Nissan Titan A60. Manual - part 548





2011

QUICK REFERENCE CHART: TITAN

QUICK REFERENCE CHART: TITAN

Engine Tune-up Data

INFOID:0000000006812182

GENERAL SPECIFICATIONS

DRIVE BELTS

Cylinder arrangement

V-8

Displacement cm

3

(in

3

)

5,552 (338.80)

Bore and stroke mm (in)

98 x 92 (3.86 x 3.62)

Valve arrangement

DOHC

Firing order

1-8-7-3-6-5-4-2

Number of piston rings

Compression

2

Oil

1

Number of main bearings

5

Compression ratio

9.8:1

Compression pressure
kPa (kg/cm

2

, psi)/rpm

Standard

1,520 (15.5, 220)/200

Minimum

1,324 (13.5, 192)/200

Differential limit between cylinders

98 (1.0, 14)/200

Cylinder number

Valve timing

Unit: degree

a

b

c

d

e

f

244

°

232

°

-8

°

60

°

10

°

54

°

SEM957C

PBIC0187E

Tension of drive belts

Auto adjustment by auto tensioner

QUICK REFERENCE CHART: TITAN

2011

SPARK PLUG

Unit: mm (in)

*: Always check with the Parts Department for the latest parts information

Front Wheel Alignment (Unladen*1)

INFOID:0000000006812180

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Target value 37

° 30′ (37.50°)

*3: Target value 33

° 58′ (33.97°)

*4: Target value 37

° 56′ (37.93°)

*5: Target value 34

° 01′ (34.02°)

*6: Some vehicles may be equipped with straight (non-adjustable) lower link bolts and washers. In order to adjust camber and caster on
these vehicles, first replace the lower link bolts and washers with adjustable (cam) bolts and washers.

Make

NGK

Model

Standard model

FFV model

Standard type*

DILFR5A-11

DILFR5A-11D

Gap (Nominal)

1.1 (0.043)

1.1 (0.043)

Drive type

2WD

4WD

Camber *6
Degree minute (decimal degree)

Minimum

-0

° 57′ (-0.95°)

-0

° 27′ (-0.45°)

Nominal

-0

° 12′ (-0.20°)

0

° 18′ (0.30°)

Maximum

0

° 33′ (0.55°)

1

° 03′ (1.05°)

Cross camber

0

° 45′ (0.75°) or less

 0

° 45′ (0.75°) or less

Caster *6
Degree minute (decimal degree)

Minimum

2

° 15′ (2.25°)

1

° 27′ (1.45°)

Nominal

3

° 0′ (3.00°)

2

° 12′ (2.20°)

Maximum

3

° 45′ (3.75°)

2

° 57′ (2.95°)

Cross caster

0

° 45′ (0.75°) or less

0

° 45′ (0.75°) or less

Kingpin inclination (reference only)
Degree minute (decimal degree)

13

° 33′ (13.55°)

13

° 0′ (13.00°)

Total toe-in

Distance (A

− B)

Minimum

1.8 mm (0.07 in)

1.8 mm (0.07 in)

Nominal

2.8 mm (0.11 in)

2.8 mm (0.11 in)

Maximum

3.8 mm (0.15 in)

3.8 mm (0.15 in)

Angle (left or right)
Degree minute (decimal degree)

Minimum

0

° 3′ (0.05°)

0

° 3′ (0.05°)

Nominal

0

° 5′ (0.08°)

0

° 5′ (0.08°)

Maximum

0

° 7′ (0.12°)

0

° 7′ (0.12°)

Wheel turning angle
(full turn)

Inside
Degree minute (decimal degree)

34

° 30′ – 38° 30′ *

2

(34.50

° – 38.50°)

34

° 56′ – 38° 56′ *

4

(34.93

° – 38.93°)

Outside
Degree minute (decimal degree)

30

° 58′ – 34° 58′ *

3

(30.97

° – 34.97°)

31

° 01′ – 35° 01′ *

5

(31.02

° – 35.02°)

SFA234AC

2011

QUICK REFERENCE CHART: TITAN

Rear Suspension Specifications

INFOID:0000000006812179

Wheelarch Height (Unladen*1)

INFOID:0000000006812181

Unit: mm (in)

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Without tow package.
*3: With tow package.

Brake Specifications

INFOID:0000000006812177

Unit: mm (in)

Suspension type

Rigid axle with semi-elliptic leaf spring

Shock absorber type

Double-acting hydraulic

Drive
type

2WD

4WD*2

4WD*3

Wheel
base

Short

Long

Short

Long

Short

Long

Body

King

Cab

Crew

Cab

King

Cab

Crew

Cab

King

Cab

Crew

Cab

King

Cab

Crew

Cab

King

Cab

Crew

Cab

King

Cab

Crew

Cab

Front
wheel
arch
height
(Hf)

P265/
70R18

912

(35.91)

914

(35.98)

912

(35.91)

914

(35.98)

949

(37.36)

951

(37.44)

949

(37.36)

951

(37.44)

949

(37.36)

951

(37.44)

949

(37.36)

951

(37.44)

P275/
70R18

922

(36.30)

925

(36.42)

922

(36.30)

925

(36.42)

960

(37.80)

962

(37.87)

959

(37.76)

962

(37.87)

960

(37.80)

962

(37.87)

959

(37.76)

962

(37.87)

P275/
60R20

917

(36.10)

919

(36.18)

917

(36.10)

920

(36.22)

955

(37.60)

957

(37.68)

954

(37.56)

957

(37.68)

955

(37.60)

957

(37.68)

954

(37.56)

957

(37.68)

Rear
wheel
arch
height
(Hr)

P265/
70R18

952

(37.48)

954

(37.56)

950

(37.40)

951

(37.44)

991

(39.02)

994

(39.13)

989

(38.94)

991

(39.02)

991

(39.02)

993

(39.09)

989

(38.94)

991

(39.02)

P275/
70R18

962

(37.87)

965

(37.99)

960

(37.80)

962

(37.87)

1002

(39.45)

1004

(39.53)

1000

(39.37)

1002

(39.45)

1001

(39.41)

1004

(39.53)

1000

(39.37)

1002

(39.45)

P275/
60R20

957

(37.68)

959

(37.76)

955

(37.60)

956

(37.64)

996

(39.21)

999

(39.33)

995

(39.17)

996

(39.21)

996

(39.21)

998

(39.29)

995

(39.17)

996

(39.21)

LEIA0085E

Front brake

Brake model

AD41VA

Rotor outer diameter

× thickness

350

× 30 (13.78 × 1.181)

Pad Length

× width × thickness

151.6

× 56.5 × 12.0 (5.97 × 2.22 × 0.472)

Cylinder bore diameter (each)

50.8 (2.00)

Rear brake

Brake model

AD14VE

Rotor outer diameter

× thickness

320

× 14 (12.6 × 0.551)

Pad Length

× width × thickness

83.0

× 33.0 × 12.0 (3.268 × 1.299 × 0.472)

Cylinder bore diameter

48 (1.89)

Control valve

Valve model

Electric brake force distribution

QUICK REFERENCE CHART: TITAN

2011

Brake Pedal

INFOID:0000000006812178

STANDARD PEDAL

Unit: mm (in)

Brake booster

Booster model

C215T

Diaphragm diameter

215 (8.46)

Free height (H)

182.3

− 192.3 (7.18 − 7.57)

Pedal full stroke (S)

152.3 (6.00)

Clearance between brake pedal bracket and the threaded end of stop lamp switch (C1) and
ASCD cancel switch [if equipped] (C

2

)

0.74

− 1.96 (0.029 − 0.077)

AWFIA0557ZZ
