PG HARNESS PG-59 < COMPONENT DIAGNOSIS > C D E F G H I J K L B A O P N C4 B12 W/3 : Seat belt buckle switch LH C4 B84 B/1 : Parking brake switch E4 B14 Y/2 : Front LH seat belt pre-tensioner Front seat LH harness D5 B15 Y/2 : LH side air bag (satellite) sensor C5 B200 W/16 : To B37 G3 B18 W/3 : Rear door switch LH C4 B204 GR/2 : Sliding motor LH F3 B19 — : Body ground D4 B205 W/2 : Reclining motor LH C5 B37 W/16 : To B200 C4 B206 GR/2 : Lifting motor (front) D2 B38 Y/2 : LH side curtain air bag module D4 B207 GR/2 : Lifting motor (rear) B5 B40 W/8 : To E34 C5 B208 W/10 : Power seat switch LH B5 B69 SMJ : To M40 C5 B209 W/3 : Front seat heater LH F4 B72 GR/4 : Subwoofer F3 B210 B/1 : Rear window defogger C4 B73 B/6 : Yaw rate/side/decel G sensor |
