Dacia Pick-Up 1304/1305/1307. Manual - part 3

LIFTING

02

02 - 2

 For lifting, place the elevator buffers on the same points where the car jack of the

vehicle is usually placed.

 The edge of the threshold shall be placed correctly in the buffer channel.

ELEVATOR POSITIONED UNDER THE CARRIAGE  BODY

TOWING

03

03 - 1

ALL TYPES

FOR TOWING OBSERVE THE LAW IN FORCE OF EACH COUNTRY

NEVER PERFORM TOWING USING FRONT TRANSMISSION

     The towing of the cars on wheels must be obligatory done by means of the unique
towing points
      These points cannot be anyhow used for drawing out the car from a trench ( hole ), for
a similar intervention or for direct or indirect lifting of the car.

F

RO NT

R

EAR

LUBRICANTS  CONSUMABLES

04

04 - 1

CONDITIONS

P

RODUCT

P

LACE



WHERE



IT



IS



USED

G

REASING

Grease

UM 170 Li Ca Pb 2M

ELF CARDREXA RNT2

UM 185 Li 2M

Grease

UM 185 Li 2M

Grease U 95 Ca 2

Grease

Li Ca Pb type II with MoS2

(or 20 UM Li III)

Grease 22

Grease U100 Ca 4-5

Clutch shaft groves
Pinions groves of front transmission
Gear box control lever
Pressure bearing
Cardan flange sealing ring

Front transmission

Front wheel steering stub groves
Cardanic  transmission
Front transmission
Front wheel bearing
Suspension ball joints
Rear axle differential

Wheels screws

Steering gear (pinion – rack gear, bearings)

Rubber gaskets of the steering gear

Steering rod

LUBRICANTS  CONSUMABLES

04

04 - 2

CONDITIONS

P

RODUCT

P

LACE



WHERE



IT



IS



USED

S

EALING

RHODORSEAL

5661

LOCTITE 518

LOCTITE 577

Mastic 503

Inferior crankcase
Distribution cover
Propeller shaft pins

Half crankcase
Clutch  crankcase
Fuel pump ( with membrane )
Cover palier 1
Rear axle

Thread of the reverse lamp contact.
Gear box plug M 16
Rear axle

Differential rear axle

S

OLDERING

FIXAMED M28

Screws of flywheel fixing
Screws  of crank shaft pulley

C

LEANING

DECAPJOINT

S.E. DERO 100

The surface of cylinder head gasket

Washing of steel, cast iron, aluminum parts
