367

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

Auxiliary socket (AUX)

Connect the portable device (MP3 player, …) to
the auxiliary Jack socket using an audio cable
(not supplied).

Press the SOURCE button several
times in succession and select AUX.

First adjust the volume on your portable device
(to a high level). then adjust the volume on
your audio system. Operation of controls is via
the portable device.

Do not connect a device to both the
Jack auxiliary socket and the uSB port
at the same time.

CD player

Insert circular compact discs only.
Some anti-pirating systems, on original discs
or CDs copied using a personal recorder, may
cause faults which are no reflection on the
quality of the vehicle's player.
Insert a CD in the player, play begins
automatically.

to play a disc which has already
been inserted, press the SOURCE
button several times in succession
and select CD.

Press one of the buttons to select a
track on the CD.

Press the LIST REFRESH button to
display the list of tracks on the CD.

Press and hold one of the buttons for
fast forward or rewind.

368

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

the audio system will only play files with
the extension ".mp3" with a sampling rate of
22.05 KHz or 44.1 KHz. No other type of file
(.wma, .mp4, .m3u, etc.) can be played.

It is advisable to restrict file names to
20 characters without using special characters
(e.g. " ? ; ù) to avoid any playing or displaying
problems.

In order to be able to play a recorded CDR or
CDRW, when recording, the ISO 9660 level 1.2
or Joliet file format is recommended.
If the disc is recorded in another format, it may
not be played correctly.
It is recommended that the same recording
format is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet format is recommended.

Information and advice

to play a disc which has already
been inserted, press the SOURCE
button several times in succession
and select "CD".

Press one of the buttons to select a
folder on the CD.

Press one of the buttons to select a
track on the CD.

Press the LIST button to display
the list of directories of the MP3
compilation.

Press and hold one of the buttons for
fast forward or backward play.

Playing an MP3 CD
compilation

Insert an MP3 compilation in the CD player.
the audio equipment searches for all of the
music tracks, which may take anything between
a few seconds and several tens of seconds,
before play begins.

On a single disc, the CD player can
read up to 255 MP3 files spread over
8 folder levels. However, it is advisable
to keep to a limit of two levels to reduce
the access time before the CD is
played.
While the CD is being played, the folder
structure is not followed.
All of the files are displayed on a single
level.

369

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

use only uSB memory sticks formatted FAt32
(File Allocation table).

It is recommended that you use
genuine Apple

uSB cables for correct

operation.

to protect the system, do not use a
uSB hub.

* In certain cases, play of the audio files must

be initiated from the keypad.

** If the telephone supports the function.

Bluetooth

audio streaming

Streaming allows music files on the telephone
to be played via the audio system.

Connect the telephone: see the "Telephone"
section.

Select in the "Bluetooth: Telephone - Audio"
menu the telephone to be connected.
the audio system connects to a newly paired
telephone automatically.

Control of tracks to be played is via the buttons
on the audio system control panel and the
steering mounted controls**. the contextual
information can be displayed in the screen.

Activate the streaming source by
pressing the SOURCE* button.

Connecting Apple

players

Connect the Apple

player to the uSB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

the classifications available are those of the
portable device connected (artists / albums /
genres / playlists / audiobooks / podcasts).

the version of software in the audio system
may not be compatible with the generation of
your Apple

player.

370

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

telephone

Pairing a Bluetooth

telephone

Screen C
(Available according to model and version)

As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
of the Bluetooth mobile telephone with
the Bluetooth hands-free system of
your audio equipment must be carried
out with the vehicle stationary and the
ignition on.

go to www.peugeot.co.uk for more information
(compatibility, more help, ...).

Activate the telephone's Bluetooth function
and ensure that it is "visible to all" (telephone
configuration).

Press the MENU button.

In the menu, select:
- "Bluetooth: Telephone - Audio"
- "Bluetooth configuration"
- "Perform a Bluetooth search"

A window is displayed with a message that a
search is in progress.

the services available depend on
the network, the SIM card and the
compatibility of the Bluetooth device
used.
Consult your telephone's manual and
your operator to find out which services
are available to you.

* If your telephone is fully compatible.

the first 4 telephones recognised are displayed
in this window.

the "Telephone" menu permits access to the
following functions in particular: "Directory"*,
"Calls list", "Consult the paired equipment".

Select the telephone to be connected from the
list. Only one telephone can be connected at
a time.

A virtual keypad is displayed in the screen:
enter a code with at least 4 digits.

Confirm by pressing OK.

A message in the screen indicates the telephone
chosen. to accept the pairing, enter the same
code on the telephone, then confirm with OK.
If pairing fails, the number of attempts is not
limited.

A message that the pairing has been
successful appears in the screen.

the automatic connection authorised is only
active after the telephone has been configured.
the directory and the call list can be accessed
after the necessary synchronisation period.

371

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Select the YES tab on the display
using the buttons.

Confirm by pressing OK.

Press this button at the steering
mounted controls to accept the call.

Making a call

From the "Bluetooth : Telephone - Audio"
menu.

Select "Manage the telephone call".

Select "Call".

Select "Calls list".

Select "Directory".

Press this button for more than two
seconds for access to your directory,
then navigate using the thumbwheel.

to dial a number, use your telephone's keypad,
with the vehicle stationary.

Ending a call

During a call, press this button for
more than 2 seconds.

Confirm with OK to end the call.

the system accesses the telephone's
contacts directory, depending on its
compatibility, and while it is connected
by Bluetooth.

With certain telephones connected by
Bluetooth you can send a contact to the
directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
the menu for the directory is not
accessible if it is empty.

372

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

Screen menu map(s)

Radio-CD

REG mode

CD repeat

Shuffle play

Vehicle config*

R wiper in rev

Options

Diagnostic

RDS options

View

Abandon

Screen A

* the settings vary according to the trim level of

the vehicle.

Guide lighting

Units

Temperature: °Celsius / °Fahrenheit

Fuel consumption: KM/L - L/100 - MPG

Display adjust

Month

Day

Hour

Minutes

Year

12 H/24 H mode

Language

Italiano

Nederlands

Portuguès

Português do Brasil

Français

Deutsch

Čeština

English

Hrvatski

Español

Magyar

373

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

Media parameters

MEDIA

TELEPHONE

Choice of playback mode

Choice of track listing

Normal

By folders

Random all

By genres

Random

By artists

Repeat

By playlists

Call

Radio parameters

Directory

Calls list

Voice mail box

Dial

Directory management

Telephone management

Hang up

Connections management

BLUETOOTH CONNECTION

Search for a device

Delete an entry

Delete all entries

Consult an entry

Telephone status

Screen C

374

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

Define the vehicle
parameters*

Choice of sounds

Choice of language

Display configuration

* Depending on vehicle equipment.

Choice of units

Date and time adjustment

Display parameters

Brightness

PERSONALISATION -
CONFIGURATION

375

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

the table below gives answers to the most frequently asked questions on your audio system.

QUESTION

ANSWER

SOLUTION

With the engine off, the
audio system switches off
after a few minutes of use.

When the engine is switched off, the audio system operating time
depends on the state of charge of the battery.
the switch-off is normal: the audio equipment switches to economy
mode and switches off to prevent discharging of the vehicle's
battery.

Start the vehicle's engine to increase the battery
charge.

the message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction in volume or CD play
stopping.

Switch the audio system off for a few minutes to
allow the system to cool.

Frequently asked questions

QUESTION

ANSWER

SOLUTION

there is a difference in
sound quality between the
different audio sources
(radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass,
treble, Ambience, Loudness) can be adapted to the different sound
sources, which may result in audible differences when changing
source (radio, CD...).

Check that the audio settings (Volume, Bass,
treble, Ambience, Loudness) are adapted to the
sources listened to. It is advisable to set the audio
functions (Bass, treble, Front-Rear Balance, Left-
Right Balance) to the middle position, select the
musical ambience "None" and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

Radio

376

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

QUESTION

ANSWER

SOLUTION

the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND ASt button to return to the
waveband (AM, FM1, FM2, FMASt) on which the
stations are stored.

the traffic announcement
(tA) is displayed. I do
not receive any traffic
information.

the radio station is not part of the regional traffic information
network.

tune to a radio station which broadcasts traffic
information.

the quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

the vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

the environment (hills, buildings, tunnels, underground car parks...)
block reception, including in RDS mode.

this phenomenon is normal and does not indicate
a failure of the audio equipment.

the aerial is absent or has been damaged (for example when going
through an automatic car wash or into an underground car park).

Have the aerial checked by a PeugeOt dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for another
frequency giving better reception of the station.

Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.

377

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

Media

QUESTION

ANSWER

SOLUTION

the message "uSB
peripheral error" is
displayed on the screen.
the Bluetooth connection
is cut.

the battery of the peripheral may not be sufficiently charged.

Recharge the battery of the peripheral device.

the uSB memory stick is not recognised.
the uSB memory stick may be corrupt.

Reformat the uSB memory stick.

the CD is ejected
automatically or is not
played by the player.

the CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.
the CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment.

Check that the CD is inserted in the player the
right way up.

Check the condition of the CD: the CD cannot
be played if it is too damaged.

Check the content in the case of a recorded
CD: consult the advice in the "Audio" section.

the audio equipment's CD player does not
play DVDs.

Due to their quality level, certain writeable
CDs will not be played by the audio system.

the CD player sound is
poor.

the CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable
conditions.

the audio equipment settings (bass, treble, ambiences) are
unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

378

Audio and Telematics

308_en_Chap10c_RD45_ed01-2016

QUESTION

ANSWER

SOLUTION

I am unable to access my
voicemail.

Few telephones or service providers allow the use of this function.

Telephone

379

Alphabetical index

308_en_Chap11_index-alpha_ed01-2016

ABS ............................................................... 121
Accessories ................................. 152, 220, 222
AdBlue

additive ....................... 26, 32, 233-237

Additive, Diesel .............................................230
Adjusting headlamps .................................... 113
Adjusting head restraints ................................77
Adjusting the seat ..................................... 73, 74
Adjusting the air distribution ...........................95
Adjusting the air flow .......................................95
Adjusting the date ......................................47-49
Adjusting the height and reach

of the steering wheel ....................................72

Adjusting the lumbar support ..........................73
Adjusting the temperature ..............................95
Adjusting the time ......................................47-49
Advice on driving .................................. 146, 147
Affaire version ...............................................291
Airbags ............................................ 23, 1 27, 1 34
Airbags, curtain .....................................129, 130
Airbags, front......................................... 127, 130
Airbags, lateral ......................................129, 130
Air conditioning ............................ 10 , 93 , 95, 9 8
Air conditioning, automatic .......................92, 9 5
Air conditioning, digital .................................100
Air conditioning, manual ................... 92-94, 100
Air intake .........................................................99
Air vents ..........................................................91
Alarm ...............................................................67
Anti-lock braking system (ABS) .................... 121
Anti-pinch ................................................70, 102
Anti-slip regulation (ASR) ............................. 121
Anti-theft .................................................53, 154
Armrest ............................................................82
Armrest, front ..................................................84
Armrest, rear ...................................................86
Assistance call .............................................. 119
Audible warning ............................................ 121
Audio streaming (Bluetooth) ......... 312, 314, 369
Auxiliary ........................................................ 312

Back-up key.....................................................63
Battery ....................................219 , 231, 2 68-271
Battery, charging ...........................................270
Battery, remote control ................ 54, 5 5, 6 4 , 65
Bicycle carrier ...............................................222
Blanking screen (snow shield) .............. 217, 218
Blind, panoramic roof ....................................102
Blind spot sensors ..................................16, 195
BlueHDi .....................................28 , 32 , 233, 2 74
Bluetooth (hands-free) ..................346 , 347 , 370
Bluetooth (telephone) ........................... 346, 347
Bonnet ...........................................................225
Boot .................................................................61
Boot lamp ........................................................88
Brake discs ....................................................232
Brake lamps .......................................... 257, 259
Brakes ...............................................21, 2 5, 2 32
Bulbs (changing) ...........................252, 257, 259

Cable, audio .................................................. 312
Cable, jack .................................................... 312
Capacity, fuel tank ........................................ 213
Cap, fuel filler ................................................ 213
CD, MP3 ........................................ 312 , 367, 3 68
Central locking ..............................51, 5 6 , 58 , 59
Changing a bulb ............................252, 257, 259
Changing a fuse ........................... 262, 264, 266
Changing a wheel .................................246, 247
Changing a wiper blade ........................ 117, 222
Changing the remote control battery ........54 , 64
Checking the engine oil level ..........................31
Checking the levels ............................... 228 -230

Checking tyre pressures

(using the kit) ..............................................239

Checks ..................................226, 2 27, 2 31, 2 32
Child lock .................................................63, 144
Children .........................................138, 142, 143
Children (safety) ............................................144
Child seats ............ 126, 131-133, 137, 138, 145
Child seats, conventional .............................. 137
Child seats, ISOFIX ......................140, 142, 143
Closing the boot ..............................................61
Closing the doors ..........................51 , 56, 5 8, 5 9
Collision risk alert .........................................190
Compressor, tyre inflation ............................239
Configuration, vehicle .....................................44
Connection, Bluetooth ......................... 346, 347
Control, electric windows ................................70
Control, emergency boot release ...................62
Control, emergency door ................................63
Control, heated seats ......................................76
Control stalk, lighting .............................. 14, 107
Control stalk, wipers .............................. 114-116
Courtesy lamps .............................................103
Cruise control ........................ 173 , 177 , 180 , 181
Cruise control, dynamic ................................180
Cup holder .......................................................82

DAB (Digital Audio Broadcasting) -

Digital radio ......................... 310, 3 11 , 364 , 365

Date (setting) ..............................................47-49
Daytime running

lamps ................. 108, 1 10, 2 52 , 253, 2 55 , 256

Deactivating the passenger

airbag .................................................. 127, 134

380

Alphabetical index

308_en_Chap11_index-alpha_ed01-2016

Hazard warning lamps .......................... 118, 238
Headlamp adjustment ................................... 113
Headlamps, automatic

illumination ...................................108, 111, 112

Headlamps, dipped beam ............. 107 , 252, 2 54
Headlamps, halogen .............................252, 254
Headlamps, main beam ........107, 2 52 , 254, 2 56
Headlamp wash ............................................ 115
Head restraints, front ......................................77
Head restraints, rear .................................80, 81
Heating ..........................................10, 9 1, 9 3 , 94
Hill start assist ...............................................162
Horn............................................................... 121

eBFD ............................................................. 121
eco-driving (advice) ........................................10
economy mode ............................................. 219
electronic brake force distribution (eBFD) ... 121
electronic stability control (eSC) ............ 17, 121
emergency braking assistance (eBA) .......... 121
emergency call ............................................. 119
emergency collision braking ...........22, 190, 193
emergency switching off ...............................152

Deactivation of DSC (eSC) ...........................123
Deadlocking ..............................................52, 6 0
Defrosting ........................................93, 100, 101
Demisting ................................................93, 100
Demisting, rear screen ......................... 101, 105
Denon (audio system) .............................89 , 293
Dimensions ...................................................289
Dipstick ....................................................31, 228
Direction indicators ....... 112 , 252, 2 55 , 257 , 259
Display of inter-vehicle time ..........................187
Display screen, instrument panel .................164
Display screen, multifunction

(with audio system) .......................................49

Display screen, multifunction

(without audio system) ..................................49

Driver Sport Pack ..........................................169
Driving abroad...............................................107
Driving economically.......................................10
Driving positions (storing) ...............................75
Dynamic pack (sport) ....................................169
Dynamic stability

control (DSC) ...........................17, 21, 121, 123

Filling the AdBlue

tank ................................237

Filling the fuel tank ................................ 213, 215
Filter, air ........................................................231
Filter, oil .........................................................231
Filter, particle ........................................230, 231
Filter, passenger compartment .....................231
Fitting a wheel ...............................................248
Fitting roof bars .............................................223
Fittings, boot ............................................. 87 , 88
Fittings, interior ...............................................82
Flap, fuel filler ................................................ 213
Flashing indicators ........................................ 112
Foglamps, rear ..............................109, 2 57, 2 59
Foglamps ......................................................252
Foglamps, front .............................109, 2 52, 2 56
Folding the rear seats .....................................80
Frequency (radio) ................................. 308, 309
Fuel.......................................................... 10, 215
Fuel consumption ............................................10
Fuel tank..........................................................22
Fusebox, engine compartment .....................266
Fuses ............................................ 262, 264, 266

emergency warning lamps ................... 118, 238
emissions control system, SCR .....................27
energy economy mode ................................. 219
engine compartment ........................... 226, 227
engine, Diesel ......... 15, 2 15 , 227, 2 74 , 281, 2 85
engine, petrol ................................215, 2 26 , 275
engines .........................................275 , 281, 2 85
environment ........................................10, 5 5 , 64

gauge, fuel.................................................... 213
gearbox, automatic ....10 , 12, 1 5 , 151 , 153, 1 62,

165 , 169-171, 1 77, 1 81, 2 32 , 268

gearbox, electronic ........................................10
gearbox, manual ............... 10 , 12, 1 5 , 162 , 163,

170, 1 71 , 177 , 181 , 232

gear lever .......................................................10
gear lever, automatic gearbox .....................165
gear lever, manual gearbox .........................163
gear shift indicator .......................................164
glove box, refrigerated ...................................82
guide-me-home ............................................ 112

381

Alphabetical index

308_en_Chap11_index-alpha_ed01-2016

Jack .................................................85, 24 6 , 312

Identification, vehicle ....................................292
Ignition .............................................98, 150, 152
Immobiliser, electronic ..................... 53 , 65 , 154
Indicator, AdBlue

range .................................32

Indicator, coolant temperature ........................28
Indicator, engine oil level ................................31
Indicator lamps, operation ............ 14, 1 5 , 17, 2 0
Indicator lamps, status ..............................15, 20
Indicators, direction ...................................... 112
Inflating tyres ..................................................10
Inflating tyres and accessories

(using the kit) ..............................................239

Instrument panel ............................................. 12
Intelligent traction Control ............................122
Interactive help ........................................44, 337
Inter-vehicle time ...........................................187
Isofix mountings .....................................140 -144

Key ....................... 50 , 51 , 56 , 58 , 59 , 63, 6 4, 6 5
Keyless entry

and Starting ...................... 58-60, 6 5, 1 51, 1 54

Key with remote control ..............51, 5 3, 5 9, 1 54
Kit, hands-free ..............................346, 3 47, 3 70
Kit, temporary puncture repair ................ 87 , 239

Labels, identification .....................................292
Level, brake fluid ...........................................229
Level, Diesel additive ............................230, 231
Level, engine coolant ..............................28, 230
Level, engine oil ......................................31, 228
Level, headlamp wash .......................... 116, 230
Levels and checks ................................ 226-230
Level, screenwash fluid ........................ 116, 230
Light-emitting diodes - LeDs ........252, 257, 259
Lighting ............................................14, 104, 107
Lighting dimmer ..............................................36
Lighting, guide-me home .................53, 111, 112
Lighting, interior ....................................103, 104
Lighting, mood ..............................................104
Lighting, welcome ......................................... 112
Loading ...................................................10, 223
Load reduction mode .................................... 219
Locating your vehicle ................................53 , 57

Locking ............................................................65
Long objects, transporting ..............................86
Low fuel level ..........................................22, 213
Luggage cover ..........................................88, 8 9
Luggage retaining strap ............................ 87, 8 8
Lumbar ......................................................73 , 78

Maintenance, routine ......................................10
Map reading lamps .......................................103
Markings, identification .................................292
Massage function ...........................................78
Mat ..................................................................83
Memorising a speed ..................................... 173
Menu ................................... 302 , 304, 3 06, 3 16,

318 , 322, 3 30 , 342, 3 44

Menu, main ...................................................362
Menus (audio) ............................. 302, 3 04, 3 06,

316, 3 18 , 342, 3 44

Menus (touch screen) ................. 295, 3 00, 3 01
Mirror, rear view ............................................106
Mirrors, door.................................. 101, 105, 195
Misfuel prevention ......................................... 214
Mountings, Isofix ................................... 140, 141
MP3 CD .........................................................368

382

Alphabetical index

308_en_Chap11_index-alpha_ed01-2016

Recirculation, air .......................................95, 9 9
Reduction of electrical load .......................... 219
Regeneration of the particle filter .................231
Reinitialisation of the under-inflation

detection system .........................................210

Reinitialising the remote control ...............54, 6 4
Reminder, key in ignition ...............................150
Remote control .................. 50, 5 1, 5 6, 5 8-60, 6 5
Removing a wheel ........................................248
Removing the mat ...........................................83
Replacing bulbs ............................252, 257, 259
Replacing fuses ................................... 262, 264
Replacing the air filter ...................................231
Replacing the oil filter ...................................231
Replacing the passenger

compartment filter ......................................231

Reservoir, headlamp wash ...........................230
Reservoir, screenwash .................................230
Resetting the service indicator .......................30
Resetting the trip recorder ..............................35
Reversing camera .........................................200
Reversing lamp ..................................... 257, 259
Risk areas (update) .......................................327
Roof bars .......................................................223
Running out of fuel (Diesel) .......................... 274

Navigation .....................................................322
Net, high load retaining ...................................90
Number plate lamps ......................................261

Oil change .....................................................228
Oil consumption ............................................228
OIl, engine .....................................................228
Opening the bonnet ......................................225
Opening the boot ......................... 50, 5 6, 5 8 , 61
Opening the doors ............................. 50 , 56, 5 8

Pads, brake ...................................................232
Paint colour code ..........................................292
Panoramic glass sunroof ..............................102
Parcel shelf, rear .............................................87
Park Assist ....................................201, 203, 206
Parking brake ..................................15, 154, 232

Radio .................................... 308, 309, 312, 362
Radio, digital (Digital Audio

Broadcasting - DAB) ........................... 310, 311

Range, AdBlue

..............................................32

RDS ...............................................................309
Rear screen, demisting .................................101
Recharging the battery .................................270

Safety, children ..............................127, 131 -133,

138, 142, 143, 145

Saturation of the particle filter (Diesel) .........231

Parking brake, electric ....................20, 1 55 , 160
Parking sensors, front ...................................198
Parking sensors, rear....................................198
PeugeOt Connect Apps .............................341
PeugeOt Connect Assistance ................... 119
PeugeOt Connect Packs ........................... 119
PeugeOt Connect SOS ............................. 119
PeugeOt Connect Sound (RD5) ................359
Plates, identification......................................292
Player, Apple

.......................................314, 369

Player, MP3 CD ............................. 312 , 367, 3 68
Player, uSB ...........................................312, 366
Port, uSB ..................................82, 8 5 , 312, 3 66
Pressures, tyres ....................239 , 245, 2 51, 2 92
Pre-tensioning seat belts ..............................126
Priming pump ................................................ 274
Priming the fuel system ................................ 274
Protecting children .................127, 131-133, 138,

140, 142, 143, 145

Puncture ........................................................239

Content .. 22 23 24 25 ..
