Renault Clio (2022 year). Manual in english - page 17





REMOTE CONTROL KEY: BATTERY: battery (2/2)
Operating faults
If the battery is too weak to ensure cor-
rect operation, you will still be able to
start and lock/unlock the vehicle
➥ 1.14.
Do not throw away your used bat-
Precautions relating to
teries; give them to an organisation
batteries:
responsible for collecting and recy-
- keep (new or used) bat-
cling batteries.
teries out of reach of chil-
dren;
- do not swallow batteries;
When replacing:
Risk of chemical burns which
- make sure that the batter-
may lead to death.
ies are correctly inserted.
- if ingested or inserted into any
part of the body, consult a doctor
Risk of explosion.
as soon as possible.
- if the flap does not close cor-
rectly, do not use and keep out of
reach of children.
5.21
CARD: battery (1/2)
1
A
The batteries are available from ap-
proved Dealers, and their service
life approximately two years. Check
that there is no dye on the battery:
risk of an incorrect electrical con-
tact.
2
When they need to be re-
Replacing the battery
When refitting, proceed in the reverse
placed, be sure to use
order, then press one of the buttons on
When the message “Keycard Battery
the same or equivalent
the card four times, close to the vehicle:
Low” appears on the instrument panel,
type of battery (consult an
the next time the vehicle is started, the
replace the battery in the card:
Approved Dealer).
message will disappear.
- slide the rear casing 1 downwards
while pressing on zone A;
Check that the cover is clipped shut.
- remove the battery cover 2;
Note: Do not touch the electronic circuit
- remove the battery by pressing on
or contacts on the card when replacing
one side and lifting the other;
the battery.
When replacing:
- replace it according to the direc-
tion and template shown inside the
- make sure that the batter-
cover.
ies are correctly inserted.
Risk of explosion.
- if the flap does not close cor-
rectly, do not use and keep out of
reach of children.
5.22
CARD: battery (2/2)
Operating faults
If the battery is too weak to ensure cor-
rect operation, you will still be able to
start and lock/unlock the vehicle
➥ 1.14.
Precautions relating to
batteries:
- keep (new or used) bat-
teries out of reach of chil-
dren;
- do not swallow batteries;
Risk of chemical burns which
may lead to death.
- if ingested or inserted into any
part of the body, consult a doctor
as soon as possible.
Do not throw away your used bat-
teries; give them to an organisation
responsible for collecting and recy-
cling batteries.
5.23
BATTERY: troubleshooting (1/3)
To avoid all risk of sparks:
Connecting a battery charger
-
Ensure that any power consumers
The battery charger must be com-
(courtesy lights, etc.) are switched
patible with a battery with nominal
off before disconnecting or recon-
voltage of 12 volts.
necting a battery;
Do not disconnect the battery when the
-
when charging, stop the charger
engine is running. Follow the instruc-
before connecting or disconnecting
tions given by the manufacturer of
the battery;
the battery charger you are using.
-
do not place metal objects on the
battery as this could create a short
Handle the battery with care
circuit between the terminals;
as it contains sulphuric acid,
-
always wait at least five minutes
which must not come into
after the engine has been switched
contact with eyes or skin. If
off before disconnecting a battery;
it does, wash the affected area with
-
make sure that you reconnect the
plenty of cold water. If necessary,
battery terminals after refitting.
consult a doctor.
Keep naked flames, red hot objects
and sparks away from the battery
components as there is a risk of
explosion.
Special procedures may be
Please note when working close to
required to charge some
the engine that it may be hot. In ad-
batteries. Contact your ap-
dition, the engine cooling fan may
proved dealer.
Avoid all risk of sparks which may
start at any moment. The
cause an immediate explosion, and
warning light in the engine compart-
charge the battery in a well venti-
ment reminds you of this.
lated area.
Risk of injury.
Before carrying out any
Risk of serious injury.
action in the engine com-
partment, you must switch
off the ignition.
➥ 2.4
➥ 2.6.
5.24
BATTERY: troubleshooting (2/3)
Starting the vehicle using the
battery from another vehicle
If you have to use the battery from an-
other vehicle to start, obtain suitable
jump leads (with a large cross section)
2
from an approved dealer or, if you al-
ready have jump leads, ensure that
they are in perfect condition.
A
The two batteries must have an iden-
tical nominal voltage of 12 volts. The
battery supplying the current should
have a capacity (amp-hours, Ah) which
is at least the same as that of the dis-
charged battery.
1
Ensure that there is no risk of contact
Battery in engine compartment
between the two vehicles (risk of short
circuiting when the positive terminals
The battery is not directly accessible.
are connected) and that the discharged
Use the terminal 1 ( + ) and the termi-
battery is properly connected. Switch
nal 2 ( - ) in the engine compartment.
off your vehicle ignition.
Raise the cover A of the terminal 1 (+).
Start the engine of the vehicle supply-
ing the current and run it at an interme-
diate engine speed.
With the engine running, the message
“Battery charging” appears on the in-
strument panel for approximately five
minutes.
5.25
BATTERY: troubleshooting (3/3)
2
1
B
A
4
3
Attach the positive cable A to the termi-
nal 1 ( + ) then to the terminal 4 ( + ) of
the battery supplying the current.
Connect the negative cable B to the
terminal 3 ( - ) of the battery supply-
ing the current and then to the termi-
nal 2 ( - ).
Start the engine, and as soon as it starts
Check that there is no con-
running, disconnect cables A and B in
tact between leads A and B
reverse order ( 2 - 3 - 4 - 1).
and that the positive lead A
is not touching any metal
parts on the vehicle supplying the
current.
Risk of injury and/or damage to
the vehicle.
5.26
FITTING A RADIO
1
-
In all cases, it is very important to
2
follow the manufacturer’s instruc-
tions carefully.
-
The specifications of the brack-
Radio location 1
Front door speakers 2
ets and wires (available from our
Unclip the blanking cover. The aerial, +
To install any equipment, please con-
network) vary depending on the
and - supply and speaker wire connec-
sult an authorised dealer.
equipment level of your vehicle
tions are located behind it.
and the type of radio.
Consult an approved Dealer to
find out the correct part number.
-
No work may be carried out on
the vehicle’s electrical or radio
circuits, except by approved
dealers: an incorrectly connected
system may result in damage
being caused to the electrical
equipment and/or the compo-
nents connected to it.
5.27
ACCESSORIES
Electrical and electronic accessories
Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po-
sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer.
Before connecting an accessory to a socket, please ensure that you do not exceed the maximum power authorised for
the socket. ➥ 3.32, ➥ 3.18. Fire hazard.
No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected
system may result in damage being caused to the electrical equipment and/or the components connected to it.
If the vehicle is fitted with any aftermarket electrical equipment, make sure that the installation is correctly protected by a fuse.
Establish the rating and position of this fuse.
Using the diagnostic socket
The use of electronic accessories on the diagnostic socket may cause serious disturbance to the vehicle’s electronic systems.
For your safety we recommend that you use only electronic accessories approved by the manufacturer, consult an Approved
Dealer. Serious accident risk.
Use of transmitting/receiving devices (telephones, CB equipment etc.).
Telephones and CB equipment with integrated aerials may cause interference to the electronic systems originally fitted to the
vehicle: it is advisable only to use equipment with an external aerial. Furthermore, we remind you of the need to conform
to the legislation in force concerning the use of such equipment.
Fitting aftermarket accessories
If you wish to install accessories on the vehicle: please contact an authorised dealer. Also, to ensure the correct operation of
your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for your
vehicle, which are the only accessories for which the manufacturer will provide a warranty.
If you are using an anti-theft device, only attach it to the brake pedal.
Obstructions to the driver
On the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regu-
larly. Do not lay one mat on top of another. There is a risk of wedging the pedals.
5.28
FUSES (1/4)
1
2
A
B
3
C
Fuse boxes
Passenger compartment fuses B
Fuses located in the passenger
compartment behind a flap in the C
If any electrical component does not
Unclip the access flap 2.
glovebox
work, check the condition of the fuses.
Open and tilt the 2 flap completely then
Unclip the access flap 3.
pull it downwards to move it in order to
Passenger compartment fuses A
access the fuses.
Unclip the access flap 1.
Check the fuse in question and replace it, if necessary, by a fuse of the
same rating.
To comply with current legislation, or
If a fuse is fitted with too high a rating, it may cause the electrical circuit
as a precaution, you can obtain an
to overheat (risk of fire) in the event of an item of equipment using an ex-
emergency kit from your approved
cessive amount of current.
dealer containing a set of spare
bulbs and fuses.
5.29
FUSES (2/4)
4
To comply with current legislation, or
Tweezers 4
as a precaution, you can obtain an
emergency kit from your approved
Remove the fuse using the tweezers 4
dealer containing a set of spare
on the back of the flap.
bulbs and fuses.
To remove the fuse from the tweezers,
slide the fuse to the side.
It is not advisable to use the free fuse
Check the fuse in question
locations.
and replace it, if neces-
sary, by a fuse of the same
rating.
If a fuse is fitted with too high a
rating, it may cause the electrical
circuit to overheat (risk of fire) in the
event of an item of equipment using
an excessive amount of current.
5.30
FUSES (3/4)
Allocation of fuses
(the presence of certain fuse depends on the vehicle equipment level)
Symbol
Allocation
H
Windscreen washer
Multimedia accessories socket, multimedia
î
screen
Æ
Front and rear second row accessories socket
Ì
Horn
Ý
Towbar socket
Heated rear view mirrors
Use the fuse allocation label in the
×
Brake lights, passenger compartment central unit
storage compartment to identify the
fuses.
Passenger compartment centre unit, rear wiper,
Certain fuses should only be re-
rear fog light
placed by a qualified professional.
These fuses are not listed on the
label.
Direction indicator lights, hazard warning lights,
D
high level brake lights
Only change the fuses represented
on the label.
5.31
FUSES (4/4)
5
D
Fuses in engine compartment D
LPG fuse in the front
Please note when work-
Some functions are protected by fuses
compartment
ing close to the engine that
it may be hot. In addition,
located in the engine compartment
5 fuse: LPG circuit shut-off.
the engine cooling fan may
(unit D).
However, because of their reduced
start at any moment. The
accessibility, we advise you to have
warning light in the engine compart-
your fuses replaced by an approved
ment reminds you of this.
Dealer.
Risk of injury.
Before carrying out any
action in the engine com-
partment, you must switch
off the ignition.
➥ 2.4 or
➥ 2.6.
5.32
WIPER BLADES: replacement (1/2)
A
B
1
2
3
4
Replacing the windscreen
To refit
wiper blades 2
To refit the wiper blade 2, insert it in its
To replace the wipers, first put them in
housing in the arm 3, then clip it until
the service positionB.
you hear a click. Make sure that the
With the engine running or the igni-
blade is correctly locked in position.
tion on:
To return the blades to lowered posi-
Check the condition of the wiper
- set the stalk 1 to position A twice in
tion, make sure that the blades are
blades. You are responsible for their
succession (single sweep): the wiper
folded down onto the windscreen then
service life:
blades will stop in position B away
set the 1 stalk to position A (single
- clean the blades, windscreen and
from the bonnet;
sweep): the windscreen wiper blades
rear screen regularly with soapy
- lift the wiper arm 3;
will fold into the bonnet when the igni-
water;
- lower the 4 tab then remove the
tion is switched on.
- do not use them when the wind-
blade 2.
screen or rear screen are dry;
- free them from the windscreen or
rear screen when they have not
been used for a long time.
5.33
WIPER BLADES: replacement (2/2)
To refit
To refit the wiper blade, proceed in re-
verse order to removal. Make sure that
the blade is correctly locked in position.
5
B
- In frosty weather, make
sure that the wiper blades
6
are not stuck by ice
(to
avoid the risk of the motor
overheating).
- Check the condition of the wiper
blades. Replace the wiper blades
Rear screen wiper blade 5
as soon as they begin to lose ef-
Stalk in stop position (deactivated):
ficiency
(approximately once a
- lift the wiper arm 6;
year).
- turn the blade horizontally 5 (move-
When changing the blade, when it
ment B) until it unclips;
has been removed, do not let the
Check the condition of the wiper
- remove the blade by pulling it.
wiper arm fall against the window:
blades.
risk of breaking the window.
- clean the blades, windscreen and
rear screen regularly with soapy
water;
- do not use them when the wind-
screen or rear screen are dry;
Before changing the rear
wiper blade, make sure the
- free them from the windscreen or
stalk is in the stop position
rear screen when they have not
(deactivated).
been used for a long time.
Risk of injury.
5.34
TOWING: breakdown recovery (1/2)
Before carrying out any towing, posi-
The speed specified by current legis-
tion the gearbox in neutral position (po-
lation for towing must always be ob-
sition N on vehicles equipped with an
served. If you are driving the towing
automatic gearbox), unlock the steering
vehicle, do not exceed the permissible
1
column then release the parking brake.
towing weight for your vehicle. ➥ 6.9.
Steering column unlocking
Towing a vehicle with an
Insert the key into the ignition, set to ON
automatic gearbox
2 position or, depending on the vehicle,
Transport the vehicle on a trailer or tow
2
with the card in the passenger compart-
it with the front wheels off the ground.
ment, press the engine start button for
In exceptional circumstances, you
approximately two seconds.
may tow it with all four wheels on the
Reposition the lever to neutral (position
ground, only in a forward gear, with the
N for vehicles fitted with an automatic
gear lever in neutral position N over a
gearbox).
maximum distance of 50 miles (80 km)
When setting off, if the lever is locked in
and at a maximum speed of 16 mph
The steering column unlocks and the
position P even though you are press-
(25 km/h).
accessory functions are powered: you
ing the brake pedal, the lever can be re-
can use the vehicle’s lights (direction
leased manually in order to unlock the
indicators, brake lights etc.). At night
drive wheels.
the vehicle must have its lights on.
To do this, unclip the base of the gaiter
Depending on the vehicle, once you
and press the 2 push button while si-
have finished towing, press the engine
Ensure that the towing eye
multaneously pressing the 1 button on
start button twice (risk of running down
is bolted correctly.
the lever to unlock the lever and shift to
the battery).
Risk of losing the towed
position N.
object.
Contact an authorised dealer as soon
as possible.
Leave the card in the vehi-
cle during towing.
Risk of the steering
column locking.
5.35
TOWING: breakdown recovery (2/2)
Tighten the towing hitch 5 fully: first
by hand until it stops, then finish by
locking it with the wheel brace or, de-
pending on the vehicle, the lever.
A
6
4
Only use the towing hitch 5 and the
C
wheelbrace or lever provided with the
B
tools. ➥ 5.7.
D
7
3
- Use a rigid towing bar.
If a rope or cable is used
5
(where the law allows this),
5
the vehicle being towed
Only use the front 3 and rear 7 towing
Access to towing points
must be able to brake.
points (never use the driveshafts or any
- A vehicle must not be towed if it is
other part of the vehicle). These towing
Front towing point
not fit to be driven.
points may only be used for pulling.
Press zone A and keep depressed
- Avoid accelerating or braking
They must never be used for lifting the
while pulling zone B to open flap 4.
suddenly when towing, as this
vehicle directly or indirectly.
may result in damage being
Rear towing point
caused to the vehicle.
Press zone C and keep depressed
- In all cases, it is advisable not to
while pulling zone D to open flap 6.
exceed 15.5 mph (25 km/h).
When the engine is
Ensure that the towing eye
Do not leave the tools unse-
stopped, steering and brak-
is bolted correctly.
cured inside the vehicle as
ing assistance are not oper-
they may come loose under
Risk of losing the towed
ational.
braking.
object.
5.36
OPERATING FAULTS (1/7)
Using the card
POSSIBLE CAUSES
WHAT TO DO
The card does not lock or unlock the
Card battery is flat.
Replace the battery. You will still be able to
doors.
lock/unlock and start your vehicle. ➥ 1.14
and ➥ 2.3 or ➥ 2.6.
Use of appliances operating on the
Stop using the devices or use the key pro-
same frequency as the card (mobile
vided. ➥ 1.14.
phone, etc.).
Vehicle located in a high electromag-
Use the key that is built into the card
netic radiation zone.
➥ 1.14.
Vehicle battery flat.
The message “Place card on zone +
Place the card in the placement area
START” appears on the instrument
➥ 2.6 then press the START button.
panel.
The vehicle is started.
With the engine running, the card’s locking/
unlocking device is blocked. Turn off the ig-
nition.
Desynchronisation of the card
Unlock the driver’s door by inserting the
key integrated in the card into the door lock
➥ 1.14 then place the card in the placement
area ➥ 2.6 and press the START button to
synchronise the card.
5.37
OPERATING FAULTS (2/7)
The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact
an approved dealer as soon as possible.
Using the remote control
POSSIBLE CAUSES
ACTION REQUIRED
The remote control does not lock or The remote control battery is flat.
Use the emergency key.
unlock the doors.
Use of appliances operating on the same
Stop using the devices or use the key.
frequency as the remote control (mobile
phone, etc.).
Vehicle located in a high electromagnetic
Replace the battery. You will still be able to
radiation zone.
lock/unlock and start your vehicle. ➥ 1.14
Discharged battery.
and ➥ 2.3 or ➥ 2.6.
The vehicle is started.
With the engine running, the key’s locking/
unlocking device is blocked. Turn off the
ignition.
Desynchronisation of the remote control
Unlock the driver’s door by inserting the
key into the door lock ➥ 1.14, then start the
engine to synchronise the remote control
➥ 2.4 or ➥ 2.6.
5.38
OPERATING FAULTS (3/7)
The starter is activated
POSSIBLE CAUSES
ACTION REQUIRED
The instrument panel indicator lights are
Battery terminals not tight, bat-
Retighten or reconnect the terminals, or clean them if
weak or fail to light up and the starter
tery terminals disconnected or
they are oxidised.
does not turn.
oxidised.
Discharged battery or not op- Connect another battery to the faulty battery. ➥ 5.24 or
erational.
replace the battery if necessary.
Do not push the vehicle if the steering column is
locked.
Faulty circuit.
Consult an approved dealer.
The engine will not start.
Starting conditions are not ful- ➥ 2.3 or ➥ 2.6.
filled.
The card does not work.
Place the card in the recess provided for this purpose
on the centre console.
➥ 2.3 or ➥ 2.6.
With the vehicle stationary, engine cold, Petrol version, this is not nec-
The engine’s idle speed should decrease after about
the engine’s idle speed is high.
essarily a fault. This may be
one minute. Otherwise, this may be caused by an-
caused by the increase in the
other fault. Call an approved Dealer.
engine temperature.
The engine cannot be switched off.
Card not detected.
Place the card in the recess provided for this purpose
on the centre console.
Press and hold the start button.
Electronic fault.
Press the start button 3 times quickly or press and
hold.
The steering column remains locked. Steering wheel locked.
Move the steering wheel while pressing the engine
start button (or, depending on the vehicle, operating
the ignition key) ➥ 2.3.
Faulty electrical circuit.
Consult an approved dealer.
5.39
OPERATING FAULTS (4/7)
On the road
POSSIBLE CAUSES
WHAT TO DO
Vibrations.
Tyres not inflated to correct pres-
Check the tyre pressures: if this is not the
sures, incorrectly balanced or dam-
problem, have them checked by an ap-
aged.
proved Dealer.
White smoke from the exhaust.
In the diesel version, this is not neces-
➥ 2.20.
sarily a fault. Smoke may be caused
by particle filter regeneration.
Petrol version, this is not necessarily
Reduce the engine speed and avoid
a fault. Depending on the climate con-
sudden acceleration to gradually make the
ditions (cold, humidity etc.), smoke
smoke disappear. Otherwise, this may be
may be produced under hard vehicle
caused by another fault. Consult an ap-
acceleration.
proved dealer.
Smoke under the bonnet.
Short-circuit or cooling system leak.
Stop, switch off the ignition, stand away
from the vehicle and contact an approved
dealer.
The oil pressure warning light comes
on:
while cornering or braking
The level is too low.
Top up the engine oil ➥ 4.5.
is slow to go out or remains lit
Loss of oil pressure.
Stop the vehicle and contact an approved
under acceleration
Dealer.
5.40
OPERATING FAULTS (5/7)
On the road
POSSIBLE CAUSES
WHAT TO DO
Steering becomes heavy.
Assistance overheating.
Drive carefully at reduced speed, be aware
of the level of force in the steering wheel
needed to turn the wheels.
Fault with the electric assistance
Consult an authorised dealer.
motor.
Fault in the assistance system
The engine is overheating. The
Engine cooling fan not working.
Stop the vehicle, switch off the engine and
coolant temperature indicator is in
contact an approved dealer.
the warning zone and warning light
®
comes on.
Coolant leaks.
Check the coolant reservoir: it should con-
tain fluid. If there is no coolant, consult an
authorised dealer as soon as possible.
Coolant boiling in the coolant reser-
Mechanical fault: damaged cylinder
Stop the engine.
voir.
head gasket.
Contact an approved dealer.
Radiator: In the event of a significant lack of coolant, remember that you must never top up using cold coolant while
the engine is very hot. After any procedure on the vehicle which has involved even partial draining of the cooling
system, it must be refilled with a new mixture prepared in the correct proportions. Reminder: only products approved
by our Technical Department may be used for this purpose.
5.41















Content      ..     15      16      17      18     ..
