5. Install the cam gear. I Align the match marks, and install the idler gear and each cam I Tighten the cam gear installation bolt by fixing the hexagonal 6. Install the timing chain, all other related parts and chain cover. Refer to “TIMING CHAIN”, EM-26. 7. After installing the timing chain, check and adjust the valve clearance before installing the spill tube. 8. Install in the reverse order of removal. FEM023 CAMSHAFT ZD Installation (Cont’d) EM-34 |
