0A–2 GENERAL INFORMATION Illustration Arrows Arrows are designed for specific purposes to aid your understanding of technical illustrations. Arrow Type Application Front of vehicle Up Side Task Related View Detail View Angle Dimension (1:2) Sectioning (1:3) • Ambient/Clean air flow • Cool air flow • Gas other than ambient air • Hot air flow • Ambient air mixed with another gas • Can indicate temperature change Motion or direction Lubrication point oil or Lubrication point grease Lubrication point jelly Arrow Type Application |
