TRIP COMPUTER: journey parameters (4/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
On-board computer with mileage-
before-service message
f)
Mileage before service or oil change.
Mileage before service
Service in
With the ignition on and engine not running, access the “Mileage
30 000 km / 12 months
before service” information. When the distance value approaches its
limit, there are several possible scenarios:
- If the range is less than 930 miles (1,500 km) or one month: the
message “Service due” is displayed accompanied by the nearest
Service due in
term (distance or time);
300 km / 24 days
- range equal to 0 miles (0 km) or date of service reached: the mes-
sage “Service Required” is displayed accompanied by the warning
The vehicle requires a service as soon as possible.
Service Required
Reset: to reset the distance before the next service, press and hold button OK for approximately 10 seconds until the display
shows the mileage before service permanently.
Note: If a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the
event of an oil change, both the distance before the next service and the next oil change should be reset.
1.84
TRIP COMPUTER: journey parameters (5/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
On-board computer with distance
before next service message (cntd.)
f) Mileage before service or oil change.
Oil change in
Mileage before service
With the ignition on and the engine not running, access the mileage
30 000 km / 24 months
information to display the mileage before the next oil change.
Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,
door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can
therefore decrease more quickly in some cases than the actual distance travelled.
Reset: to reset the distance before the next service, press and hold button OK for approximately 10 seconds until the display
shows the mileage before oil change permanently.
Note: If a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the
event of an oil change, both the distance before the next service and the next oil change should be reset.
Top Up AdBlue before 2400 km
g) Estimated range with remaining reagent.
1.85
TRIP COMPUTER AND WARNING SYSTEM: information messages
These can help in the vehicle starting phase, or give information about a selection or a driving status.
Examples of information messages are given in the following pages.
Examples of messages
Interpreting the display selected
“Parking Brake ON”
Indicates that the parking brake has been applied.
Turn the steering wheel slightly whilst pressing the vehicle start button to unlock the steer-
“Turn Steering Wheel + START”
ing column.
“Vehicle Checks in Progress”
Displayed with the ignition on when the vehicle is running self-diagnostics.
1.86
TRIP COMPUTER AND WARNING SYSTEM: operating fault messages
soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.
They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The
warning light stays on. Examples of operating fault messages are given in the following pages.
Examples of messages
Interpreting the display selected
“Clean Diesel Filter”
Indicates the presence of water in the diesel filter; contact an approved Dealer
as soon as possible.
“Check vehicle”
Indicates a fault in one of the pedal sensors, battery management system or oil
level sensor.
“WARNING: Check Airbag”
Indicates a fault in the restraint system in addition to the seat belts. In the event
of an accident, it is possible that they may not be triggered.
“Check Anti- Pollution System”
- Indicates a fault in the vehicle’s particle filter system.
- Indicates a fault in the emissions reduction system when it is accompanied
by the
warning light. ➥ 1.119.
1.87
TRIP COMPUTER AND WARNING SYSTEM: warning message
These appear with the® warning light and require you to stop immediately, for your own safety, as soon as traffic
conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.
Some examples of warning messages are given below. Note: the messages appear on the display either individually or alter-
nately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.
Examples of messages
Interpreting the display selected
“WARNING: Engine Failure Risk”
Indicates an injection fault, the vehicle’s engine has overheated or there is a
serious engine fault.
“WARNING: Braking System”
Indicates a fault in the braking system.
“WARNING: Electric System”
Indicates a fault in the vehicle battery charging circuit (alternator etc.).
“Puncture”
Indicates that at least one wheel is punctured or severely underinflated.
“WARNING: Power Steering”
Indicates a problem with the steering.
1.88
VEHICLE SETTINGS CUSTOMISATION MENU (1/3)
Adjusting the settings
d) “Welcome”:
1
- External welcome;
Select a menu then the function to be
- Automatic fold-out of mirrors;
modified (the display depends on the
- Interior welcome;
vehicle equipment and country):
- Courtesy light auto mode.
a) “Driving”:
Depending on the function, select:
- Indicator volume;
- “ON” or “OFF” to activate or deacti-
- Free-wheel;
vate,
- ...
or
b) “Access”:
- a duration to adjust the time the lights
- Unlocking the driver’s door;
are switched on (e.g. for the “Follow-
– Lock doors during driving;
me-home lighting” function).
– Opening/closing in hands-free
Please refer to the multimedia instruc-
mode;
tions for further information.
- Remote locking/Approach unlock-
ing;
Depending on the vehicle equipment,
- Distance locking sound;
this function allows you to activate/de-
- Silent mode;
activate and adjust some of the vehi-
- Automatic locking;
cle’s functions.
c) “Wiping and lighting”:
- Follow-me-home lighting;
Vehicles fitted with a
- Wiping in reverse;
multimedia screen 1
- Automatic front wiping;
- Wiping after washing;
Accessing the settings menu
Refer to the multimedia instructions for
information on accessing the various
settings.
For safety reasons, carry
out any adjustments when
the vehicle is not being
driven.
1.89
VEHICLE SETTINGS CUSTOMISATION MENU (2/3)
Adjusting the settings
d) “DRIVING ASSIST”:
2
- Lane departure warning sound
Navigate using the 4 or 5 control to
volume;
select the function to be modified and
- Lane departure warning sensitiv-
press 6 “OK” to confirm (display may
ity;
vary according to vehicle equipment
- Lane departure warning vibration;
and country):
- Lane keeping assist sensitivity;
a) “DASHBOARD”:
- Blind spot warning;
- Language;
- Active braking;
- Unit;
- Overspeed warning;
3
4
- Style;
- Distance warning.
- Colour.
e) “LIGHTING”:
b) “VEHICLE”:
- Courtesy light auto mode;
- Rear windscreen wiping in re-
- Automatic follow-me-home light-
6
verse gear;
5
ing;
- Automatic windscreen wiping;
- Follow-me-home lighting: XX sec-
Vehicles not fitted with a
- Front/rear drip wiping function;
onds.
multimedia screen
- Exterior welcome.
f)
“ACCESS”:
c) “PARKING ASSIST”:
- Lock doors during driving;
Accessing the settings menu on
- Beep volume.
- Opening/closing in hands-free
display 2
mode;
With the vehicle stationary, press
- Unlocking the driver’s door;
switch 3 as many times as required to
- Automatic re-locking;
reach the “Vehicle” tab. Press repeat-
- Silent locking;
edly on the 4 or 5 switch to access the
- Automatic opening/closing;
“Settings” menu, then confirm by press-
- Automatic deployment of door
ing 6 “OK”.
mirrors.
g) “RESET”.
=
function activated
<
function deactivated
1.90
VEHICLE SETTINGS CUSTOMISATION MENU (3/3)
To exit the menu, press 4 or 5 to access
“BACK” and confirm by pressing 6
“OK”. It may be necessary to carry out
this operation more than once.
3
4
6
5
Once a line has been selected, press 6
“OK" to adjust the function.
If you select either “PARKING ASSIST”
then “VOLUME”, or “DASHBOARD”
then “LANGUAGE”, you will have to
make a further selection (sound volume
of the parking distance control or in-
strument panel language). In this case,
make your selection and confirm it by
pressing 6 “OK”, the selected value is
shown by a =
in front of the line.
The vehicle settings personalisation
menu cannot be used when driv-
ing. At a speed exceeding 12 mph
(20 km/h), the instrument panel dis-
play switches automatically back to
trip computer and warning system
mode.
1.91
CLOCK AND EXTERIOR TEMPERATURE (1/2)
1
6
2
3
4
5
Vehicles fitted with a multimedia
Vehicles not fitted with a multimedia
Set the hour using the 3 or 4 control,
screen
screen
then wait for three seconds: the min-
utes will flash.
The time and exterior temperature are
Press the switch 2 as many times as re-
displayed on the multimedia screen 1.
quired to reach the “Vehicle” tab.
Set the minutes using the 3 or 4 control,
then wait for three seconds: the flash-
Refer to the multimedia instructions.
Repeatedly press control 3 or 4 to set
ing stops and the time setting is com-
the 6 clock.
plete.
Press and hold switch 5 “OK” until the
time display flashes.
1.92
CLOCK AND EXTERIOR TEMPERATURE (2/2)
External temperature
indicator
Depending on the vehicle, If the
electrical supply is cut (battery dis-
Special note:
connected, broken supply wire,
When the external temperature is be-
etc.), the clock will automatically
tween -3°C and +3°C, the °C symbols
go back to the right time after a few
flash (indicates risk of ice).
minutes once the system is capable
of receiving information GPS.
External temperature
indicator
As ice formation is related
to climatic exposure, local
air humidity and temperature, the
external temperature alone is not
sufficient to detect ice.
1.93
STEERING WHEEL, POWER-ASSISTED (1/2)
Activating the function
With the ignition on, press the 3 switch:
the switch warning light illuminates.
Deactivating the function
2
- Automatic:
The function switches off automatically
after the regulation phase of approxi-
mately 30 minutes. The 3 switch warn-
ing light remains on.
3
1
Note: if the function has switched off
automatically, press the switch 3 twice
to reactivate it.
If switch 3 is not pressed again, the
function will be reactivated the next
Adjusting the steering wheel
Steering wheel heating
time the ignition is switched on.
height and depth
(depending on vehicle)
- Manually:
Lower the lever 1 and position the
This function heats the steering
steering wheel in the required position.
wheel 2.
To deactivate the function during the
regulation phase, press the switch 3.
Then, raise the lever fully, beyond the
Operating principle
The 3 switch warning light goes out.
point of resistance to lock the steering
When the temperature is reached, the
wheel.
function regulates the temperature of
Make sure that the steering wheel is
the heated areas for approximately
correctly locked.
30 minutes and then switches off auto-
matically.
For safety reasons, only
adjust the steering wheel
when the vehicle is station-
ary.
1.94
STEERING WHEEL, POWER-ASSISTED (2/2)
Power-assisted steering
Note: the power-assisted steering de-
pends on the driving mode selected in
Never drive with an inadequately
the “MULTI-SENSE” menu (➥ 3.2).
charged battery.
Variable power-assisted steering
The variable power assisted steering
system is equipped with an electronic
control system which alters the level of
assistance to suit the vehicle speed.
Steering is made easier during parking
manoeuvres (for added comfort) while
the force needed to steer increases
progressively as the speed rises (for
enhanced safety at high speeds).
Special feature of Stop and Start
With the engine on standby, power-
assisted steering is no longer opera-
tional. In this case, it returns to its origi-
nal state when the engine is restarted
or when the speed exceeds 1 mph
(1 km/h) (hill, slope etc.).
Never leave the steering wheel on
Never turn the steering wheel when
full lock when the vehicle is station-
the vehicle battery is disconnected.
ary.
Never switch off the igni-
With the engine switched off, or if
tion when travelling down-
there is a system fault, it is still pos-
hill, and avoid doing so in
sible to turn the steering wheel. The
normal driving (assistance
force required will be greater.
is not provided).
1.95
REAR VIEW MIRRORS (1/2)
Electrical folding mirrors
Special case
When the rear view mirror has been
The door mirrors will fold-out automati-
manually deployed or folded back, it is
cally when the vehicle is unlocked. The
possible to reset it to a usage position.
door mirrors fold in when the vehicle is
locked.
To do this, press the 3 switch. A me-
chanical tapping noise can be heard
Note: you can deactivate/activate the
from the door mirror.
door mirrors folding mechanism ➥ 1.89.
1
If a tapping noise cannot be heard,
You can force folding by pressing the 3
press once again on 3 switch until the
switch. In this situation, the door mirrors
tapping noise can be heard from the
will remain folded until the 3 button is
2
door mirror.
pressed again, regardless of automatic
folding.
3
Door mirrors
Adjustment
For safety reasons, carry
When you select the door mirror using
out any adjustments when
the 2 switch, the built-in warning light
the vehicle is not being
on the switch will appear. Then use
driven.
the 1 button to adjust it to the desired
position.
Heated door mirrors
Objects observed in the
Mirror de-icing is carried out at the
rear view mirror glass are
same time as rear screen de-icing.
actually closer than they
➥ 3.6 ➥ 3.12.
appear. For your safety,
take this into account in order to
correctly assess the distance before
any manoeuvre.
1.96
REAR VIEW MIRRORS (2/2)
4
Interior rear view mirror
Its position can be adjusted.
For safety reasons, carry
Rear view mirror with lever 4
out any adjustments when
When driving at night, to avoid being
the vehicle is not being
dazzled by the headlights of the vehicle
driven.
behind, depress the little lever located
behind rear view mirror 4.
Rear view mirror without lever 4
Objects observed in the
rear view mirror glass are
The rear view mirror automatically dark-
actually closer than they
ens when you are being followed by a
appear. For your safety,
vehicle using main beam headlights or
take this into account in order to
in very bright lighting.
correctly assess the distance before
any manoeuvre.
1.97
FRONT HEADRESTS
To raise the headrest
Raise it to its highest position (tilt the
seatback backwards if necessary).
A
Press button 2 and lift the headrest to
release it.
3
1
To refit the headrest
Check that the headrest rods are
clean 3.
2
Insert the headrest rods into the holes 1
(tilt the seatback backwards if neces-
sary). Lower the headrest until it locks
and press button 2 to adjust to the de-
sired height. Check that each rod 3 on
To raise the headrest
the seatback is securely locked.
Pull the headrest upwards to the de-
sired height. Check that it is correctly
locked.
To lower the headrest
Press button 2 and guide the headrest
down to the desired height. Check that
The headrest is important
the bonnet is correctly locked.
for safety. Ensure that it is in
place and in the correct po-
sition: the top of the head-
rest should be as close as possible
to the top of the head and there must
be a minimal distance between the
head and the headrest A.
1.98
EXTERIOR LIGHTING AND SIGNALS (1/6)
Depending on the vehicle, the dipped
1
2
beam headlights come on automati-
cally after several sweeps of the wind-
1
screen wiper blades.
3
Side lights
Dipped beam
š
k
headlights
Turn ring 2 until the symbol is
opposite mark 3.
Manual operation
This indicator light on the instrument
Turn ring 2 until the symbol is opposite
panel comes on.
mark 3. This indicator light on the in-
strument panel comes on.
Before driving at night,
check that the electrical
Daytime running lights
Automatic operation
equipment is operating cor-
function
(depending on the vehicle)
rectly and adjust the head-
The daytime running lights come on
light beams (if your vehicle is not
Turn ring 2 until the AUTO symbol is op-
automatically with no action on stalk 1
carrying its normal load).➥ 1.106. As
posite mark 3: with the engine running,
when the engine is started, and they go
a general precaution, check that
the dipped beam headlights switch on
off once the engine is switched off.
the lights are not obscured (by dirt,
or off automatically depending on the
mud, snow or objects being trans-
brightness of the light outside, without
ported).
any action on stalk 1.
1.99
EXTERIOR LIGHTING AND SIGNALS (2/6)
During deactivation of the main beam
The main beam headlights come on au-
1
2
headlights, the dipped beam headlights
tomatically if:
return to their original position.
- exterior light is weak;
- no other vehicles or lighting are de-
tected;
Automatic main beam
- the vehicle speed is above approxi-
headlights
mately 25 mph (40 km/h).
Depending on the vehicle, this system
If any of the above conditions are not
switches the main beam headlights on
fulfilled, the system switches to dipped
and off automatically. It uses a camera
beam headlights.
3
located behind the interior rear-view
Note: make sure the windscreen is not
mirror to detect vehicles that are being
obscured (dirt, mud, snow, condensa-
followed and those coming in the oppo-
tion etc.).
site direction.
To activate automatic main beam
headlights:
Main beam headlights
á
turn the ring 2 until the AUTO symbol
With the engine running and
appears opposite the 3 mark and push
the dipped beam headlights lit, push
stalk 1. This indicator light on the instru-
the stalk 1. The
warning light is
ment panel comes on.
The system may encounter difficul-
illuminated on the instrument panel.
To return to the dipped headlight posi-
ties under certain conditions, inclu-
tion, pull the stalk 1 towards you again.
ding:
- extreme weather conditions (rain,
snow, fog, etc.);
“Raise lights during driving”
- obstruction in front of the wind-
function
screen or camera;
When the main beam headlights are
- when a following or oncoming ve-
activated, the “Raise lights during driv-
hicle has weak or hidden lighting;
ing” function improves driver visibil-
- incorrect settings for the front
ity by automatically raising the dipped
headlights;
beam headlight and the main beam
- reflective systems;
headlights.
- ...
1.100
EXTERIOR LIGHTING AND SIGNALS (3/6)
Operating faults
1
2
When the message “Check Automatic
Lighting” appears on the instrument
panel, the system is deactivated.
Consult an approved dealer.
3
Using the portable naviga-
tion system at night in the
windscreen area below the
Automatic main beam
camera may disturb the op-
headlights (continued)
eration of the “automatic main beam
headlights” system (risk of reflection
To deactivate automatic main beam
on the windscreen).
headlights:
- turn ring 2 to a position other than
AUTO;
or
- pull the stalk 1.
The “automatic main beam
headlights” system should
Warning light
goes out on the in-
under no circumstances be
strument panel.
used to replace driver atten-
Note: the main beam headlights will be
tion and responsibility with regard
activated upon deactivation of the au-
to vehicle lighting and adapting to
tomatic main beam headlights function.
light, visibility and traffic conditions.
1.101
EXTERIOR LIGHTING AND SIGNALS (4/6)
Lights-on reminder buzzer
Welcome and goodbye
2
If the lights are on after the engine is
function
switched off, a warning beep sounds
(depending on the vehicle)
when the driver’s door is opened to
Once the function is activated, the day-
warn you that the lights are still on (to
time running lights and the rear side
avoid battery discharge or other prob-
lights will light up automatically upon
lems).
detection of the card or when the vehi-
cle is unlocked.
Operating faults
They switch off automatically:
If the
“Check lighting” message ap-
- approximately one minute after light-
ing up;
- when starting the engine based on
the k
warning light flashes on the
the position of the lighting stalk;
instrument panel, this indicates a light-
ing fault.
or
Switching off the lights
Consult an authorised dealer.
- upon locking the vehicle.
The lights will go out automatically
when the engine is switched off, the
driver’s door is opened or the vehicle
Activating/deactivating the
is locked. In this case, the next time
function
the engine is started the lights will be
To activate or deactivate the external
switched back on according to the posi-
welcome function, please see the multi-
tion of the ring 2.
media instructions.
Note: if the fog lights are lit, the lights
Select “ON” or “OFF”.
are not switched off automatically.
1.102
EXTERIOR LIGHTING AND SIGNALS (5/6)
With the engine lights switched off,
2
the 2 ring in AUTO, pull the lever 1 to-
1
wards you: the side lights and dipped
beam headlights will switch on for ap-
proximately 30 seconds along with the
š
and k
warning lights on the
instrument panel.
To increase this duration, you may pull
the stalk up to four times (total time re-
stricted to approximately two minutes).
On the instrument panel, the message
“lighting on _ _ _” followed by the re-
maining time will appear as confirma-
tion. You can then lock your vehicle.
To switch off the lights before they go
“See-me-home lighting”
out automatically, turn ring 2 to any po-
function
sition, then return it to position AUTO.
This function enables you to briefly
switch on the side lights and dipped
beam headlights (e.g. to provide light
when opening a gate).
1.103
EXTERIOR LIGHTING AND SIGNALS (6/6)
Rear fog lights
Cornering lights
1
2
(depending on vehicle)
Turn centre ring 4 on the stalk
3
until the symbol faces mark 3, then re-
When driving in forward gear, with
4
lease it.
the vehicle speed below approxi-
mately 25 mph (40 km/h), whenever
Operation of the fog lights depends on
the dipped beam headlights are on:
the exterior lighting selected, and an in-
under certain conditions (the steering
dicator light will light up on the instru-
wheel at an angle, the indicator lights
ment panel.
on etc.), when turning a corner one of
Do not forget to switch off the fog lights
the front fog lights will switch on to light
when they are no longer needed, to
the inside of the bend.
avoid inconveniencing other road
When reverse gear is engaged and
users.
the dipped beam headlights are on the
two front fog lights illuminate automati-
Switching off the lights
cally.
Front fog lights
Turn the centre ring 4 again until mark 3
Note: when shifting from reverse gear
g
Turn centre ring
4
on
the
is opposite the symbol for the fog lights
into forward gear (for example during a
stalk 1 until the symbol faces mark 3,
that you wish to switch off. The corre-
parking manoeuvre), the two fog lights
then release it.
sponding indicator light on the instru-
are activated until the vehicle exceeds
ment panel goes out.
approximately 6 mph (10 km/h).
Operation of the fog lights depends on
the exterior lighting position selected,
The front and rear fog lights switch off
and an indicator light will light up on the
when the exterior lights are switched
instrument panel.
off.
When driving in fog or snow, or when transporting objects which are higher than the roof, the headlights do not come on au-
tomatically.
Switching on the fog lights remains the responsibility of the driver: the indicator lights on the instrument panel inform you
whether the fog lights are lit (indicator light on) or not (indicator light not on).
1.104















Content      ..     3      4      5      6     ..
