SUNROOF/CONVERTIBLE TOP

8I–3

Installation

1. Be sure to install the sunroof weatherstrip so that

the joint of the weatherstrip is on the rear side of the
vehicle.

2. Temporary install the glass to the sunroof frame.

3. Open and shut the sunroof four to five times to

position correctly the sunroof weatherstrip and the
glass in the longitudinal and latitudinal setting
positions.

4. Adjust the setting position to flush the surface

between the roof panel and weatherstrip of sunroof
glass.

5. Tighten the sunroof glass fixing screws to the

specified torque.

Torque: 4 N·m (0.4 kg·m/35lbin)

6. After the sunroof glass is installed, recheck the roof

panel and sunroof glass for vertical install position.
If out of standard, adjust with fixing screws.

SECTION

8I–4

SUNROOF/CONVERTIBLE TOP

Sunroof Deflector

Removal

1. Open the sunroof.

• Let a 5 mm drill go through two blind rivets (2) to

disengage riveted portions.

2. Remove the sunroof deflector (1).

665RW027

Installation

To install, follow the removal steps in the reverse order.

SECTION

SUNROOF/CONVERTIBLE TOP

8I–5

Sunshade

Disassembled View

665RW012

Legend

EndOFCallout

Removal

1. Tilt the sunroof.

2. Disconnect the battery ground cable.

3. Remove the sunroof glass.

• Refer to Sunroof Glass (LWB) in this section.

4. Pull the sight shield upward using screwdriver.

665RW006

(1) Sunroof Glass
(2) Sight Shield

(3) Sunshade Stopper
(4) Sunshade

SECTION

8I–6

SUNROOF/CONVERTIBLE TOP

5. Remove 2 sunshade stopper fixing screws and

remove sunshade stopper (1).

665RW007

6. Pull out the sunshade (4) up to the guide rail edge.

Lift the front of sunshade and clear the projection (3)
of sunshade through the notch (2) of guide rail edge,
then draw the sunshade out of the roof.

665RW009

Installation

To install, follow the removal steps in the reverse order.
