DRIVING POSITION: RIGHT-HAND DRIVE (2/2)
The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY.
1
Side air vents.
8
Main switch and controls for cruise
14
LPG control.
control/speed limiter and Stop and
2
Passenger airbag location.
Go adaptive cruise control.
15
Control for adjusting steering
wheel height and reach.
3
Heating or air conditioning con-
9
Instrument panel.
trols.
16
Engine start/stop button.
10
Driver airbag and horn location.
4
Centre air vents.
17
Gearstick.
11
Controls for:
5
Multimedia screen.
- on-board computer information
18
Controls for:
read-out and vehicle settings
- activating/deactivating the elec-
6
Controls for:
customisation menu,
tronic parking brake;
- front seat heating;
- remote radio and navigation
- activation/deactivation of the
- activation/deactivation of the
system.
function AUTOHOLD.
Stop and Start function;
- activation/deactivation, depend-
12
Steering column stalk for wind-
19
“Hands-free” card holder.
ing on the vehicle, of the ECO or
screen and rear screen wash/
MULTI-SENSE mode;
wiper.
20
Handbrake.
- hazard warning lights;
- electric door locking;
13
Controls for:
21
Charging zone/telephone storage.
- activation/deactivation of the
- lighting rheostat for control
parking distance control;
instru- ments;
22
Accessories socket.
- activating/deactivating the 360°
- headlight beam height remote
camera;
adjustment;
23
Glovebox.
- ...
- activation/deactivation of the
steering wheel heating;
24
Bonnet release control.
7
Stalk:
- activation/deactivation of Lane
- direction indicator lights;
Keeping Assist and Lane
- exterior lights;
Departure Warning.
- front fog lights;
– rear fog lights.
1.63
WARNING LIGHTS (1/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
C
A
B
1
1
1
Instrument panel A, B or C: it illumi-
In some cases, the appearance of a
nates when the ignition is switched on.
warning light is accompanied by a mes-
Press or lift the 1 switch as many times
sage on the instrument panel.
as required to adjust the intensity.
If no lights or sounds are ap-
parent, this indicates a fault
Warning light
®
re-
in the instrument panel. This
quires you to stop immedi-
indicates that it is essential
ately, for your own safety,
to stop immediately (as soon as traf-
Warning light
means you
as soon as traffic conditions
fic conditions allow). Ensure that the
should drive very carefully to an
allow. Switch off the engine and do
vehicle is correctly immobilised and
authorised dealer as soon as
not restart it. Contact an approved
contact an approved Dealer.
possible. If you fail to follow this
Dealer.
recommendation, you risk damag-
ing your vehicle.
1.64
WARNING LIGHTS (2/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Side light warning light
Indicator light airbag
Brake circuit fault warning
š
å
D
light
It lights up when the ignition or
Main beam headlight tell-
the engine is switched on and goes off
It lights up when the ignition or the
á
tale
after a few seconds.
engine is switched on and goes off after
a few seconds.
Dipped beam headlight tell-
If it does not come on when the igni-
k
tale
tion is switched on, or comes on when
If it comes on during braking and is ac-
the engine is running, there is a fault in
companied by the
®
warning light
Front fog light tell-tale
g
the system.
and a beep, it indicates that the fluid
level in the circuit is low or that there is
Contact your approved Dealer as soon
Rear fog lights tell-tale
a braking system fault.
as possible.
Stop as soon as traffic conditions allow
STOP light
Automatic main beam head-
®
and consult an approved dealer.
light indicator light ➥ 1.99
This lights up when the igni-
Battery charge warning light
tion or engine is switched on and goes
Left-hand direction indicator
Ú
-
out as soon as the engine is running. It
It lights up when the ignition or
tell-tale
comes on with other warning lights and/
the engine is switched on and goes off
Right-hand direction indica-
or messages, and is accompanied by
after a few seconds.
˜
tor tell-tale light
a beep.
If it comes on on the road, accompa-
It requires you to stop immediately, for
nied by the
®
warning light and a
your own safety, as soon as traffic con-
beep, this indicates an overload or dis-
ditions allow. Switch off the engine and
charge in the electrical circuit.
do not restart it.
Stop as soon as traffic conditions allow
Contact an approved Dealer.
and contact an approved Dealer.
1.65
WARNING LIGHTS (3/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Oil pressure warning light
Warning light
Handbrake “on” and elec-
À
}
It lights up when the ignition or
tronic parking brake warn-
This lights up when the igni-
the engine is switched on and goes off
ing light ➥ 2.22 ➥ 2.23
tion or engine is switched on and goes
after a few seconds.
out as soon as the engine is running.
Gear change indicators
If it comes on on the road, accompa-
It can light up in conjunction with other

This lights up to advise
nied by the
®
warning light and
warning lights and/or messages on the
you to change to a higher gear (arrow
a beep, stop immediately and cut the
instrument panel. It means you should
pointing upwards) or lower gear (arrow
ignition.
drive very care- fully to an approved
pointing downwards) ➥ 2.28.
Dealer as soon as possible. If you fail
Check the oil level. If the level is normal,
Warning light for the elec-
to follow this recommendation, you risk
the warning light is related to something
tronic stability program
damaging your vehicle.
else.
(ESC) and traction control system
Warning light
Call an approved Dealer.
It lights up when the ignition or the
If it appears in red during driv-
engine is switched on and goes off after
Variable power-assisted
ing and is accompanied by the
®
a few seconds.
U
steering warning light
indicator light, you must, for your safety,
There are several reasons for the warn-
It lights up when the ignition or the
stop as soon as traffic conditions allow.
ing light to appear: ➥ 2.44.
engine is switched on and goes off after
Switch off the engine and do not restart
a few seconds.
it. Call an approved Dealer. If it appears
Warning light for non-availa-
in yellow during driving and is accom-
bility of the electronic stabil-
If it comes on while driving, alongside
ity program (ESC) and traction con-
the warning light
®
, this means
an approved dealer as soon as possi-
trol system
there is a system fault.
ble. Meanwhile, drive with care. If you
Contact an authorised dealer.
Door status warning light
fail to follow this recommendation, you
2
“AUTOHOLD” system warn-
risk damaging your vehicle.
ing ➥ 2.27
1.66
WARNING LIGHTS (4/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Anti-lock braking warning
Preheating warning light
Low fuel level warning light
x
light
É
(Diesel version)
L
It lights up orange when the ig-
It lights up when the ignition or the
This should come on when the igni-
nition or the engine is switched on and
engine is switched on and goes off after
tion is switched on. It indicates that the
goes off after a few seconds.
a few seconds.
heater plugs are in operation.
If the light becomes orange while driv-
If it lights up when you are driving, it in-
It goes out when preheating is com-
ing and a beep sounds, fill up with fuel
dicates a fault in the anti-lock braking
plete. The engine can be started.
as soon as possible. There is only ap-
system.
proximately 31 miles (50 km) worth of
Toxic Fume Filter System
Ä
fuel left.
Braking will then be as normal, without
Warning Light
the ABS. Contact an approved Dealer
Mode warning light ECO
On vehicles that are equipped, this light
as soon as possible.
comes on when the engine is started
It comes on when ECO mode
Particle filter system warn-
and, depending on the vehicle, when
is active ➥ 2.28.
ing light ➥ 2.14 ➥ 2.20
the ignition is switched off while the
Free wheel warning light in
engine is in the standby phase ➥ 2.10
Warning light for reagent
mode ECO
then it goes out.
level and faults in the ex-
- If it lights up continuously, consult
It lights up in mode ECO when the
haust gas reduction system ➥ 1.119
your approved dealer as soon as
“Free wheel in mode ECO” is activated
Tyre pressure loss warning
possible;
(ON) in the user settings.
➥ 2.38
The warning light colour is dim when
- If it flashes, reduce the engine speed
until the light stops flashing. Contact
the vehicle is not while freewheeling.
your approved Dealer as soon as
This warning light is bright when the ve-
possible ➥ 2.36.
hicle is while freewheeling (automatic
neutral).
Please refer to the information on
“Driving advice, ECO-driving” in
Section 2.
1.67
WARNING LIGHTS (5/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Coolant temperature warn-
Speed limiter warning light
Assisted parking brake fault
Ô
ing light
Ð
➥ 2.92
light ➥ 2.123
This lights up blue when you switch on
Cruise control warning light
Overspeed warning light
the ignition or start the engine.
Ï
➥ 2.96
➥ 1.70
If it turns red, stop and let the engine
Adaptive cruise control
Lane departure system
idle for a minute or two.
warning light Stop and Go
warning light ➥ 2.49
➥ 2.101
The temperature should lower and the
Lane Keeping Assist system
warning light should return to a blue
Engine standby warning
warning light ➥ 2.54
colour. If not, stop the engine. Let the
light ➥ 2.10
(Depending on vehicle)
engine cool down before checking the

Unavailability of engine
Indicator of failure or
coolant.
standby warning light ➥ 2.10
unavailability of active emergency
Contact an approved Dealer.
braking ➥ 2.80
Brake pedal warning light
Ó
This lights up when the brake
Warning light to indicate de-
pedal should be depressed ➥ 2.128.
tected presence of hands on
the steering wheel ➥ 2.54
1.68
WARNING LIGHTS (6/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Front and rear seat belt re-
ß
minder warning light
(de-
pending on the vehicle) ➥ 1.23
D
On display D
Passenger Airbag ON
➥ 1.57
Passenger Airbag OFF
¹
➥ 1.57
1.69
DISPLAYS AND INDICATORS (1/7)
Instrument panel in miles
(option to switch to km/h)
Vehicles not fitted with a multimedia
screen
- With the ignition off, press the
2
switch as many times as required to
reach the vehicle tab 5;
- press 3 or 4 repeatedly to access
“Settings”, then press 1 “OK”;
2
3
- repeat the same operation to access
5
“DASHBOARD”, then “Units”.
1
4
Engine oil level low warning
Vehicles fitted with a multimedia
screen.
When the engine is started, the instru-
ment panel display alerts you if the min-
Please see the multimedia instructions
imum oil level is reached. ➥ 4.4.
for information on how to select the unit.
The first time the warning appears, it
Note: in both cases, once the battery
can be cleared by pressing 1 "OK ".
is switched off, the on-board computer
automatically returns to the original unit
Subsequent warnings will disappear
of measurement.
automatically after around 30 seconds.
To return to the previous mode, repeat
the same operation.
Please refer to the multimedia instruc-
tions for more information.
1.70
DISPLAYS AND INDICATORS (2/7)
7
6
A
12
8
11
10
9
Instrument panel A
Rev counter 7
Total mileage recorder 9 1.81
(graduations x 1000)
It lights up when the ignition is switched
This is displayed differently according
Trip computer 10 1.77
on. In some cases, the appearance of a
to how the instrument panel is custom-
warning light is accompanied by a mes-
Estimated mileage with remaining
ised. Depending on the style selected,
sage.
fuel 11
it may not be displayed.
Depending on the vehicle, you can cus-
The value is displayed after driving
tomise your instrument panel with the
Overspeed buzzer
400 metres. ➥ 1.81.
content and colours of your choice.
Depending on the vehicle and country,
For vehicles fitted with a multimedia
Trip computer and multimedia
screen, refer to the equipment instruc-
the
warning light is displayed
information 12
tions.
and a beep sounds. This beep sounds
Depending on the vehicle, you can dis-
For vehicles not fitted with a multimedia
as soon as the vehicle is travelling at
play information from the multimedia
screen ➥ 1.89.
over 75 mph (120 km/h). This warning
screen (the compass, telephone, navi-
light remains lit for as long as the ve-
gation, etc.) or information from the trip
Speedometer 6
hicle is travelling at over
74 mph
computer.
Depending on the style selected, the
(120 km/h).
Please refer to the multimedia instruc-
display varies.
tions for more information.
Driving style indicator 8 2.28
1.71
DISPLAYS AND INDICATORS (3/7)
14
15
13
Coolant temperature indicator 14
Fuel gauge 15
In normal use, indicator 14 should be
If the level is at the minimum, warn-
before area 13. Under “intensive” op-
ing light M
integrated in the indica-
erating conditions, the needle may ap-
tor comes on orange, accompanied by
proach this zone. This is not serious
a beep. Fill up as soon as possible.
unless the warning light
®
comes
on accompanied by a message on the
instrument panel and a beep.
1.72
DISPLAYS AND INDICATORS (4/7)
17
18
19
16
B
20
Instrument panel B
Coolant temperature indicator 16
Overspeed buzzer
It lights up when the ignition is switched
In normal use, indicator 16 should be
Depending on the vehicle and country,
on. In some cases, the appearance of a
before area 17. Under “intensive” op-
the
warning light is displayed
warning light is accompanied by a mes-
erating conditions, the needle may ap-
and a beep sounds. This sounds as
sage.
proach this zone. This is not serious
soon as the vehicle exceeds 74 mph
Depending on the vehicle, you can cus-
unless the warning light
®
comes
(120 km/h). The warning light remains
tomise your instrument panel with the
on accompanied by a message on the
on as long as the vehicle speed is over
content and colours of your choice.
instrument panel and a beep.
74 mph (120 km/h).
For vehicles fitted with a multimedia
screen, refer to the equipment instruc-
Speedometer 18
Rev counter 19
tions.
Depending on the style selected, the
(graduations x 1000)
For vehicles not fitted with a multimedia
display varies.
This is displayed differently according
screen ➥ 1.89.
to how the instrument panel is custom-
ised. Depending on the style selected,
it may not be displayed.
Driving style indicator 20 ➥ 2.28.
1.73
DISPLAYS AND INDICATORS (5/7)
25
21
24
23
22
Multimedia information 21
Fuel gauge 25
Depending on the vehicle, you can dis-
If the level is at the minimum, warn-
play information from the multimedia
screen (the compass, telephone, navi-
ing light M
integrated in the indica-
gation, etc.).
tor comes on orange, accompanied by
Please refer to the multimedia instruc-
a beep. Fill up as soon as possible.
tions for more information.
Estimated mileage with remaining
fuel 22
The value is displayed after driving
400 metres. ➥ 1.81.
Total mileage recorder 23 1.81
Trip computer 24 1.77
1.74
DISPLAYS AND INDICATORS (6/7)
26
C
29
28
27
31
30
Instrument panel C
Rev counter 26
Trip computer 29
(graduations x 1000)
➥ 1.77
It lights up when the ignition is switched
on. In some cases, the appearance of a
Coolant temperature indicator 28
Estimated mileage with remaining
warning light is accompanied by a mes-
fuel 30
In normal use, the indicator 28 should
sage.
The value is displayed after driving
be before the red zone 27. Under “in-
Depending on the vehicle, you can cus-
400 metres.
tensive” operating conditions, the
tomise your instrument panel with col-
➥ 1.81
needle may approach this zone. This
ours of your choice.
is not serious unless the warning light
Total mileage recorder 31
For vehicles fitted with a multimedia
®
comes on accompanied by a
➥ 1.81
screen, refer to the equipment instruc-
message on the instrument panel and
tions.
a beep.
For vehicles not fitted with a multimedia
screen ➥ 1.89.
1.75
DISPLAYS AND INDICATORS (7/7)
Fuel gauge 34
32
33
If the level is at the minimum, warn-
M
integrated in the indica-
ing light
tor comes on orange, accompanied by
a beep. Fill up as soon as possible.
34
Driving style indicator 32 2.28
Speedometer 33
Overspeed buzzer
Depending on the vehicle and country,
the
warning light is displayed
and a beep sounds. This sounds as
soon as the vehicle exceeds 74 mph
(120 km/h). The warning light remains
on as long as the vehicle speed is over
74 mph (120 km/h).
1.76
TRIP COMPUTER: general information (1/4)
A
B
C
1
2
1
2
1
2
4
3
3
4
3
4
Trip computer A, B or C
Depending on the vehicle, this includes
the following functions:
- distance travelled;
- journey settings;
- information messages;
- operating fault messages
(con-
- warning messages (connected to the
®
warning light);
– vehicle settings customisation menu
➥ 1.89.
All these functions are described on the
following pages.
1.77
TRIP COMPUTER: general information (2/4)
A
6
5
A
1
2
7
4
3
Vehicle fitted with trip computer A
The functions will be distributed in
zones 5, 6 and 7. The location of the
zones differs depending on the style
selected.
The 7 area is dedicated to driving aids
and cannot be customised.
Press the 1 switch to browse between
areas 5 and 6, then select the functions
by pressing the 2 or 3 switches repeat-
edly.
1.78
TRIP COMPUTER: general information (3/4)
5
6
B
C
1
2
1
2
4
3
7
4
3
Vehicle fitted with trip computer B
Vehicle fitted with trip computer C
The functions will be distributed in
Press the 1 switch as many times as re-
zones 5, 6 and 7.
quired to reach the “Vehicle” tab.
Press the 1 switch to browse between
Repeatedly press the 2 or 3 switches.
the zones and select the functions by
repeatedly pressing the 2 or 3 switches.
1.79
TRIP COMPUTER: general information (4/4)
Selections
Interpreting some of the
(the display depends on the vehicle
values displayed after
equipment and country)
resetting
a) Trip log, operating faults and infor-
The values showing average fuel con-
mation message readout;
sumption, range and average speed
will become more stable and reliable
b) Journey settings:
the further you travel after pressing the
- average fuel consumption;
reset button.
– current fuel consumption;
For the first few miles after pressing the
- estimated range with remaining fuel;
reset key you will notice that the range
increases as you travel. This range
- distance travelled;
takes into account the average fuel con-
- average speed;
sumption since the last time the reset
4
button was pressed. However, average
- LPG average fuel consumption;
consumption can decrease when:
- estimated range with remaining LPG
Resetting the trip mileage
- the vehicle stops accelerating;
fuel;
recorder and journey
- the engine reaches its operating
- LPG range;
parameters (reset button)
temperature (if the engine was cold
c) trip mileage recorder and average
With one of the trip parameters se-
when the reset key was pressed);
speed;
lected as the display, press and hold
- when driving from an urban area
the
4 switch “OK” until the display
d) Reset the tyre pressure;
onto the open road.
resets to zero.
e) set the time;
f) distance before service;
Automatic resetting of the
- distance before service;
journey parameters
- mileage before oil change.
Resetting occurs automatically when
g) Estimated range with remaining rea-
the maximum value of any of the pa-
gent.
rameters is exceeded.
1.80
TRIP COMPUTER: journey parameters (1/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
a) Trip log.
Successive display:
Vehicle Systems OK
- information messages (passenger airbag OFF etc.);
- operating fault messages (“Check injection”, etc.).
b) Current fuel consumption.
This value is displayed after a speed of approximately 20 mph (30 km/h) is
7.4 L/100
reached.
Average fuel consumption since the last reset.
The value is displayed after having travelled at least 400 metres since the last
5.8 L/100
reset.
c) Trip mileage recorder: distance travelled since the last reset.
112,4 km
Average speed since the last reset.
123.4 km/h
The value is displayed after driving 400 metres.
1.81
TRIP COMPUTER: journey parameters (2/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
Average LPG
d) Average LPG fuel consumption
--.- L/100
Range LPG
Estimated range with remaining LPG fuel.
--- km
Distance LPG
Distance travelled on LPG fuel since the last reset.
--- km
55.8 mph (90 km/h)
e) Current speed (depending on the vehicle).
1.82
TRIP COMPUTER: journey parameters (3/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
Tyre pressure init.
f) Reset the tyre pressure.
long press
➥ 2.38
g) Setting the time.
16:30
➥ 1.92
1.83















Content      ..     2      3      4      5     ..
