STARTING AND CHARGING 16 16 - 24 STARTER REPAIR The operation is performed after the starter is dismounted from the vehicle. D ISMO UNTING Dismount: sheet cap and the screw from the rotor top (A) electric plug (B), Check the state of the collector; if the wear on diameter is higher than 0,5 mm, Check: the state of the coupling mechanism (bendix) and of the brushes the R EMO UNTING Lubricate with bearing oil the bushing of the support bearing and introduce the Tighten the attachment nuts of the solenoid and introduce the fork shaft. Mount the washers on the rotor in the following order: 1. The steel washer bearing bushing. Mount: stator, collector bearing, spring (3) and washer (4). Tighten the attachment screw (A) and mount the sheet cap. STARTER |
