DIAGNOSIS SYSTEM (TCM)

BATTERY VOLT (V)

X

—

ATF PRES SW 1 (ON-OFF display)

X

X

ATF PRES SW 2 (ON-OFF display)

X

X

(for LC/B solenoid)

ATF PRES SW 3 (ON-OFF display)

X

X

ATF PRES SW 5 (ON-OFF display)

X

X

ATF PRES SW 6 (ON-OFF display)

X

X

RANGE SW 1 (ON-OFF display)

X

—

RANGE SW 2 (ON-OFF display)

X

—

RANGE SW 3 (ON-OFF display)

X

—

RANGE SW 4 (ON-OFF display)

X

—

1 POSITION SW (ON-OFF display)

X

—

1st position switch

SLCT LVR POSI

—

X

Selector lever position is recognized by the TCM.
For fail-safe operation, the specific value used
for control is displayed.

OD CONT SW (ON-OFF display)

X

—

POWERSHIFT SW (ON-OFF display)

X

—

Not mounted but displayed.

HOLD SW (ON-OFF display)

X

—

DS RANGE (ON-OFF display)

—

—

MANU MODE SW (ON-OFF display)

X

—

NON M-MODE SW (ON-OFF display)

X

—

UP SW LEVER (ON-OFF display)

X

—

DOWN SW LEVER (ON-OFF display)

X

—

SFT UP ST SW (ON-OFF display)

—

—

SFT DWN ST SW (ON-OFF display)

—

—

ASCD-OD CUT (ON-OFF display)

—

—

ASCD-CRUISE (ON-OFF display)

—

—

ABS SIGNAL (ON-OFF display)

—

—

ACC OD CUT (ON-OFF display)

—

—

Not mounted but displayed.

ACC SIGNAL (ON-OFF display)

—

—

TCS GR/P KEEP (ON-OFF display)

—

—

TCS SIGNAL 2 (ON-OFF display)

—

—

TCS SIGNAL 1 (ON-OFF display)

—

—

TCC SOLENOID (A)

—

X

LINE PRES SOL (A)

—

X

I/C SOLENOID (A)

—

X

FR/B SOLENOID (A)

—

X

Monitored item (Unit)

Monitor Item Selection

Remarks

ECU IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

DIAGNOSIS SYSTEM (TCM)

TM-155

< FUNCTION DIAGNOSIS >

[5AT: RE5R05A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

D/C SOLENOID (A)

—

X

HLR/C SOL (A)

—

X

ON OFF SOL (ON-OFF display)

—

—

LC/B solenoid

TCC SOL MON (A)

—

—

L/P SOL MON (A)

—

—

I/C SOL MON (A)

—

—

FR/B SOL MON (A)

—

—

D/C SOL MON (A)

—

—

HLR/C SOL MON (A)

—

—

ONOFF SOL MON (ON-OFF display)

—

—

LC/B solenoid

P POSI IND (ON-OFF display)

—

—

R POSI IND (ON-OFF display)

—

—

N POSI IND (ON-OFF display)

—

—

D POSI IND (ON-OFF display)

—

—

4TH POSI IND (ON-OFF display)

—

—

3RD POSI IND (ON-OFF display)

—

—

2ND POSI IND (ON-OFF display)

—

—

1ST POSI IND (ON-OFF display)

—

—

MANU MODE IND (ON-OFF display)

—

—

Not mounted but displayed.

POWER M LAMP (ON-OFF display)

—

—

F-SAFE IND/L (ON-OFF display)

—

—

ATF WARN LAMP (ON-OFF display)

—

—

BACK-UP LAMP (ON-OFF display)

—

—

STARTER RELAY (ON-OFF display)

—

—

RANGE SW3M (ON-OFF display)

—

—

C/V CLB ID1

—

—

C/V CLB ID2

—

—

C/V CLB ID3

—

—

UNIT CLB ID1

—

—

UNIT CLB ID2

—

—

UNIT CLB ID3

—

—

TRGT GR RATIO

—

—

TRGT PRES TCC (kPa, kg/cm

2

 or psi)

—

—

TRGT PRES L/P (kPa, kg/cm

2

 or psi)

—

—

TRGT PRES I/C (kPa, kg/cm

2

 or psi)

—

—

Monitored item (Unit)

Monitor Item Selection

Remarks

ECU IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

TM-156

< FUNCTION DIAGNOSIS >

[5AT: RE5R05A]

DIAGNOSIS SYSTEM (TCM)

DTC & SRT CONFIRMATION

DTC Work Support Mode

Diagnosis Procedure without CONSULT-III

INFOID:0000000005273997

 OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)

Refer to

EC-76, "Generic Scan Tool (GST) Function"

 (QR25DE) or

EC-536, "Generic Scan Tool (GST) Func-

tion"

 (VQ40DE).

 OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)

Refer to

TM-150, "Malfunction Indicator Lamp (MIL)"

.

 TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)

Description

TRGT PRE FR/B (kPa, kg/cm

2

 or psi)

—

—

TRGT PRES D/C (kPa, kg/cm

2

 or psi)

—

—

TRG PRE HLR/C (kPa, kg/cm

2

 or psi)

—

—

SHIFT PATTERN

—

—

DRV CST JUDGE

—

—

START RLY MON

—

—

NEXT GR POSI

—

—

SHIFT MODE

—

—

MANU GR POSI

—

—

VEHICLE SPEED (km/h or mph)

—

X

Vehicle speed recognized by the TCM.

Monitored item (Unit)

Monitor Item Selection

Remarks

ECU IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

DTC work support item

Description

Check item

1ST GR FNCTN P0731

Following items for “1GR incorrect ratio” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed

or not)

• Self-diagnostic results (OK or NG)

• Input clutch solenoid valve
• Front brake solenoid valve
• Direct clutch solenoid valve
• High and low reverse clutch

solenoid valve

• Each clutch and brake
• Hydraulic  control circuit

2ND GR FNCTN P0732

Following items for “2GR incorrect ratio” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed

or not)

• Self-diagnostic results (OK or NG)

3RD GR FNCTN P0733

Following items for “3GR incorrect ratio” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed

or not)

• Self-diagnostic results (OK or NG)

4TH GR FNCTN P0734

Following items for “4GR incorrect ratio” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed

or not)

• Self-diagnostic results (OK or NG)

5TH GR FNCTN P0735

Following items for “5GR incorrect ratio” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed

or not)

• Self-diagnostic results (OK or NG)

DIAGNOSIS SYSTEM (TCM)

TM-157

< FUNCTION DIAGNOSIS >

[5AT: RE5R05A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

When the ignition switch is switched “ON”, the O/D OFF indicator lamp lights up for 2 seconds. As a method
for locating the suspect circuit, when the self-diagnostics start signal is input, the memory for the malfunction
location is output and the O/D OFF indicator lamp flashes to display the corresponding DTC.

Diagnostic Procedure

1.

CHECK O/D OFF INDICATOR LAMP

1.

Start the engine with selector lever in “P” position. Warm engine to normal operating temperature.

2.

Turn ignition switch ON and OFF at least twice, then leave it in the OFF position.

3.

Wait 10 seconds.

4.

Turn ignition switch ON. (Do not start engine.)

Does O/D OFF indicator lamp come on for about 2 seconds?

YES

>> GO TO 2.

NO

>> Go to

TM-235, "Symptom Chart"

.

2.

JUDGMENT PROCEDURE STEP 1

1.

Turn ignition switch OFF.

2.

Keep pressing shift lock release button.

3.

Move selector lever from “P” to “D” position.

4.

Release accelerator pedal. (Set the closed throttle position signal “ON”.)

5.

Depress brake pedal. (Stop lamp switch signal “ON”.)

6.

Turn ignition switch ON. (Do not start engine.)

7.

Wait 3 seconds.

8.

Move the selector lever from “D” to “3” position.

9.

Release brake pedal. (Stop lamp switch signal “OFF”.)

10. Move the selector lever from “3” to “2” position.
11. Depress brake pedal. (Stop lamp switch signal “ON”.)
12. Depress accelerator pedal fully and release it.

>> GO TO 3.

3.

CHECK SELF-DIAGNOSIS CODE

Check O/D OFF indicator lamp.
Refer to "Judgement Self-diagnosis Code".
If the system does not go into self-diagnostics. Refer to

TM-163, "Diagnosis Procedure"

,

TM-212, "Diagnosis

Procedure"

,

TM-213, "Diagnosis Procedure"

.

>> DIAGNOSIS END

Judgment Self-diagnosis Code
