Peugeot 508 Dag (2010.5). Instruction - part 18

259

06 USING THE TELEPHONE

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed display

in the screen.

"Yes " to accept the call is selected by
default.
Press " OK " to accept the call.
Select " No

" and conﬁ rm to reject the

call.

A short press on TEL or PHONE

accepts an incoming call.

A long press on TEL or PHONE or a

press on HANG UP

rejects an incoming

call.

260

06 USING THE TELEPHONE

OPTIONS DURING A CALL *

During a call, press the MODE button

several times to select display of the
telephone screen, then press " OK " to

open the contextual menu.

Select " Private mode

" and conﬁ rm to

take the call on the handset.
Or select " Hands-free mode " and

conﬁ rm to take the call via the vehicle's

speakers.

Select " Put call on hold

" and conﬁ rm to

put the current call on hold.
Or select " Resume the call " and

conﬁ rm to resume the call on hold.

Select " DTMF ring tones " to use the

numerical keypad, so as to navigate

through the menu of an interactive vocal

server.

Select " Hang up " to end the call.

* Depending on the compatibility of the phone and your service plan.

it is possible to hold a 3-way conference call by making 2 calls

in succession. Select " Conference mode call

" in the contextual

menu accessible using the TEL button at the steering mounted

controls.

261

Press PHONE .

Select " List of the paired peripherals "

and conﬁ rm.

It is possible to:
-

" Connect " or " Disconnect " the
selected telephone,

- delete the pairing of the selected

telephone.

It is also possible to select all pairings.

USING THE TELEPHONE

MANAGING PAIRED TELEPHONES

CHANGING THE RING TONE

Press PHONE .

Select " Phone functions

" and conﬁ rm.

Select " Ring options

" and conﬁ rm.

You can adjust the volume and the ring

tone used.

Select " Bluetooth functions ".

Select " OK

" and conﬁ rm to save the

changes.

262

07 DIRECTORY - ADDR BOOK

Access to the "CONTACTS" menu

" Directory of contacts

Directory of contacts

Directory of contacts "

" Display contacts

Display contacts

Display contacts " ("

" ("

" (" Open

Open

Open ",

" Import

Import

Import ", "

", "

", " Delete

Delete

Destination:
- from the contacts in the mobile telephone and the SIM

card (depending on the synchronization options in the

Bluetooth menu and the compatibility of the telephone),

saved in the system.

Select a contact and conﬁ rm.
Then select " Guide

" and conﬁ rm.

Telephone contacts:
- from the mobile telephone and the SIM card

(depending on the synchronization options in the

Bluetooth menu and the compatibility of the telephone),

saved in the system.

Press ADDR BOOK .

Select a telephone contact and conﬁ rm to start the call.

The sorting of the list of

contacts depends on the
telephone used.

263

DIRECTORY/SYNCHRONIZING CONTACTS

Press ADDR BOOK twice then select
" New contact " to enter a new contact.

Press ADDR BOOK twice then select
"

Conﬁ guration " and conﬁ rm.

Select " Delete all contacts " to delete
the contacts saved in the system.

Select " Import all the entries " to import
all the contacts in the telephone and
save them in the system.

Select " Synchronization options " and

conﬁ rm:
-

No synchronization: only the
contacts saved in the system

(always present).

Display telephone contacts: only the
contacts saved in the telephone.

- Display SIM card contacts: only the

contacts saved on the SIM card.

Display all phone contacts:

contacts on the SIM card and in the

telephone.

Press ADDR BOOK twice then select
" Contact mem. status " to see the
number of contacts saved in the system
or imported, and the free memory.

DIRECTORY - ADDR BOOK

264

MANAGING CONTACTS

ADDR BOOK twice then select

" Display contacts

" and conﬁ rm.

Select the desired contact and conﬁ rm.

Select " Import " to copy one contact to
the system.

Select " Open

" to view an external contact

or modify a contact saved in the system.

Select OK or ESC

to exit this menu.

Select " Delete " to delete a contact saved
in the system.

It is necessary to import an external contact to modify the record.

It will be saved in the system. It is not possible to modify or delete

contacts in the telephone or the SIM card via the Bluetooth

connection.

DIRECTORY - ADDR BOOK

265

08 RADIO

Access to the "RADIO" menu

" FM/AM band

FM/AM band

FM/AM band "

Press  or  or use the rotary control to select the

previous or next station in the list.

This list can also be displayed by pressing LIST on the

steering mounted controls.

Go from the list to the menu (left/right).

A long press on LIST refreshes

the list of stations received.

Press RADIO .

266

RADIO

By alphabetical list
Press RADIO or LIST , select the station

of your choice and conﬁ rm.

By automatic frequency search
Press  or  for the automatic search

for a lower or higher radio frequency.

Or turn the thumb wheel on the steering

mounted control.

  By manual frequency search
Press    or    to adjust the radio
frequency step by step.

Press the button on the numerical
keypad to recall a preset station.
Or press then turn the thumb wheel at

the steering mounted controls.

SELECTING A STATION

The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode.

This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio
system.

PRESETTING A STATION

Press one of the buttons on the
numerical keypad for 2 seconds to
preset the current station.
An audible signal conﬁ rms that the

station has been preset.

The quality of reception is represented
by this symbol.

267

Press RADIO .

ACTIVATE/DEACTIVATE RDS

RDS, if displayed, allows you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the entire country as radio stations do not

cover 100 % of the territory. This explains the loss of reception of

the station during a journey.

Select " Guidance options

" and conﬁ rm.

Select " Activate/Deactivate RDS " and

conﬁ rm.

RADIO

Select " Activate/Deactivate RDS ".

Radio displayed, press " OK

" to display the contextual menu.

268

09 MUSIC MEDIA PLAYERS

Access to the "MUSIC MEDIA PLAYER" menu

" MEDIA

MEDIA

MEDIA "

This list can also be displayed by pressing LIST

at the steering mounted controls.

Go from the list to the menu (left/right).

Press MUSIC .

269

CD, MP3 CD/USB PLAYER

The audio equipment will only play audio ﬁ les with ".m4a, .m4b, .aac,

.ﬂ ac, .ogg and.mp3" ﬁ le extensions and with a bit rate of between

32 Kbps and 320 Kbps.
It also supports the VBR (Variable Bit Rate) mode.

No other type of ﬁ le (.wma, .mp4, .m3u...) can be played.

The sampling rates supported are 11, 22, 44 and 48 KHz.

It is advisable to restrict ﬁ le names to 20 characters, without using of

special characters (e.g. : " " ? ; ù) to avoid any playing and displaying

problems.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it may not be played correctly.
It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.
In the particular case of a multi-session CD, the Joliet standard is
recommended.

INFORMATION AND ADVICE

The system supports USB mass storage or IPod

devices via the USB port (suitable cable not supplied).
Control of the peripheral device is with the audio
system controls.
Other peripherals, not recognised on connection, must

be connected to the auxiliary socket using a Jack cable

(not supplied).

In order to be read, a USB memory stick must be formatted FAT 16 or 32.

270

MUSIC MEDIA PLAYERS

CD, MP3 CD, USB PLAYER

Insert the CD in the player, insert the USB memory
stick in the USB player or connect the USB

peripheral to the USB port using a suitable cable

(not supplied).

The system builds playlists (in temporary memory),

an operation which can take from a few seconds to
several minutes.
Reduce the number of non-music ﬁ les and the

number of folders to reduce the waiting time.

The playlists are updated every time the ignition is

switched off or connection of a USB memory stick.
Play starts automatically after a period which
depends on the capacity of the USB memory stick.

SELECTION OF SOURCE

The SOURCE

button on the steering mounted controls allows a

direct change to the next media source.

" CD/CD MP3 "

" USB, IPod "

" AUX "

" STREAMING "

" RADIO "

Press MUSIC to display the " MEDIA "
menu.

Select " Following media source " and

conﬁ rm.

Repeat the operation as many times as necessary to obtain the

desired media source (except for radio which is accessible either

with SOURCE or RADIO

271

SELECTING A TRACK

MUSIC MEDIA PLAYERS

Previous track.

Next track.

Previous folder.

Next folder.

Fast forward.

Fast backward.

Pause: long press on SRC .

LIST: List of USB or CD tracks or
folders

Up or down in the list.

Conﬁ rm, next menu level.

Up one menu level.

Long press

272

AUDIO STREAMING

Streaming allows audio ﬁ les on your telephone to be played via the

vehicle's speakers.

Connect the telephone: see "USING THE TELEPHONE".
Select " Audio " or " All

" proﬁ le.

If play does not start automatically, it may be necessary to start the
audio playback from the telephone.
Control is from the peripheral device only.

Once connected in streaming mode, the telephone is considered to be

a media source.
It is recommended that you activate " Repeat " on the Bluetooth
peripheral.

MUSIC MEDIA PLAYERS

IPOD/IPHONE

Connect the IPod or IPhone to the USB port using a suitable cable

(not supplied).
Play starts automatically.

Control is via the audio system.

The classiﬁ cations available are those of the portable device

connected (artists/albums/genres/playlists/audiobooks/podcasts).

The default classiﬁ cation used is by artist. To modify the classiﬁ cation

used, return to the ﬁ rst level of the menu then select the desired

classiﬁ cation (playlists for example) and conﬁ rm to go down through

the menu to the desired track.

273

MUSIC MEDIA PLAYERS

USING THE AUXILIARY INPUT (AUX)
Cable not supplied

Connect the portable device (MP3 player…) to the auxiliary JACK

socket using an audio cable.

Press MUSIC to display the " MEDIA "
menu.

Select " Activate/Deactivate AUX input "

and conﬁ rm.
First adjust the volume of your portable

device (to a high level). Then adjust the

volume of your audio system.

Display and management of the controls are via the portable device.

274

AUDIO SETTINGS

They are accessible by a long press on

RADIO or MUSIC or from the " FM/AM
band " or " MEDIA " menus.

" Equalizer

" (choice of 6 musical ambiences)

Equalizer

" Bass "

" Treble "

" Loudness

" (Activate/Deactivate)

" Distribution " (" Driver ", "

Driver

All passengers

" Le-Ri balance

" (Left/Right)

" Fr-Re balance

" (Front/Rear)

" Auto. Volume

" depending on road speed (Activate/Deactivate)

The audio settings ( Equalizer ,

Equalizer Bass , Treble and Loudness

) are

different and independent for each sound source.
The settings for distribution and balance are common to all sources.

The distribution (or spatialisation) of sound is an audio process that

allows the audio quality to be adapted to the number of listeners in the
vehicle.

Content .. 16 17 18 19 ..
