Renault Talisman (2016 year). Instruction - part 7





1.98

REAR SCREEN WASH/WIPE

(2/2)

In the event of obstacles present on the

rear window (dirt, snow, etc.), the wiper

will try to sweep away all the obstacles.

If an obstacle prevents the blade from

moving, it can be stopped. Remove the

obstacle, wait for around 30 seconds

and reactivate the wiper using the wiper

stalk.

Precautions
–

In the event of ice, check whether

the blades are stuck to the wind-

screen before operating the wiping

mechanism. If you activate the wiper

while the blade is blocked by ice, you

risk damaging both the blade and the

wiping motor.

–

Do not activate the wipers on a dry

screen. This will lead to premature

wear or damage to the blades.

Activation/deactivation of the rear

screen wiper
Engaging reverse gear triggers inter-

mittent wiping (if the front wipers are in

operation). If your vehicle is fitted with

a vehicle settings customisation menu,

you can opt to activate or deactivate

this function. To do this, refer to the in-

formation on the “Vehicle settings cus-

tomisation menu” in Section 1; “Rear

wiping in reverse gear”.
For vehicles not fitted with a settings

customisation menu, you can have this

function deactivated by an authorised

dealer.

p

Rear screen wash/wipe

With the ignition on, push and

hold stalk 1, then release.
A longer action will trigger three sweeps

of the wipers followed, a few seconds

later, by a fourth, in addition to the wind-

screen washer.

1

1.99

Fuel grade

Use a high-grade fuel that complies

with the legislation in force in each

country and which must comply with

the specifications given on the label

on the cover 1. Please refer to the in-

formation on “Engine specifications” in

Section 6.

Diesel versions

Only use diesel fuel which complies

with the information on the label located

inside the cover 1.

Petrol versions

It is essential to use unleaded petrol.

The octane rating (RON) must comply

with the information given on the label

on the cover 1. Refer to Section 6 for

information on “Engine specifications”.

FUEL TANK

(1/3)

Useable fuel tank capacity:

– Approximately  11.22 gallons

(51 litres) for the petrol versions;

– Approximately  11.44 gallons

(52 litres) for the diesel versions

with two-wheel steering mode;

– Approximately  10.34 gallons

(47 litres) for the diesel versions

with four-wheel steering mode.

With the vehicle unlocked, to open

cover 1, press area A then release. The

cover 1 opens.

Valve 2 is integrated into the filler pipe.

For details on filling the fuel tank, refer

to the information on “Filling with fuel”.

To close it, press on the fuel filler flap by

hand, as far as it will go.

Never press valve 2 with

your fingers.
Do not wash the filler

area with a high-pressure

washer.

Do not mix even small amounts of petrol (unleaded or E85) with diesel.

Do not use ethanol-based fuel if your vehicle is not compatible with this

fuel.

Do not add additive to the fuel –otherwise you risk damaging the engine.

1

A

2

1

1.100

FUEL TANK

(2/3)

Filling with fuel

Insert the nozzle to open the valve 2

and insert it fully before turning it on to

fill the fuel tank (risk of splashing).
Keep the nozzle in this position through-

out the entire filling operation.
When the pump cuts out automatically

at the end of the filling procedure, a

maximum of two further filling attempts

may be made, as there must be suffi-

cient space in the fuel tank to allow for

expansion.
Make sure that no water enters the fuel

tank during filling. The valve 2 and its

surround must remain clean.

2

Petrol versions
Using leaded petrol will damage the

antipollution system and may lead to a

loss of warranty.
To ensure that the fuel tank is not filled

with leaded petrol, the fuel tank filler

neck consists of a restrictor fitted with

a safety system which only allows

a nozzle for unleaded petrol to be

used (at the pump).

Vehicle fitted with the Stop and

Start function
To fill up with fuel, the engine must

be stopped (and not on standby):

stop the engine (Please See

“Starting, stopping the engine” in

Section 2).

1.101

Vehicles with RENAULT card
With the card RENAULT in the pas-

senger compartment, press the start

button  3 without pressing any of the

pedals. Wait a few minutes before start-

ing. This will enable the fuel circuit to

be primed. If the engine does not start,

repeat the procedure.
If the engine does not start after several

attempts, please contact an authorised

dealer.

No modifications what-

soever are permitted on

any part of the fuel supply

system (electronic units,

wiring, fuel circuit, injectors, pro-

tective covers, etc.) as this may be

dangerous (unless undertaken by

qualified Network personnel).

3

FUEL TANK

(3/3)

Running out of fuel on diesel

versions

Vehicles with key/remote control
–  Put the ignition key in the “On” posi-

tion M (please see the information on

the "Ignition switch" in Section 2) and

wait for a few minutes before start-

ing, to enable the fuel circuit to be

primed;

–  turn the key to position D. If the

engine does not start, repeat the pro-

cedure.

–  If the engine does not start after sev-

eral attempts, please contact an au-

thorised dealer.

Persistent smell of

fuel

If you notice a persistent

smell of fuel you should:

–  stop the vehicle as soon as traf-

fic conditions allow and switch off

the ignition;

– switch on the hazard warning

lights and ask your passengers

to leave the vehicle and to keep

away from traffic;

–  contact an authorised dealer.

1.102

2.1

Section 2: Driving

(Advice on use relating to fuel economy and the environment)

Running in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2

Ignition switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3

Starting/stopping the engine: vehicle with key/remote control unit . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4

Starting/stopping the engine: vehicle with RENAULT CARD  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5

Stop and Start Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.8

Special features of petrol versions  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.12

Special features of Diesel versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.13

Gear lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.14

Electronic parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.15

Driving advice, Eco-driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.18

Maintenance and antipollution advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.23

Environment  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.24

Tyre pressure monitoring system  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.25

Driver correction devices/aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.28

Lane departure warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.40

Blind spot warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.43

Safe distance alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.47

Speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.49

Speeding alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.52

Cruise control  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.55

Adaptive cruise control  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.59

Parking distance control  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.66

Reversing camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.71

Assisted parking  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.74

Piloted dampened suspension  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.78

Automatic gearbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   2.79

2.2

RUNNING IN

Petrol version

For the first 600 miles (1,000 km), do

not exceed 78 mph (130 km/h) in the

highest gear, or 3,000 to 3,500 rpm.
You may only expect top performance

from your vehicle after approximately

1,800 miles (3,000 km).
Service intervals: refer to the

Maintenance Document for your vehi-

cle.

Diesel version

For the first 1,000 miles (1,500 km),

do not exceed 80 mph (130 km/h) in

the highest gear, or 2,500 rpm. After

completing this mileage you may drive

faster, although you may only expect

top performance after approximately

3,600 miles (6,000 km).
During the running in period, do not ac-

celerate hard while the engine is still

cold and do not let the engine over-rev.
Service intervals: refer to the

Maintenance Document for your vehi-

cle.

2.3

“Ignition” position ON 2
The ignition is switched on: Any acces-

sories (radio etc.) can be used.

“Start” position START 3
If the engine fails to start at the first

attempt, the key must be turned back

before the starter can be activated

again. Release the key as soon as the

engine starts.
Note:  on diesel versions, several se-

conds may pass between turning the

key and the engine starting to allow for

engine preheating.

Ignition switch

Off position LOCK 0 (steering lock

applied)
To lock: remove the key and turn the

steering wheel until the steering column

locks.
To unlock: turn the key and the steering

wheel slightly.

IGNITION SWITCH: vehicle with key

2.4

STARTING, STOPPING THE ENGINE: vehicle with key

Starting the engine

Petrol versions

–

Activate the starter without ac-

celerating;

–

release the key as soon as the

engine starts.

É

Diesel versions



–

Turn the ignition key to the “ON"

position  2 and hold this position

until the engine preheating light

goes off;

–

turn the key to the start position

“START" 3 without pressing the

accelerator;

–

release the key as soon as the

engine starts.

Special note: if starting the engine

when the outdoor temperature is very

low (below - 10 ° C): hold down the

clutch pedal until the engine starts.

Stopping the engine

With the engine idling, turn the key to

the “LOCK" position 0.

Never start your vehicle

while freewheeling on a

gradient. Risk of non-ac-

tivation of power-assisted

steering.
There is a risk of accidents.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing, etc. and the passive safety de-

vices such as air bags and preten-

sioners will no longer operate.

2.5

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(1/3)

The RENAULT card must be inserted in

detection zone 1.
To start:
–  vehicles with an automatic gearbox,

place the lever in position P, depress

the brake pedal   and press button 2;

– vehicles with a manual gearbox,

depress the brake or clutch pedal

and press the button 2. If a gear is

engaged, the vehicle may only be

started by depressing the clutch

pedal.

“Hands-free” starting with

the tailgate open

In this case, the RENAULT card should

not be located in the boot, to avoid any

risk of loss.

2

1

Special features
–  If one of the starting conditions is not

met, the message “Press brake +

START”, “Press clutch + START” or

“Select P” is displayed on the instru-

ment panel;

–  in some cases it might be necessary

to move the steering wheel while

pressing the start button 2 to assist

in unlocking the steering column.

The message “Turn steering wheel +

START” warns of this.

2.6

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(2/3)

Depress the brake or clutch pedal, then

place the RENAULT 3 card (logo side)

in contact with the start button 2 for

around 2 seconds. Press the 2 button

to start the vehicle. The message goes

out.

2

Accessories function

(switching on the ignition)
Once you have gained access to your

vehicle, you may use some of its func-

tions (radio, navigation, wipers, etc.).
To use the other functions, with the

RENAULT card in the passenger com-

partment, press button 2 without press-

ing the pedals.

3

Operating faults

In certain cases, the RENAULT  “hands-

free” card may not work:
–  when the RENAULT card battery is

drained, etc.;

–  near to appliances operating on the

same frequency as the card (moni-

tor, mobile phone, video game, etc.);

–  vehicle located in a high electromag-

netic radiation zone.

The message “Place card close START

and push” appears on the instrument

panel.

2.7

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(3/3)

If the RENAULT card is no longer in the

passenger compartment when you try

to switch the engine off, the message

“No keycard Press and hold” appears

on the instrument panel: press the

button 2 for longer than two seconds.

If the card is no longer in the passen-

ger compartment, make sure you can

retrieve it before pressing and holding

the button. Without the card  RENAULT

, you will not be able to start.
With the engine switched off, any ac-

cessories being used (radio, etc.) will

continue to function for approximately

10 minutes.
When the driver’s door is opened, the

accessories stop working.

Conditions for stopping the

engine

The vehicle must stationary, with the

lever positioned in N or P for vehicles

with an automatic transmission.
With the RENAULT card in the vehicle,

press the 2 button: the engine will stop.

The steering column is locked when the

driver’s door is opened or the vehicle

is locked.

When you leave your vehi-

cle, especially if you have

your RENAULT card with

you, check that the engine

is completely switched off.

2

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing, etc. and the passive safety de-

vices such as air bags and preten-

sioners will no longer operate.

2.8

For manual gearboxes:
–  the gearbox is in neutral;

and

–  the clutch pedal is released. If the

warning light

 flashes, this

means that the clutch pedal is not

sufficiently released;

and

–  the vehicle speed is less than ap-

proximately 7 mph (3 km/h).

For all vehicles:

Warning light

 on the instru-

ment panel is lit when the engine is on

standby.
The vehicle equipment remain opera-

tional while the engine is stopped.

STOP AND START FUNCTION

(1/4)

This system enables a reduced fuel

consumption and lower greenhouse

gas emissions.

The system is activated automatically

when the vehicle is started.

While driving, the system stops the

engine (standby) when the vehicle is

at a standstill (traffic jam, traffic lights,

etc).

Conditions for engine

standby

The vehicle has set off from where it

was parked;
For automatic gearboxes:

–  the gearbox is in position D, M or N;

and

–  the brake pedal is depressed (suffi-

ciently hard);

and

– the accelerator pedal is not de-

pressed;

and

–  the vehicle’s speed is zero for around

1 second.

The engine remains on standby if posi-

tion P is selected, or if position N is se-

lected with the handbrake engaged and

the brake pedal released.

If the engine is put in

standby, the electronic par-

king brake (depending on

the vehicle) is not applied

automatically.

Engine on standby - braking

assistance is no longer ope-

rational.

The ignition must be

switched off before leaving

the vehicle (please see the

information on «Starting,

stopping the engine» in Section 2).

If the engine stalls while the system

is in operation, pressing the clutch

pedal right down will start it again.

Keep your vehicle station-

ary when the engine is

on standby (shown by the

warning light

 on the

instrument panel).

Engine on standby - power-

assisted steering is no

longer operational.

2.9

Conditions for coming out of

engine standby

For automatic gearboxes:
–  the brake pedal is released, position

D or M engaged or;

–  the brake pedal is released, position

N engaged and the parking brake off

or;

–  the brake pedal is pressed again,

with position P engaged or position

N engaged with the handbrake ap-

plied, or;

–  position R is engaged or;
–  the accelerator pedal is depressed

or;

–  in manual mode, the gear lever is

moved towards + or -.

For manual gearboxes:
–  the gearbox is in neutral and the

clutch pedal is slightly depressed, or

–  the engine is in gear and the clutch

pedal is pressed right down.

To fill up with fuel, the engine must

be stopped (and not on standby):

stop the engine (please see

«Starting, stopping the engine»).

STOP AND START FUNCTION

(2/4)

Preventing the engine from

standing by

In certain situations, such as negotiat-

ing a crossroads for instance, it is pos-

sible (with the system activated) to keep

the engine running so as to be ready to

move off quickly.
Automatic gearbox:
Keep the vehicle stationary without

pressing too hard on the brake pedal.
Manual gearbox:
Keep the clutch pedal pressed right

down.

Special note: depending on the vehi-

cle, if you switch off the ignition when

the engine is on standby, the warning

light

Ä

 is displayed for a few sec-

onds on the instrument panel.

2.10

STOP AND START FUNCTION

(3/4)

Conditions preventing the

standby of the engine

Certain conditions prevent the system

from using the engine standby function,

including when:
For vehicles with a RENAULT card:
–  the driver’s door is not closed;
–  the driver’s seatbelt is not fastened;
For all vehicles:
–  reverse gear is engaged;
–  the bonnet is not locked;
–  the outdoor temperature is too low

or too high (less than around 5°C or

higher than around 30°C);

–  the battery is not sufficiently char-

ged;

–  the difference between the vehicle

interior temperature and the automa-

tic climate control instruction is too

high;

–  parking distance control is in opera-

tion;

– for vehicles with automatic gear-

boxes, the gradient is steeper than

approximately 12%;

–  the «Clear View» function is activa-

ted (please see «Automatic climate

control» in Section 3);

–  the engine temperature is too low;
–  the emission control system is being

regenerated;

– ...

Warning light

 is displayed on the

instrument panel. This notifies you that

engine standby is not available.

Deactivate the Stop and

Start function when perfor-

ming any operations in the

engine compartment.

Special cases for vehicles

with a RENAULT card

With the engine on standby (traffic jam,

traffic lights, etc.), if the driver unfastens

the seat belt and opens the driver’s

door, or gets out of the seat, the ignition

is switched off.
The assisted parking brake is applied

automatically.
To restart and reactivate the Stop and

Start system, start the engine (please

refer to “Starting, stopping the engine”

in Section 2).

Special case of vehicles with

a key

With the engine on standby (traffic

jam, traffic lights, etc.), if you get out of

the vehicle, a beep warns you that the

engine is on standby and has not been

stopped.

2.11

STOP AND START FUNCTION

(4/4)

Special feature of the automatic

engine re-start
Under certain conditions, the engine

can restart on its own in order to gua-

rantee your safety and comfort.
This can occur especially when:
–  the outdoor temperature is too low or

too high (less than around 0 °C or

higher than around 30 °C);

–  the «Clear View» function is activa-

ted (please see «Automatic climate

control» in Section 3);

–  the battery is not sufficiently char-

ged;

–  the vehicle speed is above 3 mph

(5 km/h) (downhill slope, etc.); ;

– repeated pressing on the brake

pedal or braking system require-

ment;

– ...

1

2

Deactivating, activating the

function

Press 1 to deactivate the function. The

message “Stop & Start deactivated” will

appear on the instrument panel and the

integrated warning light 2 on the switch

will light up.

Pressing again will reactivate the

system. The message «Stop & Start

activated» will appear on the instru-

ment panel and the integrated warning

light 2 on switch 1 will go out.

Note: With the engine on standby,

press switch 1 to automatically re-

start the engine.

The system is automatically reacti-

vated each time the vehicle is started

(see “Starting, stopping the engine” in

Section 2).

Operating faults

When the message “Check Stop &

Start” appears on the instrument panel

and the integrated warning light 2 lights

up on the switch 1, the system is deac-

tivated.
Consult an approved dealer

Before getting out of the

vehicle, you must switch off

the ignition (please see sec-

tion on “Starting, stopping

the engine”).

Special feature of vehicles with

a key: for some of these condi-

tions the automatic restarting of the

engine is inhibited if a front door is

open.















Content   ..  5  6  7  8   ..
