Peugeot 308 (2017 year). Instruction

Instruments

308_en_Chap01_instruments-de-bord_ed01-2016

Touch screen

Setting the date and time

F In the secondary page, press on "Time/

Date".

F Select the "Configuration"

menu.

this function is accessible in the touch screen.

F Select "Adjust time" or "Adjust date"

and modify the settings using the numeric
keypad, then confirm.

F Press "Confirm" to quit.

Instruments

For more information on the
Multimedia menu, refer to the "Audio
and telematics" section.

Screen C

F Press the MENU button for access to the

main menu.

F Press the "7" or "8" button to select the

Personalisation-configuration menu,
then confirm by pressing the "OK" button.

F Press the "5" or "6" and "7" or "8" buttons

to set the date and time, then confirm by
pressing the "OK" button.

F Press the "5" or "6" button to select the

Display configuration menu then confirm
by pressing the "OK" button.

Instruments

308_en_Chap01_instruments-de-bord_ed01-2016

Screen A (without audio system)

F Once you have selected a setting using

the "5" or "6" buttons, press the "OK"
button to change its value.

F Wait for approximately ten seconds without

any action to allow the change to be
registered or press the "ESC" button to
cancel.

the screen then returns to the normal display.

F Press the "MENU" button to gain access

to the main menu, then press the "5"
or "6" buttons to go to the Display
settings menu.

F Press the "OK" button to select the menu

required.

F Once you have selected a setting, press

the "7" or "8" buttons to change its value.

You have access to the following settings:
- year,
- month,
- day,
- hour,
- minutes,
-

12 or 24 hour mode.

Screen A

F Press the "5" or "6" buttons to switch

respectively to the previous or next setting.

F Press the "OK" button to register the

change and return to the normal display or
press the "]" button to cancel.

Access

308_en_Chap02_ouvertures_ed01-2016

System for the central locking or unlocking
of the vehicle using the door lock or from a
distance.
It is also used to open and close the fuel filler
cap, locate and start the vehicle, as well as
providing protection against theft.

Remote control key

Unfolding / Folding the key

F Press this button to unfold or fold the key.

Complete unlocking

Using the key

Using the remote control

F Press this button to unlock the

vehicle.

unlocking is confirmed by rapid
flashing of the direction indicators for
approximately two seconds.
According to version, the door mirrors
unfold at the same time.

F turn the key to the front of the vehicle to

unlock the vehicle, then pull the handle to
open the door.

If your vehicle has an alarm, this is not
deactivated. Opening a door will trigger the
alarm, which can then be stopped by switching
the ignition on.

If you do not press the button, you risk
damaging the remote control.

Access

308_en_Chap02_ouvertures_ed01-2016

Selective unlocking

F to unlock the driver's door only,

press this button once.

Using the remote control

Complete unlocking is activated by default.
this is set in the "Driving assistance" menu,
then "Vehicle settings" and "Vehicle access".

unlocking is confirmed by rapid
flashing of the direction indicators for
approximately two seconds.
According to version, the door mirrors
unfold at the same time as the first
unlocking action.

F to unlock the other doors and the boot,

press this button again

use this button for access to
additional information.

Locking is confirmed by fixed
lighting of the direction indicators for
approximately two seconds.
According to version, the door mirrors
fold at the same time.

Driving with the doors locked may
render access for the emergency
services difficult in an emergency.
As a safety measure (children on
board), never leave the vehicle without
taking your key, even for a short period.

Normal locking

Using the remote control

F Press this button to fully lock the

vehicle.

F turn the key towards the rear of the vehicle

to fully lock the vehicle.

If your vehicle has an alarm, this will not be
activated.

Maintaining the locking action (key or remote
control) automatically closes the windows.

When a door or the boot is not
fully closed, engine running or
vehicle moving (speed above 6 mph
(10 km/h)), a message appears for a
few seconds.

Using the key

Access

308_en_Chap02_ouvertures_ed01-2016

If one of the doors or the boot is still
open, the central locking does not take
place.
When the vehicle is locked, if it is
unlocked inadvertently, it will lock itself
again automatically after about thirty
seconds unless a door is opened.

And if your vehicle has an alarm, this
will not be reactivated.
the folding and unfolding of the door
mirrors by the remote control can be
deactivated by a PeugeOt dealer or a
qualified workshop.

Deadlocking

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
therefore, never leave anyone inside
the vehicle when it is deadlocked.

F turn the key to the rear in the driver's door

lock to lock the vehicle completely.

F turn the key to the rear again within five

seconds to deadlock the vehicle.

Deadlocking is confirmed by fixed
lighting of the direction indicators for
approximately two seconds.
Depending on version, the door mirrors
fold at the same time.

Using the remote control

F Press this button to fully lock the

vehicle.

F Press this button again within five seconds

to deadlock the vehicle.

Using the key

Access

308_en_Chap02_ouvertures_ed01-2016

Electronic engine immobiliser

the key contains an electronic chip which has
a special code. When the ignition is switched
on, this code must be recognised in order for
starting to be possible.
this electronic engine immobiliser locks the
engine management system a few moments
after the ignition is switched off and prevents
starting of the engine by anyone who does not
have the key.

F Press this button.

Locating your vehicle

this will switch on the courtesy lamps and
the direction indicators will flash for around
ten seconds.

Remote operation of lighting

A short press this button switches
on the lighting remotely (sidelamps,
dipped beam headlamps and number
plate lamps).

A second press before the end of the timed
period cancels the remote lighting.

Anti-theft protection

In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and
a message in the screen.

Keep safely, away from your vehicle,
the label attached to the keys given to
you on acquisition of the vehicle.

In this case, your vehicle will not start; contact
a PeugeOt dealer as soon as possible.

this function allows you to identify your vehicle
from a distance, particularly in poor light. Your
vehicle must be locked.

Access

308_en_Chap02_ouvertures_ed01-2016

Back-up control

F Insert the key in the lock to lock or unlock

the door.

F On the rear doors, check that the child lock

is not on.

F Insert the integral key into the latch on the

edge of the door and turn it an eighth of a
turn to the right, for the right-hand side and
to the left for the left-hand side.

F Close the doors and check from the

outside that they have locked correctly.

For mechanically locking and unlocking the doors in the event of a fault with the central locking
system or a battery failure.

If your vehicle has an alarm, it will not
be activated and deactivated on locking
and unlocking the vehicle.
Opening a door will trigger the alarm,
which can be stopped by switching on
the ignition.

Driver's door

Passenger doors

Remote control problem

Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.
F First of all, use the key in the lock to unlock

or lock your vehicle.

F then, reinitialise the remote control.
If the problem persists, contact a PeugeOt
dealer as soon as possible.

Access

308_en_Chap02_ouvertures_ed01-2016

Changing the battery

Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
take them to an approved collection
point.

If the battery is flat, you are informed
by lighting of this warning lamp in the
instrument panel, an audible signal
and a message in the screen.

F Switch off the ignition.
F turn the key to position 2 (Ignition).

Battery ref.: CR1620 / 3 volts.

F Press the closed padlock

immediately for a few seconds.

F Switch off the ignition and remove the key

from the ignition switch.

the remote control is fully operational again.

Reinitialisation

F unclip the cover using a screwdriver in the

cut-out.

F  Remove the cover.
F  Remove the flat battery from its housing.
F  Place the new battery into its housing,

observing the polarity.

F Clip the cover in place.

Access

308_en_Chap02_ouvertures_ed01-2016

"Keyless entry and Starting" with remote control

Complete unlocking

Selective unlocking

System for the central locking or unlocking of the vehicle using the door lock or from a distance.
It is also used to locate and start the vehicle, as well as providing protection against theft.

Complete unlocking is activated by default.

unlocking is confirmed by rapid
flashing of the direction indicators for
two seconds.
At the same time, depending on
version, the door mirrors unfold. And
if your vehicle has an alarm, it is
deactivated

F to unlock only the driver's door,

press this button once.

F Press this button to unlock the

vehicle.

F to unlock the other doors and the boot,

press this button again.

this setting is done in the "Driving
assistance" menu, then "Vehicle settings"
and "Vehicle access".

use this button for access to
additional information.

Locking

Locking is confirmed by fixed
illumination of the direction indicators
for a few seconds.
Depending on version, the door mirrors
fold and the alarm is activated.

F Press this button to fully lock the

vehicle.

Hold the button down until the
windows close completely.

Driving with the doors locked may make
access to the passenger compartment
by the emergency services difficult in
the event of an emergency.
Be aware of children when operating
the windows.

If a door or the boot is not properly
closed, with the engine running
or the vehicle moving (speed
above 6 mph (10 km/h)), a message
appears for a few seconds.

Access

308_en_Chap02_ouvertures_ed01-2016

this function allows you to identify your vehicle
from a distance, particularly in poor light. Your
vehicle must be locked.

Locating your vehicle

F Press this button.

As a safety measure (children on
board), never leave the vehicle without
taking the key for the Keyless entry
and Starting system, even for a short
period.
guard against theft when the key for
the Keyless entry and Starting system
is in the recognition zone with the
vehicle unlocked.
In order to preserve the charge of the
cell battery in the remote control, the
"hands-free" functions go into extended
stand-by after 21 days of non-use. to
restore these functions, press one of
the remote control buttons or start the
engine with the electronic key in the
reader.

this will switch on the courtesy lamps and
the direction indicators will flash for around
ten seconds.

Access

308_en_Chap02_ouvertures_ed01-2016

Complete unlocking

"Keyless entry and Starting"

System for unlocking, locking and starting the
vehicle while keeping the electronic key on your
person.

F With the electronic key on your person and

in the recognition zone A, pass your hand
behind one of the front door handles to
unlock the vehicle, then pull on the handle
to open the door.

the central locking does not take place:
-

if the ignition is on,

if one of the doors or the boot is still
open,

if the key for the Keyless entry and
Starting system has been left inside
the vehicle.

When the vehicle is locked, if it is
unlocked inadvertently, it will lock itself
again automatically after about thirty
seconds unless a door is opened.
And if your vehicle has an alarm, this is
not reactivated.
the folding and unfolding of the door
mirrors by the remote control can be
deactivated by a PeugeOt dealer or a
qualified workshop.

Selective unlocking

When selective unlocking of the driver's door is
activated:
F With the electronic key in the driver's door

zone, pass your hand behind the driver's
door handle to unlock just the driver's door,
then pull on the door handle to open the
door.

F With the electronic key in the passenger's

door zone, pass your hand behind the
passenger's door handle to unlock the
whole vehicle, then pull on the door handle
to open the door.

By default, complete unlocking is activated.
this setting is done in the "Driving
assistance" menu, then "Vehicle settings"
and "Vehicle access".

use this button for access to
additional information.

unlocking is confirmed by rapid
flashing of the direction indicators for a
few seconds.
Depending on version, the door mirrors
unfold and the alarm is deactivated.

Access

308_en_Chap02_ouvertures_ed01-2016

Locking

F With the electronic key in the recognition

zone A, press with a finger on one of the
front door handles (at the markings) or
press the locking control on the tailgate to
lock the vehicle.

Maintain pressure with your finger until the
windows close completely.

ensure that nobody prevents the
correct operation of the windows.
Be aware of children when operating
the windows.

For reasons of safety and theft
protection, do not leave your electronic
key in the vehicle, even when you are
close to it.

It is recommended that you keep it on
your person.

If a door or the boot is not properly
closed, with the engine running
or the vehicle moving (speed
above 6 mph (10 km/h)), a message
appears for a few seconds.

Locking is confirmed by fixed illumination of the
direction indicators for a few seconds.
Depending on version, the door mirrors fold
and the alarm is activated.

Access

308_en_Chap02_ouvertures_ed01-2016

Deadlocking

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
locking button.
You must therefore never leave
anyone inside the vehicle when it is
deadlocked.

Using the remote control

F Press this button to lock the

vehicle completely.

Maintain pressure with your finger to
close the windows.

With Keyless Entry and Starting

By the doors or tailgate:
F With the electronic key on your person

in the recognition zone A, press with a
finger or thumb on the door handle (at the
markings) or on the locking control on the
tailgate (right-hand side) to lock the vehicle.

ensure that nothing or any person
prevents the correct closing of the
windows.
Be particularly aware of children when
operating the windows.

F Press this button again within five seconds

to deadlock the vehicle.

Accumulations (water, dust, grime, salt...) on the inner surface of the door handle may affect
detection.
If cleaning the inner surface of the door handle using a cloth does not restore detection,
contact a PeugeOt dealer or a qualified workshop.
A sudden splash of water (stream of water, high pressure jet washer, …) may be identified
by the system as the desire to open the vehicle.

F Within five seconds, press the door handle

or the locking control on the tailgate (right-
hand side) again to deadlock the vehicle.

Access

308_en_Chap02_ouvertures_ed01-2016

Boot

F After unlocking the vehicle with

the remote control, press this
button and then open the boot.

Opening using the "Keyless
Entry and Starting" remote
control

F Press this button, the vehicle is

unlocked.

Opening using the key

Complete unlocking is selected by default.
this setting is done in the "Driving
assistance" menu, then "Vehicle settings"
and "Vehicle access".

Complete unlocking

Selective unlocking

F Press this button, the boot is

unlocked.

use this button for access to
additional information.

F Press the opening control, then raise the

tailgate.

F Press the opening control, then raise the

tailgate.

F With the electronic key on your person in

the recognition zone A, press the opening
control then raise the tailgate.

Opening using the "Keyless
Entry and Starting" system

By default, complete unlocking is activated.
this setting is done in the "Driving
assistance" menu, then "Vehicle settings"
and "Vehicle access".

Selective unlocking

Complete unlocking

Access

308_en_Chap02_ouvertures_ed01-2016

When unlocking of the boot only is activated:
F With the electronic key in the recognition

zone A, press the boot unlocking control
to unlock just the tailgate, then raise the
tailgate.

unlocking is signalled by rapid flashing of the
direction indicators for a few seconds.

use this button for access to
additional information.

Closing

F Lower the tailgate using one of the interior

grab handles.

If the tailgate is not closed correctly (the lock
has two positions), with the engine running or
when moving (speed above 6 mph (10 km/h)),
a message appears for a few seconds.

Tailgate release

F Fold back the rear seats to gain access to

the lock from inside the boot.

F Insert a small screwdriver into hole A of the

lock to unlock the tailgate.

F Move the latch to the right.

Locking after closing

If the fault persists after closing again, the boot
will remain locked.

System allowing the mechanical unlocking
of the boot in the event of a battery or central
locking system malfunction.

F With the electronic key in the recognition

zone A, press the boot locking control to
lock the vehicle.

Locking is signalled by rapid flashing of the
direction indicators for a few seconds.

Locking with the "Keyless
Entry and Starting" system

Unlocking

Peugeot 308 (2017 year). Instruction - part 4
