8F–98 BODY STRUCTURE Legend (1) Front Cowl Cover sealing adhesive is additionally filled (4) Apply primer to the glass and portion where sealing adhesive is additionally filled (5) Windshield (7) Cowl Upper Panel (10) Sealing Adhesive (11) Windshield Upper Moulding (12) Moulding Clip 5. Install the windshield side seal. 631RS014 D Apply a sealing adhesive to the circumference of D Apply the sealing adhesive to the frange portion of D Adjust the gap clearance of the windshield. D Install the windshield to the body panel by applying D Cure the adhesive at a temperature of 20~30 ° C (68 ∼ 86 ° F) for 24 hours. D Check that the windshield does not leak water. 607RS007 7. Install the windshield side moulding. D Insert the windshield (5) side moulding (1) into the 607RS008 D Take care not to damage the side moulding when 8. Install the front cowl cover. |
