LU-18
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and Limit
INFOID:0000000009886464
OIL PRESSURE
Unit: kPa (kg/cm
2, psi)
*: Engine oil temperature at 80
°C (176°F)
OIL PUMP
Unit: mm (in)
REGULATOR VALVE
Unit: mm (in)
ENGINE OIL CAPACITY (APPROXIMATE)
Unit: (US qt, Imp qt)
Engine speed
Approximate discharge oil pressure*
Idle speed
More than 98 (1.0, 14)
2,000 rpm
More than 294 (3.0, 43)
6,000 rpm
More than 392 (4.0, 57)
Body to outer rotor radial clearance
0.114 - 0.200 (0.0045 - 0.0079)
Inner rotor to outer rotor tip clearance
Below 0.180 (0.0071)
Body to inner rotor side clearance
0.030 - 0.070 (0.0012 - 0.0028)
Body to outer rotor side clearance
0.030 - 0.090 (0.0012 - 0.0035)
Inner rotor to brazed portion of housing clearance
0.045 - 0.091 (0.0018 - 0.0036)
Regulator valve to oil pump cover clearance
0.040 - 0.097 (0.0016 - 0.0038)
Drain and refill
With oil filter change
6.5 (6-7/8, 5-3/4)
Without oil filter change
6.2 (6-1/2, 5-1/2)
Dry engine (engine overhaul)
7.6 (8, 6-3/4)
