6E–218 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS 2. Disconnect the EGR VSV connector and vacuum hose from the EGR VSV. 035RW063 3. Remove the MAP sensor assembly and EGR VSV. 035RW067 4. Remove the EGR VSV from the MAP sensor bracket. 035RW062 Installation Procedure 1. Install the EGR VSV and tighten nut to specified torque. Torque: 8 N·m (69 lb in) 035RW062 |
