1A – 26 HEATING AND VENTILATION INSTALLATION To install, follow the removal steps in the reverse order, 1. Adjust the control cables Air source control cable the link unit of blower assembly and fix it with the Temperature control cable position). 2) Connect the control cable at the “COLD” position of the temperature control link of the heater unit Air select control cable position). 2) Connect the control cable at the “DEFROST” position of the mode control link of the heater unit 2. Check control cable operation. AIR SELECTOR CABLE Air selector knob VENT BI-LEVEL FOOT DEF/FOOT DEF (DEF) TEMPERATURE CONTROL CABLE Temperature control knob COLD HOT (MAX COLD) AIR SOURCE SELECT CABLE Air source select lever (CIRC) CIRC FRESH Clip |
