Dacia Pick-Up 1304/1305/1307. Manual - part 113





REPAIR MANUAL

DACIA COMMERCIAL

RM 502-3



SEALING, ELECTRICITY

ENGINE: C3L

GEARBOX: NG1; NG7

TAPV: U75B; U75F

Ref: 6001999453

NOVEMBER  2004

English version

The reparation methods prescribed by the manufacturer in the present document are established subject to

technical specifications in force at the document issuing date.

These are subject to modifications brought by the manufacturer at the fabrication of different assemblies,

subassemblies or accessories of its vehicles.

All rights reserved to SC Automobile Dacia SA.
  Reproduction or translating even partially of this present document is forbidden without the written

authorisation of AUTOMOBILE DACIA S.A.

Mechanisms and accessories

5

Garnishing and tack room

7

Electric equipment

8

57 LOWER INTERNAL ACCESSORIES

Dashboard  ..........................................................

57-1

Documents compartment .....................................

57-5

The hand brake casin and gearbox lever
ornament ..............................................................

57-6

Inside rear view mirror ........................................

57-7

Sun visors ............................................................

57-8

Turn handles  .......................................................

57-9

Doors thresholds ................................................. 57-10

59 SAFETY ELEMENTS

Front safety belts .......................................... 59-1
Rear safety belts ........................................... 59-2

61 HEATING

Climate control block ................................... 61-1
Climate control unit ...................................... 61-3
Climate control valve .................................... 61-4
Climate control G.M.V. ................................ 61-5
Diagnostic ..................................................... 61-6

62 AIR CONDITIONING

Generalities .................................................. 62-1
AC circuit operating diagram ....................... 62-3
Maintenance ................................................. 62-4
Detectation of refrigerant fluit leakage ......... 62-5
Condenser ..................................................... 62-6
Dryer filter tank ............................................ 62-7
Compressor .................................................. 62-8
Evaporator .................................................... 62-11
System piping ............................................... 62-13
Thermostate expansion valve ....................... 62-14
Pressure controller ....................................... 62-15
Diagnostic ..................................................... 62-16

65 SEALING OPENING ELEMENTS

Frame sealing gaskets ................................... 65-1
Door sealing gaskets ..................................... 65-2

66 SEALING WINDOWS AND SCREENS

Glasses sealing gaskets ................................. 66-1
Inner wipers .................................................. 66-2
Outside wipers .............................................. 66-3

71 INTERNAL BODY TRIM

Floor carpets ................................................. 71-1
Windscreen coverings ................................... 71-2
Middle pillar lining ....................................... 71-3
Upper side panel lining ................................. 71-4
Cabin wall lining .......................................... 71-5
Ceiling covering ........................................... 71-6
Floor noise absorbent mats ........................... 71-7

72 SIDE OPENING ELEMENTS TRIM

Front door panel ........................................... 72-1
Dacia 1307 rear door panel .......................... 72-2

75 FRONT SEATS FRAMES AND RUNNERS

Front seats .................................................... 75-1
Front seat frames .......................................... 75-2
Front seat slide guides .................................. 75-3

76 REAR SEATS FRAMES AND RUNNERS

Back rest armature ........................................ 76-1
Rear bench seat armature  ............................. 76-2

77 FRONT SEAT TRIM

Seats upholstery ............................................ 77-1
Back rest upholstery ..................................... 77-2

78 REAR SEAT TRIM

Seats upholstery ............................................ 78-1
Bench rest upholstery ................................... 78-2

80 BATTERY - FRONT HEADLIGHTS

Battery .......................................................... 80-1
Headlight bulbs replacement ........................ 80-5
Lamps ........................................................... 80-6
Fog projector ................................................ 80-8
Headlights adjustment .................................. 80-9

81 REAR AND INTERIOR LIGHTING

Rear and interior lighting .............................. 81-1
Diagnostic ..................................................... 81-2

82 HORN - ENGINE IMMOBILISER

Presentation .................................................. 82-1
Electronic keys programming procedure ...... 82-4

83 INSTRUMENT PANEL

Instrument panel-series 5136 (Sacele) .......... 83-1
Replacement of instrument panel  ................ 83-2
Connectors-series 5136 (Sacele) .................. 83-3
Connectors type TAKOSAN ........................ 83-5
120Km/h speed warning ............................... 83-6
Instruments panel
(commercial equipped with CA) .................. 83-7
Fasten safety belts warning lights ................. 83-8
Vehicle with dashboard
type 1325 replacement .................................. 83-9
Diagnostic ..................................................... 83-10
Flexible cable ............................................... 83-13
Oil pressure switch checking ........................ 83-14
Thermocouple checking ............................... 83-15

Air conditioning

6

Temperature transmitter checking ................ 83-16
Fuel level transmitter .................................... 83-17

84 CONTROLS - SIGNALLING

Starting-ignition switch ................................. 84-1
Under wheel control module ........................ 84-3
Switches dashboard ...................................... 84-5

85 WINDSCREEN WIPERS

Windscreen wiper mechanism ...................... 85-1
Windscreen wiper drive motor ..................... 85-4
Windscreen washer assembly ....................... 85-6
Diagnostic ..................................................... 85-7

.

89 ELECTRICAL DIAGRAMS

Generalites .................................................... 89-1
Functional diagrams list ................................ 89-6
Electric components index ........................... 89-8
Couplings list. Mass index ............................ 89-9
Location of electric coupling on the vehicle ..89-10
Fixation of electric mass on the vehicle ....... 89-11
Electric components location on
the vehicle ..................................................... 89-12
Cockpit fuse box............................................ 89-15
Engine compartment fuse box ...................... 89-16
Wire functions index in connectors and
couplings ...................................................... 89-18
Wire functions in connectors and
couplings ...................................................... 89-21
Wire functions explanation ........................... 89-92

57

LOWER INTERNAL ACCESSORIES

57 - 1

DISMOUNTING

Dismount the battery
Dismount:

- the windscreen,
- the steering wheel and the lower/upper casing.

Dismount the attachment nut (12) of the coupling bar for dashboard sustaining.
Dismount the dashboard attachment screws (8) on the side support (9).
Dismount the dashboard attachment screws (11) on the windshield lower frame cross

member.

Dismount the headlamp adjustment switch (5) and the two attachment screws.
Dismount from the engine compartment:

- the control cable from the climate control valve,
- the vacuum hose from the servobrake valve,

Detach the dashboard and swing it over, in order to have access to the wiring discon-

necting.

Disconnect the following connectors:

- dashboard,
- fog lamp switch,
- hazard switch,
- electronic clock,
- blower switch,
- blower wiring connection,
- 4 X 4 switch,

1
2
3

4

5

6

8

9

10

11

7

15

16

12

13

14

DASHBOARD
