Renault Talisman (2016 year). Instruction - part 5





1.66

1

Display selection keys 2

Scroll through the following information

by repeated short presses on button 2

(the display depends on the vehicle

equipment and country):
a)  total mileage and trip mileage re-

corder;

b) journey parameters:

–  average fuel consumption;

–

current fuel consumption;

– estimated range;

– distance travelled;

– average speed;

c) mileage before service;
d) reset the tyre pressure;
e) trip log, operating faults and informa-

tion message readout.

On-board computer 1

Depending on the vehicle, this includes

the following functions:
– distance travelled;
– journey parameters;
– information messages;
–  operating fault messages (associ-

ated with the

©

 warning light);

–  warning messages (associated with

the

®

 warning light);

All these functions are described on the

following pages.

ON-BOARD COMPUTER: general information (1/2)

2

1.67

3

ON-BOARD COMPUTER: general information (2/2)

Interpreting some of the

values displayed after

resetting

The values showing average fuel con-

sumption and average speed will

become more stable and reliable the

further you have travelled since the last

time the Reset button was pressed.
The average fuel consumption may de-

crease when:
–

the vehicle stops accelerating;

–

the engine reaches its operating

temperature (if the engine was cold

when the reset key was pressed);

–

when driving from an urban area

onto the open road.

Automatic resetting of the

journey parameters

Resetting occurs automatically when

the maximum value of any of the pa-

rameters is exceeded.

Trip mileage resetting

With “trip mileage recorder” selected

on the display, press key OK 3 until the

mileage recorder resets to zero.

Resetting the journey

parameters (reset button)

with the display showing one of the trip

settings, press key OK 3 until the dis-

play is reset to zero.

1.68

ON-BOARD COMPUTER: trip settings

(1/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

101778 km

a) Total mileage and trip mileage recorder.

   112.4 km

Middle

b) Journey parameters:

Average fuel consumption.

The value is displayed after having travelled at least 400 metres since the last

reset.

5.8 L/100

Current

  Current fuel consumption.

This value is displayed after a speed of approximately 20 mph (30 km/h) is reached.

7.4 L/100

1.69

ON-BOARD COMPUTER: trip settings

(2/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

Range

b) Journey parameters (continued):
  Estimated range with remaining fuel.

    The value is displayed after driving 400 metres.

541 km

Distance

 Distance

travelled since last reset.

522 km

Middle

 Average

speed since the last reset.

    The value is displayed after driving 400 metres.

123.4 km/H

1.70

ON-BOARD COMPUTER: trip settings

(3/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with mileage-

before-service message

c) Mileage before service or oil change.

Mileage before service

With the ignition switched on, the engine not running and

the display set to “Reichweite bis zur Wartung”, press button

OK  for approximately 5 seconds to display the mileage before

service (distance or time to the next service). When the distance

value approaches its limit, there are several possible scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed along

with the nearest limit (distance or time);

–

range equal to 0 km/miles or service date reached: the

message “Service required” is displayed accompanied by
warning light

©

.

The vehicle requires a service as soon as possible.

Service Intervals

Service in

30 000 Kms / 12 mo

Service due in

300 Kms / 24 days

Service required

Resetting: to reset the distance before service, press and hold button 2 for approximately 10 seconds until the display shows

the mileage permanently.
Note: If a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.71

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

ON-BOARD COMPUTER: trip settings

(4/5)

Examples of selections

Interpreting the display selected

On-board computer with distance before

next service message (cntd.)

c) Mileage before service or oil change.

Mileage before service

With the ignition on, the engine not running and the display

selected “Reichweite bis zur Wartung”, press button OK for about

5 seconds to display the mileage before the next service, then

press button 2 to view the mileage before the next oil change

(distance or time remaining before the next service). When the

distance value approaches its limit, there are several possible

scenarios:

–

distance/time remaining less than 900 miles (1,500 km) or

one month: the message “Service due in” is displayed, ac-

companied by the nearest term (distance or time);

–

range equal to 0 km/miles or service date reached: the

message “Service required” is displayed accompanied by
warning light

©

.

The vehicle requires an oil change as soon as possible.

Service Intervals

Oil change in

30 000 Kms / 24 mo

Service due in

300 Kms / 24 days

Service required

Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,

door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can

therefore decrease more quickly in some cases than the actual distance travelled.
Resetting: to reset the mileage before a service, press and hold button 2 for approximately 10 seconds until the display shows

the range permanently.

Note: If a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.72

ON-BOARD COMPUTER: trip settings

(5/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

d) Reset the tyre pressure.

Refer to the information on the “Tyre pressure

monitoring system” in Section 2.

+

Tyre pressure

No message

memorised

e) Trip log.

Successive display:
–

information messages (passenger airbag OFF

etc.);

–

operating fault messages (Check injection

system, etc.).

1.73

TRIP COMPUTER AND WARNING SYSTEM: information messages

Examples of messages

Interpreting the display selected

« Parking brake on »

Indicates that the parking brake has been applied.

« Checking control

functions »

Displayed with the ignition on when the vehicle is running self-diagnostics.

« Turn steering

wheel + START »

Turn the steering wheel slightly whilst pressing the vehicle start button to unlock the steering

column.

« Steering wheel

not locked »

Indicates that the steering column has not been locked.

These can help in the vehicle starting phase, or give information about a selection or a driving status.

Examples of information messages are given in the following pages.

1.74

TRIP COMPUTER AND WARNING SYSTEM: operating fault messages

These appear with the

©

 warning light and mean that you should drive very carefully to an authorised dealer as

soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.

They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The

©

 warning light stays on. Examples of operating fault messages are given in the following pages.

Examples of messages

Interpreting the display selected

« Clean diesel filter »

Indicates the presence of water in the diesel filter; contact an approved Dealer

as soon as possible.

« Check lighting »

Indicates a fault in the headlights.

« Check vehicle »

Indicates a fault in one of the pedal sensors, battery management system or oil

level sensor.

« Check airbag »

Indicates a fault in the restraint system in addition to the seat belts. In the event

of an accident, it is possible that they may not be triggered.

« Check anti-pollution system »

Indicates a fault in the vehicle’s particle filter system.

1.75

TRIP COMPUTER AND WARNING SYSTEM: warning message

These appear with the

®

 warning light and require you to stop immediately, for your own safety, as soon as traf-

fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.

Some examples of warning messages are given below. Note: the messages appear on the display either individually or al-

ternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.

Examples of messages

Interpreting the display selected

« Engine failure hazard »

Indicates an injection fault, the vehicle’s engine has overheated or there is a

serious engine fault.

“Power steering fault”

Indicates a fault in the steering or a problem with the four-wheel drive.

“Braking system fault” or ”Stop vehicle” Indicates a fault in the braking system. Apply the electronic parking brake ma-

nually and ensure that the vehicle is immobilised using a chock.

« Electric failure DANGER »

Indicates a fault in the vehicle battery charging circuit (alternator etc.).

« Puncture »

Indicates a puncture on the tyre displayed on the instrument panel.

1.76

VEHICLE SETTINGS CUSTOMISATION MENU (1/2)

Adjusting the settings
Select the function to modify:
a) unlocking the driver’s door;
b) automatic locking of the doors while

driving;

c) hands-free function;
d) indicator audio volume;
e) internal welcome sound;
f) external welcome;
g) reading lamp in automatic mode;
h) configuration of the driving style indi-

cator;

i)  Active noise control.
Select “ON” or “OFF” to activate or de-

activate the function.
For the “Light brightness intensity”

function, select the intensity by press-

ing “+” or “-”.

Depending on the vehicle equipment,

this function allows you to activate/

deactivate and adjust some of the vehi-

cle’s functions.

Vehicles fitted with a

navigation system

Accessing the settings menu
With the vehicle at a standstill, using

the multifunction screen 1, select menu

“Vehicle”, “User settings” to access the

various settings.

1

For safety reasons, carry

out any adjustments when

the vehicle is stationary.

1.77

VEHICLE SETTINGS CUSTOMISATION MENU (2/2)

Adjusting the settings
Browse using the control 4 to select the

function to adjust:
a) unlocking the driver’s door;
b) automatic locking of the doors while

driving;

c) hands-free function;
d) indicator audio volume;
e) internal welcome sound;
f) external welcome;
g) reading lamp in automatic mode;
h) configuration of the driving style indi-

cator;

i)  Active noise control.

=

 function activated

<

 function deactivated

Once a line has been selected, press

the switch 3 OK to adjust the function.

Vehicles not fitted with a

navigation system

Accessing the settings menu on

display 2
With the vehicle at a standstill, press

and hold the switch 3 OK to access the

settings menu.

2

3

4

Make your selection and confirm it by

holding the switch 3 OK. The selected

value is shown by a

~

 in front of

the line.
To exit the menu, press the control 4

upwards or downwards. It may be ne-

cessary to carry out this operation se-

veral times.

The vehicle settings personalisa-

tion menu cannot be used when dri-

ving. At speed exceeding 12 mph

(20 km/h), the instrumental panel

display switches automatically back

to trip computer and warning system

mode.

1.78

External temperature

indicator

Special note:
When the exterior temperature is - 3 °C

to + 3 °C, the °C characters flash (sig-

nalling a risk of ice on the road).

Display 1

Vehicles fitted with a touchscreen

multimedia screen, navigation aid

systems, etc.
The time and exterior temperature are

displayed on the multifunction screen 1.
Refer to the handbook for the equip-

ment.

CLOCK AND EXTERIOR TEMPERATURE

External temperature

indicator
As ice formation is related

to climatic exposure, local

air humidity and temperature, the

external temperature alone is not

sufficient to detect ice.

1

If the electrical supply is cut (battery

disconnected, broken supply wire,

etc.), the clock will automatically

go back to the right time after a few

minutes once the system is capable

of receiving information GPS.

1.79

STEERING WHEEL (1/2)

Adjusting the steering wheel

height and depth

Lower the lever 1 and position the

steering wheel in the required position.
Then, raise the lever fully, beyond the

point of resistance to lock the steering

wheel.
Make sure that the steering wheel is

correctly locked.

For safety reasons, only

adjust the steering wheel

when the vehicle is station-

ary.

1

Steering wheel heating

(depending on the vehicle)
This function heats the steering wheel

in areas 3 and 4.

Operating principle
When the temperature is reached, the

function regulates the temperature of

the heated areas for approximately

30 minutes and then switches off auto-

matically.

2

3

4

Activating the function
With the ignition on, press the switch 2

the warning light integrated in the

switch lights up.

Deactivating the function
- Automatic:

The function switches off automatically

after the regulation phase of approxi-

mately 30 minutes. The warning light

integrated in the switch 2 remains on.
Note: If the function has switched off

automatically, press the switch 2 twice

to reactivate it.
If switch 2 is not pressed again, the

function will be reactivated the next

time the ignition is switched on.
- Manually:

To deactivate the function during the re-

gulation phase, press the switch 2. The

indicator light in the switch 2 goes out.

1.80

STEERING WHEEL (2/2)

NB: power-assisted steering depends

on the mode selected in the “Multi-

Sense” menu (please refer to the infor-

mation in “Multi-Sense” in Section 3).

Power-assisted steering

Variable power-assisted steering
The variable power assisted steering

system is equipped with an electronic

control system which alters the level of

assistance to suit the vehicle speed.
Steering is made easier during parking

manoeuvres (for added comfort) while

the force needed to steer increases

progressively as the speed rises (for

enhanced safety at high speeds).

Stop and Start feature
With the engine on standby, power-as-

sisted steering is no longer operational.

In this case it returns to its original state

when the engine is restarted or when

the speed moves above 0.62 mph

(1 km/h) (hill, slope, etc.).

Never leave the steering wheel at

full lock while stationary.

Do not switch off the engine

when driving downhill and,

as a general rule, when

driving (the power-assisted

steering and brake cannot operate

normally).

With the engine switched off, or if

there is a system fault, it is still pos-

sible to turn the steering wheel. The

force required will be greater.

Engine on standby - power-

assisted steering is no

longer operational.

1.81

Folding door mirrors

The door mirrors automatically fold in

when the vehicle is locked (switch 3 in

position B).
In any case, you can make the door

mirrors fold in (switch 3 in position C) or

fold out (switch 3 in position A).

Automatic mode is then deactivated. To

reactivate it, position switch 3 to B.

REAR-VIEW MIRRORS

(1/3)

Door mirrors

Adjustment
Select the door mirror using switch 2

then use button 1 to adjust it to the de-

sired position.

Heated door mirrors
Mirror de-icing is carried out at the

same time as rear screen de-icing.
Please refer to the information

on “Manual air conditioning” and

“Automatic climate control” in Section 3.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

A

B C

1

2

3

Objects observed in the

door mirror glass are actu-

ally closer than they appear.
For your safety, take this

into account in order to correctly

assess the distance before any ma-

noeuvre.

Welcome and goodbye function
(depending on vehicle)
From the multifunction screen, select

menu “Vehicle”, “User settings”,

“External welcome” and activate or de-

activate the function (ON or OFF).
Depending on the selected choice, the

door mirrors will fold out:
–  when the ignition is next switched on

(function deactivated);

–  upon detecting the RENAULT card

or upon unlocking the vehicle (func-

tion activated).















Content   ..  3  4  5  6   ..
