sit-
vehicle from rolling backwards by au-
uations (extremely steep gradients,
tomatically applying the brakes when
etc.).
the driver lifts his/her foot off the brake
In all cases, the driver may depress
pedal to depress the accelerator pedal.
the brake pedal to prevent the vehi-
cle from rolling backwards.
System operation
The hill start assistance function
It only operates when the gear lever is
should not be used for prolonged
in a position other than neutral (other
stops: use the brake pedal.
than N or P for automatic transmis-
sions) and the vehicle is completely
This function is not designed to im-
stationary (brake pedal depressed)
mobilise the vehicle permanently.
The system holds the vehicle for ap-
If necessary, use the brake pedal to
proximately 2 seconds. The brakes are
stop the vehicle.
then released (the vehicle will move ac-
The driver must remain particularly
cording to the slope).
vigilant when driving on slippery or
low-grip surfaces.
Risk of serious injury.
2.47
DRIVER CORRECTION DEVICES AND AIDS (6/6)
Operating faults
A
B
- If the
warning light, together
with the message “Check power
steering”, is displayed on the instru-
ment panel: please contact an au-
thorised dealer.
- If the warning light
®
, together
with the message
“WARNING:
Power Steering”, is displayed on the
instrument panel, this indicates a
fault in the system.
®
requires you to stop
Rear wheel steering
When driving at higher speeds, the rear
as soon as traffic conditions
wheels steer in the same direction as
allow. Contact an approved
On equipped vehicles, this system,
the front wheels (figure B) to optimise
Dealer.
when the vehicle is being driven, steers
the vehicle’s stability. This is useful
the rear wheels according to driving
An impact to the underside of the
when changing lanes or when corner-
conditions: at low speed this system
vehicle (e.g.: striking a post, raised
ing etc.
offers manoeuvrability, at higher speeds
kerb or other street furniture) may
it optimises stability.
Note: the system configuration (re-
result in damage to the vehicle (e.g.:
sponsiveness etc.) depends on the
When driving at low speeds, the rear
deformation of an axle).
mode selected in the “MULTI-SENSE"
wheels steer in the opposite direction to
To avoid any risk of accident, have
menu ➥ 3.2.
the front wheels (figure A) to increase
your vehicle checked by an ap-
the vehicle’s manoeuvrability. This is
proved Dealer.
used when driving in towns, on winding
roads, during parking manoeuvres, etc.
2.48
LANE DEPARTURE WARNING (1/5)
1
Using information from the 1 camera,
the function warns the driver when a
continuous or broken line is crossed
or when approaching the roadside (di-
vider, barrier, pavement, embankment,
etc.) without the direction indicator
lights being activated.
This function is an addi-
Note: make sure the windscreen is not
tional driving aid. This func-
obscured (dirt, mud, snow, condensa-
tion is not under any cir-
tion etc.).
cumstances intended to
replace the due care and attention
of the driver, who should at all times
be in control of the vehicle.
The lane departure warning func-
tion does not correct the vehi-
cle’s trajectory.
2.49
LANE DEPARTURE WARNING (2/5)
To disable the function, press the 2
switch as many times as required to
select
“Lane departure warning off”
(or, depending on the vehicle “Lane
Keeping deactivated”) on the instru-
ment panel. Warning light
goes
2
out on the instrument panel.
3
Operation
When the function is activated, the
warning light and the left and
right lines 3 are displayed in grey on the
instrument panel.
The function is set to notify the
Activation/deactivation
The function alerts the driver:
driver if:
- by a vibration in the steering wheel;
To activate the function, press the 2
- speed is between approximately
and
switch as many times as required to
43 mph (70 km/h) and 112 mph
select “Lane Departure Warning” on
(180 km/h);
- the
warning light and 3 the in-
the instrument panel. The “Lane depar-
and
dicator for the crossed line turn red.
ture warning on” message and “
- the
warning light and left/right
warning light are displayed on the in-
line indicators 3 are coloured white.
strument panel.
The warning function is triggered
if the vehicle breaches a line or ap-
proaches a roadside (divider, barrier,
pavement, embankment, etc.) without
the direction indicator lights being ac-
tivated.
Each time the vehicle is started,
the function continues the mode
saved the last time the engine was
stopped.
2.50
LANE DEPARTURE WARNING (3/5)
Temporarily not available
Conditions for non-activation
- Very fast lane departure;
of the system
4
- driving continuously on a line;
The system cannot be activated when:
- four seconds approximately after
- reverse gear is engaged;
changing lanes;
- the field of vision of the camera is ob-
- tight bends;
structed;
- impaired visibility;
- the® warning light is displayed.
- activation of one of the direction indi-
The
warning light and the left/
cator lights;
right line indicators turn to grey on the
- strong acceleration;
instrument panel.
– ...
When the function is not available, the
Settings
- “Alert”: adjust the line detection sen-
warning light and the left/right in-
Vehicles fitted with a multimedia
sitivity level. To do this, select:
dicators turn to grey on the instrument
screen.
panel.
- “Late”: line detected when cross-
To access the multimedia screen func-
ing;
tion settings 4, refer to the multimedia
instructions:
- “Standard”: line detected on ap-
proach;
- “Vibration”: adjust the steering wheel
vibration level;
- “Early”: line detected nearby.
2.51
LANE DEPARTURE WARNING (4/5)
- press the 6 or 7 control repeatedly to
Operating faults
reach the “DRIVING ASSIST” menu.
In the event of a malfunction, the left
Press the switch 8 OK;
and right line indicators (and, depend-
- press the 6 or 7 control repeatedly to
reach the “Lane Departure Vibration”
ing on display style, the
warning
or
“Lane Departure Sensitivity”
light) disappear or stay grey on the in-
menu. Press the switch 8 OK;
strument panel.
- press the 6 or 7 control repeatedly to
In some cases, they are accompa-
adjust the setting. Press 8 OK.
nied by the message “Front camera to
6
5
check” or the
warning light on
the instrument panel.
Consult an approved dealer.
8
7
Adjustments (continued)
Vehicles not fitted with a multimedia
screen
- With the vehicle stopped, press the
switch 5 as many times as required
to reach the “Vehicle” tab;
- press the 6 or 7 control repeatedly to
reach the “Settings” menu. Press the
switch 8 OK;
2.52
LANE DEPARTURE WARNING (5/5)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate
the function, then consult an authorised dealer.
- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried
out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
Some conditions can disrupt or damage the operation of the system, for example:
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, hail, black ice etc.);
- poor visibility (night, fog etc.);
- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding or undulating (tight bends etc.);
- closely following a vehicle travelling in the same lane.
Risk of false alarms or absence of warnings
2.53
LANE KEEPING ASSIST (1/6)
Note: make sure the windscreen is not
obscured (dirt, mud, snow, condensa-
1
tion etc.).
Using information from the 1 camera,
the function triggers corrective action
on the vehicle steering system when
a continuous or broken line is crossed
or when approaching the roadside (di-
vider, barrier, pavement, embankment,
etc.) without the direction indicator
lights being activated.
This function is an addi-
tional driving aid. This func-
tion is not under any circum-
stances intended to replace
the due care and attention of the
driver, who should at all times be
in control of the vehicle.
You can retake control of the ve-
hicle at any time by operating the
steering wheel.
2.54
LANE KEEPING ASSIST (2/6)
To disable the function, press the 2
switch as many times as required to
select “Lane Keeping deactivated” on
the instrument panel.
Warning light
goes out on the in-
strument panel.
Note: deactivating the “Lane Keeping
2
Assist” function causes deactivation of
the “Lane Departure Warning” function.
Activation/deactivation
To activate the function, press the 2
switch as many times as required to
select “Lane Keeping Assist” on the in-
strument panel.
The “Lane Keeping activated” message
and “
” warning light are displayed
on the instrument panel.
When Lane Keeping Assist is activated,
the “Lane Departure Warning” function
is automatically activated. ➥ 2.49.
Each time the vehicle is started,
the function continues the mode
saved the last time the engine was
stopped.
2.55
LANE KEEPING ASSIST (3/6)
In these cases:
Special cases
- the function triggers an action on the
When using the function:
vehicle’s steering system to correct
-
If the system can no longer detect
the vehicle trajectory;
any action by the driver on the steer-
- the warning light
and the indi-
ing wheel, the
warning light
cator 3 on the side of the breached
appears in yellow on the instrument
line turns to yellow on the instrument
panel, accompanied by the message
3
panel.
“Keep hands on steering wheel” and
an audible warning.
Note: on bends, the function allows for
slightly cutting the bend.
The audible warning is emitted along
with the warning light and message
If the corrective action on the steer-
until the driver takes control;
ing system is not sufficient, the
-
if the system is active for too long,
warning light and 3 indicator on the side
an audible warning is emitted along
Operation
of the breached line turn to red on the
with flashing of the side indicators 3
When the function is activated, the
instrument panel, accompanied by a vi-
on the side of the vehicle concerned
bration on the steering wheel.
until the driver takes control.
warning light and the left and
right lines 3 are displayed in grey on the
instrument panel.
The function is set to operate when
the vehicle speed is between approxi-
mately 43 mph (70 km/h) and 112 mph
(180 km/h) and if the
warning
light and 3 correction indicators are col-
oured white.
The function operates if the vehicle
breaches a line or if the vehicle ap-
proaches the roadside (divider, barrier,
You can interrupt the trajectory cor-
pavement, embankment, etc.) without
rection at any time by moving the
the direction indicator lights being ac-
steering wheel.
tivated.
2.56
LANE KEEPING ASSIST (4/6)
Temporarily not available
Conditions for non-activation
of the system
4
- Very fast lane departure;
- driving continuously on a line;
The system cannot be activated when:
– four seconds approximately after
- reverse gear is engaged;
changing lanes;
- the field of vision of the camera is ob-
– tight bends;
structed;
– impaired visibility;
- the® warning light is displayed.
– activation of one of the direction indi-
cator lights;
The
warning light and the left/
– strong acceleration;
right line warning lights are displayed in
– emergency braking;
grey on the instrument panel.
– ...
Adjustment
If the function is unavailable, the
warning light and the left/right correc-
Vehicles fitted with a multimedia
tion warning lights 3 appear in grey on
screen.
-
“Alert”: adjust the line detection sen-
the instrument panel.
sitivity level. To do this, select:
To access the function settings from the
multimedia screen 4 please refer to the
- “Late”: line detected when cross-
multimedia instructions:
ing;
- “Vibration”: adjust the steering wheel
- “Standard”: line detected on ap-
vibration level;
proach;
- “Early”: line detected nearby.
Please refer to the multimedia instruc-
tions for further information.
2.57
LANE KEEPING ASSIST (5/6)
- press the 6 or 7 control repeatedly to
Operating faults
reach the “DRIVING ASSIST” menu.
When the system detects an operating
Press the switch 8 OK;
fault, the
warning light appears
– press the 6 or 7 control repeatedly
on the instrument panel along with the
to reach the “Lane Keeping sensitiv-
message “Front camera to check”.
ity=#” menu. Press the switch 8 OK;
Consult an approved dealer.
- press the 6 or 7 control repeatedly to
adjust the setting. Press 8 OK.
6
5
8
7
Adjustments (continued)
Vehicles not fitted with a multimedia
screen
- With the vehicle stopped, press the
switch 5 as many times as required
to reach the “Vehicle” tab;
- press the 6 or 7 control repeatedly to
reach the “Settings” menu. Press the
switch 8 OK;
2.58
LANE KEEPING ASSIST (6/6)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate
the function and consult an authorised dealer.
- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried
out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
Some conditions can disrupt or damage the operation of the system, for example:
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, rain, hail, black ice etc.);
- poor visibility (night, fog etc.);
- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface);
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding or undulating (tight bends etc.);
- closely following a vehicle travelling in the same lane.
In this case, the “Lane Keeping Assist” may react incorrectly or not at all.
Risk of unwanted, incorrect correction or no correction of trajectory.
Deactivating the function
You must disable the function if:
- the area of the camera has been damaged (on the windscreen side or the interior rear-view mirror side);
- the road is slippery (snow, black ice, aquaplaning, gravel etc.) ;
- poor visibility (night, fog etc.);
- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an Authorised
Dealer);
- the vehicle is towing a trailer or a caravan;
- the vehicle is entering an area with several surface markings (an area with road works etc.).
2.59
BLIND SPOT WARNING (1/7)
C
B
A
A
B
Using information from the sensors in-
Special feature
stalled on each side of the rear bumper
Make sure that the radar area C is not
(area C), the function warns the driver:
obscured (by stickers, mud, snow etc.).
- when another vehicle appears in the
If a radar is obscured, the message
detection area A;
“Side radars no visibility” will appear on
and/or
the instrument panel. Clean the area
where the sensors are located.
- when there is a risk of collision with
a vehicle that is in area B, driving
faster than you.
This function is an addi-
tional driving aid. This func-
The function warns you when the ve-
tion is not under any cir-
hicle is travelling at a speed above ap-
cumstances intended to
proximately 9 mph (15 km/h).
replace the due care and attention
of the driver, who should at all times
be in control of the vehicle.
2.60
BLIND SPOT WARNING (2/7)
- press the switch 5 OK again to acti-
vate or deactivate the function:
1
=
function activated
<
function deactivated
2
3
5
4
Activation/deactivation
- press the 3 or 4 control repeatedly to
reach the “Settings” menu. Press the
Vehicles fitted with a multimedia
switch 5 OK;
screen 1
- press the 3 or 4 control repeatedly to
To activate or deactivate the function,
reach the “DRIVING ASSIST” menu.
refer to the multimedia instructions.
Press the switch 5 OK;
Select “ON” or “OFF”.
- press the 3 or 4 control repeatedly to
reach the “Blind spot alert” menu and
Vehicles not fitted with a multimedia
press 5 OK;
screen
- With the vehicle stopped, press the
switch 2 as many times as required
The system’s detection range oper-
to reach the “Vehicle” tab;
ates according to a standard lane
width. When driving in a narrow
lane, the function may warn you
when a vehicle is detected further
away than the nearest lane.
2.61
BLIND SPOT WARNING (3/7)
6
A
B
7
A
B
Indicator 6
Operation
An indicator light 6 is located on each
The function warns you when the speed
rear view mirror 7.
of your vehicle exceeds approximately
9 mph (15 km/h):
Note: clean the rear view mirrors 7 reg-
- when another vehicle is in the blind
ularly so that the indicators 6 can be
spot area A and travelling in the
seen.
same direction as your vehicle;
- when a vehicle approaches quickly
from the rear in an adjacent lane
within the range of detection area B.
If you overtake another vehicle, the in-
dicator 6 will only come on if that vehi-
cle remains for a long enough period in
your vehicle’s blind spot A.
The function does not notify the
driver if the other vehicles are not
moving.
2.62
BLIND SPOT WARNING (4/7)
Display E
Conditions for non-function
6
Direction indicator activated, the 6
- When driving on a road with tight
warning light flashes when the func-
bends;
tion detects a vehicle in the blind spot
- in reverse.
D
warning area and/or a vehicle is rapidly
approaching from the rear on the side
If the vehicle is equipped with a towbar
towards which you will turn the wheel.
recognised by the system, the “Trailer:
If you cancel the direction indicator, the
blind spot alert off” message displayed
function will return to the initial warning
on the instrument panel informs you
(display D).
that the function is not operational. For
E
information on the range of equipment
adapted to your vehicle, we advise you
to consult an approved Dealer.
Display D
First warning: direction indicator not
activated, the 6 warning light indicates
that a vehicle is detected in the blind
spot area and/or that a vehicle is rap-
idly approaching from the rear in an ad-
jacent lane.
When the engine is started, the
system adopts the last status saved
before the ignition was switched off
(refer to the previous pages).
2.63
BLIND SPOT WARNING (5/7)
Operating faults
If the system detects a fault, the mes-
sage “Side radars to check” is displayed
on the instrument panel. Consult an ap-
proved dealer.
- The system’s detection
range operates according
to a standard lane width. If
you are driving in wide traf-
fic lanes, the system might not
be able to detect a vehicle in the
blind spot.
- The system might be disrupted
momentarily if it is exposed to
strong electromagnetic waves
(as beneath high-tension power
lines) or to very poor weather
conditions
(heavy rain, snow
etc.). Remain aware of driving
Due to the presence of sensors
conditions.
behind the bumper, it is advisable to
entrust any operation on the bumper
There is a risk of accidents.
(repair, replacement, paintwork,
etc.) to a qualified professional.
2.64
BLIND SPOT WARNING (6/7)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.
System servicing/repairs
- In the event of an impact, radar alignment may be changed, and its operation will consequently be affected. Deactivate the
function and consult an authorised dealer.
- Any work in the area where the radars are located (repairs, replacements, etc.) must be carried out by a qualified profes-
sional.
Only an authorised dealer is qualified to service the system.
System disturbance
Some conditions can disturb or damage the operation of the system, such as:
- complex surroundings (metal bridges, tunnels, roads with barriers at the edge, etc.);
- poor weather conditions (snow, hail, black ice, etc.).
Risk of false alarms or absence of warnings
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
2.65
BLIND SPOT WARNING (7/7)
Limitation of the system operation
- The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the
system.
- Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system.
- When turning into a bend, the radars may temporarily cease to detect vehicles in adjacent lanes.
- The function may warn you late when two other vehicles are approaching from the rear, side by side in the adjacent lanes
(driving on a 3-lane road) and at a much higher speed than your vehicle.
- The system may not provide a warning when the other vehicles are travelling at a significantly different speed.
- If the vehicle is being overtaken by a long vehicle (e.g. heavy goods vehicle overtaking at a similar speed to the vehicle) the
system may interrupt the warning before the end of the manoeuvre.
- The vehicle is travelling on a winding road.
Deactivating the function
You must disable the function if:
- the radar area has been damaged (rear bumper);
- the vehicle is fitted with a towbar that is not recognised by the system.
2.66















Content      ..     7      8      9      10     ..
