Peugeot 207 (2011 year). Instruction - part 12

175

IDENTIFICATION MARKINGS

Various visible markings for the identifi -

cation of your vehicle.

Wheels which are fi tted with 205/45

R17 and, only on SW Outdoor,

with 205/55 R16 tyres, cannot be

fi tted with snow chains. For more

information, contact a PEUGEOT

dealer.

If the infl ation pressures are too low,

this increases fuel consumption.

The infl ation pressures must be

checked when the tyres are cold,

at least once a month.

A. Vehicle identifi cation number (VIN)

under the bonnet.

This number is etched on the bodywork

near the passenger compartment fi lter.

B. Visible VIN on the dashboard.

This number is indicated on a self-ad-

hesive label which is visible through the

windscreen.

C. VIN on the chassis.

This number is indicated on a self-de-

stroying label affi xed to the centre pillar,

near the driver's door striker.

D. Manufacturer's label.

This label is affi xed to the edge of the

door on the driver's side.

It bears the following information:

the wheel rim and tyre sizes,

the brands of tyre recommended by

the manufacturer,

the associated infl ation pressures,

the paint colour code.

176

177

EMERGENCY OR ASSISTANCE CALL

178

EMERGENCY OR ASSISTANCE CALL

If an impact is detected by the airbag ECU, and

independently of the deployment of any airbags, an

emergency call is made automatically.

Pressing this button again immediately cancels the request. The green

LED goes off.
A press (at any time) of more than 8 seconds on this button, cancels the

request.

When the ignition is switched on, the green

LED comes on for 3 seconds indicating that

the system is operating correctly.

Pressing this button again immediately cancels the request.
The cancellation is confi rmed by a voice message.

Press this button for more than 2 seconds to request

assistance if the vehicle breaks down.
A voice message confi rms that the call has been made * .

OPERATION OF THE SYSTEM

The green LED remains on (without fl ashing) when communication is

established. It goes off at the end of communication.

This call is dealt with by the PEUGEOT Emergency team which receives

locating information from the vehicle and can send a detailed alert to the

appropriate emergency services. In countries in which the team is not

operational, or when the locating service has been expressly declined,

the call is dealt with directly by the emergency services (112) without the

vehicle location.

In an emergency, press this button for more than 2 seconds.

Flashing of the green LED and a voice message confi rm that the

call has been made to the PEUGEOT Emergency team * .

* These services are subject to conditions and availability.

Consult a PEUGEOT dealer.

If the orange LED fl ashes: there is a system

fault.
If the orange LED is on continuously: the

backup battery must be replaced.
In either case, contact a PEUGEOT.

If you purchased your vehicle outside the PEUGEOT dealer network,

we invite you to have a dealer check the confi guration of these services

and, if desired, modifi ed to suit your wishes. In a multi-lingual country,

confi guration is possible in the offi cial national language of your choice.

For technical reasons, particularly to improve the quality of PEUGEOT

CONNECT services to customers, the manufacturer reserves the right to

carry out updates to the vehicle's on-board telematic system.

179

way that it will only operate in your vehicle. If it is to be

installed in another vehicle, contact a PEUGEOT dealer

for confi guration of the system.

Certain functions described in this handbook will

become available during the year.

PEUGEOT CONNECT
NAVIGATION

For safety reasons, the driver must carry out operations

which require prolonged attention while the vehicle is

stationary.
When the engine is switched off and to prevent

discharging of the battery, the Peugeot Connect

Navigation switches off following the activation of the

Energy Economy mode.

MULTIMEDIA AUDIO SYSTEM/BLUETOOTH TELEPHONE
SATELLITE NAVIGATION SYSTEM FOR EUROPE BY SD CARD

01 First steps

CONTENTS

  02  Steering mounted controls
  03  General operation
  04  Navigation - Guidance
  05  Traffic information
  06 Radio

  07  Music media players
  08  Bluetooth telephone
  09 Configuration

10 Trip computer

p.
p.
p.
p.
p.
p.
p.
p.
p.
p.

11 Screen menu map
Frequently asked questions

p.
p.

180
181
182
185
193
195
196
199
202
203
204
208

180

144

155

1. Engine not running

- Short press: on/off.
- Long

press:

CD pause, mute for the radio.

Engine running
- Short press: CD pause, mute for the radio.
- Long press: reinitialisation of the system.

2. Volume

adjustment

(each source is

independent, including also navigation

messages and alerts).

3. Access to the "Radio" Menu. Display the list

of stations.

4. Access to the "Music" Menu. Display the

tracks.

5. Access to the "SETUP" menu.

Long press: access to the GPS coverage

and the demonstration mode.

6. Access to the "Phone" Menu. Display the

call list.

7. Access to the "MODE" menu.

Selection of the successive display of:

Radio, Map, NAV (if navigation is in

progress), Telephone (if a conversation is in

progress), Trip computer.

Long press: display of a black screen (DARK).

8. Access to the "Navigation" Menu. Display

the last destinations.

9. Access to the "Traffi c" Menu. Display the

current traffi c alerts.

10. ESC: abandon the operation in progress.

11. CD eject.

12. Selection of the previous/next radio station

from the list.

Selection of the previous/next MP3 folder.

Selection of the previous/next page of a list.

13. Selection of the previous/next radio station.

Selection of the previous/next CD or MP3 track.

Selection of the previous/next line of a list.

14. Buttons 1 to 6:

Selection of the stored radio station.

Long press: store the current radio station.

15. SD card reader (navigation SD card only).

16. Dial for selection of the screen display and

according to the context of the menu

Short press: contextual menu or confi rmation.

Long press press: contextual menu specifi c

to the list displayed.

FIRST STEPS

Peugeot Connect Navigation CONTROL PANEL

3 - 4. Long press: access to the audio settings:

front/rear fader and left/right balance,

bass/treble, equaliser, loudness, automatic

volume adjustment, initialise the settings.

181

02 STEERING MOUNTED CONTROLS

RADIO: selection of the previous stored station.
Selection of the previous entry in the address book.

RADIO: selection of the next stored station.
Selection of the next entry in the address book.

RADIO: change to the next radio station on the list.
Long press: automatic search for a higher frequency.
CD: selection of the next track.
CD: continuous press: fast forward play.

RADIO: change to the previous radio station on the List.
Long press: automatic search for a lower frequency.
CD: selection of the previous track.
CD: continuous press: fast reverse.

- Change the sound source.
-

Make a call from the address

book.

- Pick

up/Hang up the telephone.

- Press for more than 2 seconds:

access to the address book.

Volume increase.

Volume decrease.

Mute: function activated

by pressing the volume

increase and decrease

buttons simultaneously.
Restore the sound by

pressing one of the two

volume buttons.

182

03 GENERAL OPERATION

For a detailed global view of the menus available, refer to the

"Screen menu map" section.

Press the MODE button several times in succession for access to the following menus:

For cleaning the screen, the use of a soft, non-abrasive cloth

(spectacles cloth) is recommended, with no additional product.

RADIO/ MUSIC MEDIA

PLAYERS

TELEPHONE

(If a conversation is in progress)

FULL SCREEN MAP

NAVIGATION
(If guidance is in progress)

SETUP: system language * , date and time * , display,
vehicle settings * , unit and system settings, "Demo

mode".

TRAFFIC:
TMC information and messages.

* Available according to model.

TRIP COMPUTER

183

03 GENERAL OPERATION

A press on the OK dial gives access to

short-cut menus according to the display

on the screen.

DISPLAY ACCORDING TO THE CONTEXT

NAVIGATION (IF GUIDANCE IS IN

PROGRESS):

TRIP COMPUTER:

Abort guidance

Repeat advice

Block road

Route info

Show destination

Trip info

Route type

Avoid

Satellites

Zoom/Scroll

Voice advice

Route options

Alert log

Status of functions

TELEPHONE:

End call

Hold call

Dial

DTMF-Tones

Private mode

Micro off

184

03 GENERAL OPERATION

DISPLAY ACCORDING TO THE CONTEXT

FULL SCREEN MAP:

Abort guidance / Resume guidance

Set destination

POIs nearby

Position info

Map settings

Zoom/Scroll

RADIO:

In FM mode

Traffi c info (TA)

RDS

Radiotext

Regional prog.

In AM mode

Refresh AM list

MUSIC MEDIA PLAYERS:

Traffi c info (TA)

Play options

Normal order

Random track

Repeat folder

Select music

Scan

185

NAVIGATION - GUIDANCE

SELECTING A DESTINATION

Press the NAV button again or select

the Navigation Menu function and

press the dial to confi rm.

Select the "Destination input"

function and press the dial to

confi rm.

Press the NAV button.

Select the letters of the town one

by one confi rming each time by

pressing the dial.

Once the country has been selected,

turn the dial and select the town

function. Press the dial to confi rm.

Insert the SD card in the front panel reader and leave it there to use the

Navigation functions.
The navigation SD card data must not be modifi ed.
Map data updates are available from PEUGEOT dealers.

A pre-set list (by entering the fi rst few letters) of the towns in the

country selected can be accessed via the LIST button on the virtual

keypad.

Select the "Address input" function

and press the dial to confi rm.

The list of the last 20 destinations appears under the Navigation

Menu function.

Navigation Menu

Destination input

Address input

186

To clear a destination; from steps 1 to 3, select "Choose from last destinations".
A long press on one of the destinations displays a list of actions from which you can select:
Delete entry
Delete list

Repeat steps 5 to 7 for the "Street"

and "House number" functions.

Turn the dial and select OK.
Press the dial to confi rm.

Select the "Save to address book" function to record the address

entered in a directory fi le. Press the dial to confi rm the selection.
Peugeot Connect Navigation allows up to 500 contact fi les to be

recorded.

To speed up the process, the post code can be entered directly

after selecting the "Postal code" function.
Use the virtual keypad to enter the letters and digits.

Then select "Start route guidance"

and the press the dial to confi rm.

During guidance, pressing the end

of the lighting stalk repeats the last

guidance instruction.

Map settings
You can zoom in/zoom out on the map using the dial.
It is possible to move the map or select its orientation via the short-

cut menu of the FULL SCREEN MAP.
Press MODE until the map is displayed full screen. Press the dial

then select "Map settings". Select "2.5D Map" or "2D Map" and in

the latter case, select "North Up" or "Heading Up".

Select the route type:
"Fast route", "Short route" or "Optimized route" and press the dial

to confi rm.
It is also possible to select a destination via "Choose from address

book" or "Choose from last destinations".

Choose from last destinations

Choose from address book

Start route guidance

NAVIGATION - GUIDANCE

187

NAVIGATION - GUIDANCE

SETTING AND NAVIGATING TO MY

"HOME ADDRESS"

Press the NAV button twice to display

the Navigation Menu.

To be set as the "Home address", an address must fi rst be

entered in the address book, for example from "Destination

input"/"Address input" then "Save to address book".

Select "Address book" and confi rm.

Then select "Search entry (complete

address book)" and confi rm.

Select "Destination input" and confi rm.

Then select "Choose from address

book" and confi rm.

Select "Set as home address" and

confi rm to save.

Select your home address and confi rm.

Then select "Edit entry" and confi rm.

To start navigation towards "Home address", press NAV twice

to display the Navigation Menu, select "Destination input" and

confi rm.
Then select "Navigate HOME" and confi rm to start guidance.

Navigation Menu

Destination input

Address book

Edit entry

Set as "Home address"

188

NAVIGATION - GUIDANCE

ROUTE OPTIONS

Select the "Route dynamics"

function.
This function gives access to the

"Traffi c independent" or "Semi-

dynamic" options.

Select the "Avoidance criteria"

function. This function provides

access to the AVOID options

(motorways, toll roads, ferries).

Turn the dial and select the

"Recalculate" function to take into

account the route options selected.

Press the dial to confi rm.

Press the NAV button.

Press the NAV button again or select

the Navigation Menu function and

press the dial to confi rm.

Select the "Route type" function

and press the dial to confi rm. This

function allows you to change the

route type.

Select the "Route options" function

and press the dial to confi rm.

Recalculate

Avoidance criteria

Route dynamics

Route type

Route options

Navigation Menu

The route selected by the Peugeot Connect Navigation system depends

directly on the route options.
Changing these options may change the route completely.

189

ADDING A STOPOVER

Once the new address has been

entered, select OK and press the dial

to confi rm.

Select "Recalculate" and press the

dial to confi rm.

Press the NAV button.

Press the NAV button again or select

the Navigation Menu function and

press the dial to confi rm.

Select the "Add stopover" function

(5 stopovers maximum) and press

the dial to confi rm.

Select the "Stopovers" function and

press the dial to confi rm.

Address input

Add stopover

Stopovers

Navigation Menu

Recalculate

The stopover must be completed or deleted in order for the

guidance to continue to the next destination. Otherwise, the

Peugeot Connect Navigation will always return you to the previous

stopover.

Stopovers can be added to the route once the destination has been

selected.

NAVIGATION - GUIDANCE

190

NAVIGATION - GUIDANCE

SEARCHING FOR POINTS OF INTEREST

(POI)

Press the NAV button.

Press the NAV button again or select

the Navigation Menu function and

press the dial to confi rm.

Select the "POI nearby" function to

search for POIs around the vehicle.

Select the "POI search" function and

press the dial to confi rm.

Navigation Menu

POI search

POI nearby

Select the "POI in city" function to

search for POIs in the city required.

Select the country then enter the

name of the city using the virtual

keypad.

Select the "POI near route" function

to search for POIs near the route.

Select the "POI in country" function

to search for POIs in the country

required.

Select the "POI near destination"

function to search for POIs near the

point of arrival of the route.

POI near destination

POI near route

POI in country

POI in city

A list of cities present in the country selected can be accessed via

the LIST button on the virtual keypad.

The points of interest (POI) indicate all of the service locations in the

vicinity (hotels, various businesses, airports...).

Content .. 10 11 12 13 ..
