EC-62 < ECU DIAGNOSIS INFORMATION > [VK56DE] ECM TER- MI- NAL NO. WIRE COLOR ITEM CONDITION DATA (DC Voltage) 1 B ECM ground [Engine is running] Body ground 2 LG/B A/F sensor 1 heater (bank 1) [Engine is running] (More than 140 seconds after starting en- Approximately 2.9 - 8.8V 3 L Throttle control motor relay [Ignition switch: ON] BATTERY VOLTAGE 4 L/W Throttle control motor (Close) [Ignition switch: ON] 0 - 14V 5 L/B Throttle control motor (Open) [Ignition switch: ON] 0 - 14V 6 GR Heated oxygen sensor 2 heat- [Engine is running] following conditions are met. - Engine: After warming up and 4,000 rpm for 1 minute and at idle for 1 0 - 1.0V [Ignition switch: ON] BATTERY VOLTAGE 10 W Intake valve timing control so- [Engine is running] BATTERY VOLTAGE [Engine is running] 7 - 12V PBIA8148J PBIB1104E PBIB1105E PBIB1790E |
