Renault Talisman (2016 year). Instruction

1.50

Child seat fitted using the ISOFIX

mounting



Seat which allows an ISOFIX child

seat to be attached.

The rear seats are fitted with

an anchorage point which allows a

forward-facing ISOFIX child seat with

universal approval to be attached. The

anchorage points are located on the

backs of the rear seats.
The size of the ISOFIX child seat is in-

dicated by a letter:
– A, B and B1: for forward-facing seats

in group 1 (9 to 18 kg);

– C and D: shell seat or rear-facing

seats in group 0+ (less than 13 kg)

or group 1 (9 to 18 kg);

– E: rear-facing shell seats in group 0

(less than 10 kg) or 0+ (less than

13 kg);

– F and G: cots in group 0 (less than

10 kg).

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

Seat which does not allow a

child seat to be fitted.

CHILD SEATS: attachment using the ISOFIX system

(3/3)

1.51

Front passenger air bag

deactivation

You must deactivate certain devices

in addition to the front passenger seat

belt before fitting a child seat in the front

passenger seat.

CHILD SAFETY: deactivating/activating the front passenger airbag

(1/3)

To deactivate the airbag: with the ve-

hicle stationary and the ignition off,

push and turn the lock 1 to the OFF po-

sition.
With the ignition on, you must check

that the warning light

is lit on the

display 2.
This light remains permanently lit to

let you know that you can fit a child

seat.

The front passenger air bag

must only be deactivated or

activated when the vehicle

is stationary.

If it is interfered with when the ve-

hicle is being driven, indicator lights

and

will come on.

Switch the ignition off then on again

to reset the air bag in accordance

with the lock position.

DANGER
Since operation of the front

passenger airbag is not

compatible with the position

of a rear-facing child seat, NEVER

fit a restraint system for a rear-fac-

ing child in a seat protected by an

ACTIVATED front AIRBAG. This

can cause the CHILD’S DEATH or

SERIOUS INJURY.

1.52

The markings on the dashboard and

labels A on each side of the passen-

ger sun visor 3 (example: label shown

above) remind you of these instruc-

tions.

CHILD SAFETY: deactivating/activating the front passenger airbag

(2/3)

DANGER
Since operation of the front

passenger airbag is not

compatible with the position

of a rear-facing child seat, NEVER

fit a restraint system for a rear-fac-

ing child in a seat protected by an

ACTIVATED front AIRBAG. This

can cause the CHILD’S DEATH or

SERIOUS INJURY.

1.53

CHILD SAFETY: deactivating/activating the front passenger airbag

(3/3)

Operating faults

It is forbidden to fit rear-facing child

seats to the front passenger seat if the

airbag activation/deactivation system is

faulty.
Allowing any other passenger to sit in

that seat is not recommended.
Contact an approved dealer as soon as

possible.

Activation of the front

passenger air bag

You should reactivate the air bag as

soon as you remove the child seat from

the front passenger seat to ensure the

protection of the front passenger in the

event of an impact.

To reactivate the air bags: with the

vehicle stationary and the ignition

off, press and turn the lock 1 to the ON

position.
With the ignition switched on, you must

check that the warning light

]

out and that the warning light



comes on the display 2 after each start-

up for around 60 seconds.
The front passenger seat belt additional

restraint systems are activated.

The front passenger air bag

must only be deactivated or

activated when the vehicle

is stationary.

If it is interfered with when the ve-

hicle is being driven, indicator lights

and

will come on.

Switch the ignition off then on again

to reset the air bag in accordance

with the lock position.

1.54

DRIVING POSITION

(1/2)

13 14

1.55

DRIVING POSITION

(2/2)

The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY.

  1  Side air vent.
  2 Demister outlet.
  3 Stalk for:

– direction indicator lights;

– exterior lights;

– fog lights.

  4  Driver Airbag and horn location.
  5 Instrument panel.
  6 Head-up display.
  7 Controls for:

–

on-board computer information

read-out and vehicle settings cus-

tomisation menu,

–

remote radio and navigation

system.

8 Steering column stalk for winds-

creen and rear screen wash/wiper.

9 Centre air vents.
10 Windscreen demister outlet.
11 Multimedia touchscreen.

12 Multifunction screen controls:

–

screen activation/deactivation;

–

volume;

– welcome menu;

–

driving aids menu;

– settings.

13 Switches for:

– hazard warning lights,

–

electric door locking.

14 Heating or air conditioning con-

trols.

15 Passenger

Airbag location.

16 Glovebox.
17 Storage compartment.
18 Accessories and multimedia

socket

19 Cup holders
20 Controls for:

– electronic parking brake.

–

cruise control/speed limiter.

21 Central multifunction and Multi-

Sense control.

22 Gearstick.

23 Controls for:

–

heated front seats,

–

ventilated front seats,

–

activation/deactivation of ECO

mode,

–

activation/deactivation of assisted

parking,

–

activation/deactivation of the Stop

and Start function.

24 Engine start/stop button (vehicles

with RENAULT card).

25 Ignition switch (vehicles with key).
26 Control for adjusting steering

wheel height and reach.

27 Cruise control/speed limiter and

adaptive cruise control controls.

28 Bonnet release control.

29 Controls for:

–

electric headlight beam adjust-

ment,

–

instrument panel lighting dimmer,

–

lane departure warning,

–

ESP and traction control system,

–

heated steering wheel.

1.56

Side light warning light

Main beam headlight tell-

tale

Dipped beam headlight tell-

tale

Front fog lights tell-tale

Rear fog lights tell-tale



Automatic main beam head-

light indicator light

Please refer to the information

on “External signals and lights” in

Section 1.

Left-hand direction indicator

tell-tale

Right-hand direction indica-

tor tell-tale

Low fuel level warning light

It lights up orange when the ig-

nition or the engine is switched on and

goes off after a few seconds.

If it comes on orange while driving and

is accompanied by a beep, fill up with

fuel as soon as possible. There is only

approximately 30 miles (50 km) worth

of fuel left.

If no lights or sounds are ap-

parent, this indicates a fault

in the instrument panel. This

indicates that it is essential

to stop immediately (as soon as traf-

fic conditions allow). Ensure that the

vehicle is correctly immobilised and

contact an approved Dealer.

Instrument panelA: lights up when the

driver’s door is opened.
In some cases, the appearance of a

warning light is accompanied by a mes-

sage.

The

warning light means

you should drive very carefully to

an approved dealer as soon as pos-

sible. If you fail to follow this recom-

mendation, you risk damaging your

vehicle.

Warning light

re-

quires you to stop immedi-

ately, for your own safety,

as soon as traffic conditions

allow. Switch off the engine and do

not restart it. Contact an approved

Dealer.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

WARNING LIGHTS

(1/6)

1.57

WARNING LIGHTS

(2/6)

STOP light

This lights up when the igni-

tion or engine is switched on and goes

out as soon as the engine is running. It

comes on with other warning lights and/

or messages, and is accompanied by

a beep.
It requires you to stop immediately, for

your own safety, as soon as traffic con-

ditions allow. Switch off the engine and

do not restart it.
Contact an approved Dealer.

Oil pressure warning light
It lights up when the ignition or

the engine is switched on and goes off

after a few seconds.
If it comes on on the road, accompa-
nied by the

warning light and

a beep, stop immediately and cut the

ignition.
Check the oil level. If the level is normal,

the indicator light is being lit by some-

thing else. Contact an approved Dealer.

Variable power-assisted

steering warning light

It lights up when the ignition or the

engine is switched on and goes off after

a few seconds.
If it comes on while driving, alongside
the warning light

, this means

there is a system fault.
Contact an authorised dealer.

Brake circuit fault warning

light

It lights up when the ignition or the

engine is switched on and goes off after

a few seconds.
If it comes on during braking and is ac-
companied by the

warning light

and a beep, it indicates that the fluid

level in the circuit is low or that there is

a braking system fault. Stop as soon as

traffic conditions allow and contact an

authorised dealer.

Battery charge warning light
It lights up when the ignition or

the engine is switched on and goes off

after a few seconds.
If it comes on on the road, accompa-
nied by the

warning light and a

beep, this indicates an overload or dis-

charge in the electrical circuit.
Stop as soon as traffic conditions allow

and contact an approved Dealer.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

1.58

Anti-lock braking warning

light

It lights up when the ignition or the

engine is switched on and goes off after

a few seconds.

If it lights up when you are driving, it in-

dicates a fault in the anti-lock braking

system.

Braking will then be as normal, without

the ABS. Contact an approved Dealer

as soon as possible.



Warning light for electronic

stability program ( ESC ) and

traction control system

It lights up when the ignition or the

engine is switched on and goes off after

a few seconds.

There are several reasons for the warn-

ing light to come on: please refer to the

information on “Driver correction de-

vices and aids” in Section 2.

WARNING LIGHTS

(3/6)

Warning light

This lights up when the ignition

or engine is switched on and goes out

as soon as the engine is running. It can

light up in conjunction with other warn-

ing lights and/or messages on the in-

strument panel.

It means you should drive very care-

fully to an approved dealer as soon as

possible. If you fail to follow this recom-

mendation, you risk damaging your ve-

hicle.

Toxic Fume Filter System

Warning Light

On vehicles which are equipped with it,

this light comes on when the engine is

started and, depending on the vehicle,

when the ignition is switched off if the

vehicle is in the engine standby phase

(refer to the information on the “Stop

and Start Function” in section 2) then

goes out.
– If it lights up continuously, consult

your approved dealer as soon as

possible;

– if it flashes, reduce the engine speed

until the light stops flashing. Contact

your approved Dealer as soon as

possible.

Refer to the information on “Advice:

antipollution, fuel economy and driving”

in Section 2.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

1.59

WARNING LIGHTS

(4/6)

Preheating warning light

(diesel version)

This should come on when the igni-

tion is switched on. It indicates that the

heater plugs are in operation.
It goes out when preheating is com-

plete. The engine can be started.

}

Handbrake or electronic

parking brake warning light

Refer to the information on the “Assisted

parking brake” in Section 2.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Air bag warning light

This warning light will be dis-

played on the instrument panel when

the ignition is switched on or the engine

is started, and will then go out after a

few seconds.

If it does not come on when the igni-

tion is switched on, or comes on when

the engine is running, there is a fault in

the system.

Contact your approved Dealer as soon

as possible.

Coolant temperature warn-

ing light

This lights up red when the ignition is

switched on or the engine is started.
If it turns red, stop and let the engine

idle for a minute or two.
The temperature should lower and the

warning light should return to a blue

colour. If not, stop the engine. Let the

engine cool down before checking the

coolant.
Contact an approved Dealer.

Rear seat belt reminder (depending

on vehicle)

Warning light

comes on, accom-

panied (depending on the vehicle) by

a message indicating the number of

fastened seat belts on the instrument

panel for approximately 30 seconds,

each time the vehicle is started, a door

is opened or a rear seat belt is fas-

tened/unfastened. Check that the rear

passengers are wearing seat belts and

that the number of seat belts shown as

fastened corresponds to the number of

rear seat places occupied.

‰

Gear change indicator

This lights up to advise you to

change to a higher gear (up arrow) or

lower gear (down arrow).

Please refer to the information on

“Driving advice, Eco-driving” in

Section 2.

Door(s) open warning light

1.60

WARNING LIGHTS

(5/6)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.



Assisted parking brake fault

light

Please refer to the information on the

“Assisted parking brake” in Section 2.



Emergency active brake

assist

Refer to the information on “Driving cor-

rection devices and aids” in Section 2.



ECO mode warning light
This comes on when ECO

mode is activated.
Please refer to the information on “Eco-

driving” in Section 2.

Brake pedal warning light
This lights up when the brake

pedal should be depressed. Refer to

the information on the “Automatic gear-

box” in Section 2.
Please refer to the information on

“Driving advice, Eco-driving” in

Section 2.

Î¦

Speed limiter,

cruise control and

adaptive cruise control warning

lights
Please refer to the information on the

“Speed limiter”, “Cruise control” and

“Adaptive cruise control” in Section 2.



Tyre pressure monitoring

system

Refer to the information on the “Tyre

pressure monitoring system” in

Section 2.

Rear seat belt reminder

warning light

This comes on for approximately

30 seconds, each time the vehicle is

started, a door is opened or a rear seat

belt is fastened/unfastened. Please

see the information on “Seat belts” in

Section 1.



Engine standby warning

light

Please see information in the para-

graph on “Stop and Start Function” in

Section 2.



Unavailability of engine

standby warning light

Please see information in the para-

graph on “Stop and Start Function” in

Section 2.

1.61

WARNING LIGHTS

(6/6)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

On the rear-view mirror B



Passenger airbag ON

Please refer to the information

on “Child safety: deactivating/activating

the front passenger airbag” in Section 1.

Passenger airbag OFF

Please refer to the information

on “Child safety: deactivating/activating

the front passenger airbag” in Section 1.

Driver’s seat belt reminder

and, depending on the vehi-

cle, front passenger seat belt re-

minder.

This lights up in the rear-view mirror

when the ignition is started, then, if the

driver or front passenger seat belt (if

this seat is occupied) is not fastened

and the vehicle has reached approxi-

mately 12.4 mph (20 km/h), it flashes

and a beep sounds for around 2 min-

utes.

Note: an object placed on the passen-

ger seat base can activate the warning

light.

1.62

DISPLAYS AND INDICATORS

(1/4)

Instrument panel A

lights up when the driver’s door is

opened. In some cases, the appear-

ance of a warning light is accompanied

by a message.
On a vehicle equipped with a multifunc-

tion screen you can customise your in-

strument panel with the content and

colours of your choice.
From the multifunction screen, select

the menu “System”, then “User profile”.

Refer to the handbook for the equip-

ment.

Rev counter 1

(graduations x 1000)

Speedometer 2
This is displayed differently according

to how the instrument panel is custom-

ised.

Overspeed buzzer
Depending on the vehicle and coun-

try, a buzzer sounds for approximately

10 seconds every 40 seconds, as long

as the vehicle is travelling in excess of

72 mph (120 km/h).

Driving style indicator 3
Please refer to the information on “Eco-

driving” in Section 2.

Trip computer and warning system
Refer to the information on the “Trip

computer and warning system” in

Section 1.

1.63

DISPLAYS AND INDICATORS

(2/4)

Engine oil level low warning

When the engine is started, the instru-

ment panel display A alerts you when

the minimum oil level is reached. Refer

to the information on the “Engine oil

level” in Section 4.
The first time the warning appears,

it can be cleared by pressing the OK

button 7. Subsequent warnings will dis-

appear automatically after around

30 seconds.

Fuel gauge 6
If the level is at the minimum, warn-

ing light

integrated in the indica-

tor comes on orange, accompanied by

a beep. Fill up as soon as possible.

Coolant temperature indicator 4
In normal use, indicator 4 should be

before area 5. Under “intensive” oper-

ating conditions, the needle may ap-

proach this zone. This is not serious
unless the warning light

comes

on accompanied by a message on the

instrument panel and a beep.

1.64

DISPLAYS AND INDICATORS

(3/4)

Head-up display 8

The display details driving and navi-

gation information from the instrument

panel and the multifunction screen.
If fitted to the vehicle, this comes on

when the engine is started and is re-

tracted when the engine is switched off.

You can adjust certain settings from the

multifunction screen: with the engine

running, access menu “System”,

“Display” then “Head-up display”.

Adjusting the display information

height
Depending on your driving position,

you can raise or lower the information

on the display.

Adjusting the display brightness
You can adjust the brightness (day or

night mode)

– automatically: the brightness will

vary depending on the outdoor light.

– manually: the brightness automati-

cally switches with the activation/de-

activation of the lights.

In both cases, the day mode varies

based on the outdoor brightness.

Good information visibility can be af-

fected by:
– the seat position;
– the presence of an object placed

on the opened display;
– the polarisation of some spectacle

lenses;
– extreme weather conditions (rain,

snow, very strong sunlight, etc.).

In the event of contradic-

tory information between

the instrument panel and

the head-up display/multi-

function screen, please refer to the

information displayed on the instru-

ment panel.

Do not manually force the opening/

closure of the head-up display.

For safety reasons, carry

out any adjustments when

the vehicle is stationary.

1.65

DISPLAYS AND INDICATORS

(4/4)

Operating faults
In the event of a malfunction (the dis-

play fails to open when the engine is

started, or the display retracts, with the

engine running, following an object im-

pacting the display):
– stop and restart the engine;
or
– from the multifunction screen,

change the display opening settings.

If there is still a problem, contact an au-

thorised dealer.

With the display opened or closed,

no object should be placed on it or

in its housing.
Do not use solvents, detergents or

an abrasive cloth to clean the dis-

play.
Only use a microfibre wipe.

Vehicles not fitted with a navigation

system
– With the ignition off, press the OK

button 7 and the engine start/stop

button;

– using control 9, select “Settings”,

“Instrument panel”, then the unit;

– Press the OK button 7 to confirm.
To return to the previous mode, repeat

the same operation.
Vehicles fitted with a navigation

system
On the multifunction screen, select

“System” , “User profile” and “Unit”.
Note: In both cases, once the battery

is switched off, the on-board computer

automatically returns to the original unit

of measurement.

Instrument panel in miles

(option to switch to km/h)

Renault Talisman (2016 year). Instruction - part 4
