AUDIBLE AND VISUAL SIGNALS
Direction indicators
Move the stalk 1 in the same direc-
tion as you want to move the steering
wheel.
One-touch mode
1
When driving, it is possible that the
A
steering wheel may not be turned suf-
ficiently to return the stalk automatically
to its starting position.
In this case, move the stick 1 to half-
2
way, then release it: the stalk returns to
its original point and the indicator light
flashes three times.
Horn
Hazard warning lights
é
Press the steering wheel boss A to ac-
Press switch 2.
tivate the horn.
This switch activates all four direction
indicators and the side indicator lights
simultaneously. It must only be used in
Headlight flasher
an emergency to warn drivers of other
Pull stalk 1 towards you then release it
vehicles that you have had to stop in
to flash the headlights.
an area where stopping is prohibited or
unexpected, or that you are obliged to
drive under special conditions.
1.105
HEADLIGHT BEAM ADJUSTMENT
Examples of positions for
adjusting
control A according to the load
A
Driver alone or with front passenger
0
All seats occupied
2
Switch A is used to adjust the height of
Driver with passengers and luggage
the headlight beams according to the
(or load) reaching the maximum
3
load.
permissible all-up weight
With the dipped beam headlights lit,
press or lift switch A as many times
as is necessary to select the required
Driver without passengers and luggage
position on the instrument panel. The
(or load) reaching the maximum
4
position selected is displayed on the
permissible all-up weight
instrument panel for approximately
30 seconds.
Note: depending on the vehicle, at
each engine start-up the selected po-
sition may be displayed on the instru-
The table below gives some examples. In all cases, adjust control A accord-
ment panel for approximately 30 sec-
ing to the vehicle load so that the road can be seen and other drivers are not
onds.
dazzled.
1.106
WINDSCREEN WASH, WIPE (1/5)
2
A
1
1
B
C
D
E
Vehicle fitted with intermittent
Special note
windscreen wipers
When driving the vehicle, the wiping
speed slows down whenever the ve-
A single sweep
hicle stops. For example, fast wiping
A short push will trigger one sweep
speed will slow to normal wiping speed.
of the wipers.
As soon as the vehicle moves off,
B stop
wiping will return to the speed originally
C intermittent wiping
selected.
The wipers will pause for several
If stalk 1 is operated, it overrides and
seconds between sweeps. It is
cancels the automatic function.
possible to change the time be-
tween sweeps by turning ring 2.
D slow continuous wiping
E fast continuous wiping
1.107
WINDSCREEN WASH, WIPE (2/5)
When activating automatic wiping
or when increasing sensitivity, one
sweep of the blades is performed.
A
1
F
Note:
1
2
- the rain sensor is only intended as a
B
driving aid. In the event of reduced
visibility, the driver should manually
C
activate the wipers. In foggy weather
or during snowfalls, wiping is not au-
D
tomatically triggered and remains
E
G
under the driver’s control;
- in the event of temperatures below
zero, automatic wiping is not acti-
vated when the vehicle is started. It
is automatically activated as soon as
Vehicle fitted with front
C
automatic wiper function
the vehicle exceeds a certain speed
When this position is selected, the
windscreen wiper rain sensor
(approximately 5 mph (8 km/h));
system detects water on the wind-
The rain sensor is located on the winds-
screen and triggers the wipers at a
- do not activate automatic wiping in
creen, in front of the interior rear-view
suitable wiping speed. It is possi-
dry weather;
mirror.
ble to change the triggering thresh-
- fully de-ice the windscreen before
old and the time sweeps by turning
A single sweep
activating automatic wiping.
ring 2:
A short push will trigger one sweep
- F: minimum sensitivity
of the wipers.
- G: maximum sensitivity
B stop
The higher the sensitivity, the
quicker the wipers will react and
the faster the wipe.
1.108
WINDSCREEN WASH, WIPE (3/5)
Operating faults
Special note
In the event of a malfunction of the au-
When driving the vehicle, the wiping
tomatic wiping, the wiper is set to inter-
speed slows down whenever the vehi-
A
mittent wiping. Contact an authorised
cle stops. For example, fast wiping
1
dealer.
speed will slow to normal wiping speed.
As soon as the vehicle moves off,
The operation of the rain sensor can be
B
wiping will return to the speed originally
disturbed in the event of:
selected.
- damaged windscreen wipers; a
C
If stalk 1 is operated, it overrides and
film of water or traces left by a
cancels the automatic function.
blade in the sensor’s detection
D
zone may increase the response
E
Precautions
time of the automatic wiper, or in-
crease the wiping frequency;
- In the event of ice, check whether the
- a windscreen with any chip or
blades are stuck to the windscreen
crack level with the sensor, or a
before operating the wiping mecha-
windscreen covered in dust, dirt,
nism. If you activate the wipers while
D
slow continuous wiping
insects, ice, the use of washing
the blades are stuck down with ice,
wax and water-repellent chemi-
E
fast continuous wiping
you may risk damaging both the
cals; the windscreen wiper will
blade and the wiper motor.
be less sensitive or may even not
- Do not activate the wipers on a dry
react at all.
screen. This will lead to premature
wear or damage to the blades.
1.109
WINDSCREEN WASH, WIPE (4/5)
Specific front wiper position
(service position)
This position enables the blades to be
A
lifted to remove them from the winds-
1
creen.
B
It may be useful to:
- to clean the blades;
C
- to release the blades from the winds-
creen in winter;
D
- replace the blades ➥ 5.33.
E
With the ignition on or the engine run-
ning, lift the 1 stalk twice to position A
(single sweep). The blades stop slightly
away from the bonnet.
To return the blades to low position,
with the ignition on, ensure that the
wipers have folded down onto the wind-
screen, then move the stalk 1 to posi-
tion A (single sweep).
Before switching on the ignition,
In the event of obstacles on the
place the wipers on the windscreen.
windscreen (dirt, snow, ice etc.),
Otherwise, there may a risk of damage
clean the windscreen (including the
to the bonnet or the wipers when they
central area located behind the inte-
are switched on.
rior rear view mirror) before starting
Before
carrying
out any
the wipers (risk of motor overheat-
action involving the wind-
ing).
screen (washing the vehi-
If an object is preventing a blade
cle, de-icing, cleaning the
from moving, it may stop functio-
windscreen etc.) return the 1 stalk
ning. Remove the obstacle and
to position B (stop).
reactivate the wiper using the wiper
Risk of injury and/or damage.
stalk.
1.110
WINDSCREEN WASH, WIPE (5/5)
Note:
In temperatures below zero, the washer
1
liquid risks freezing to the windscreen,
thereby reducing visibility. Heat the
windscreen using the demister control
before cleaning.
Efficiency of a wiper blade
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
Windscreen washer
- free it from the screen when it has
With the ignition on, pull stalk 1 then
not been used for a long time.
release.
In all cases, replace it as soon as
A longer pull will trigger, in addition to
it begins to lose efficiency: approxi-
the windscreen washer, two sweeps
mately once a year. ➥ 5.33.
of the wipers followed, a few seconds
later, by a third.
Precaution for using the
On vehicles fitted with a multimedia
wipers
screen, you can choose to activate or
disable the third sweep of the blades.
- In freezing or snowy weather
➥ 1.89.
conditions, clear the screen
When working in the engine
before starting the wipers (risk of
compartment, ensure that
motor overheating);
the windscreen wiper stalk
- ensure that no objects are ob-
is in position B (park).
structing the travel of the blade.
Risk of injury.
1.111
REAR SCREEN WASHER, WIPER (1/2)
To stop the operation, pivot ring 3 again.
Note
3
2
When washing using a roller type car
wash, return the ring 3 on the stalk 1
1
to the stop position to deactivate auto-
matic wiping.
Follow usage recommendations.
Efficiency of a wiper blade
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
Rear screen wiper
- free it from the screen when it has
Y
With the ignition on, rotate the
not been used for a long time.
ring 3 on the lever 1 until the symbol is
In all cases, replace it as soon as
opposite the reference point 2.
it begins to lose efficiency: approxi-
- stopping
mately once a year. ➥ 5.33.
Do not use the wiper arm to open or
- intermittent wiping
close the tailgate.
The wipers will pause for several
Precaution for using the
seconds between sweeps. Wiping
wipers
frequency varies with vehicle
speed;
Before any action involving
- In freezing or snowy weather
conditions, clear the screen
the rear screen (washing
– slow continuous wiping
before starting the wipers (risk of
the vehicle, de-icing, clean-
motor overheating);
ing, etc.) return stalk 1 to
- ensure that no objects are ob-
the stop position.
structing the travel of the blade.
Risk of injury and/or damage.
1.112
REAR SCREEN WASHER, WIPER (2/2)
Activation/deactivation of the rear
In the event of obstacles present on the
screen wiper
rear window (dirt, snow, etc.), the wiper
will try to sweep away all the obstacles.
Engaging reverse gear triggers inter-
If an obstacle prevents the blade from
mittent wiping (if the front wipers are in
moving, it can be stopped. Remove the
1
operation). If your vehicle is equipped
obstacle, wait for around 30 seconds
with a vehicle settings customisation
and reactivate the wiper using the wiper
menu, you can opt to activate or deacti-
stalk.
vate this function. ➥ 1.89.
For vehicles not fitted with a settings
Precautions
customisation menu, you can have this
- In the event of ice, check that the
function deactivated by an authorised
blades are not stuck to the wind-
dealer.
screen before operating the wipers.
If you activate the wiper while the
blade is blocked by ice, you risk dam-
aging both the blade and the wiping
motor.
Rear screen wash/wipe
p
- Do not operate the wipers on a dry
With the ignition on, push and
screen. This will lead to the prema-
hold stalk 1, then release.
ture wear or damage to the blades.
Holding the stalk for longer will trigger
(in addition to the windscreen washer)
two sweeps of the wipers followed,
a few seconds later, by a third (drip
wiping function).
When the stalk is released, it returns to
the rear wipe position.
1.113
FUEL TANK (1/5)
Fuel grade
Use a high-grade fuel that complies
with the legislation in force in each
country and which must comply with
1
the specifications given on the label on
1
the cover 1. ➥ 6.6.
3
A
2
Fuel types that conform to European
standards with which the engines of
vehicles sold in Europe are compat-
ible: refer to the table ➥ 6.6.
Useable tank capacity:
- Approximately
9.24
gallons
(42 litres) for petrol versions;
Do not mix even small
- Approximately
8.58
gallons
amounts of petrol
(un-
Filler cap: this is specific.
(39 litres) for diesel versions.
leaded or E85) with diesel.
With the vehicle unlocked, to open
If you have to replace it,
Do not use ethanol-based
cover 1, press area A then release. The
make sure it is identical to
fuel if your vehicle is not compatible
cover 1 opens slightly.
the original cap. Contact an
with this fuel.
Use the cap holder 2 on the flap 1
approved Dealer.
Do not add reagent to the fuel - oth-
during filling to hold the cap 3 in place.
Never place the cap near a source
erwise you risk damaging the engine
For details on filling the fuel tank, refer
of heat or flame.
➥ 0.8. If you wish to add an additive
to the information on “Filling up with
Do not wash the filler area with a
to the fuel, use a product approved
fuel”.
high-pressure washer.
by our Technical Department.
To close it, press on the fuel filler flap by
Consult an approved dealer.
hand, as far as it will go.
1.114
FUEL TANK (2/5)
Filling with fuel
If it is not possible to add at least
1.10 gallons (5 litres) of fuel due to the
With the ignition off, insert the nozzle
fuel level in the tank, drive the vehicle
and insert it fully before turning it on to
until the tank has capacity.
fill the fuel tank (risk of splashing). Keep
1
the nozzle in this position throughout
Petrol versions
the entire filling operation.
Using leaded petrol will damage the
When the pump cuts out automatically
antipollution system and may lead to a
at the end of the filling procedure, a
loss of warranty.
maximum of two further filling attempts
To ensure that the tank is not filled
may be made, as there must be suffi-
with leaded petrol, the fuel tank filler
cient space in the fuel tank to allow for
neck consists of a restrictor fitted with
expansion. Make sure that no water
a safety system which only allows
enters the fuel tank during filling. The
a nozzle for unleaded petrol to be
cover 1 and its surround must remain
used (at the pump).
clean.
Diesel version
Special case
It is essential to use diesel fuel that
conforms with the information given on
When the vehicle has been stopped for
the label inside cover 1.
around three months, you must add
fuel to prevent damage to the fuel
Petrol version
pump. To do this, with the ignition off,
It is essential to use unleaded petrol.
top-up at least 1.10 gallons (5 litres)
The octane rating (RON) must comply
then start the engine to operate the
To fill up with fuel, the engine
with the information given on the label
pump and renew the fuel in the circuit.
must be stopped (and not
on the cover 1. ➥ 6.6.
only on standby in the case
of vehicles equipped with
the STOP and START function): you
must switch off the ignition ➥ 2.4,
➥ 2.6.
Fire hazard.
After filling, check that the cap and
cover are closed.
1.115
FUEL TANK (3/5)
Vehicles with card
No modifications what-
With the card in the passenger com-
soever are permitted on
4
partment, press the start button 4 with-
any part of the fuel supply
out pressing any of the pedals. Wait a
system
(electronic units,
few minutes before starting.
wiring, fuel circuit, injectors, pro-
This will enable the fuel circuit to be
tective covers, etc.) as this may be
primed. If the engine does not start,
dangerous (unless undertaken by
repeat the procedure.
qualified Network personnel).
If the engine does not start after several
attempts, please contact an authorised
dealer.
Running out of fuel on diesel
Persistent fuel odour
versions
If you notice a persistent
Vehicles with key/remote control
fuel odour you should:
- Set the ignition key to “On” position
- stop the vehicle as soon as traf-
M ➥ 2.3 and wait a few minutes
fic conditions allow and switch off
before starting to enable the fuel cir-
the ignition;
cuit to be primed;
- switch on the hazard warning
- turn the key to position D. If the
lights and ask your passengers to
engine does not start, repeat the pro-
leave the vehicle and stay clear
cedure;
of the traffic;
- if the engine does not start after sev-
- contact an approved Dealer.
eral attempts, please contact an au-
thorised dealer.
1.116
FUEL TANK (4/5)
Useable capacity of the LPG tank: ap-
5
5
proximately 7.04 gallons (32 litres).
Filling up with LPG
Apply the parking brake, stop the
engine, switch off the ignition and
switch off the lights.
Always respect the safety instructions
5
given at filling stations.
Depending on the country, before refill-
ing you must screw the filling adapter 5
onto the LPG filler end piece.
It is always advisable to completely fill
the tank.
When the pump stops delivering LPG,
Filling stations without self-
or when the pump flow reduces signif-
service
icantly, the maximum LPG level has
been reached.
If the service station personnel carry
IMPORTANT: LPG filling
At this point, do not attempt to carry on
out the LPG filling procedure, you must
adapter 5
filling.
give them the adapter 5.
Depending on the country, the use
of a specific adapter is required for
LPG filling.
The filling adapter 5 is provided in
a pouch in the glove box. It may or
may not be present in the vehicle,
depending in which country the ve-
hicle was sold.
Before driving the vehicle to another
country, it is essential to consult an
If you exceed the LPG tank capacity when topping-up, please go to an
approved dealer to find out the type
accredited garage or an authorised dealer to check the automatic filler
of adapter to use if necessary.
device.
1.117
FUEL TANK (5/5)
Depending on the type of station, it may
be necessary to perform press and hold
6
the station button before filling will start.
When the pump stops supplying LPG,
or when the pump flow reduces sig-
nificantly, the maximum tank level has
been reached.
The filling will stop as soon as you re-
lease the button. Release the stop
lever (a small amount of gas may be re-
leased), lift the pistol and place it on the
7
distributor.
Replace the cap 6 to avoid any water
or foreign bodies from entering the
system.
Filling stations with self-
service
We recommend that you wear gloves
when handling the LPG pistol.
Open the tank flap of your vehicle and
unscrew the cap 6 from the end piece
of the LPG filler 7.
Carefully follow the instructions shown
on LPG distributors. These explain how
to fill up properly.
1.118
REAGENT TANK (1/4)
Please ensure that you comply with the
legislation of your country. It is impor-
tant to remember that failure to respect
regulations in force could lead to legal
action being taken against the vehicle
1
To fill up with reagent, the engine
owner.
A
must be stopped
(and not on
standby in the case of vehicles
equipped with the STOP and Start
Operating principle
function). You must switch off the ig-
The reagent is intended for diesel en-
nition ➥ 2.4 ➥ 2.6.
gines fitted with the SCR (selective cat-
alytic reduction) system.
Using a reagent reduces the quantity of
nitrogen oxides in exhaust gases.
If the
“XXX MILES (XXX
Reagent consumption in real time de-
KM) failure Top up AdBlue”
pends on vehicle usage conditions, the
warning message appears,
equipment fitted, and driving style.
Filling
fill the reagent tank and
refer to the filling instructions.
Useable capacity of the tank: 2.42
Reagent quality
gal (11 litres) approximately.
Risk of immobilisation of the ve-
Use only reagents which conform
hicle.
With the ignition switched off, open the
to standard ISO 22241 and in accor-
cover A, then unscrew the cap 1.
dance with the mark on the tank filler
cap.
Note: ammonium hydroxide vapour
may escape from the cap opening
Fuel filler cap: this is a
when the tank temperature is high.
specific type.
If you have to replace it,
make sure it is identical
to the original cap. Contact an ap-
proved Dealer. Do not wash the filler
area with a high pressure washer.
The reagent must not come into contact with eyes or skin. If it does, wash
the affected area with plenty of cold water. If necessary, consult a doctor.
1.119
REAGENT TANK (2/4)
Filling (continued)
If the reagent overflows, or contami-
nates any paintwork, clean the affected
The tank can be filled at the pump. With
area quickly with plenty of cold water
the ignition off, insert the nozzle fully
and a soft cloth.
before activating it to fill the fuel tank
(risk of splashing). Keep the nozzle in
Note: if the reagent crystallises, use a
this position throughout the entire filling
soft sponge.
After filling the reagent tank, check
operation.
that the cap and cover are closed,
In extreme cold weather conditions
start the engine and WAIT 10 sec-
When the pump cuts out automatically
In frosty weather conditions, the rea-
onds with the vehicle stationary,
at the end of the filling procedure, a
gent tank should be refilled when the
engine running before setting off
maximum of two further filling attempts
again.
may be made, as there must be suffi-
indicator and the message “TOP
If this operation is not carried out,
cient space in the fuel tank to allow for
UP AdBlue before 1200 km” appear on
the filling of the tank will not be
expansion.
the instrument panel.
taken into account automatically
In other filling cases, it is essential to
Special cases
until after several dozens of minutes
read the information shown on the rea-
of driving.
The reagent fluid freezes below about
gent container (e.g. the can or bottle).
The message “--- Top up AdBlue”
-10°C.
and/or the warning lights will con-
In these conditions, do not attempt filling
tinue to appear until the filling has
Precautions for use
when the fluid is frozen. In the event of
been taken into account by the
When filling:
needing to top up or fill the tank with re-
system.
- handle the reagent with care. They
agent (
on), park the vehicle in a
can damage clothes, shoes, body-
hotter location if possible so that the re-
work components etc.;
agent becomes liquid again. Otherwise,
have a qualified professional top up or
- make sure that no water enters the
fill up with reagent fluid.
fuel tank.
No work whatsoever is
permitted on any part of
the system. To prevent
damage, only qualified per-
sonnel from our network may work
on the system.
1.120
REAGENT TANK (3/4)
Maintenance/Range
The information displayed on the instrument panel may be accompanied by a beep.
Indicator
Message
What to do?
lights
When the message is displayed when the ignition is switched
on, you have less than 1,488 miles (2,400 km) range.
-
“Top Up AdBlue before 2400 km”
Plan to refill, or have an Approved Dealer refill the reagent in
the tank.
When the message is displayed when the ignition is switched
on, you have between 744 miles (1,200 km) and 496 miles
comes
“TOP UP AdBlue before 1200 km”
(800 km) range.
on.
Plan to refill, or have an Approved Dealer refill the reagent in
the tank.
The message is displayed when the ignition is switched on and
is repeated:
- Approximately every 62 miles (100 km), you have between
about 496 miles (800 km) and 124 miles (200 km) range;
comes
“XXX KM failure Top up AdBlue”
- Approximately every 31 miles (50 km), you have less than
on.
124 miles (200 km) range.
In any event, fill or have an Approved Dealer fill the reagent
tank as soon as possible.
The engine will not start.
“0 KM failure Top up AdBlue”
flashes.
To restart, you must fill the reagent tank yourself.
1.121
REAGENT TANK (4/4)
System faults
When the indicator lights light up, this may be accompanied by a beep.
Indicator lights
Message
Readings
“Check Anti- Pollution System”
Indicates a fault in the system. Contact your approved
“AdBlue quality to check”
Dealer as soon as possible.
“AdBlue injection to check”
Indicates a system fault and that in less than 496
miles (800 km) it will become impossible to re-
start the vehicle.
These warnings are repeated:
- every 62 miles (100 km) until there is between
“XXX KM failure antipollution”
500 miles (800 km) and 124 miles (200 km) left
before the vehicle cannot be restarted;
- Every 31 miles (50 km) when there is less than
124 miles (200 km) left before the vehicle cannot
be restarted.
Contact your approved dealer as soon as possible.
Indicates that after the ignition is switched off the ve-
“0 KM failure antipollution”
hicle will not restart. Call an approved Dealer.
1.122
Section 2: Driving
Running in
2.2
Ignition switch
2.3
Starting, stopping the engine
2.4
Stop and Start Function
2.10
Special features of petrol versions, particle filter
2.14
Special features of LPG versions
2.16
Special features of diesel versions
2.20
Gear lever, handbrake
2.22
Electronic parking brake
2.23
“AUTOHOLD” function
2.27
Eco-driving
2.28
Maintenance and antipollution advice
2.36
Environment
2.37
Tyre pressure loss warning
2.38
Driver correction devices and aids
2.44
Lane departure warning
2.49
Lane Keeping Assist
2.54
Blind spot warning
2.60
Safe distance alert
2.67
360° camera
2.71
Active emergency braking
2.80
Detection of road signs
2.88
Speed limiter
2.92
Cruise control
2.96
Stop and Go adaptive cruise control
2.101
Parking distance control
2.114
Reversing camera
2.121
Assisted parking
2.123
Automatic gearbox
2.128
Emergency call
2.132
2.1
RUNNING IN
Petrol version
Diesel version
For the first 600 miles (1,000 km), do
For the first 1,000 miles (1,500 km),
not exceed 78 mph (130 km/h) in the
do not exceed 80 mph (130 km/h) in
highest gear, or 3,000 to 3,500 rpm.
the highest gear, or 2,500 rpm. After
completing this mileage you may drive
You may only expect top performance
faster, although you may only expect
from your vehicle after approximately
top performance after approximately
1,800 miles (3,000 km).
3,600 miles (6,000 km).
Service intervals: refer to the
During the running in period, do not ac-
Maintenance Document for your vehi-
celerate hard while the engine is still
cle.
cold and do not let the engine over-rev.
Service intervals: refer to the
Maintenance Document for your vehi-
cle.
2.2
IGNITION SWITCH: vehicle with key
“Ignition” position ON 2
The ignition is switched on: Any acces-
sories (radio etc.) can be used.
“Start” position START 3
If the engine fails to start at the first
attempt, the key must be turned back
before the starter can be activated
again. Release the key as soon as the
engine starts.
Note: on diesel versions, several sec-
onds may pass between turning the
key and the engine starting to allow for
engine preheating.
Ignition switch
Off position LOCK 0 (steering lock
applied)
To lock: remove the key and turn the
steering wheel until the steering column
locks.
To unlock: turn the key and the steering
wheel slightly.
2.3















Content      ..     4      5      6      7     ..
