Nissan Sentra (2019 year). Instruction - part 10

2. The indicator light will begin to flash

after 20 seconds. Without releasing the
HomeLink® button, proceed with “Pro-
gramming HomeLink®” - Step 1.

For

questions

comments,

contact

HomeLink®

at:

www.homelink.com

1–800–355–3515 (except Mexico).

The HomeLink® Universal Transceiver but-
ton has now been reprogrammed. The
new device can be activated by pressing
the HomeLink® button that was just pro-
grammed. This procedure will not affect
any other programmed HomeLink® but-
tons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change
the codes of any non-rolling code device
that

has

been

programmed

into

HomeLink®. Consult the Owner’s Manual of
each device or call the manufacturer or
dealer of those devices for additional infor-
mation.

When your vehicle is recovered, you will
need to reprogram the HomeLink® Uni-
versal Transceiver with your new trans-
mitter information.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause interference, and (2) this
device must accept any interference re-
ceived, including interference that may
cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s author-
ity to operate the equipment.

For Canada:

This

device

complies

with

Industry

Canada licence-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must ac-
cept any interference, including interfer-
ence that may cause undesired opera-
tion of the device.

2-68

Instruments and controls

3 Pre-driving checks and adjustments

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

NISSAN Intelligent Key® (if so equipped) . . . . . . . 3-2
NISSAN Vehicle Immobilizer System
keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Locking with key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Locking with inside lock knob. . . . . . . . . . . . . . . . . 3-6
Locking with power door lock switch . . . . . . . . . 3-6
Automatic door locks (if so equipped) . . . . . . . . 3-7
Child safety rear door lock . . . . . . . . . . . . . . . . . . . . 3-7

Remote keyless entry system (if so equipped) . . . 3-8

How to use remote keyless entry
system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

NISSAN Intelligent Key® (if so equipped) . . . . . . . . . .3-11

Troubleshooting guide
(manual transmission only) . . . . . . . . . . . . . . . . . . 3-24

Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
Trunk lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26

Trunk lid release switch . . . . . . . . . . . . . . . . . . . . . . 3-26
Interior trunk lid release . . . . . . . . . . . . . . . . . . . . . 3-26
Interior trunk access . . . . . . . . . . . . . . . . . . . . . . . . 3-27

Fuel-filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27

Opener operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
Fuel-filler cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-28

Steering wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30

Tilt operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
Telescopic operation . . . . . . . . . . . . . . . . . . . . . . . . 3-30

Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30

Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31

Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31

Manual anti-glare rearview mirror
(if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31
Automatic anti-glare rearview mirror
(if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
Outside mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-33

Integrated door lock key fob

Key number plate

CAUTION

Do not leave the ignition key inside the
vehicle when you leave the vehicle.

A key number plate is supplied with your
keys. Record the key number and keep it in
a safe place (such as your wallet), not in the
vehicle. If you lose your keys, it is recom-
mended that you visit a NISSAN dealer for
duplicates by using the key number.

NISSAN does not record key numbers so it
is very important to keep track of your key
number plate.

A key number is only necessary when you
have lost all keys and do not have one to
duplicate from. If you still have a key, it can
be duplicated without knowing the key
number.

Intelligent Keys (two sets)

Mechanical key

Key number plate (one plate)

NISSAN INTELLIGENT KEY® (if so
equipped)

Your vehicle can only be driven with the
Intelligent Keys which are registered to
your vehicle’s Intelligent Key components
and NISSAN Vehicle Immobilizer System
components.

Never leave the keys in the vehicle.

Type A (if so equipped)

LPD2027

Type B (if so equipped)

LPD2076

KEYS

3-2

Pre-driving checks and adjustments

As many as four Intelligent Keys can be
registered and used with one vehicle. The
new keys must be registered prior to use
with the Intelligent Key and NISSAN Vehicle
Immobilizer System of your vehicle. It is rec-
ommended that you visit a NISSAN dealer
for this service. Since the registration pro-
cess requires erasing all memory in the
Intelligent Key components, when register-
ing new keys, be sure to take all Intelligent
Keys that you have to a NISSAN dealer.

A key number is only necessary when you
have lost all keys and do not have one to
duplicate from. If you still have a key, it can
be duplicated without knowing the key
number.

CAUTION

Listed below are conditions or occur-
rences which will damage the Intelli-
gent Key:

∙ Do not allow the Intelligent Key, which

contains electrical components, to
come into contact with water or salt
water. This could affect the system
function.

∙ Do not drop the Intelligent Key.

∙ Do not strike the Intelligent Key

sharply against another object.

∙ Do not change or modify the Intelli-

gent Key.

∙ Wetting may damage the Intelligent

Key. If the Intelligent Key gets wet, im-
mediately wipe until it is completely
dry.

∙ Do not place the Intelligent Key for an

extended period in an area where
temperatures exceed 140°F (60°C).

∙ Do not attach the Intelligent Key with

a key holder that contains a magnet.

∙ Do not place the Intelligent Key near

equipment that produces a magnetic
field, such as a TV, audio equipment
and personal computers.

If an Intelligent Key is lost or stolen,
NISSAN recommends erasing the ID
code of that Intelligent Key from the ve-
hicle. This may prevent the unauthor-
ized use of the Intelligent Key to oper-
ate

the

vehicle.

For

information

regarding the erasing procedure, it is
recommended that you visit a NISSAN
dealer.

Pre-driving checks and adjustments

3-3

Mechanical key

The Intelligent Key contains the mechani-
cal key.

To remove the mechanical key, release the
lock knob on the back of the Intelligent Key.

To install the mechanical key, firmly insert it
into the Intelligent Key until the lock knob
returns to the lock position.

Use the mechanical key to lock or unlock
the driver’s door.

CAUTION

Always carry the mechanical key in-
stalled in the Intelligent Key slot.

For additional information, refer to “Doors”
in this section.

NISSAN VEHICLE IMMOBILIZER
SYSTEM KEYS

You can only drive your vehicle using the
keys which are registered to the NISSAN
Vehicle Immobilizer System components
in your vehicle.

A mechanical key can be used for all the
locks.

Never leave the keys in the vehicle.

Additional or replacement keys:

If you still have a key, the key number is not
necessary when you need extra NISSAN
Vehicle Immobilizer System keys. Your ex-
isting key can be duplicated without know-
ing the key number. As many as four
NISSAN Vehicle Immobilizer System keys
can be used with one vehicle. You should
bring all NISSAN Vehicle Immobilizer Sys-
tem keys that you have to a NISSAN dealer
for registration. This is because the regis-
tration process will erase the memory of all

key codes previously registered into the
NISSAN Vehicle Immobilizer System. After
the registration process, these compo-
nents will only recognize keys coded into
the NISSAN Vehicle Immobilizer System
during registration. Any key that is not
given to the dealer at the time of registra-
tion will no longer be able to start your
vehicle.

CAUTION

Do not allow the immobilizer system
key, which contains an electrical tran-
sponder, to come into contact with wa-
ter or salt water. This could affect sys-
tem function.

SPA1951

3-4

Pre-driving checks and adjustments

When the doors are locked using one of the
following methods, the doors cannot be
opened using the inside or outside door
handles. The doors must be unlocked to
open the doors.

WARNING

∙ Always have the doors locked while

driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from unintention-
ally opening the doors, and will help
keep out intruders.

∙ Before opening any door, always look

for and avoid oncoming traffic.

∙ To help avoid risk of injury or death

through unintended operation of the
vehicle and/or its systems, including
entrapment in windows and/or inad-
vertent door lock activation, do not
leave children, people who require the
assistance of others and/or pets un-
attended in your vehicle. Additionally,
the temperature inside a closed ve-
hicle on a warm day can quickly be-
come high enough to cause a signifi-
cant risk of injury or death to people
and pets.

LOCKING WITH KEY

To lock or unlock the vehicle, turn the key as
shown.

Manual

To lock either the driver or passenger side
door, turn the key toward the front of the
vehicle

䊊

. To unlock, turn it toward the rear

䊊

Driver’s side

LPD2129

DOORS

Pre-driving checks and adjustments

3-5

Power (if so equipped)

The power door lock system allows you to
lock or unlock all doors at the same time.

Turning the key toward the front

䊊

of the

vehicle locks all doors.

Turning the key one time toward the rear

䊊

of the vehicle unlocks that door. From

that position, returning the key to neutral

䊊

(where the key can only be removed and

inserted) and turning it toward the rear
again

䊊

within five seconds unlocks all

doors.

LOCKING WITH INSIDE LOCK KNOB

To lock the door without the key, move the
inside lock knob to the lock position

䊊

then close the door.

To unlock the door without the key, move
the inside lock knob to the unlock position

䊊

LOCKING WITH POWER DOOR
LOCK SWITCH

To lock all the doors without a key, push the
door lock switch (driver’s or front passen-
ger’s side) to the lock position

䊊

. When

locking the door this way, be certain not to
leave the key inside the vehicle.

To unlock all the doors without a key, push
the door lock switch (driver’s or front pas-
senger’s side) to the unlock position

䊊

Driver’s side

LPD0461

Inside lock

SPA2726

Driver’s and passenger’s side

LPD2309

3-6

Pre-driving checks and adjustments

Lockout protection

When the power door lock switch is moved
to the lock position and any door is open, all
doors will lock and unlock automatically.
With the Intelligent Key left in the vehicle
while any door open, all doors will unlock
automatically and a chime will sound after
the door is closed.

These functions help to prevent the Intelli-
gent Key from being accidentally locked
inside the vehicle.

AUTOMATIC DOOR LOCKS (if so
equipped)

∙ All doors lock automatically when the

vehicle

speed

reaches

mph

(24 km/h).

∙ Continuously

Variable

Transmission

(CVT) (if so equipped)

– All doors unlock automatically when

the transmission is placed in the P
(Park) position.

∙ Manual transmission (if so equipped)

– All doors unlock automatically when

the ignition is placed in the off posi-
tion.

∙ Vehicles not equipped with Intelligent

Key (if so equipped)

– All doors unlock automatically when

the transmission is placed in the P
(Park) position (if so equipped), the
ignition is turned to the OFF position
or when the key is removed from the
ignition.

NOTE:

The automatic door unlock function can
be changed using the “Vehicle Settings”
of the vehicle information display. For
additional information, refer to “Vehicle
information display” in the “Instruments
and controls” section of this manual (if
so equipped).

CHILD SAFETY REAR DOOR LOCK

Child safety locks help prevent the rear
doors from being opened accidentally, es-
pecially when small children are in the ve-
hicle.

The child safety lock levers are located on
the edge of the rear doors.

When the lever is in the unlock position

䊊

the door can be opened from the outside
or the inside.

When the lever is in the LOCK position

䊊

the door can be opened only from the
outside.

LPD2570

Pre-driving checks and adjustments

3-7

WARNING

∙ Radio waves could adversely affect

electric medical equipment. Those
who use a pacemaker should contact
the

electric

medical

equipment

manufacturer for the possible influ-
ences before use.

∙ The remote keyless entry key fob

transmits radio waves when the but-
tons are pressed. The FAA advises ra-
dio waves may affect aircraft naviga-
tion and communication systems. Do
not operate the remote keyless entry
key fob while on an airplane. Make
sure the buttons are not operated un-
intentionally when the unit is stored
for a flight.

It is possible to lock/unlock all doors, turn
the interior lights on, and activate the panic
alarm by using the key fob from outside the
vehicle.

Be sure to remove the key from the ve-
hicle before locking the doors.

The key fob can operate at a distance of
approximately 33 ft (10 m) from the vehicle.
The effective distance depends on the
conditions around the vehicle.

As many as four key fobs can be used with
one vehicle. For information concerning
the purchase and use of additional key
fobs, it is recommended that you visit a
NISSAN dealer.

The key fob will not function when:

∙ The battery is discharged.

∙ The distance between the vehicle and

the key fob is over 33 ft (10 m).

The panic alarm will not activate when
the key is in the ignition switch.

CAUTION

Listed below are conditions or occur-
rences which will damage the key fob:

∙ Do not allow the key fob, which con-

tains electrical components, to come
into contact with water or salt water.
This could affect the system function.

∙ Do not drop the key fob.

∙ Do not strike the key fob sharply

against another object.

∙ Do not change or modify the key fob.

∙ Wetting may damage the key fob. If

the key fob gets wet, immediately
wipe until it is completely dry.

∙ Do not place the key fob for an ex-

tended period in an area where tem-
peratures exceed 140°F (60°C).

∙ Do not attach the key fob with a key

holder that contains a magnet.

∙ Do not place the key fob near equip-

ment that produces a magnetic field,
such as a TV, audio equipment and
personal computers.

If a key fob is lost or stolen, NISSAN rec-
ommends erasing the ID code of that
key fob. This will prevent the key fob
from unauthorized use to unlock the
vehicle. For information regarding the
erasing procedure, it is recommended
that you visit a NISSAN dealer.

REMOTE KEYLESS ENTRY SYSTEM (if
so equipped)

3-8

Pre-driving checks and adjustments

HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM

Locking the doors

1. Remove the ignition key.

2. Close all the doors.

3. Press the

button on the key fob.

∙ All the doors will lock.

∙ The hazard indicator flashes twice and

the horn beeps once.

NOTE:

An auto-relock function will operate af-
ter a full or partial unlock, when no fur-
ther user action occurs. The relock will
operate approximately 1 minute after
full or partial unlock. The auto-relock
function is canceled when any door is
opened or the key is inserted into the
ignition.

Unlocking the doors

1. Press the

button on the key fob to

unlock the driver’s door.

2. The hazard warning lights flash once.

3. Press the

button again within

5 seconds to unlock all doors.

LPD2028

LPD2029

Pre-driving checks and adjustments

3-9

Releasing the trunk lid

Press the

button on the key fob for

longer than 0.5 seconds to open the trunk
lid. The trunk release button on the key fob
will not operate when the ignition switch is
placed in the ON position.

Using the panic alarm

If you are near your vehicle and feel threat-
ened, you may activate the panic alarm to
call attention by pressing and holding
the

button on the key fob for longer

than 0.5 seconds.
The panic alarm will stay on for a period of
time.

The panic alarm stops when:

∙ It has run for a period of time.

∙ Any button is pressed on the key fob.

Using the interior light

Press the

button on the key fob once

to turn on the interior lights.
For additional information, refer to “Interior
lights” in the “Instruments and controls”
section of this manual.

LPD2030

LPD2031

3-10

Pre-driving checks and adjustments

Silencing the horn beep feature

If desired, the horn beep feature can be
deactivated using the key fob.

To deactivate: Press and hold the
and

buttons for at least 2 seconds.

The hazard warning lights will flash three
times to confirm that the horn beep fea-
ture has been deactivated.

To activate: Press and hold the
and

buttons for at least 2 seconds

once more.

The hazard warning lights will flash once
and the horn will sound once to confirm
that the horn beep feature has been reac-
tivated.

Deactivating the horn beep feature does
not silence the horn if the alarm is trig-
gered.

WARNING

∙ Radio waves could adversely affect

electric medical equipment. Those
who use a pacemaker should contact
the

electric

medical

equipment

manufacturer for the possible influ-
ences before use.

∙ The Intelligent Key transmits radio

waves when the buttons are pressed.
The FAA advises the radio waves may
affect aircraft navigation and com-
munication systems. Do not operate
the Intelligent Key while on an air-
plane. Make sure the buttons are not
operated unintentionally when the
unit is stored for a flight.

The Intelligent Key system can operate all
the door locks using the remote control
function or pushing the request switch on
the vehicle without taking the key out from
a pocket or purse. The operating environ-
ment and/or conditions may affect the In-
telligent Key system operation.

Be sure to read the following before using
the Intelligent Key system.

LPD2032

NISSAN INTELLIGENT KEY® (if so
equipped)

Pre-driving checks and adjustments

3-11

CAUTION

∙ Be sure to carry the Intelligent Key

with you when operating the vehicle.

∙ Never leave the Intelligent Key in the

vehicle when you leave the vehicle.

The Intelligent Key is always communicat-
ing with the vehicle as it receives radio
waves. The Intelligent Key system trans-
mits weak radio waves. Environmental
conditions may interfere with the opera-
tion of the Intelligent Key system under the
following operating conditions:

∙ When operating near a location where

strong radio waves are transmitted,
such as a TV tower, power station and
broadcasting station.

∙ When in possession of wireless equip-

ment, such as a cellular telephone,
transceiver or a CB radio.

∙ When the Intelligent Key is in contact

with or covered by metallic materials.

∙ When any type of radio wave remote

control is used nearby.

∙ When the Intelligent Key is placed near

an electric appliance such as a personal
computer.

∙ When the vehicle is parked near a park-

ing meter.

In such cases, correct the operating condi-
tions before using the Intelligent Key func-
tion or use the mechanical key.

Although the life of the battery varies de-
pending on the operating conditions, the
battery’s life is approximately two years. If
the battery is discharged, replace it with a
new one.

When the Intelligent Key battery is low, the
Intelligent Key system warning light (

)

will blink green for about 30 seconds after
the ignition switch is placed in the ON po-
sition.
Since the Intelligent Key is continuously re-
ceiving radio waves, if the key is left near
equipment which transmits strong radio
waves, such as signals from a TV and per-
sonal computer, the battery life may be-
come shorter.

For information regarding replacement of
a battery, refer to “Battery replacement” in
the “Do-it-yourself ” section of this manual.

As many as four Intelligent Keys can be
registered and used with one vehicle. For
information about the purchase and use of

additional Intelligent Keys, it is recom-
mended that you visit a NISSAN dealer.

CAUTION

Listed below are conditions or occur-
rences which will damage the Intelli-
gent Key:

∙ Do not allow the Intelligent Key, which

contains electrical components, to
come into contact with water or salt
water. This could affect the system
function.

∙ Do not drop the Intelligent Key.

∙ Do not strike the Intelligent Key

sharply against another object.

∙ Do not change or modify the Intelli-

gent Key.

∙ Wetting may damage the Intelligent

Key. If the Intelligent Key gets wet, im-
mediately wipe until it is completely
dry.

∙ Do not place the Intelligent Key for an

extended period in an area where
temperatures exceed 140°F (60°C).

∙ Do not attach the Intelligent Key with

a key holder that contains a magnet.

3-12

Pre-driving checks and adjustments

∙ Do not place the Intelligent Key near

equipment that produces a magnetic
field, such as a TV, audio equipment
and personal computers.

If an Intelligent Key is lost or stolen, NISSAN
recommends erasing the ID code of that
Intelligent Key from the vehicle. This may
prevent the unauthorized use of the Intelli-
gent Key to operate the vehicle. For infor-
mation regarding the erasing procedure, it
is recommended that you visit a NISSAN
dealer.

OPERATING RANGE

The Intelligent Key functions can only be
used when the Intelligent Key is within the
specified operating range from the request
switch

䊊

When the Intelligent Key battery is dis-
charged or strong radio waves are present
near the operating location, the Intelligent
Key operating range becomes narrower,
and the Intelligent Key may not function
properly.

The operating range is within 31.50 in
(80 cm) from each request switch

䊊

If the Intelligent Key is too close to the door
glass, handle or rear bumper, the request
switches may not function.

When the Intelligent Key is within the oper-
ating range, it is possible for anyone, even
someone who does not carry the Intelli-
gent Key, to push the request switch to
lock/unlock the doors.

LPD2402

Pre-driving checks and adjustments

3-13

DOOR LOCKS/UNLOCKS
PRECAUTION

∙ Do not push the door handle request

switch with the Intelligent Key held in
your hand as illustrated. The close dis-
tance to the door handle will cause the
Intelligent Key system to have difficulty
recognizing that the Intelligent Key is
outside the vehicle.

∙ After locking with the door handle re-

quest switch, verify the doors are se-
curely locked by testing them.

∙ To prevent the Intelligent Key from be-

ing left inside the vehicle, make sure you
carry the Intelligent Key with you and
then lock the doors.

∙ Do not pull the door handle before

pushing

the

door

handle

request

switch. The door will be unlocked but
will not open. Release the door handle
once and pull it again to open the door.

NISSAN INTELLIGENT KEY®
OPERATION

You can lock or unlock the doors and trunk
lid without taking the Intelligent Key out of
your pocket or bag.

When you carry the Intelligent Key with you,
you can lock or unlock all doors and trunk
lid by pushing the door handle request
switch within the range of operation.

LPD2554

LPD2399

3-14

Pre-driving checks and adjustments

Locking doors

1. Move the shift lever to the P (Park) posi-

tion (Continuously Variable Transmis-
sion only), place the ignition switch in
the LOCK position and make sure you
carry the Intelligent Key with you.

2. Close all doors.

3. Push any door handle request switch

䊊

while carrying the Intelligent Key

with you.

4. All doors and the trunk will lock.

5. The hazard warning lights flash twice

and the outside chime sounds twice.

NOTE:

∙ Doors and trunk lid lock with the door

handle request switch while the ignition
switch is not in the LOCK position.

∙ Doors and trunk lid do not lock by push-

ing the door handle request switch
while any door is open. However, doors
lock with the mechanical key even if any
door is open.

∙ Doors and trunk lid do not lock with the

door handle request switch with the In-
telligent Key inside the vehicle; a beep
sounds to warn you. However, when an
Intelligent Key is inside the vehicle,
doors can be locked with another Intel-
ligent Key.

CAUTION

∙ After locking the doors using the re-

quest switch, make sure that the
doors have been securely locked by
operating the door handle or the
trunk opener switch.

∙ When locking the doors using the re-

quest switch, make sure to have the
Intelligent Key in your possession be-
fore operating the request switch to
prevent the Intelligent Key from being
left in the vehicle.

∙ The request switch is operational only

when the Intelligent Key has been de-
tected by the Intelligent Key system.

LPD2400

LPD2165

Pre-driving checks and adjustments

3-15

Content .. 8 9 10 11 ..
