EC-66 < ECU DIAGNOSIS INFORMATION > [VK56DE] ECM 46 L/R Ignition signal No. 7 [Engine is running] 0 - 0.3V [Engine is running] 0.1 - 0.6V 47 G Sensor power supply [Ignition switch: ON] Approximately 5V 48 SB Sensor power supply [Ignition switch: ON] Approximately 5V 49 R/Y Sensor power supply [Ignition switch: ON] Approximately 5V 50 B Throttle position sensor 1 [Ignition switch: ON] More than 0.36V [Ignition switch: ON] Less than 4.75V 51 W Mass air flow sensor [Engine is running] 1.0 - 1.3V [Engine is running] 1.7 - 2.1V 53 L Intake calue timing contorol [Engine is running] 0 - 1.0V [Engine is running] 0 - 1.0V TER- MI- NAL NO. WIRE COLOR ITEM CONDITION DATA (DC Voltage) SEC986C SEC987C PBIB2046E |
