INTERIOR TRIM MAINTENANCE (2/2)
Removal/replacing removable
You should not:
equipment originally fitted in
Position objects such as deodorants,
the vehicle
scents etc. near air vents as this could
damage your dashboard trim.
If you need to remove equipment in
order to clean the passenger com-
partment (for example, mats), always
ensure that they are correctly refitted
and are the right way around (the driv-
er’s mat should be fitted on the driver’s
Use high-pressure
side, etc.) and fit them with the compo-
cleaning equipment or
nents supplied with the equipment (for
sprays inside the pas-
example, the driver mat should always
senger compartment:
be fixed using the pre-fitted mounting
without careful use, this equipment
components).
could impair the correct functioning
With the vehicle stationary, always
of the electrical or electronic compo-
ensure that nothing will impede driving
nents in the vehicle, or have other
(anything obstructing the pedals, heel
detrimental effects.
wedged by the mat etc.).
4.19
Section 5: Practical Advice
Puncture, emergency spare wheel
5.2
Tyre inflation kit
5.4
Tools
5.7
Wheel trim, wheel
5.8
Changing a wheel
5.9
Tyres (tyre and wheel safety, use in winter)
5.11
Headlights (changing bulbs)
5.14
Rear lights and side lights (replacing bulbs)
5.15
Indicator lights (changing bulbs)
5.17
Interior lighting: changing bulbs
5.18
Remote control key: battery
5.20
Card: battery
5.22
Battery
5.24
Fitting a radio
5.27
Accessories
5.28
Fuses
5.29
Wiper blades: replacement
5.33
Towing
5.35
Operating faults
5.37
5.1
PUNCTURE, EMERGENCY SPARE WHEEL (1/2)
In case of puncture
If the emergency spare wheel has been stored for several years, have it
Depending on the vehicle, a tyre infla-
checked by your Dealer to ensure that it is safe to use.
tion kit or emergency spare wheel is
Vehicle fitted with an emergency spare wheel that differs from the
provided (refer to the following pages).
other wheels:
Vehicle fitted with a tyre pressure
-
Never fit more than one emergency spare wheel to the same vehicle.
loss warning system
Replace the emergency spare wheel as soon as possible with a wheel identi-
In the event of under-inflation (punc-
cal to the original one.
tures, under-inflation etc.), the
-
When this is fitted to the vehicle, which must only be a temporary measure, the
warning light appears on the instrument
driving speed must not exceed the speed indicated on the label on the wheel.
panel. ➥ 2.38.
-
Fitting an emergency spare wheel may alter the way the vehicle usually runs.
Avoid sudden acceleration or deceleration and reduce your speed when cor-
nering.
-
If you need to use snow chains, fit the emergency spare wheel to the rear axle
and check the tyre pressure.
If the vehicle is parked on the hard shoulder, you must warn other road
users of your vehicle’s presence with a warning triangle or with other de-
vices as per the legislation applying to the country you are in.
5.2
PUNCTURE, EMERGENCY SPARE WHEEL (2/2)
1
1
1
2
B
A
3
D
4
C
Emergency spare wheel
- remove the tool kit 4;
To get to it:
- remove the emergency spare wheel
-
open the boot;
(A or B, depending on the vehicle).
depending on the vehicle, lift up the
movable floor and the luggage com-
partment mat 1;
-
depending on the vehicle, remove
the cover 2 from the tool kit 4 by slid-
ing it (movement C or D);
-
unscrew the central mounting 3 (lo-
On vehicles equipped with emer-
cated, depending on the vehicle,
gency spare wheel B, the punctured
under the jack) anti-clockwise;
wheel may not be stored in place
of the emergency spare wheel B.
The 4 tool kit must be attached
using the central attachment 3 and
the punctured tyre must be placed
in the luggage compartment.
5.3
TYRE PRESSURE KIT (1/3)
Do not attempt to use the
The kit is only approved for
B
inflation kit if the tyre has
inflating the tyres of the ve-
been damaged as a result
hicle originally equipped
of driving with a puncture.
with the kit.
You should therefore carefully check
It must never be used to inflate
A
the condition of the tyre sidewalls
the tyres of another vehicle, or any
before any operation.
other inflatable object (rubber ring,
rubber boat, etc.).
Driving with underinflated, flat or
punctured tyres can be dangerous
Avoid spillage on skin when han-
and may make the tyre impossible
dling the repair product bottle. If
to repair.
droplets do leak out, rinse them off
with plenty of water.
This repair is temporary.
Keep the repair kit away from chil-
A tyre which has been punctured
dren.
should always be inspected (and re-
paired, where possible) as soon as
Do not dispose of the empty bottle
The kit repairs tyres when
possible by a specialist.
in the countryside. Return it to your
tread A has been dam-
approved dealer or to a recycling or-
aged by objects smaller
When taking a tyre which has been
ganisation.
than 4 mm. It cannot repair
repaired using this kit to be replaced,
all types of puncture, such as cuts
you must inform the specialist.
The bottle has a limited service
larger than 4 mm, or cuts in tyre
life which is indicated on its label.
When driving, vibration may be felt
sidewall B.
Check the expiry date.
due to the presence of the repair
Ensure also that the wheel rim is in
product injected into the tyre.
Contact an approved dealer to re-
good condition.
place the inflation tube and repair
product bottle.
Do not pull out the foreign body
causing the puncture if it is still in
the tyre.
5.4
TYRE PRESSURE KIT (2/3)
With the engine running and the
If a minimum pressure of 1.8 bar is
parking brake applied,
not reached after 15 minutes, repair
- Disconnect any accessories previ-
is not possible; do not drive the ve-
ously connected to the vehicle’s ac-
hicle but contact an approved dealer.
cessories sockets;
- refer to the information on the in-
flation kit compressor located in
the luggage compartment of the ve-
hicle and follow the instructions;
- inflate the tyre to the recommended
pressure ➥ 4.11 ;
1
- after a maximum of 15 minutes, stop
2
inflating and read the pressure (on
Before using this kit, park
pressure gauge 2).
the vehicle at a sufficient
distance from traffic, switch
Note: while the bottle is emptying
on the hazard warning
(approximately
30 seconds), the
Depending on the vehicle, in the event
lights, apply the handbrake, ask all
pressure gauge 2 will briefly indicate
of a puncture, use the kit located in the
passengers to leave the vehicle and
a pressure of 6 bar, then the pres-
boot or underneath the luggage com-
keep them away from traffic.
sure drops;
partment carpet.
- Adjust the pressure: to increase it,
Vehicle fitted with a tyre pressure
continue inflation with the kit. To
loss warning system
reduce it, press the button 1.
In the event of under-inflation (punc-
If the vehicle is parked on
tures, under-inflation etc.), the
the hard shoulder, you must
warning light appears on the instrument
warn other road users of
panel. ➥ 2.38.
your vehicle’s presence
with a warning triangle or with other
devices as per the legislation apply-
ing to the country you are in.
5.5
TYRE PRESSURE KIT (3/3)
- Start immediately and drive at a
speed between 12 to 37 mph (20 to
60 km/h) in order to distribute the
3
product evenly in the tyre; after driv-
ing a distance of 2 miles (3 km), stop
and check the pressure.
- If the pressure is higher than 1.3 bar
Please be aware that a
but lower than the recommended
poorly tightened or miss-
pressure (refer to the label affixed to
ing valve cap can make the
the edge of the driver’s door), adjust
tyres less airtight and may
it. Otherwise, contact an approved
lead to pressure loss.
dealer: the tyre cannot be repaired.
Always use valve caps identical to
those fitted originally and tighten
them fully.
Precautions when using the
kit
Once
the
tyre is
correctly inflated,
The kit should not be operated for more
remove the kit: unscrew the inflation
than 15 consecutive minutes.
adapter slowly from the container 3 to
The container must be replaced after
Following repair with the kit,
prevent any product spatter and store
the first use even if liquid remains
do not travel further than
the container in plastic packaging to
inside.
120 miles (200 km). In addi-
prevent product leaks.
tion, reduce your speed and
- Affix the driving recommendation
under no circumstances exceed
label (located under the container) to
48 mph (80 km/h). The sticker,
the dashboard where the driver can
which you must affix in a prominent
see it.
position on the dashboard, reminds
- Put the kit away.
you of this.
Nothing should be placed
- At the end of this initial inflation op-
Depending on the country or local
around the driver’s feet
eration, air will still escape from the
legislation, a tyre repaired with the
as such objects may slide
tyre. You must drive a short distance
inflation kit may need to be replaced.
under the pedals during
in order to seal the hole.
sudden braking manoeuvres and
obstruct their use.
5.6
TOOLS
Jack 2
2
Fold it correctly before refitting it in its
housing (ensure that the wheelbrace is
correctly positioned).
A
B
Hubcap tool 3
This tool is used to remove the wheel
D
1
trims.
3
Wheel bolt guide 4
C
To finish loosening or starting to tighten
the wheel bolts.
4
5
Tow eye 5
The tools included in the tool kit depend
Wheelbrace 1
➥ 5.35
on the vehicle.
Locks or unlocks the wheel bolts and
Tool kit A is located in the tray under
tow eye 5.
the luggage compartment carpet.
Depending on the vehicle, remove the
cover B from the tool kit A by sliding it
(movement C or D). After use, ensure
the tools are correctly stored.
Ensure correct positioning and locking
Do not leave the tools unsecured inside the vehicle as they may come
(movement C or D) of cover B.
loose under braking. After use, check that all the tools are correctly
clipped into the tool kit, then position it correctly in its housing: risk of
injury.
If bolts are supplied with the emergency spare wheel, you must use these bolts
only for the emergency spare wheel.
The jack is designed for wheel changing purposes only. Under no circumstances
should it be used for carrying out repairs underneath the vehicle or to gain access
to the underside of the vehicle.
5.7
WHEEL TRIM, WHEEL
A
1
2
C
B
D
Remove the wheel trim using hubcap
tool 1 (located in the tool kit) by en-
gaging the hook in the opening near
valve 2.
To refit it, align it with valve 2. Push the
retaining hooks in fully, starting with
side A near the valve, followed by B
and C, finishing at D opposite the valve.
Do not leave the tools un-
secured inside the vehicle
as they may come loose
under braking. After use,
check that all the tools are correctly
clipped into the tool kit, then posi-
tion it correctly in its housing: risk of
injury.
5.8
CHANGING A WHEEL (1/2)
Vehicles equipped with a jack
Start cranking the jack by hand, posi-
tioning the 4 jack support plate in the
and wheelbrace
slightly indented groove underneath
If necessary, remove the wheel trim.
the vehicle, located between the two
Use the wheelbrace 1 to slacken off the
notches 5 and in the direction of the
5
1
wheel bolts. Position it so as to be able
arrow 3.
4
to push from above.
Continue to crank the jack so that the
Place the jack 2 horizontally. The jack
baseplate is correctly positioned
(it
3
head must be lined up with the sill clos-
should be underneath the vehicle and
est to the wheel concerned and indi-
aligned with the jack head).
cated by the arrow 3.
Turn it a few times to lift the wheel off
the ground.
2
Switch on the hazard warn-
ing lights.
Keep the vehicle away from
traffic and on a level surface
where it will not slip.
Apply the parking brake and engage
a gear (first or reverse, or P for auto-
If the vehicle is parked on
matic transmissions).
the hard shoulder, you must
Ask all the passengers to leave the
warn other road users of
vehicle and keep them away from
your vehicle’s presence
traffic.
with a warning triangle or with other
devices as per the legislation apply-
ing to the country you are in.
5.9
CHANGING A WHEEL (2/2)
Undo the bolts and take off the wheel.
Vehicle fitted with a tyre pressure
loss warning system
Fit the emergency spare wheel on the
central hub and turn it to locate the
In the event of under-inflation (punc-
mounting holes in the wheel and the
tures, under-inflation etc.), the
hub.
warning light appears on the instrument
Tighten the bolts, checking that the
panel. ➥ 2.38.
wheel is correctly positioned on its hub.
Lower the jack.
With the wheel on the ground, tighten
the bolts fully and have the tightness of
the bolts checked and the emergency
Do not leave the tools un-
spare wheel pressure checked as soon
secured inside the vehicle
as possible.
as they may come loose
under braking. After use,
check that all the tools are correctly
clipped into the tool kit, then posi-
tion it correctly in its housing: risk of
injury.
If bolts are supplied with the emer-
gency spare wheel, you must use
these bolts only for the emergency
spare wheel.
The jack is designed for wheel
changing purposes only. Under no
If you have a puncture, re-
circumstances should it be used for
place the wheel as soon as
carrying out repairs underneath the
possible.
vehicle or to gain access to the un-
A tyre which has been punc-
derside of the vehicle.
tured should always be inspected
(and repaired, where possible) by a
specialist.
5.10
TYRES (1/3)
Tyre and wheel safety
When the tyre tread has been worn
to the level of the warning strips, they
The tyres are the only contact between
become visible 2: it is then neces-
the vehicle and the road, so it is essen-
sary to replace your tyres because the
tial to keep them in good condition.
tread rubber is now only 1.6 mm deep
2
You must make sure that your tyres
at most, resulting in poor road hold-
con- form to local road traffic regula-
ing on wet roads.
tions.
An overloaded vehicle, long journeys
by motorway, particularly in very hot
1
weather, or continual driving on poorly
surfaced minor roads will lead to more
rapid tyre wear and affect safety.
Maintaining the tyres
The tyres must be in good condition
and the tread form must have sufficient
depth; tyres approved by our Technical
Department have wear warning strips 1
which are indicators moulded into
the tread at several points.
Incidents which occur when
driving, such as striking the
kerb, may damage the tyres
and wheel rims, and could
also lead to misalignment of the
front or rear axle geometry. In this
case, have the condition of these
checked by an approved dealer.
5.11
TYRES (2/3)
Tyre pressures
Pressures should be checked when the
Vehicle fitted with a tyre pressure
tyres are cold; ignore higher pressures
loss warning system
Adhere to the tyre pressures (including
which may be reached in hot weather
the emergency spare wheel). The tyre
In the event of under-inflation (punc-
or following a fast journey.
pressures should be checked at least
tures, under-inflation etc.), the
once a month and additionally before
If tyre pressures cannot be checked
warning light appears on the instrument
any long journey (refer to the label af-
when the tyres are cold, assume an in-
panel. ➥ 2.38.
fixed to the edge of the driver’s door).
crease of 0.2 to 0.3 bar (or 3 PSI).
Never deflate a hot tyre.
Emergency spare wheel
➥ 5.2, ➥ 5.9.
Changing wheels around
Incorrect tyre pressures
This practice is not recommended.
lead to abnormal tyre wear
and unusually hot running.
These are factors which
may seriously affect safety and lead
to:
- poor road holding;
- risk of bursting or tread separa-
tion.
Please be aware that a
The pressure depends on the load
poorly tightened or miss-
and the speed of use. Adjust the
ing valve cap can make the
pressure according to the condi-
tyres less airtight and lead
tions of use (refer to the label affixed
to pressure loss.
to the edge of the driver’s door).
Always use valve caps identical to
those fitted originally and tighten
them fully.
5.12
TYRES (3/3)
Fitting new tyres
Use in winter
Snow or Winter tyres
We would recommend that these be
Chains
fitted to all four wheels to ensure that
For safety reasons, fitting snow
your vehicle retains maximum adhe-
chains to the rear axle is strictly for-
sion.
bidden.
Warning: These tyres sometimes have
Chains cannot be fitted to tyres which
a specific direction of rotation and a
are larger than those originally fitted to
maximum speed index which may be
the vehicle.
lower than the maximum speed of your
For your safety, please re-
vehicle.
spect the speed limit.
One-way tyres
Studded tyres
When they need to be re-
An one-way tyre must only be fitted in
placed, only tyres of the
one direction. You must observe this di-
This type of equipment may only be
same make, size, type and profile
rection.
used for a limited period and as laid
should be used on a single axle.
down by local legislation. It is neces-
If an one-way tyre must be fitted in the
sary to observe the speed specified by
They must either have a load ca-
opposite to its direction of rotation fol-
current legislation.
pacity and speed rating at least
lowing a puncture, drive with caution,
equal to those of the original
particularly on a wet road, because the
These tyres must, at a minimum, be
tyres, or be recommended by an
tyre specifications will not be adapted.
fitted to the two front wheels.
authorised dealer.
Failure to heed these instructions
could endanger your safety and
affect your vehicle’s roadworthi-
ness.
Risk of loss of control of the ve-
hicle.
Chains may only be fitted
In all cases, we would recommend
to tyres of the same size
that you contact an approved Dealer
as those originally fitted to
who will be able to advise you on
your vehicle.
the choice of equipment which is
most suitable for your vehicle.
5.13
FRONT HEADLIGHTS: replacing the bulbs
LED front fog lights/
cornering lights 3
(depending on the vehicle)
2
Consult an authorised dealer.
1
Additional lights
If you wish to fit fog lights to your ve-
hicle, please see an authorised dealer.
3
Direction indicators/dipped
beam headlights/LED main
beam headlights 1
Please see an authorised dealer.
Any operation on (or modi-
LED daytime running lights/
fication to) the electrical
side lights 2
system must be performed
(depending on the vehicle)
by an approved dealer
Please see an authorised dealer.
since an incorrect connection might
damage the electrical equipment
(harness, components and in par-
ticular the alternator). In addition,
your Dealer has all the parts re-
quired for fitting these units.
5.14
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (1/3)
1
2
3
5
4
LED side light/brake light 1
– release the light assembly from out-
Refitting
side the vehicle by pulling towards
Consult an approved dealer
To refit, proceed in the reverse order,
the rear;
taking care not to damage the wiring.
- remove the 4 bulb holder by un-
Direction indicators 5
screwing it a quarter of a turn, then
- Open the boot;
replace the bulb.
- remove the trim 2;
Bulb type: WY16W.
- unscrew the nut 3;
The bulbs are under pres-
To comply with current legislation, or
sure and can break when
as a precaution, you can obtain an
replaced.
emergency kit from your approved
Risk of injury.
dealer containing a set of spare
bulbs and fuses.
5.15
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (2/3)
7
6
9
8
9
Fog lights and reversing
High level brake light 7
Number plate lights 8
lights 6
Consult an approved dealer.
- Unclip the light by pressing tab 9;
Consult an approved dealer
- remove the light cover to gain access
to the bulb.
Bulb type: W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.16
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (3/3)
11
10
LED number plate lights 10
LED side repeaters11
(depending on vehicle)
(depending on vehicle)
Consult an approved Dealer.
Consult an approved dealer.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.17
INTERIOR LIGHTING: changing bulbs (1/2)
1
2
1
Courtesy light
Map reading lights 2
Consult an authorised dealer.
Courtesy light fitted with diffusers 1
Unclip the lens
(using a flat-blade
screwdriver or similar).
Remove the bulb concerned.
Bulb type: W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.18
INTERIOR LIGHTING: changing bulbs (2/2)
5
4
3
Luggage compartment light
Glovebox light
Courtesy mirror lights 5
Unclip the light 3 by pressing the tab on
Unclip the light 4 by pressing the tab on
Please consult an authorised dealer.
its left side (using a flat-bladed screw-
its left side (using a flat-bladed screw-
driver or similar).
driver or similar).
Ambient lighting
Remove the bulb concerned.
Remove the bulb concerned.
Please consult an authorised dealer.
Bulb type: W5W.
Bulb type: W5W.
5.19
REMOTE CONTROL KEY: BATTERY: battery (1/2)
2
1
Replacing the battery
Note: It is not advisable to touch the
electronic circuit in the key cover when
Open the case at slot 1 using a flat-
replacing the battery.
blade screwdriver or similar, and re-
place the battery 2, observing the type
When refitting, ensure that the cover is
and polarity shown on the back of the
correctly clipped on and the screw tight-
cover.
ened.
When they need to be re-
placed, be sure to use
The batteries are available from ap-
the same or equivalent
proved Dealers, and their service
type of battery (consult an
life approximately two years.
Approved Dealer).
Check that there is no dye on the
battery: risk of an incorrect electri-
cal contact.
5.20















Content      ..     14      15      16      17     ..
