Peugeot 308 (2017 year). Instruction

Access

308_en_Chap02_ouvertures_ed01-2016

Back-up key

Unlocking / Locking using the integral key with Keyless
Entry and Starting

the integral key is used to lock and unlock the
vehicle when the electronic key cannot operate:
-

battery flat, vehicle battery discharged or
disconnected, ...

vehicle located in an area with strong
electromagnetic signals.

F Maintain a pull on button 1, to extract the

integral key 2.

F Insert the integral key in the door lock, then

turn it to the rear.

Unlocking the driver's door

F Insert the integral key in the door lock, then

turn it to the front.

F Open the doors.
F For the rear doors, check that the child lock

is not on.

F Insert the integral key in the latch located

on the edge of the door and turn it an
eighth of a turn to the right for the right-
hand door, and to the left for the left-hand
door.

F Close the doors and check that the vehicle

has locked correctly from the outside.

If the alarm is activated, the audible
signal triggered on opening a door
with the key (integral with the remote
control) will stop when the ignition is
switched on.

Unlocking the passenger doors

F Pull the interior door opening control.

For more information on the Child lock,
refer to the corresponding section.

Locking the driver's door

Locking the passenger doors

Access

308_en_Chap02_ouvertures_ed01-2016

Changing the battery

Battery ref.: CR2032 / 3 volts.
this replacement battery is available from a
PeugeOt dealer or a qualified workshop.
A message appears in the instrument panel
screen when replacement of the battery is
needed.
F unclip the cover using a small screwdriver

at the cutout.

F  Lift off the cover.
F  Remove the flat battery from its location.
F  Fit the new battery into its location

observing the original direction of fitment.

F Clip the cover onto the casing.

Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
take them to an approved collection
point.

Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.

Remote control problem -
reinitialisation

F Place the mechanical key (integral with the

remote control) in the lock to unlock your
vehicle.

F Remove the mat under 12 V socket.
F Place the electronic key in the housing

provided.

F Switch on the ignition by pressing StARt/

StOP.

the electronic key is fully operational again.

If the problem persists, contact a PeugeOt dealer
or a qualified workshop as soon as possible.

Access

308_en_Chap02_ouvertures_ed01-2016

Lost keys, remote control, electronic key

Visit a PeugeOt dealer with the vehicle's registration certificate, your personal identification documents and if possible, the label bearing the
key code.
the PeugeOt dealer will be able to retrieve the key code and the transponder code required to order a new key

Remote control

the high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the
vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk of stopping it from
working and the remote control would have to be reinitialised.
the remote control does not operate when the key is in the ignition, even when the ignition is switched off.

Locking the vehicle

Driving with the doors locked may make access to the passenger compartment by the emergency services more difficult in an emergency.
As a safety precaution (with children on board), remove the key from the ignition or take the electronic key when you leave the vehicle, even for
a short time.

Electrical interference

the Keyless entry and Starting electronic key may not operate if close to certain electronic devices: telephone, laptop computer, strong
magnetic fields, ...

Anti-theft protection

Do not make any modifications to the electronic engine immobiliser system; this could cause malfunctions.
Don't forget to turn the steering to engage the steering lock.

When purchasing a second-hand vehicle

Have the key codes memorised by a PeugeOt dealer, to ensure that the keys in your possession are the only ones which can start the vehicle.

Access

308_en_Chap02_ouvertures_ed01-2016

Locking/ unlocking from the inside

After unlocking, if no door is opened
within 30 seconds, the doors lock again
automatically.

If the vehicle is deadlocked or locked
with the remote control or the door
handles, the button is not active. In this
case, use the key or the remote control
to unlock.

Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
difficult in an emergency.

F Press the button.
this allows the doors and the boot to be locked
or unlocked.

When carrying large objects with the
boot open, you can press this button to
lock just the doors.
When locking from inside, the door
mirrors do not fold.

to activate or deactivate this
function, press and hold the button
until a message appears in the
screen.

Automatic central locking of the
doors

the doors can lock automatically while driving
(speed above 6 mph (10 km/h)).

Access

308_en_Chap02_ouvertures_ed01-2016

F Lock the vehicle using the "Keyless entry

and Starting" system.

Locking the vehicle with full
alarm system

Activation

F Lock the vehicle using the

remote control.

the monitoring system is active: the indicator
lamp in the button flashes once per second
and the direction indicators come on for about
2 seconds.
After an instruction to lock the vehicle using
the remote control or the Keyless entry
and Starting system, the exterior perimeter
monitoring is activated after a delay of
5 seconds, the interior volumetric monitoring
after 45 seconds.
If an opening (door, boot, bonnet...) is not
closed fully, the vehicle is not locked but
monitoring will be activated after a delay of
45 seconds.

F Switch off the ignition and get out of the vehicle.

System which protects and provides a deterrent
against theft and break-ins.
It provides the following types of monitoring:

Alarm

Exterior perimeter

the system checks for opening of the vehicle.
the alarm is triggered if anyone tries to open a
door, the boot or the bonnet.

Self-protection function

the system checks for the
disconnection of any of its components.
the alarm is triggered if the battery,
the button or the wires of the siren are
disconnected or damaged.

For all work on the alarm system,
contact a PeugeOt dealer or a
qualified workshop.

Interior volumetric

the system checks for any variation in the
volume in the passenger compartment.
the alarm is triggered if anyone breaks a
window, enters the passenger compartment or
moves inside the vehicle.

the system checks for movement of the vehicle
on the ground.
the alarm is triggered if the vehicle is lifted,
moved or collided with.

Tilt*

For vehicles fitted with the system, the
volumetric monitoring is not compatible
with programmed temperature pre-
conditioning.

* On gt and gti versions.

Access

308_en_Chap02_ouvertures_ed01-2016

Deactivation

F Press this unlocking button on

the remote control.

F unlock the vehicle using the "Keyless entry

and Starting" system.

If the vehicle self-locks automatically
(occurs after 30 seconds if a door or
the boot is not opened), the monitoring
system is not reactivated automatically.
to reactivate the system, it is necessary
to unlock and then lock the vehicle
again, using the remote control or the
"Keyless entry and Starting" system.

the monitoring system is deactivated: the
indicator lamp in the button goes off and the
direction indicators flash for about 2 seconds.

Locking the vehicle with exterior perimeter monitoring
only

Deactivate the interior volumetric monitoring
(and tilt monitoring if your vehicle has it) to
avoid unwanted triggering of the alarm in
certain cases such as:
-

occupant(s) present in the vehicle,

leaving a window partially open,

washing your vehicle,

changing a wheel,

towing your vehicle,

transport on a ferry.

Deactivating the volumetric
monitoring

the tilt alarm is deactivated as well, if your
vehicle has it.

F Switch of the ignition and within

ten seconds press this button
until its indicator lamp is on fixed.

F get out of the vehicle.

F Immediately lock the vehicle

using the remote control or the
"Keyless entry and Starting"
system.

Only the exterior perimeter protection system is
active: the indicator lamp in the button flashes
once per second.
to be taken into account, this deactivation must
be done every time the ignition is switched off.

Access

308_en_Chap02_ouvertures_ed01-2016

Failure of the remote control

to deactivate the monitoring functions:
F unlock the vehicle using the key (integral

with the remote control) in the driver's door
lock.

F Open the door; the alarm is triggered.
F Switch on the ignition; the alarm stops. the

indicator lamp in the button goes off.

Locking the vehicle without
activating the alarm

F Lock or deadlock the vehicle using the key

(integral with the remote control) in the
driver's door lock.

Operating fault

When the ignition is switched on, fixed
illumination of the indicator lamp in the
button indicates a fault in the system.

Automatic activation

this function is either not available, an option
or is standard.
2 minutes after the last door or the boot is
closed, the system is activated automatically.

F to avoid triggering the alarm on entering

the vehicle, first press the unlocking button
on the remote control or unlock the vehicle
using the Keyless entry and Starting
system.

Triggering of the alarm

this is indicated by sounding of the siren
and flashing of the direction indicators for
thirty seconds.
the monitoring functions remain active until
the alarm has been triggered eleven times in
succession.

When the vehicle is unlocked using
the remote control or the Keyless
entry and Starting system, rapid
flashing of the indicator lamp in the
button informs you that the alarm was
triggered during your absence.
When the ignition is switched on, this
flashing stops immediately.

Reactivating the volumetric
monitoring

the tilt alarm is reactivated as well, if your
vehicle has it.

the indicator lamp in the button goes off.

F Deactivate the exterior perimeter

monitoring by unlocking the
vehicle using the remote control
or the Keyless entry and Starting
system.

F Reactivate the full alarm system

by locking the vehicle using the
remote control or the "Keyless
entry and Starting" system.

the indicator lamp in the button flashes once
per second again.

Have it checked by a PeugeOt dealer or a
qualified workshop.

Access

308_en_Chap02_ouvertures_ed01-2016

electric windows

1.  Front left.
2.  Front right
3.  Rear right.
4.  Rear left.
5.  Deactivating the rear electric window

switches.

Manual operation

to open or close the window, press or pull
the switch fully: the window opens or closes
completely when the switch is released.
Pressing the switch again stops the movement
of the window.

Safety anti-pinch
(depending on version)

Automatic one-touch operation
(depending on version)

to open or close the window, press or pull the
switch gently. the window stops as soon as the
switch is released.

When the window rises and meets an obstacle,
it stops and immediately partially lowers again.

Maintaining the locking action (on the
key or the remote control) closes the
windows automatically.

the electric window switches remain
operational for approximately one minute after
the key has been removed.
Once this time has elapsed, the electric
windows will not operate. to reactivate them,
switch the ignition on again.

In the event of unwanted opening of the window
when closing automatically, press the switch
until the window opens completely, then pull
the switch immediately until the window closes.
Continue to hold the switch for approximately
one second after the window has closed.

the safety anti-pinch function is not active
during this operation.

Access

308_en_Chap02_ouvertures_ed01-2016

Reinitialising the electric
windows

Always remove the key when leaving
the vehicle, even for a short time.
In the event of contact during operation
of the windows, you must reverse the
movement of the window. to do this,
press the switch concerned.
When operating the passenger electric
window switches, the driver must
ensure that no one is preventing correct
closing of the windows.
the driver must ensure that the
passengers use the electric windows
correctly.
Be aware of children when operating
the windows.

For the safety of your children, press
this switch to prevent operation
of the windows of the rear doors,
irrespective of their position.

Deactivating the rear
window controls

With the indicator lamp on, the rear switches
are deactivated.
With the indicator lamp off, the switches are
active.

Following reconnection of the battery, the
safety anti-pinch function must be reinitialised.
the safety anti-pinch is not active during these
operations:
-

lower the window completely, then raise
it, it will rise in steps of a few centimetres
each time the switch is pressed. Repeat
the operation until the window closes
completely,

press and hold the switch upwards for
at least one second after reaching this
position, window closed.

Ease of use and comfort

308_en_Chap03_ergonomie-et-confort_ed01-2016

Steering wheel adjustment

F When stationary, lower the control lever

to release the steering wheel adjustment
mechanism.

F Adjust the height and reach to suit your

driving position.

F Pull the control lever to lock the steering

wheel adjustment mechanism.

As a safety precaution, these
operations should only be carried out
while the vehicle is stationary.

PeugeOt i-Cockpit

Before taking to the road and to make the most
of the special ergonomics of the PeugeOt
i-Cockpit, carry out these adjustments in the
following order:
-

head restraint height,

backrest angle,

seat cushion height,

seat longitudinal position,

steering wheel reach and then height

the interior and door mirrors.

Once these adjustments have been made,
ensure that from your driving position you can
see the "head-up" instrument panel clearly,
over the reduced diameter steering wheel.

Before moving the seat backwards,
ensure that there is nothing that might
prevent the full travel of the seat, so as
to avoid the risk of jamming the seat
caused by the presence of objects
on the floor behind the seat or rear
passengers. If the seat jams, stop the
movement immediately.

Ease of use and comfort

308_en_Chap03_ergonomie-et-confort_ed01-2016

Front seats with manual adjustments

F Raise the control and slide the seat

forwards or backwards.

F Pull the control upwards to raise or push

it downwards to lower, as many times as
required, to obtain the position required.

F turn the knob to adjust the backrest.

Forwards-backwards

Height

Backrest angle

As a safety measure, seat adjustments should only be carried out when stationary.

F turn the knob manually to obtain the

desired level of lumbar support.

Lumbar

Before moving the seat backwards, ensure that there is nothing that might prevent the full
travel of the seat, so as to avoid the risk of jamming the seat caused by the presence of
objects on the floor behind the seat or rear passengers. If the seat jams, stop the movement
immediately.

Ease of use and comfort

308_en_Chap03_ergonomie-et-confort_ed01-2016

electric driver's seat

Forwards-backwards

Seat backrest angle

Seat cushion height and
angle

to avoid discharging the battery, carry out
these adjustments with the engine running.

F Push the control forwards or rearwards to

slide the seat.

F tilt the control forwards or rearwards to

adjust the angle of the seat backrest.

F tip the rear of the control upwards or

downwards to obtain the desired height.

F tip the front of the control upwards or

downwards to obtain the desired angle.

Before moving the seat backwards, ensure that there is nothing that might prevent the full
travel of the seat, so as to avoid the risk of jamming the seat caused by the presence of
objects on the floor behind the seat or rear passengers. If the seat jams, stop the movement
immediately.

Ease of use and comfort

308_en_Chap03_ergonomie-et-confort_ed01-2016

System which registers the electrical settings
of the driver's seat.
two positions can be stored and recalled, using
the buttons on the side of the driver's seat.

Storing driving positions

Storing a position using
buttons M / 1 / 2

F  Switch on the ignition.
F  Adjust your seat.
F  Press button M, then press button 1 or 2

within four seconds.

An audible signal indicates that the position has
been stored.
Storing a new position cancels the previous
position.

Recalling a stored position

F With the ignition on or the engine

running, press button 1 or 2 to recall the
corresponding position.

An audible signal confirms that adjustment is
complete.
You can interrupt the current movement by
pressing button M, 1 or 2 or by using one of the
seat controls.
A stored position cannot be recalled while
driving.
Recalling stored positions is deactivated
45 seconds after switching off the ignition.

Ease of use and comfort

308_en_Chap03_ergonomie-et-confort_ed01-2016

Heated seats

0: Off.
1: Low.
2: Medium.
3: High.

F use the adjustment thumbwheel to switch

on and select the desired level of heating:

With the engine running, the front seats can be
heated separately.

Additional adjustments

Prolonged use at the highest setting
is not recommended for those with
sensitive skin.
there is a risk of burns for those that
do not have normal perception of heat
(illness, taking medicines, ...).
there is a risk of overheating the
system if material with insulating
properties is used, such as cushions or
seat covers.
Do not use the system:
-

if wearing damp clothing,

if child seats are fitted.

to avoid breaking the heating element
in the seat:
-

do not place heavy objects on the
seat,

do not kneel or stand on the seat,

do not place sharp objects on the
seat,

do not spill liquids onto the seat.

to avoid the risk of short-circuit:
-

do not use liquid products for
cleaning the seat,

never use the heating function
when the seat is damp.

Do not use the function if the seat is not
occupied.
Reduce the level of heating as soon as
possible.
Once the seat and passenger
compartment are at a comfortable
temperature, you can switch off the
function; reducing electric current
consumption also reduces fuel
consumption.

Ease of use and comfort

308_en_Chap03_ergonomie-et-confort_ed01-2016

Electric lumbar adjustment

F Press the control to obtain the desired

lumbar support.

F to raise the head restraint, pull it upwards.
F to remove the head restraint, press the

lug A and pull the head restraint upwards.

F to put the head restraint back in place,

engage the head restraint stems in the
openings keeping them in line with the seat
backrest.

F to lower the head restraint, press the lug A

and the head restraint at the same time.

the head restraint is fitted with a frame
with notches which prevents it from
lowering; this is a safety device in case
of impact.
The adjustment is correct when the
upper edge of the head restraint is
level with the top of the head.
Never drive with the head restraints
removed; they must be in place and
adjusted correctly.

Head restraint height

Ease of use and comfort

308_en_Chap03_ergonomie-et-confort_ed01-2016

Activation / Deactivation

Massage function

this system provides the occupants of the front seats with a lumbar massage. It only operates
when the engine is running or in StOP mode of the Stop & Start system.

F Press this button.

During this time, massage is performed in
6 cycles of 10 minutes (6 minutes of massage
followed by 4 minutes break).
After one hour, the function is deactivated, the
indicator lamp goes off.
Deactivate the massage function by pressing
this button; its indicator lamp goes off.

Adjustment of intensity

F Press this button to adjust the

intensity of the massage.

two levels of massage are available.

Its indicator lamp comes on and the
massage function is activated for a
period of 1 hour.

Peugeot 308 (2017 year). Instruction - part 5
