Peugeot 301 (2017 year). Instruction

191

AUDIO and TELEMATICS

APPLE

players or portable

player

The audio files of a portable Mass Storage
player* can be heard through the vehicle's
speakers by connecting it to the USB port
(cable not supplied).

Management of the device is via the audio
system controls.
The Apple

player software must be

updated regularly for the best connection.
The playlists are those defined in the
Apple

player.

The Apple

player must be generation 5

or later.

* Check your player's manual.

Having selected the desired
sorting ("

By folders", "By

artists", "By genres", "By

playlists") press the thumb

wheel.
Then press the thumb wheel to
confirm and save the changes.
-

By folders: all folders

containing audio files
recognised on the peripheral
device, in alphabetical order
without following the folder
structure.

By artists: all of the artist

names defined in the ID3
Tags, in alphabetical order.

By genres: all of the genres

defined in the ID3 Tags.

By playlists: if playlists have

been saved.

192

VOL+

VOL-

AUDIO and TELEMATICS

Press the

SRC/TEL button

repeatedly and select "

AUX".

The display and management of controls
is on the portable device.

Then adjust the volume of the
audio system.

Streaming - Playing audio

files via Bluetooth

Depending on the compatibility of the phone

The play modes available are:
- Normal: the tracks are played in order,

depending on the classification of the
selected files.

- Random: the tracks in an album or

folder are played in a random order.

- Random all: all of the tracks saved in

the media are played in random order.

- Repeat: the tracks played are only

those from the current album or folder.

Play mode

Press the thumb wheel to
access the contextual menu.
or
Press

MENU.

First adjust the volume on your portable device.

Streaming allows music files on a
telephone to be heard via the vehicle's
speakers.
The telephone must support the
appropriate Bluetooth profiles (Profiles
A2DP / AVRCP).

In certain cases, playing of the audio files
must be initiated from the telephone.
The audio quality depends on the quality
of transmission by the telephone.

Pair/connect the telephone: see the
TELEPHONE section.

Activate the streaming source
by pressing

SRC/TEL.

Control of playback is via the
audio system. The contextual
information can be displayed
in the screen.

Auxiliary input (AUX)

193

AUDIO and TELEMATICS

Using the telephone

Pairing a telephone

First connection

The services offered depend on
the network, the SIM card and the
compatibility of the Bluetooth telephone
used.
Check the instructions for your telephone
and with your service provider for the
services to which you have access.

As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
of the Bluetooth mobile telephone with
the Bluetooth hands-free system of your
audio system must be carried out with the

vehicle stationary and the ignition on.

Visit www.peugeot.co.uk for more
information (compatibility, more help, ...).

Select "

Read mode" and

confirm

Choose the desired playback
method then press the thumb
wheel to validate and save
the changes.

Select "

Multimedia" and

confirm

Select "

Media settings" and

confirm

194

AUDIO and TELEMATICS

Press

MENU.

Select "

Bluetooth

connection" and confirm

Select "

Search for a device".

Select the telephone to be
connected from the list. Only one
telephone can be connected at
a time.

In some cases, the reference number of
the telephone or the Bluetooth address
may appear instead of the name of the
telephone.

If pairing fails, the number of attempts is
not restricted.

Activate the telephone's Bluetooth function
and ensure that it is "visible to all" (refer to the
telephone user guide).

A window is displayed with "

Search in

progress…".

Accept the connection on the telephone.
A message appears in the screen to confirm
the result of the connection.

Pairing can also be initiated from the
telephone by searching for detected
Bluetooth devices.
The directory and the call list can
be accessed after the necessary
synchronisation period (if the telephone is
compatible).
Automatic connection must be configured
in the telephone to allow the connection
each time the vehicle is started.

A virtual keypad is displayed
on the screen: enter a code of
at least 4 digits then press the
control knob to confirm.

A message is displayed in the screen of the
telephone: enter the same code and confirm.

195

AUDIO and TELEMATICS

Status of the telephone

To find out the status of the
telephone, press

MENU.

Select "

Telephone" and

confirm

Select "

Telephone

management" and confirm

Select "

Telephone status"

and confirm

The screen displays the name of the
telephone, the name of the network,
the quality of network reception, and
the confirmation of the Bluetooth and
streaming connections.

Streaming - Playing audio

files via Bluetooth

Pair/connect the telephone and listen: see the
AUDIO chapter.

196

AUDIO and TELEMATICS

Indicates that a device is
connected.

Indicates connection of the
audio steaming profile.

Indicates the hands-free
telephone profile.

Managing connections

Press

MENU.

Select "

Bluetooth

connection" and confirm

Select "

Connections

management" and confirm

The list of paired devices is
displayed.

The telephone connection automatically
includes hands free operation and audio
streaming.
The ability of the system to connect to just
one profile depends on the telephone.
Both profiles may connect by default.

Then select and confirm:
- "

Connect telephone" /

Disconnect telephone":

to connect / disconnect the
telephone or the hands-free
connection only.

- "

Connect media player" /

Disconnect media player":

to connect / disconnect only
streaming.

- "

Connect telephone +

media player" / "Disconnect

telephone + media player":

to connect / disconnect the
telephone (hands-free and
streaming).

- "

Delete connection": to

delete the pairing.

Select a telephone and confirm.

197

AUDIO and TELEMATICS

Making a call - Dialling

To display the "

TELEPHONE"

menu:
- Make a long press on

SRC/TEL.

- Or, press the dial to

display the contextual
menu. Select "

Call" and

confirm

- Or, press

MENU, select

Telephone" and

confirm. Select "

Call" and

confirm

Select "

Dial" to enter a

number and confirm.

Correction allows numbers to be deleted
one at a time.

Press the thumb wheel to confirm
and place the call.

Making a call - Recently

called numbers

(Depending on the compatibility of the phone)

To display the "

TELEPHONE"

menu:
- Make a long press on

SRC/TEL.

- Or, press the dial to

display the contextual
menu. Select "

Call" and

confirm

- Or, press

MENU, select

Telephone" and

confirm. Select "

Call" and

confirm

Select "

Calls list" and

confirm

Select the number and
confirm to start the call.

Select numbers one at a time
using the 7 and 8 buttons
and confirm.

198

AUDIO and TELEMATICS

The calls list includes calls sent and
received in the vehicle using the
connected telephone.

It is possible to make a call directly from
the telephone; park the vehicle first as a
safety measure.

Making a call - From the

directory of contacts

To display the "

TELEPHONE"

menu:
- Make a long press on

SRC/TEL.

- Or, press the dial to

display the contextual
menu. Select "

Call" and

confirm

- Or, press

MENU, select

Telephone" and

confirm. Select "

Call" and

confirm

Select "

Directory" and

confirm

Select a contact then confirm.

Home
Work
Mobile
(depending on the information
available in the contact
records of the telephone
connected).

Select the number and
confirm.

199

BACK

AUDIO and TELEMATICS

Receiving a call

An incoming call is announced by a ring and
a superimposed display in the multifunction
screen.

YES" to accept the call is

selected by default.
Press the thumb wheel to
accept the call.
Select "

NO" and confirm to

reject the call.

or
Press one of these buttons to
accept the call.

A long press on

BACK or on SRC/

TEL also rejects an

incoming call.

Managing calls

During a call, press the thumb
wheel to display the contextual
menu.

Hang up

In the contextual menu, select
"

Hang up" to end the call.

A long press on one
of these buttons also
ends the call.

200

AUDIO and TELEMATICS

Secret - Mute

(so that the caller cannot hear)

In the contextual menu:
- select "

Micro OFF" to switch

off the microphone.

- deselect "

Micro OFF" to

switch the microphone on.

Combined mode

(to leave the vehicle without ending the call)

In the contextual menu:
- select "

Telephone mode"

to transfer the call to the
telephone.

- deselect "

Telephone mode"

to transfer the call to the
vehicle.

In some cases, the combined mode must
be activated from the telephone.
If the contact has been cut off, when
you reconnect on returning to the
vehicle, the Bluetooth connection will be
restored automatically (depending on the
compatibility of the telephone).

Interactive voice response

From the contextual menu, select
"

DTMF tones" and confirm to use

the digital keypad to navigate in
the interactive voice response
menu.

Consultation call

From the contextual menu, select
"

Switch" and validate to return to

a call left on hold.

201

AUDIO and TELEMATICS

Directory

The directory of the

telephone is transmitted

to the system, depending

on the compatibility of the

telephone.

The directory is temporary

and depends on the

Bluetooth connection.

The contacts, imported from
the telephone to the audio
system directory, are saved
in a permanent directory
visible to all, regardless of
the telephone connected.

To access the director, press
and hold

SRC/TEL.

or
Press on the thumb wheel
then select "

Call" and

confirm.

Select "

Directory" to see the

list of contacts.

To modify the contacts saved
in the system, press

MENU

then select "

Telephone" and

confirm.

Select "

Directory

management" and confirm

You can:
- "

Consult an entry",

- "

Delete an entry",

- "

Delete all entries".

202

AUDIO and TELEMATICS

Audio settings

Screen C

Press ¯ to display the audio
settings menu.

The distribution (or spatialisation using the
Arkamys

system), is an audio process

which allows the sound quality to be
improved according to the setting chosen,
corresponding to the position of the
listeners in the vehicle.

The audio Ambience, Treble and Bass
settings are different and independent for
each sound source.

Onboard audio: le Sound Staging
d'Arkamys

With Sound Staging, the driver and the
passengers are immersed into a "sound
stage" recreating the natural atmosphere
of a theatre: truly centre stage in surround
sound.
This new sensation is possible thanks
to the software installed in the radio
which processed the digital signals of the
media players (radio, CD, MP3...) without
changing the setting of the loudspeakers.
This process takes into account the
features of the passenger compartment
for optimum performance.
The Arkamys

software installed in your

audio system processes the digital signal
of all the media players (radio, CD, MP3...)
and makes it possible to recreate a
natural sound setting, with a harmonious
placement of the instruments and
voices in space, facing the passengers,
positioned at the height of the windscreen.

The settings available are:
- Ambience,
- Bass,
- Treble,
- Loudness,
-  Distribution: Personalised or Driver,
-  Left / right balance,
-  Fader (front / rear balance),
-  Auto. volume

Select and confirm "

Other

settings…" to display the rest

of the list of settings available.

203

AUDIO and TELEMATICS

Frequently asked questions

The following tables contain answers to the most frequently asked questions.

QUESTION

RESPONSE

SOLUTION

There is a difference in sound quality between
the different audio sources (radio, CD...).

To allow for optimal listening quality, the audio
settings (Volume, Bass, Treble, Ambience,
Loudness) can be tailored to different
sound sources, which can generate audible
differences when changing source (radio, CD...).

Check that the audio settings (volume, bass,
treble, ambience, loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-
Rear Fader, Left-Right Balance) to the middle
position, select the musical ambience "None"
and set the loudness correction to the "Active"
position in CD mode or to the "Inactive" position
in radio mode.

When changing the settings for treble and bass,
the ambience setting is deselected.
When changing the ambience setting, treble
and bass are reset to zero.

Choosing an ambience imposes settings for
treble and bass. Modifying one without the other
is not possible.

Modify the treble and bass settings or the
ambience setting to obtain the desired sound
quality.

204

AUDIO and TELEMATICS

QUESTION

RESPONSE

SOLUTION

When changing the balance setting, distribution
is deselected.

Choosing a distribution setting imposes a
balance setting. Modifying one without the other
is not possible.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

The reception quality of the tuned radio station
gradually deteriorates or the stored stations are
not working (no sound, 87.5 Mhz is displayed ...).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the RDS mode and start a new search
for the station so that the system can check
whether a stronger transmitter is available in the
geographic area.

The environment (hills, buildings, tunnels,
basement car parks...) block reception, including
in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for
example when going through an automatic car
wash or in an underground car park).

Have the antenna checked by the PEUGEOT
network.

Sound cut-outs of 1 to 2 seconds in radio mode. During this brief sound cut-out, the RDS

searches for another frequency giving better
reception of the station.

Switch off the RDS function if the phenomenon
is too frequent and always on the same route.

The traffic announcement (TA) is displayed. I do
not receive any traffic information.

The radio station does not broadcast traffic
information.

Tune to a radio station which broadcasts traffic
information.

The stored stations are not found (no sound,
87.5 MHz is displayed...).

An incorrect waveband is selected.

Press the BAND button to return to the
waveband on which the stations are stored.

205

AUDIO and TELEMATICS

QUESTION

RESPONSE

SOLUTION

The CD is ejected every time or is not played.

The CD is upside down, cannot be read, does
not contain audio files or contains audio files
of a format that cannot be played by the audio
system.
The CD is protected by an anti-pirating system
not recognised by the audio system.

- Check that the CD is inserted in the player

the right way up.

- Check the condition of the CD: the CD

cannot be played if it is too badly damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio"
section.

- The audio system CD player does not read

DVDs.

- Due to insufficient quality, certain burned

CDs will not be read by the audio system.

The CD sound is of poor quality.

The CD used in scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambience) are
unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

I am unable to connect my Bluetooth telephone. It is possible that Bluetooth is switched off on

the telephone or that the telephone has been
made not visible.

- Check that your telephone has Bluetooth

switched on.

- Check in the telephone settings that it is

“visible to all”.

The Bluetooth telephone is not compatible with
the system.

You can check the compatibility of your
telephone at www.peugeot.co.uk (services).

The Bluetooth connection is cut.

The battery of the peripheral may not be
sufficiently charged.

Charge the battery of the peripheral device.

206

AUDIO and TELEMATICS

QUESTION

RESPONSE

SOLUTION

The "USB peripheral error" or "Peripheral not
recognised" message appears on the screen.

The USB memory stick is not recognised.
The memory stick could be corrupt.

Reformat the memory stick (FAT 32).

A telephone connects automatically,
disconnecting another telephone.

Automatic connection overrides manual
connection.

Modify the telephone settings to remove
automatic connection.

The Apple

player is not recognised when

connecting to the USB port.

The Apple

player is of a generation that is not

compatible with a USB connection.

Connect the Apple

player to the AUX Jack

socket using a suitable cable (not supplied).

The hard disk or peripheral is not recognised
when connecting to the USB socket.

Some hard disks and devices need a power
supply greater than is provided by the audio
system.

Connect the peripheral to the 230 V socket, the
12V socket or an external power supply.

Caution: ensure that the device does not

transmit a voltage greater than 5 V (risk of
destruction of the system).

When streaming, the sound cuts momentarily.

Some telephones prioritise connection of the
"hands-free" profile.

Delete the "hands-free" connection profile to
improve streaming.

In "Random all" play, not all of the tracks are
played.

In "Random all" play, the system can only take
into account up to 999 tracks.

With the engine off, the audio system switches
off after a few minutes of use.

When the engine is switched off, the audio
system operating time depends on the battery
charge.
The switch-off is normal: the audio system
switches to economy mode and switches off to
prevent discharging the vehicle's battery.

Turn the ignition on to increase charge of the
battery.

Peugeot 301 (2017 year). Instruction - part 13
