Peugeot 207 (2011 year). Instruction - part 15





223

06

1

2

3

4

5

6

7

8

9

10

BLUETOOTH

  For safety reasons and because they require prolonged attention

on the part of the driver, the operations for pairing of the Bluetooth

mobile telephone with the Bluetooth hands-free system of your

audio equipment must be carried out with the vehicle stationary

and the ignition on.

Press the MENU button.

  A window is displayed with "Searching...".

  Activate the telephone's Bluetooth function.

In the menu, select:
-  Bluetooth

telephone

function -

Audio

-  Bluetooth

confi guration

-

Perform a Bluetooth search

The services offered depend on the network, the SIM card and the

compatibility of the Bluetooth equipment used.
Consult your telephone's manual and your operator to fi nd out which services

are available to you. A list of mobile telephones which offer the best range of

services is available from the network. Consult a PEUGEOT dealer.

          BLUETOOTH TELEPHONE

SCREEN C

  The TELEPHONE menu permits access to the following functions

in particular: Directory * , Call list, Pairing management.

The fi rst 4 telephones recognised are displayed in this window.

  A virtual keypad is displayed on the

screen: enter a code with at least 4 digits.
 Confi rm by pressing OK.

  "Pairing of Name_telephone successful" appears on the screen.

  Select the telephone to be connected from the list. Only one

telephone can be connected at a time.

  A message is displayed on the screen of the telephone

chosen: to accept the pairing, enter the same code on

the telephone, then confi rm by pressing OK.

 The automatic connection authorised is only active after the

telephone has been confi gured.
 The directory and the call list can be accessed after the

synchronisation period.

  PAIRING A TELEPHONE

  The pairing can also be initiated from the telephone.

(AVAILABILITY DEPENDS ON MODEL AND VERSION)

  *   If your telephone is fully compatible.

  If pairing fails, the number of attempts is not limited.

224

06

2

1

2

2

3

  RECEIVING A CALL

display on the multifunction screen.

Initiate the pairing between the telephone and

the vehicle. This pairing can be initiated from

the vehicle's telephone function menu or via the

telephone's keypad. See steps 1 to 10 on the

previous pages. During the pairing phase, the vehicle

must be stationary with the key in the ignition.

Select the telephone to be connected from the telephone function

menu.
The audio system connects to a newly paired telephone

automatically.

  Select the YES tab on the display

using the buttons and confi rm by

pressing OK.

  Press the steering mounted control OK to accept

the call.

       BLUETOOTH AUDIO STREAMING

  Wireless transmission of the telephone's music fi les via the audio

equipment. The telephone must be able to manage the appropriate

bluetooth profi les (Profi les A2DP/AVRCP).

*   In certain cases, playing of the Audio fi les must be initiated from the

keypad.

**   If the telephone supports the function.

  Activate the streaming source by

pressing the SOURCE button * . The

tracks to be played can be controlled

as usual via the buttons on the

Radio control panel and the steering

mounted controls ** . The contextual

information can be displayed on the

screen.

  MAKING A CALL

  From the Bluetooth telephone function Audio menu, select Manage

the telephone call then Call, Call list or Directory.

  Press the end of the steering mounted control for

more than two seconds to gain access to your

directory.
 Or
 To dial a number, use your telephone's keypad,

with the vehicle stationary.

 BLUETOOTH

225

07

1

2

3

4

5

6

7

8

CONFIGURATION

Press the MENU button.

Using the arrows, select DISPLAY

CONGIGURATION.

Press to confi rm the selection.

  Using the arrows, select YEAR.

Press to confi rm the selection.

Press to confi rm the selection.

  Adjust the setting.

Start again from step 1 then set

MONTH, DAY, HOUR, MINUTES.

          SETTING THE DATE AND TIME

SCREEN A

226

07

1

2

3

4

5

6

7

8

CONFIGURATION

Press the MENU button.

Using the arrows, select

PERSONALISATION

CONFIGURATION.

Press to confi rm the selection.

  Using the arrows, select DISPLAY

CONFIGURATION.

Press to confi rm the selection.

Press to confi rm the selection.

Using the arrows, select ADJUST

DATE AND TIME.

  Adjust the settings one by one

confi rming by pressing the OK button.

Next select the OK tab on the screen

then confi rm.

SETTING THE DATE AND TIME

SCREEN C

227

11

08

Each press of the button, located at the end of the

wiper stalk, displays the different trip computer

information in succession, depending on the screen.

-

the "vehicle" tab with:

   ●  the range, the current fuel consumption and the distance remaining

to the destination,

-

the "1" tab (trip 1) with:

   ●  the average speed, the average consumption and the distance

travelled calculated over trip  "1",

-

the "2" tab (trip 2) with the same information for a second trip.

  A FEW DEFINITIONS

  Zero reset
 When the required trip is displayed, press the control for more than

two seconds.

 TRIP COMPUTER

Range:  displays the distance which can travelled with the remaining fuel

detected in the tank, based on the average fuel consumption over the last

few miles (kilometres).
This displayed value may vary signifi cantly following a change in the

vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are displayed.

After fi lling with at least 5 litres of fuel, the range is recalculated and is

displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits,

contact a PEUGEOT dealer.
Current fuel consumption:  only calculated and displayed above 20 mph (30 km/h).

Average fuel consumption:  this is the average fuel consumption since

the last trip computer zero reset.

Average speed:  this is the average speed calculated since the last trip

computer zero reset (ignition on).

Distance travelled:  calculated since the last trip computer zero reset.

Distance remaining to the destination: calculated with reference to

the fi nal destination, entered by the user. If guidance is activated, the

navigation system calculates it as a current value.

228

09  SCREEN MENU MAP

  RADIO-CD

  MAIN FUNCTION

  *   The parameters vary according to vehicle.

  CHOICE A

  CHOICE B...

MONOCHROME A

Choice A1

Choice A2

REG MODE

CD REPEAT

RANDOM PLAY

  VEHICLE CONFIG *

  REV WIPE ACT

  OPTIONS

  GUIDE LAMPS

DIAGNOSTICS

RDS SEARCH

CONSULT

ABANDON

  UNITS

TEMPERATURE: °CELSIUS/°FAHRENHEIT

FUEL CONSUMPTION:

KM/L - L/100 - MPG

1

2

3

3

1

2

2

2

2

1

2

3

2

3

1

2

2

1

2

2

229

09

  DISPLAY ADJUST

  MONTH

  DATE

  HOUR

  MINUTES

YEAR

  12 H/24 H MODE

  LANGUAGE

  ITALIANO

  NEDERLANDS

  PORTUGUES

  PORTUGUES-BRASIL

  FRANCAIS

  DEUTSCH

  ENGLISH

  ESPANOL

1

2

2

2

2

2

2

1

2

2

2

2

2

2

2

2

230

09 SCREEN MENU MAP

Press the OK dial for access to short-cut menus according to the display on the

screen:

MONOCHROME C

activate/deactivate RDS

activate/deactivate REG mode

activate/deactivate radiotext

  RADIO

activate/deactivate Intro

  CD/MP3 CD

activate/deactivate track repeat (the

entire current CD for CD, the entire

current folder for MP3 CD)

activate/deactivate random play (the

entire current CD for CD, the entire

current folder for MP3 CD)

activate/deactivate track repeat (of the

current folder/artist/genre/playlist)

  USB

activate/deactivate random play (of the

current folder/artist/genre/playlist)

1

1

1

1

1

1

1

1

231

09

MONOCHROME C

 SCREEN MENU MAP

  AUDIO FUNCTIONS

alternative frequencies (RDS)

activate/deactivate

FM BAND PREFERENCES

regional mode (REG)

activate/deactivate

radio-text information (RDTXT)

activate/deactivate

1

2

3

4

3

4

3

4

PLAY MODES

album repeat (RPT)

 activate/deactivate

track random play (RDM)

 activate/deactivate

2

3

4

3

4

  TRIP COMPUTER

Distance: x miles

  ENTER DISTANCE TO DESTINATION

Diagnostics

  ALERT LOG

Functions activated or deactivated

  STATUS OF THE FUNCTIONS *

1

2

3

3

2

3

2

video brightness adjustment

DISPLAY CONFIGURATION

DEFINE THE VEHICLE PARAMETERS *

  PERSONALISATION-CONFIGURATION

normal video

inverse video

brightness (- +) adjustment

date and time adjustment

day/month/year adjustment

hour/minute adjustment

choice of 12 h/24 h mode

choice of units

l/100 km - mpg - km/l

°Celsius/°Fahrenheit

CHOICE OF LANGUAGE

1

2

4

3

2

4

4

3

3

4

4

2

3

4

4

Pressing the MENU button displays:

  *   The parameters vary according to vehicle.

232

09 SCREEN MENU MAP

  BLUETOOTH TELEPHONE

Connect/Disconnect a device

 Consult the paired device

BLUETOOTH CONFIGURATION

Telephone function

Audio Streaming function

 Delete a paired device

 Perform a Bluetooth search

Calls list

CALL

 Directory

Terminate the current call

  MANAGE THE TELEPHONE CALL

Activate private mode

1

2

3

3

3

4

4

4

2

3

4

2

3

3

233

 FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

 There is a difference in

sound quality between

the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

 Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the musical ambience "None" and

set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

 The CD is ejected

automatically or is not

played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

  -

Check that the CD is inserted in the player the

right way up.

  -

Check the condition of the CD: the CD cannot

be played if it is too damaged.

  -

Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

  -

The audio equipment's CD player does not

play DVDs.

  -

Due to their quality level, certain writeable

CDs will not be played by the audio system.

The message "USB

peripheral error" is

displayed on the screen.
 The Bluetooth connection

is cut.

The battery of the peripheral may not be suffi ciently charged.

  Recharge the battery of the peripheral device.

The USB memory stick is not recognised.
The memory stick may be corrupt.

 Reformat the memory stick.

 The CD player sound is

poor.

The CD used is scratched or of poor quality.

 Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

 Set the treble or bass level to 0, without selecting

an ambience.

234

QUESTION

ANSWER

SOLUTION

 The stored stations do

not function (no sound,

87.5 Mhz is displayed...).

 An incorrect waveband is selected.

 Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

 The traffi c announcement

(TA) is displayed. I do

not receive any traffi c

information.

The radio station is not part of the regional traffi c information network.

 Tune to a radio station which broadcasts traffi c

information.

 The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

  This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

 Have the aerial checked by a PEUGEOT dealer.

 Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

 Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

 With the engine off,

the audio equipment

switches off after a few

minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

 Start the vehicle's engine to increase the battery

charge.

 The message "the audio

system is overheated"

appears on the display.

In order to protect the installation if the surrounding temperature is too

high, the audio equipment switches to an automatic thermal protection

mode leading to a reduction of the volume or stopping of the playing of

the CD.

 Switch the audio system off for a few minutes to

allow the system to cool.

235

VISUAL SEARCH

 EXTERIOR (SALOON)

 7Door mirrors .............................57

 Lighting controls ....................82-84
 Headlamp adjustment ................85
 Changing bulbs .................142-143

   -  front

lamps

  -  foglamps

  -   direction indicator repeaters

 Electric windows ....................72-73
 Rear quarter panel windows .......73

 Doors .....................................74-76

   -  opening/closing

  -  central

locking

  -  emergency

control



 Remote control key ...............68-71

   -  opening/closing

  -  anti-theft

protection

  -  starting

  -  battery



 Accessories ..............................160
 Roof bars ..................................159
 Panoramic sunroof .....................78

 Fuel tank .....................................79
 Misfuel prevention ......................81

 Wiper controls .......................86-88
 Changing a wiper blade ............155

 Boot ............................................76

   -  opening/closing

  -  emergency

control



 Changing a wheel .............132-136,

137-138, 140-141

   -  tools

  -  removal

  -   temporary tyre repair kit

 Parking sensors ........................121
 Towbar ......................................157
 Towing ......................................156

 Changing bulbs .................144-145

   -  rear

lamps

  -   3rd brake lamp

  -   number plate lamps

 Braking assistance ...................103
 Trajectory control ......................104
 Tyre pressure ...........................175

236

VISUAL SEARCH

 EXTERIOR (SW)

 Door mirrors ...............................57

 Lighting controls ....................82-84
 Headlamp adjustment ................54
 Changing bulbs .................142-143

   -  front

lamps

  -  foglamps

  -   direction indicator repeaters

 Electric windows ....................72-73

 Doors .....................................74-76

   -  opening/closing

  -  central

locking

  -  emergency

control



 Remote control key ...............68-71

   -  opening/closing

  -  anti-theft

protection

  -  starting

  -  battery



 Accessories ..............................160
 Roof bars ..................................159
 Panoramic sunroof .....................78

 Fuel tank .....................................79
 Misfuel prevention ......................81

 Wiper controls .......................86-88
 Changing a wiper blade ............155

 Boot .......................................76-77

   -  opening/closing

  -  emergency

control



 Changing

a wheel ............ 132-137, 139-141

   -  tools

  -  removal

  -   temporary tyre repair kit

 Parking sensors ........................121
 Towbar ......................................157
 Towing ......................................156

 Changing bulbs .................146-147

   -  rear

lamps

  -   3rd brake lamp

  -   number plate lamps

 Braking assistance ...................103
 Trajectory control ......................104
 Tyre pressures ..........................175

237

VISUAL SEARCH

 INTERIOR

 Boot fi ttings (Saloon) .............63-64

   -  hooks

  -   rear parcel shelf

 Temporary tyre

repair kit ..........................132-136

 Conventional child seats .......90-95
 ISOFIX child seats .................96-99
 Child lock ..................................100

 Front seats ............................52-54
 Rear seats (Saloon) ..............54-55
 Rear seats (SW) ...................54, 56

 Seat belts ..........................105-107

 Airbags .............................. 108-111

 Glove box ...................................62
 Deactivating the passenger's

airbag .....................................109

 Boot fi ttings(SW) ...................65-67

   -  stowing

rings

  -   luggage retaining straps

  -  hooks

  -   12 V accessory socket

  -   load space cover

  -   high load retaining net

 Temporary tyre repair kit ....132-136

238

VISUAL SEARCH

 INSTRUMENTS AND CONTROLS

 Multifunction screens .............33-41
 Seat belt warning lamps ....105-106
 Hazard warning lamps ..............102

 Instrument panels .......................19
 Warning lamps .......................20-27
 Indicators ...............................28-31
 Gear shift indicator ................... 113
 Buttons .......................................32

   -   trip distance recorder

  -  lighting

dimmer



 Lighting controls ....................82-84
 Headlamp adjustment ................85

 Speed limiter ..................... 117-118
 Cruise control .................... 119-120

 Door mirrors ...............................57
 Windows ................................72-73

 Dashboard fuses ...............148-150
 Opening the bonnet ..................124

 Steering wheel adjustment .........59
 Horn ..........................................102

 Courtesy lamps ..........................89
 Rear view mirror .........................58
 Sun visor ....................................59
 Toll card/car park ticket windows ....59

 Wiper controls .......................86-88
 Trip computer ........................42-44

 Peugeot Connect

Navigation ....................... 179-211

 Setting the date/time ................202
 Peugeot Connect Sound ...213-234
 Setting the date/time ................226
 Emergency and assistance call .... 178

 Ventilation ..............................45-46
 Heating ..................................47-48
 Manual air conditioning .........47-49
 Digital air conditioning ...........50-51

 Interior fi ttings ........................60-62

   -  glove

box

  -   12 V socket

  -  mat



 Automatic gearbox ............ 114-116
 Parking brake ........................... 112
 Blind control (SW) ......................78















Content   ..  13  14  15  16   ..
