Peugeot 207 (2011 year). Instruction - part 14

207

* Available according to model.

Dark blue

Map colour

Night mode for map

Units

Day mode for map

Vehicle *

Vehicle information

Alert log

Status of functions

Temperature

Celsius

Fahrenheit

Metric/Imperial

Kilometres (Consumption: l/100)

Kilometres (Consumption: km/l)

Miles (Consumption: MPG)

System

Auto. Day/Night for map

Factory reset

Software version

Automatic scrolling

Colour

Pop titanium

Toffee

Blue steel

Technogrey

Display

Brightness

208

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between

the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the Linear musical ambience and

set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

The CD is ejected

automatically or is not

played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

Check that the CD is inserted in the player the

right way up.

Check the condition of the CD: the CD cannot

be played if it is too damaged.

Check the content in the case of a recorded

CD: consult the advice in the Audio section.

The audio equipment's CD player does not

play DVDs.

- Because

of their quality level, certain writeable

CDs will not be played by the audio system.

Insert good quality

CDs and store them in

suitable conditions.

The CD player sound is poor.

The CD used is scratched or of poor quality.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

209

QUESTION

ANSWER

SOLUTION

The stored stations do

not function (no sound,

87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off,

the audio equipment

switches off after a few

minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

210

QUESTION

ANSWER

SOLUTION

Wait until the traffi c

information is being

received correctly

(displaying of the traffi c

information symbols on

the map).

TA is selected. However, certain traffi c jams along the route are not

indicated in real time.

On starting, it is several minutes before the

system begins to receive the traffi c information.

In certain countries, only major routes (motorways...) are listed for the

traffi c information.

This phenomenon is normal. The system is

dependent on the traffi c information available.

I receive a speed camera

alert for a camera which

is not on my route.

The system announces all speed cameras located in a conical zone

forward of the vehicle. It may detect speed cameras on nearby or parallel

roads.

Zoom the map to view the exact position of the

speed camera.

The audible speed

camera alert is not

working.

Audible alerts are not active.

Activate audible alerts in Navigation Menu,

Settings, Set parameters for risk areas.

The alert volume level is set to minimum.

Increase the speed camera alert volume.

The altitude is not

displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 3 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

3 satellites (long press on the SETUP button, then

select GPS coverage).

Depending on the geographical environment (tunnel...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is

dependent on the conditions of reception of the

GPS signal.

The route is not

calculated successfully.

The exclusion criteria may confl ict with the current location (exclusion of

toll roads on a motorway with tolls).

Check the exclusion criteria.

211

QUESTION

ANSWER

SOLUTION

There is a long waiting

time after inserting a CD.

When a new medium is inserted, the system reads a certain amount of

data (directory, title, artist, etc.). This may take a few seconds.

This phenomenon is normal.

I cannot connect my

Bluetooth telephone.

The telephone's Bluetooth function may be deactivated or the equipment

may not be visible.

- Check

that

your telephone's Bluetooth

function is activated.

Check that your telephone is visible.

A telephone connected

by Bluetooth is inaudible.

The volume level depends on both the system and the telephone.

Increase the Peugeot Connect Navigation volume

setting, possibly to maximum, and increase the

telephone volume level if necessary.

212

213

PEUGEOT CONNECT SOUND

Your Peugeot Connect Sound is coded in such a way

that it will only operate in your vehicle. If it is to be

installed in another vehicle, contact your PEUGEOT

dealer for confi guration of the system.

For safety reasons, the driver must carry out operations

which require prolonged attention while the vehicle is

stationary.
When the engine is switched off and to prevent

discharging of the battery, the audio equipment may

switch off after a few minutes.

AUDIO SYSTEM/BLUETOOTH

  01  First steps
  02  Steering mounted controls
  03  Main menu
  04 Audio

05 Peugeot Connect USB
06 Bluetooth

07 Configuration

08 Trip computer
09 Screen menu map

p.
p.
p.
p.
p.
p.
p.
p.
p.

214
215
216
217
220
223
225
227
228

CONTENTS

Frequently asked questions

233

214

133

144

155

122

FIRST STEPS

1. On/Off and volume adjustment.
2. CD

eject.

3. Selection of the display on the screen from

the following modes:
Audio (AUDIO), Trip Computer (TRIP) and

Telephone (TEL) functions.

4. Selection of source:

radio, audio CD/MP3 CD, USB, Jack

connection, Streaming.

5. Selection of FM1, FM2, FMast and AM

wavebands.

6. Setting audio options: front/rear fader, left/

right balance, loudness, sound ambience.

7. Display the list of local stations, of the

tracks on the CD or of the MP3 folders.

8. Abandon current operation.
9. TA

(Traffi c Announcement) function on/off.

Long press: access to the PTY (Types of

radio programme) mode.

10. Confi rmation.
11. Automatic search for a lower/higher

frequency.

Selection

previous/next CD, MP3 or USB

track.

12. Selection of a lower/higher radio frequency.

Selection of the previous/next MP3 folder.

Selection of the previous/next USB device

folder/genre/artist/playlist.

13. Display the main menu.
14. Buttons 1 to 6:

Selection of a stored radio station.

Long press: store a station.

15. The DARK button changes the display on

the screen to improve driving comfort at

night.

1st press: lighting the upper band only.

2nd press: display of a black screen.

3rd press: return to the standard display.

215

02 STEERING MOUNTED CONTROLS

RADIO: selection of the next stored station.
USB: selection of the next genre/artist/folder from

the classifi cation list.
Selection of the next item on a menu.

RADIO: selection of the previous stored station.
USB: selection of the previous genre/artist/folder

from the classifi cation list.
Selection of the previous item on a menu.

RADIO: automatic search for a higher frequency.
CD/MP3/USB: selection of the next track.
CD/USB: continuous press: fast forwards play.
Selection of the previous item.

RADIO: automatic search for a lower frequency.
CD/MP3/USB: selection of the previous track.
CD/USB: continuous press: fast reverse.
Selection of the next item.

Change of sound source.

Confi rmation of a selection.

- Pick

up/Hang up the telephone.

- Press for more than 2 seconds:

access to the telephone menu.

Volume increase.

Volume decrease.

Mute: press the volume

increase and decrease

buttons simultaneously.
The sound is restored by

pressing one of the two

volume buttons.

216

03 MAIN MENU

AUDIO FUNCTIONS: radio,

CD, USB, options.

> MONOCHROME SCREEN C

For a detailed global view of the

menus available, refer to the

"Screen menu map" section.

TELEPHONE: Bluetooth

hands-free, pairing,

management of a call.

PERSONALISATION-

CONFIGURATION: vehicle

parameters, display, languages.

TRIP COMPUTER: entering

of distances, alerts, status of

functions.

> MONOCHROME SCREEN A

217

AUDIO

Press the SOURCE button several

times in succession and select the

radio.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Briefl y press one of the buttons to

carry out an automatic search of the

radio stations.

Press one of the buttons to carry out a

manual search of the radio stations.

Press the LIST REFRESH button to

display the list of stations received

locally (30 stations maximum).

To update this list, press for more than

two seconds.

The external environment (hills, buildings, tunnels, basement car parks, ...)

may block reception, including in RDS mode. This is a normal effect of the

way in which radio waves are transmitted and does not indicate any failure

of the audio system.

RDS

RADIO

SELECTING A STATION

Press the MENU button.

Select AUDIO FUNCTIONS then

press OK.

Select the FM WAVEBAND

PREFERENCES function then press

OK.

Select ACTIVATE RDS then press

OK. RDS appears on the screen.

The RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative fequencies. However, in

certain conditions, coverage of an RDS station may not be assured

throughout the country as radio stations do not cover 100 % of the

territory. This explains the loss of reception of the station during a journey.

218

AUDIO

Insert circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using a

personal recorder, may cause faults which are no refl ection on the

quality of the original player.
Without pressing the EJECT button, insert a CD in the player, play

begins automatically.

PLAYING A CD

To play a disc which has already been

inserted, press the SOURCE button

several times in succession and

select CD.

Press one of the buttons to select a

track on the CD.

Press the LIST REFRESH button to display the list of tracks on the CD.

Press and hold one of the buttons for

fast forward or backward.

RECEIVING TA MESSAGES

Press the TA button to activate or

deactivate traffi c messages.

The TA (Traffi c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a traffi c

report is transmitted, the current audio source (Radio, CD, ...) is

interrupted automatically to play the TA message. Normal playback

of the audio source resumes at the end of the transmission of the

message.

219

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3,

is an audio compression standard which permits the recording of

several tens of music fi les on a single disc.

In order to be able to play a recorded CDR or CDRW, when

recording, the ISO 9660 level 1.2 or Joliet fi le format is

recommended.
If the disc is recorded in another format, it may not be played

correctly.
It is recommended that the same recording format is always used

for an individual disc, with as low a speed as possible

(4x maximum) for optimum sound quality.
In the particular case of a multi-session CD, the Joliet format is

recommended.

The audio system will only play fi les with the extension ".mp3" with

a sampling rate of 22.05 KHz or 44.1 KHz. No other type of fi le

(.wma, .mp4, .m3u...) can be played.

It is advisable to restrict fi le names to 20 characters without using

special characters (e.g. " ? ; ù) to avoid any playing or displaying

problems.

MP3 CD

INFORMATION AND ADVICE

AUDIO

Empty CDs are not recognised and may damage the system.

Insert an MP3 compilation in the player.
The audio equipment searches for all of the music tracks, which

may take anything between a few seconds and several tens of

seconds, before play begins.

MP3 CD
PLAYING AN MP3 COMPILATION

On a single disc, the CD player can read up to 255 MP3 fi les

spread over 8 folder levels. However, it is advisable to keep to

a limit of two levels to reduce the access time before the CD is

played.
While the CD is being played, the folder structure is not followed.
All of the fi les are displayed on a single level.

To play a disc which has already

been inserted, press the SOURCE

button several times in succession

and select CD.

Press one of the buttons to select a

track on the CD.

Press the LIST REFRESH button to display the list of directories of

the MP3 compilation.

Press and hold one of the buttons for

fast forward or backward play.

220

PEUGEOT CONNECT USB

The system puts together playlists (temporary memory) created

over a period which depends on the capacity of the USB device.
The other sources are available during this time.
The playlists are updated each time the ignition is switched off or

each time a USB memory stick is connected.
When connecting for the fi rst time, the classifi cation suggested

is by folder. When you reconnect, the classifi cation selected

previously is retained.

Connect the memory stick to the port, directly or

using a lead. If the audio equipment is switched

on, the USB source is detected as soon as it

is connected. Play begins automatically after a

delay which depends on the capacity of the USB

memory stick.
The fi le formats recognised are .mp3 (mpeg1

layer 3 only), .wma (standard 9 only, 128 kbits/sec

compression), .wav and .ogg.
The playlists types accepted are m3u, .pls, .wpl.

This unit consists of a USB port and an auxiliary

Jack socket * . The audio fi les are transmitted

from portable equipment such as a digital

player or a USB memory stick to your Peugeot

Connect Sound to be listened to via the vehicle's

speakers.

USB memory stick (1.1, 1.2 and 2.0) or iPod

generation 5 or later:
- USB

memory sticks should be formatted

FAT or FAT 32 (NTFS not supported),

the iPod

lead is essential,

- navigation through the fi le database is by

means of the steering mounted controls,

- the iPod

software should be regularly

updated for the best connection.

The list of compatible equipment and the compression rates supported

are available from PEUGEOT dealers.

USING THE PEUGEOT CONNECT USB

CONNECTING A USB MEMORY STICK

Other iPod

players of earlier generations and

players using the MTP protocol * :
- play via Jack-Jack lead only (not supplied),
- navigation through the fi le database is from

the portable device.

* According to vehicle.

221

PEUGEOT CONNECT USB

USING THE PEUGEOT CONNECT USB

Press LIST briefl y to display the

previously selected classifi cation.
Navigate through the list using the left/

right and up/down buttons.
Confi rm the selection by pressing OK.

The lists available are Artist, Genre and Playlist (as defi ned on the

iPod

Selection and Navigation are described in steps 1 to 5 above.

Do not connect a hard disk or USB devices other than audio

equipment to the USB port. This could damage your installation.

CONNECTING AN iPOD

VIA THE USB PORT

Press one of these buttons to gain

access to the previous/next track on

the classifi cation list currently being

played.
Press and hold one of the buttons for

fast forward or backward play.

Press one of these buttons to gain

access to the previous/next Genre,

Folder, Artist or Playlist on the

classifi cation list currently being

played.

Press and hold LIST to display the

different classifi cations.
Select by Folder/Artist/Genre/Playlist,

press OK to select the classifi cation

required, then press OK again to confi rm.

by Folder: all folders containing audio

fi les recognised on the peripheral

device, classifi ed in alphabetical

order without following the fl ow chart.

by Artist: all of the artist names

defi ned in the ID3 Tags, classifi ed in

alphabetical order.

by Genre: all of the genres defi ned in

the ID3 Tags.

by Playlist: in accordance with the

playlists recorded on the USB device.

222

The display and control is via the portable device.

First adjust the volume of your portable device.

Then adjust the volume of your audio

system.

USING THE AUXILIARY INPUT (AUX)

JACK SOCKET OR USB PORT

(according to vehicle)

ADJUSTING THE VOLUME OF THE

AUXILIARY SOURCE

PEUGEOT CONNECT USB

The auxiliary input, JACK or USB, allows the connection of

portable equipment (MP3 player...).

Do not connect a single piece of equipment via the JACK socket

and the USB port at the same time.

Connect the portable equipment

(MP3 player…) to the JACK

socket or to the USB port, using

a suitable cable (not supplied).

Press the SOURCE button several

times in succession and select AUX.

Content .. 12 13 14 15 ..
