Selection Procedure for Selective Part Location Selective part combination Item Method Cylinder block - piston Piston and piston assembly (Part No. is given to a piston and piston pin as a set.) Piston grade (Piston outer diameter) Refer to “Selective combination chart”. I Identification grade stamped on each part represents initial I Measure correct dimensions of a reused or modified part, then I Refer to the applicable pages for measurement method for Disassembly 1. Remove engine assembly from vehicle. Refer to EM-63, “ENGINE REMOVAL”. 2. Remove pilot bushing from flywheel using pilot bearing puller (SST), if necessary (M/T model). 3. Install engine to engine stand (SST). 1) Remove flywheel (M/T model) or drive plate (A/T model). I Using ring gear stopper (SST), secure ring gear, and remove CAUTION: Do not disassemble flywheel. I Flywheel has a two-piece structure. When being pressed 2) Remove pilot converter (A/T model) and rear plate. SEM364G YEM043 CYLINDER BLOCK ZD EM-67 |
