Peugeot 508 Dag (2010.5). Instruction - part 20

291

04 AUDIO

Radio text is information transmitted by the radio station related to the current programme or song.

With the radio displayed on the screen,
press OK

to display the contextual

menu.

Select " RadioText (TXT) display " and

conﬁ rm OK to save.

DISPLAY RADIO TEXT

Screen C

292

AUDIO

AUDIO CD

Insert 12 cm diameter circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using a

personal recorder, may cause faults which are no reﬂ ection on the

quality of the original player.

Without pressing the EJECT button, insert a CD in the player, play

begins automatically.

To play a disc which has already been
inserted, press the SOURCE button
several times in succession and

select " CD ".

Press one of the buttons to select a

track on the CD.

PLAYING A CD

Press LIST

to display the list of tracks

on the CD.

Press and hold one of the buttons for

fast forward or backward.

293

04 AUDIO

CD, USB

INFORMATION AND ADVICE

On a single disc, the CD player can read up to 255 MP3 ﬁ les spread

over 8 directory levels. However, it is recommended that this be kept

to 2 levels so as to limit the time taken to access and play the CD.

During play, the folder structure is not observed.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select standards ISO 9660 level 1.2 or Joliet.
If the disc is recorded in another format, it may not be played correctly.
It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.
In the particular case of a multi-session CD, the Joliet standard is

recommended.

Do not connect a hard disk or USB device other than audio players to

the USB port. This may cause damage to your installation.

The audio system will only play ﬁ les with extension ".mp3" or ".wma"

and a compression rate that is constant or variable between 32 Kbps

and 320 Kbps.

It is advisable to restrict ﬁ le names to 20 characters without using

special characters (e.g. " ?; ù) to avoid any playing or displaying

problems.

The playlists accepted are types .m3u and .pls.
The number of ﬁ les is limited to 5 000 in 500 directories on a

maximum of 8 levels.

294

CD, USB

AUDIO

PLAYING A COMPILATION

Insert an MP3 compilation in the CD player or

connect a memory stick to the USB port, directly or

via an extension lead.

The system creates playlists (temporary memory) the creation time

for which can take from a few seconds to several minutes.

The playlists are updated every time the ignition is switched off or a

USB memory stick is connected.
Play starts automatically after a period which depends on the

capacity of the USB memory stick.

At a ﬁ rst connection, the order suggested is by folder.

When connecting again, the order previously chosen is

retained.

To play a disc or memory stick which

has already been inserted, press
SOURCE several times in succession

and select " CD " or " USB ".

Press one of the buttons to select the

next or previous track.

Press one of the buttons to select the

next or previous folder in the order

chosen.

Press and hold one of the buttons for

fast forwards or backwards.

Press LIST to display the menu of
folders in the compilation.

295

Select a track or a folder.

Jump a page.

Up a level in the menu.

AUDIO

USB MEMORY STICK - FILE
CLASSIFICATION

Having selected the desired classiﬁ cation

(" By folders ", " By artists ", " By genres ",

" By playlists ") press OK .

Then conﬁ rm OK to save the modiﬁ cations.

- By folders : all folders containing audio

ﬁ les recognised on the peripheral device,

in alphabetical order without following the

folder structure.

- By artists : all of the artist names deﬁ ned

in the ID3 Tags, in alphabetical order.

- By genres : all of the genres deﬁ ned in

the ID3 Tags.

- By playlists : if playlists have been saved.

Make a long press on LIST or press

MENU

, select " Multimedia ", then " Media

parameters

" and ﬁ nally " Choice of

track listing

" to display the different

classiﬁ cations.

296

04 AUDIO

IPOD

or PORTABLE PLAYER

Management of the device is via the audio system controls.

The audio ﬁ les on a Mass Storage portable player * can

be heard through the vehicle's speakers by connecting

it to the USB port (cable not supplied).

If the portable player is not recognised by the USB port,

connect it to the auxiliary Jack socket.

The Ipod

must be updated regularly for the best connection.

The playlists are those deﬁ ned in the Ipod

The Ipod

must be generation 5 or later.

* Check your player's manual.

297

AUDIO

AUXILIARY SOCKET (AUX)

AUXILIARY JACK SOCKET

Do not connect a device to the USB port and to the auxiliary

Jack socket at the same time.

The auxiliary Jack socket permits the connection of a portable

non mass storage device or an iPod

if not recognised by the

USB port.

Connect the portable device to the auxiliary Jack socket using

a suitable cable (not supplied).

Press the SOURCE button several times

in succession and select " AUX ".

First adjust the volume on your portable device.

Then adjust the volume of the audio
system.

The display and management of controls is on the

portable device.

298

AUDIO

STREAMING - PLAYING AUDIO FILES
VIA BLUETOOTH

Depending on the compatibility of the phone

Connect the telephone: see the "USING THE

TELEPHONE" section.

Streaming allows music ﬁ les on a telephone to be heard via the

vehicle's speakers.

The telephone must support the appropriate bluetooth proﬁ les

(Proﬁ les A2DP/AVRCP).

Activate the streaming source by pressing SOURCE .

Control of playback is via the audio system. The

contextual information can be displayed on the screen.

In certain cases, playing of the audio ﬁ les must be initiated from

the telephone.

The audio quality depends on the quality of the transmission from
the telephone.

PLAY MODE

The play modes available are:

- Normal: the tracks are played in order, depending on the

classiﬁ cation of the selected ﬁ les.

- Random: the tracks in an album or folder are played in a

random order.

- Random all: all of the tracks saved in the media ar played in

random order.

- Repeat: the tracks played are only those from the current

album or folder.

Press OK

for access to the contextual

menu.
or
Press MENU .

Select " Multimedia " and conﬁ rm.

Select " Media parameters " and

conﬁ rm.

Select " Read mode " and conﬁ rm.

Select the desired play mode and

conﬁ rm OK to save the modiﬁ cations.

299

USING THE TELEPHONE

PAIRING A TELEPHONE

The services offered depend on the network, the SIM card and the compatibility of the Bluetooth telephone used.

Consult your telephone's manual and your operator to ﬁ nd out which services are available to you. A list of mobile telephones which offer the best

range of services is available from the PEUGEOT dealer network.

Activate the telephone's Bluetooth function.

Press MENU .

A window is displayed " Search in progress… ".

Select the telephone to be connected
from the list. Only one telephone can
be connected at a time.

Select " Search for a device ".

For safety reasons and because they require prolonged attention on the part of the driver, the operations for pairing of the Bluetooth mobile

telephone with the Bluetooth hands-free system of your audio system must be carried out with the vehicle stationary and the ignition on.

Select " Bluetooth connection " and

conﬁ rm.

300

Saisir code authentification

Del

USING THE TELEPHONE

A virtual keypad is displayed on the

screen: enter a code with at least

4 digits and conform with OK .

A message is displayed on the screen of the

telephone: enter the same code and conﬁ rm.

A message appears in the screen to conﬁ rm the result of the

connection.

Pairing can also be initiated from the telephone by searching for

detected Bluetooth devices.

Accept the connection to the telephone.

If pairing fails, try agin; the number of attempts is not limited.

The directory and the calls list can be accessed after the

synchronisation period (if the telephone is compatible).

Automatic connection must be conﬁ gured in the telephone to allow

the connection each time the vehicle is started.

In some cases, the reference number of the telephone may appear
instead of the name of the telephone.

301

USING THE TELEPHONE

To see the telephone status, press
MENU .

Select " Telephone " and conﬁ rm.

Select " Telephone management "

conﬁ rm.

Select " Telephone status " and conﬁ rm.

TELEPHONE STATUS

The screen displays: the name of the telephone, the name of the

network, network signal strength, conﬁ rmation of the Bluetooth

connection and the streaming connection.

302

USING THE TELEPHONE

The telephone connection automatically includes hands free operation

and audio streaming.

Press MENU .

Select " Bluetooth connection " and

conﬁ rm.

Indicates connection of the audio steaming proﬁ le.

MANAGING CONNECTIONS

Select " Connections management "

and conﬁ rm. The list of paired

telephones is displayed.

Select a telephone and conﬁ rm.

Indicates connection of the hands-free proﬁ le.

Then select and conﬁ rm:

- " Connect telephone "/" Disconnect

telephone

": to connect/disconnect

the telephone or the hands-free

connection only.

- " Connect media player "/

Connect media player

" Disconnect media player ": to

Disconnect media player

connect/disconnect only streaming.

- " Connect telephone + media

player

"/"

player

Disconnect telephone +

media player

": to connect/disconnect

media player

the telephone (hands-free and

streaming).

- " Delete connection ": to delete the

pairing.

Indicates that a device is connected.

303

05 USING THE TELEPHONE

To display the " TELEPHONE " menu:

- Make along press on SOURCE .

- Or, press OK to display the

contextual menu. Select " Call " and

conﬁ rm.

- Or, press MENU , select

" Telephone " and conﬁ rm. Select

" Call " and conﬁ rm.

Select " Dial " to enter a number and

conﬁ rm.

Repeat the previous step 1 to display

the " TELEPHONE " menu.

Select OK

and conﬁ rm to start the

call.

Select " Calls list " and conﬁ rm.

MAKING A CALL - DIALLING

Select numbers one at a time using

the  and 

buttons and conﬁ rm.

MAKING A CALL - RECENTLY CALLED
NUMBERS *

Select the number and conﬁ rm to

start the call.

The calls list includes calls sent and received in the vehicle using the

connected telephone.

* Depending on the compatibility of the telephone.

Correction allows numbers to be deleted one at a time.

304

05 USING THE TELEPHONE

Repeat the previous step 1 to display

the " TELEPHONE " menu.

Select " Directory " and conﬁ rm.

An incoming call is announced by a ring and a superimposed display

in the multifunction screen.

Mobile
(depending on the information

available in the contact records of

the telephone connected).

" YES

" "

" to accept the call is selected

by default.
Press OK to accept the call.
Select " NO " and conﬁ rm to reject the

call.
or
Press SOURCE to accept the call.

MAKING A CALL - FROM THE
DIRECTORY

Select a contact then conﬁ rm.

RECEIVING A CALL

Select the number and conﬁ rm.

A long press on ESC or on SOURCE also

rejects an incoming call.

Business

Home

305

05 USING THE TELEPHONE

During a call, press OK to display the

contextual menu.

Hang up

In the contextual menu:

- select " Telephone mode " to

transfer the call to the telephone.

- deselect " Telephone mode " to

transfer the call to the vehicle.

In the contextual menu:

- select " Micro OFF " to switch off the

microphone.

- deselect " Micro OFF " to switch the

microphone on.

In certain cases, the combined mode has to activated from the
telephone.
If the contact has been cut off, when you reconnect on returning to

the vehicle, the Bluetooth connection will be restored automatically

(depending on the compatibility of the telephone).

MANAGING CALLS

A long press on SOURCE or TEL also

ends the call.

In the contextual menu, select " Hang up "

to end the call.

Secret - Mute
(so that the caller cannot hear)

Combined mode
(to leave the vehicle without ending the call)

306

05 USING THE TELEPHONE

From the contextual menu, select

" DTMF tones " and conﬁ rm to use

the digital keypad to navigate in the

interactive voice response menu.

From the contextual menu, select

" Switch " and conform to return to a call

left on hold.

Interactive voice response

Consultation call

Content .. 18 19 20 21 ..
