ENGINE MECHANICAL 6A – 41 5. Piston and Connecting Rod • Apply engine oil to the cylinder bores, the • Check to see that the piston ring end gaps are • Insert the piston/connecting rod assemblies into • The front marks must be facing the front of the 4. Connecting Rod Bearing Cap • Apply engine oil to screw and seat of bearing cap • Tighten the cap nuts in 2 steps, using angular N·m (kg·m/lb·ft) 45 ° ~ 60 ° 1st step 2nd step 29 (3.0/22) After tightening the cap nuts, check to see that the 3. Oil Pump Assembly 2. Crankcase Assembly • Refer to “Crankcase” in Section 6A2. 1. Cylinder Head Assembly • Refer to “Cylinder head” in Section 6A2. |
