0•12
Weekly Checks
Warning: DO NOT attempt to
remove the expansion tank
pressure cap when the engine
is hot, as there is a very great
risk of scalding. Do not leave
open containers of coolant
about, as it is poisonous.
Car Care
l With a sealed-type cooling system,
adding coolant should not be necessary on a
regular basis. If frequent topping-up is
required, it is likely there is a leak. Check the
radiator, all hoses and joint faces for signs of
staining or wetness, and rectify as necessary.
l It is important that antifreeze is used in
the cooling system all year round, not just
during the winter months. Don’t top-up with
water alone, as the antifreeze will become
too diluted.
Coolant level
The coolant level varies with engine
temperature. When cold, the coolant
level should be on the “MAXI” mark
(arrowed). When the engine is hot, the level
may rise slightly above the “MAXI” mark.
If topping up is necessary, wait until the
engine is cold. Unscrew the expansion
tank cap to the first stop, to release any
pressure present in the system. Push the cap
down, turn to the second stop, and remove it.
Add a mixture of water and antifreeze
through the expansion tank filler neck,
until the coolant level is up to the “MAXI”
level mark. Refit the cap, turning it clockwise
as far as it will go to secure.
1
2
3
Engine oil level
Before you start
4 Make sure your car is on level ground.
4 Check the oil level before the car is driven,
or at least 5 minutes after the engine has been
switched off.
The correct oil
Modern engines place great demands on their
oil. It is very important that the correct oil for
your car is used (See “Lubricants, fluids and
tyre pressures”).
Car Care
l If you have to add oil frequently, you
should check whether you have any oil leaks.
Place some clean paper under the car
overnight, and check for stains in the morning.
If there are no leaks, the engine may be
burning oil (see “Fault Finding”).
l Always maintain the level between the
upper and lower dipstick marks (see photo 3).
If the level is too low severe engine damage
may occur. Oil seal failure may result if the
engine is overfilled by adding too much oil.
If the oil is checked
immediately after driving the
vehicle, some of the oil will
remain in the upper engine
components, resulting in an inaccurate
reading on the dipstick!
The dipstick top is often brightly coloured
for easy identification (see “Underbonnet
check points” on pages 0•10 and 0•11
for exact location). Withdraw the dipstick.
Using a clean rag or paper towel remove
all oil from the dipstick. Insert the clean
dipstick into the tube as far as it will go,
then withdraw it again.
Note the oil level on the end of the
dipstick, which should be between the
upper ("MAX") mark and lower ("MIN")
mark. Approximately 1.0 litre of oil will raise
the level from the lower mark to the upper
mark.
Oil is added through the filler cap.
Unscrew the cap and top-up the level; a
funnel may help to reduce spillage. Add
the oil slowly, checking the level on the dipstick
often. Don’t overfill (see “Car Care” left).
1
2
3
4
